Clarke CSB34 Manual de instrucciones

OPERATION & MAINTENANCE

INSTRUCTIONS

LS0513

SIPHON FEED SANDBLASTER

MODEL NO: CSB34

PART NO: 7640120

INTRODUCTION

Thank you for purchasing this Clarke Siphon Feed Sandblaster.

Before you try to use this product, read this manual and follow the instructions

carefully. In doing so you will ensure your safety and the safety of others

around you. You can also look forward to a purchase that gives you long and

satisfactory service.

GUARANTEE

This product is guaranteed against faulty manufacture for a period of 12

months from the date of purchase. Please keep your receipt which will be

required as proof of purchase.

This guarantee is invalid if the product is found to have been abused or

tampered with in any way, or not used for the purpose for which it was

intended.

Faulty goods should be returned to their place of purchase, no product can

be returned to us without prior permission.

This guarantee does not effect your statutory rights.

CONSUMABLES

Please be aware that certain parts of this sandblaster will wear, requiring

replacement and that these parts may not be covered by your guarantee.

The wear on certain parts depends on the abrasiveness of the materials used.

Replacement parts are available from your nearest Clarke International

dealer.

GENERAL SAFETY RULES

1. Read this instruction manual before connecting the sandblaster to a compressor.

2. Do not use any silica based abrasives with this sandblaster. Silica based abrasives

have been linked to severe respiratory disease. Always use recommended

abrasives. Abrasives used in this sandblaster may be covered by COSHH

Regulations.

3. Safety glasses, hood, long-sleeve shirt, gloves and a respirator should be worn during

operation and clean up.

4. During operation, do not expose the hands or skin to the blasted material, keep

hands away from the nozzle.

5. Everyone in the blasting area must also wear personal protective equipment.

6. Check the condition of hoses and air lines before each use.

7. Make sure all connections are secure before use.

8. Abrasives used in this unit may be covered by COSHH Regulations.

9. ALWAYS make sure there is adequate ventilation. Do not spray in confined areas.

10. ALWAYS disconnect the gun from the air supply when the sandblaster is not in use.

11. ALWAYS clean the gun thoroughly after use. See ‘Maintenance’.

12. ALWAYS turn off the compressor and expel all air from the air hose and gun before

disconnecting the sandblasting gun.

13. ALWAYS use appropriate air hoses and couplings and ensure that they are in good

condition. If any parts are worn or damaged, they should be replaced immediately.

14. ALWAYS hold the tool firmly and maintain good balance.

15. NEVER carry the gun by the hose. Keep hoses away from heat, oil and sharp edges.

16. NEVER use wet or even damp grit. Ensure the grit is completely dry,

17. In the case of injury seek expert medical advice immediately.

18. NEVER allow children to use or play with the sandblaster.

Warning: Compressed air can be dangerous. Ensure that you are

thoroughly familiar with all precautions relating to the use of

compressors and compressed air supplies.

Warning: Disconnect the sandblaster from the air supply before

changing accessories, attempting to move the sandblaster or perform

any maintenance.

Warning: Do not point the sandblaster gun at anyone or objects other

than the intended work object.

UNPACKING

Unpack your sand blaster and its accessories and make sure that the following

items are present. Should there be any damage caused during transit contact

your Clarke dealer immediately.

Drum Assembly

Lower Frame

2 x Wheels

Upper Frame

Sandblasting Gun

Delivery Hose

Axle

Leg/Prop Stand

Combination

Mesh Filter

Ceramic nozzles

Hood & Mask

(HTCSB3401)

(HTCSB3404)

(HTCSB3402)

(HTCSB3410)

(HTCSB3403)

(HTCSB3406) (HTCSB3408)

(HTCSB3409)

(HTCSB3407)

(HTCSB3405)

Available from your Clarke

1 x Fixings Pack

(HTCSB3411)

Dealer: Part no: 7640122

Please dispose of any packaging responsibly. The cardboard packaging can

be recycled.

ASSEMBLY

Upper Frame

Axle

Lower Frame

Slide the axle through the upper

frame and lower frame as shown

on the right.

Split Pin

Washer

Wheel

Spacer

Slide the spacer (5) onto the axle

followed by the wheel, then the

thin washer (6), and secure in

place using the split pin (2).

3. Repeat on the other end of the

axle.

4. Attach the drum to the upper

frame and secure in place using 2

bolts (4), 4 washers (3) and 2 nuts

(7) to secure into place.

5. Fit the leg/prop stand to the drum

and secure in place using 2 short

bolts (1), 4 washers (3) and 2 nuts

(7).

6. Secure in leg/prop stand to the

lower frame using the long bolt

(9), 2 washer (3) and 1 nut (7).

7. Place a jubilee clip (8) onto each

end of the hose.

8. Firmly push the end of the hose

onto the abrasive inlet on the

sandblasting gun.

9. Slide one of the jubilee clips so

that it is overlapping both the

hose and the abrasive inlet.

10. Tighten the jubilee clip with a

screwdriver.

11. Firmly push the opposite end of

the hose onto the abrasive outlet,

located at the base of the drum.

NOTE: there is an air hole in the

abrasive outlet - do not

cover this air hole with the

abrasive hose.

12. Position the remaining jubilee clip

so that it is overlapping both the

hose and the abrasive outlet of

the drum.

13. Tighten the jubilee clip with a screwdriver.

OPERATION

USING YOUR SANDBLASTER

Connect your sandblasting gun to a compressor (minimum 3hp capable of

supplying a minimum of 10 CFM of air) via the 3/8” hose adaptor located at

the base of the handle.

Set the working pressure on your air compressor to 6 - 8 bar (87 - 116 psi).

1. Connect an air hose (sold

separately) from your compressor,

to the hose fitting on the

sandblasting gun.

2. Make sure air hole located on the

base of the abrasive tank is not

covered.

3. Place the mesh filter on top of the

drum and pour the blasting

medium through the filter into the

drum.

4. Start compressor according to the

manufacturers instructions.

5. Check for leaks along all hoses

and fittings. if leaks are found, turn off the compressor, disconnect the hose

and repair immediately.

6. Point the sandblasting gun in a safe direction away from people, pets or

anything around you that may be damaged by direct or indirect abrasive

spray.

7. Press and hold the sandblasting gun trigger until abrasive medium is flowing

through the nozzle.

TO STOP BLASTING

1. Release the trigger on the sandblasting gun.

MAINTENANCE

REPLACING THE NOZZLE

After 10-12 hours of blasting time the nozzle should be checked for wear. The

nozzle will wear out overtime and should be replaced when the hole is no longer

round or the abrasive media does not flow smoothly through it. To replace the

nozzle:

1. Disconnect the sandblasting gun from the air hose.

Nozzle

Unscrew the nozzle adaptor,

located at the front of the

sandblasting gun.

3. Remove the old nozzle.

4. Insert new nozzle.

• Replacement nozzles are

available from your Clarke

dealer Part number 7640122

5. Replace the nozzle adapter and

firmly screw it onto sandblasting gun.

• Keep your sandblaster clean and protect it from damage.

• Check for worn abrasive hose and fittings. Watch for leaks, blistering,

bulging or thinning of the hose.

• Replace any parts which appear worn.

PARTS AND SERVICING

For Parts & Servicing, please contact your nearest dealer, or

CLARKE International, on one of the following numbers.

PARTS & SERVICE TEL: 020 8988 7400

PARTS & SERVICE FAX: 020 8558 3622

or e-mail as follows:

PARTS: [email protected]

SERVICE: Service@clarkeinternational.com

SPECIFICATIONS

CSB34

Sand Grade Type Up to 60 Grit (Clarke AOP60)

Abrasive Material Aluminium Oxide, Garnet Powder,

Glass Bead

Drum Capacity: 34 Litres (7.5 UK gallons)

Sand Capacity: (kg/lbs) 22.6/50

Working Pressure: 6 - 8 bar (87 - 116 psi)

Flow Rate Required: (cfm) 10 - 16

Compressor Size Hp: (Minimum) 3

Gun Inlet Size: 3/8” hose adaptor fitted

Air Inlet Hose Diameter: 3/8” (10mm)

Nozzle Sizes: (mm) 4, 5, 6, 7 (Ceramic)

Dimensions (Length x Width x Height) 490 mm x 430 mm x 895 mm

Weight 8.5 Kg
