Integrated Security Devices

G83-14201

Biometric Keyboard

with Smart Card Reader

Main Applications

-Rack Mount Systems

-Airlines

-Education/Schools

-Banking

-Medical Equipment

-Automotive Equipment

-POS/POT

-Office/Data Entry

-White Box PCs

-Field Services

-Test Equipment

-Kiosk Applications

-POS/POT

-Manufacturing

-Transport

Key Features

•USB keyboard with fingerprint sensor

and PC/SC smart card reader

•CardMan 3121-compatible

Smart card reader

•AuthenTec AES4000 CMOS Fingerprint

Sensor with TruePrint®Technology

Main Part Numbers

G83-14201LPAUS-2

Black housing, smart card reader,

fingerprint sensor

G83-14201LPAUS-0

Light grey housing, smart card reader,

fingerprint sensor

Biometric Keyboard with

Integrated AuthenTec

AES4000 CMOS Fingerprint

Sensor and CardMan 3121-

Compatible Smart Card Reader

Main Part Numbers Technical Data

Interface

USB, bus powered device

Current Input

Max 150 mA

Smart Card Interface

Reads and writes all ISO 7816 cards

supports T=0, T=1, 12C

(S=8), 2 wire (S=10), 3 wire (S=9)

Card Connecting Unit

approx. 100,000 insertions

Smart Card Speed

412, 903 bps

Clock Frequency Smart Card

4.8 MHz

Sensor Resolution

(250 dpi)

Storage Temperature

-20°C to 60°C

Operating Temperature

0°C to 50°C

Keyswitch Lifetime

>20 million operations

System Requirements

USB Connection

Insertion Cycles

approx. 100,000

Cable Length

approx. 1.75 m

Number of Keys

104 = EU Layout with WindowsTM keys

105 = US Layout with WindowsTM keys

Weight (without/with packaging)

approx. 2.62 lbs. without packaging

approx. 3.30 lbs. with packaging

Dimension

17.9 x 7.7 x 2.1 (keyboard)

19.4 x 10.0 x 2.3 (packaging)

Packaging Units

40 keyboards per master carton

2 master cartons per pallet

Agency Approvals

FCC, GS, CE, c-tick, GHOST-R, VCCI

Microsoft WHQL Windows™ 2000, XP

Delivery Volume

Keyboard, Printed manual, CD with

smart card reader drivers and Protektor

Suite OEM

Warranty

2 years

For information on repairs or

warranty status contact:

Cherry Technical Support

Phone: 800.510.1689

E-Mail: [email protected]

G83-14201LPAUS-2

Contact

Call, fax or visit our

website for more information.

Last Update: 10/15/08

Cherry Electrical Products

11200 88th Avenue

Pleasant Prairie, WI 53158

Phone: 262.942.6500

Web: www.cherrycorp.com

E-Mail: [email protected]

Fax: 262.942.6566

The manufacturer accepts no

liability for errors or non-availability,

and reserves the right to change

specifications without prior notice.

Technical data relates to product

specifications only. Features may

differ from those described.

Only drawings combined with

product specifications shall be

deemed binding.

Integrated Security Devices

G83-14201

Biometric Keyboard

with Smart Card Reader
