sk450 Single Ecoclean Oven

Manual for Installation, Use and Maintenance

Important

This appliance must only be used for the purpose for which it is

intended, i.e. domestic cooking, defrosting and reheating foods. Any

other use could be dangerous and may lead to premature failure of

the appliance.

The CDA Group Ltd cannot be held responsible for injuries or losses

caused by incorrect use or installation of this product. Please note

that CDA reserve the right to invalidate the guarantee supplied with

this product following incorrect installation or misuse of the appliance.

User information:

•Ovens become hot during and immediately after use. Ensure you

do not touch the heating elements located inside the appliance.

•The oven door can become very hot during operation.

•After use, please ensure that the appliance is switched o.

•Keep children away from the appliance when in use, and

immediately after use.

•Keep the oven door closed when in use.

Appliance information:

Please enter the details on the appliance rating plate below for

reference, to assist CDA Customer Care in the event of a fault with

your appliance and to register your appliance for guarantee purposes.

Appliance Model

Serial Number

CE Declarations of Conformity:

This oven has been designed, constructed and marketed in

compliance with safety requirements of EEC Directive 2006/95/EEC

(Low voltage) and requirements of EMC Directive 2004/108/EEC.

This appliance has been manufactured to the strictest standards and

complies with all applicable legislation, including Electrical safety (LVD)

and Electromagnetic interference compatibility (EMC). Parts intended

to come into contact with food conform to EEC/89/109.4

IMPORTANT INFORMATION FOR CORRECT DISPOSAL OF THE

PRODUCT IN ACCORDANCE WITH EC DIRECTIVE 2002/96/EC.

At the end of its working life, the product must be taken to a special

local authority waste collection centre or to a dealer providing

appliance recycling services. Disposing of a household appliance

separately avoids possible negative consequences for the

environment and health. It also enables the constituent materials to be

recovered, saving both energy and resources.

As a reminder of the need to dispose of household appliances

separately, the product is marked with a crossed-out wheeled dustbin.

Important

• Read the user instructions carefully before using the oven for the

ﬁrst time.

• Follow the instructions for rst use of the oven.

• Clean the oven regularly.

• Remove spills as soon as they occur.

• Always use oven gloves when removing shelves and trays from the

ovens.

• Do not allow children near the oven when in use.

• Do not allow fat or oils to build up on the oven shelves, grill pan or

oven base.

• Do not place any cooking utensils or plates directly on the oven

base.

• Always grill with the oven door closed.

• Do not grill food containing fat without using the grill pan grid.

• Do not cover the grill pan grid or the oven walls with aluminium foil.

• Do not use the oven tray for roasting.

• Do not perform maintenance or cleaning of the oven without rst

switching o the electricity supply. If the oven has recently been

used, allow to cool.

• Do not place hot enamel parts in water. Leave them to cool rst.

• Do not allow vinegar, coee, milk, saltwater, lemon or tomato juice to

remain in contact with enamel parts.

• Do not use abrasive cleaners or powders that will scratch the

surface of the enamel.

• Do not attempt to repair the internal workings of your oven.

Using the Touch

Controls

The touch controls should be used with

the ﬂat of your ﬁnger, rather than the

ﬁngertip.

ﬁg. 1

The Control Panel

A B C D E F G H

I J K L M

A: Oven light

B: Conventional oven

C: Warming oven

D: Half grill

E: Full grill

F: Fanned grill

G: Fan assisted oven

H: Fan oven

I: On/O and key lock

J: Rapid preheat

K: Oven clean

L: Stop

M: Start

ﬁg. 2

N O P Q R S T

U V W X Y Z

N: Fan oven + lower heat

O: Defrost

P: Auto recipe

Q: Conﬁrm

R: Scroll downward / Reduce power

S: Scroll upward / Increase power

T: Digital display

U: Timer function

V: Timer - cooking time

W: Timer - end time

X: Minute minder

Y: Decrease settings

Z: Increase settings

Before First Use

When the oven is connected to the electrical supply for the ﬁrst time,

the display will ask you to select your language: Use the

buttons to select the language you want, use the “ok” button to

conﬁrm your choice.

The oven will remember your language preference, even after future

power outages.

After setting the language, the oven will go into “demonstration” mode

(it will also go into this mode after any power failure).

In this mode, the oven keys light up in sequence but no heating

elements are powered. The control panel is inactive so the oven will

not respond to commands.

To exit the demonstration mode, touch the “Light” key for

approximately ﬁve seconds, the control panel will revert to normal

operation and be ready for use.

You can set the clock at this stage, but it is not necessary for turning

on the oven.

Before using the oven for the ﬁrst time we recommend that you clean

it with soapy water, rinse carefully and then heat on the fan oven

setting at maximum temperature for 30 minutes. A slightly unpleasant

smell may be produced, caused by grease remaining on the oven

elements from the production process.

General Settings & Use

Clock

To set the clock, touch the “Timer function” key for at least 3

seconds, the clock will show “00:00” with the separator dots ﬂashing.

Use the “+” and “-” keys to set the correct time: Five seconds after

selecting the time the dots will stop ﬂashing and the time will be set.

Key lock

This appliance is equipped with a key lock to prevent accidental

use. For safety reasons the “On/O” key will work to switch the

appliance o when the key lock is set.

To switch the key lock on or o, touch and hold the “On/O” key

the appliance will give a brief beep when the button is ﬁrst pressed

and a longer beep after three seconds, when the key lock is either

activated or deactivated. The padlock closed symbol will show in the

display when the key lock is on and the padlock open symbol when

the key lock is o.

Oven light

The oven light may be turned on and o by touching the “Oven light”

key .

Alternatively, the oven light will turn on automatically when the door

is opened then after the door is closed will stay on for approximately

three minutes before automatically turning itself o.

To turn the oven on

Touch the “On/O” key brieﬂy, it gives one short beep followed

immediately by a long one, the word ”ON” appears on the display for

approximately one minute.

To turn the oven o

Touch the “On/O” key brieﬂy, it gives one long beep, the word

”OFF” appears briey on the display.

While the word “ON” is showing on the display, any of the cooking

functions can be selected by touching one of the function keys.

If a cooking function is not selected within one minute the oven

will switch itself o and the word “OFF” will show briey on the

display.

The cooking functions available when the oven is on are:

Conventional oven

First touch the “On/O” key (as above), then touch the “Conventional

oven” key. The cooking temperature defaults to 190°C and can be set

between 50-250 (MAX) °C in 5˚C increments.

The temperature can be changed at any time by touching the

keys. During heating the “°C” symbol ﬂashes and the display shows

the actual temperature in the oven.
