www.cda.eu
DC741 Built-under
&
DC941 Built-In
Double Oven
Installation, use and maintenance
2
Contents:
3 Important information
4 Important safety notes
6 Before first use
7 Notes on usage
8 Oven controls and use
10 Setting the time/clock
10 Minute minder
11 Semi-automatic cooking
12 Automatic cooking
13 Care and maintenance
14 Changing the oven lamp
16 Removing the oven door(s)
17 Troubleshooting
19 Mains electricity connection
21 Installation
22 Appliance dimensions
23 Energy eciency information
3
Important
This appliance must only be used for the purpose for which it is
intended, i.e. domestic cooking. Any other use could be dangerous
and may lead to premature failure of the appliance.
The CDA Group Ltd cannot be held responsible for injuries or losses
caused by incorrect use or installation of this product. Please note that
CDA reserve the right to invalidate the guarantee supplied with this
product following incorrect installation or misuse of the appliance.
This appliance is not designed to be used by people (including
children) with reduced physical, sensorial or mental capacity, or
who lack experience or knowledge about it, unless they have had
supervision or instructions on how to use the appliance by someone
who is responsible for their safety.
Under no circumstances should any external covers be removed for
servicing or maintenance except by suitably qualified personnel.
User information:
•Ovens become hot during and immediately after use.
•The oven door can become hot during operation.
•After use, please ensure that the control knobs are in the
‘O’ position.
•Keep children away from the appliance when in use, and
immediately after use.
•Keep the oven door closed when the appliance is in use.
4
Appliance information:
Please enter the details on the appliance rating plate below for
reference, to assist CDA Customer Care in the event of a fault with
your appliance and to register your appliance for guarantee purposes.
Appliance Model
Serial Number
EU Declarations of Conformity:
This oven has been designed, constructed and marketed in
compliance with safety requirements of EU Directive 2014/35/EU (LVD)
and requirements of EU Directive 2014/30/EU (EMC).
This appliance has been manufactured to the strictest standards and
complies with all applicable legislation, including Electrical safety (LVD)
and Electromagnetic interference compatibility (EMC). Parts intended
to come into contact with food conform to 1935/2004/EC.
IMPORTANT INFORMATION FOR CORRECT DISPOSAL OF THE
PRODUCT IN ACCORDANCE WITH EC DIRECTIVE 2012/19/EU.
At the end of its working life, the product must not be disposed of as
urban waste. It must be taken to a special local authority dierentiated
waste collection centre or to a dealer providing this service.
5
Disposing of a household appliance separately avoids possible
negative consequences for the environment and health deriving from
inappropriate disposal and enables the constituent materials to be
recovered to obtain significant savings in energy and resources. As a
reminder of the need to dispose of household appliances separately,
the product is marked with a crossed-out wheeled dustbin.
Important
• Read the user instructions carefully before using the oven
for the first time.
• Follow the instructions for first use of the oven.
• Clean the oven regularly.
• Steam cleaners must not be used when cleaning this
appliance.
• Remove spills as soon as they occur.
• Always use oven gloves when removing shelves and trays
from the ovens.
• Do not allow children near the oven when in use.
• Do not allow fat or oils to build up on the oven shelves,
grill pan or oven base.
• Do not place any cooking utensils or plates directly on the
oven base.
• Keep the oven door closed when the oven is in use.
• Do not grill food containing fat without using the grill pan
grid.
• Do not cover the grill pan grid or the oven walls with
aluminium foil.
• Do not use the oven tray for roasting.
6
• Do not perform maintenance or cleaning of the oven
without first switching o the electricity supply. If the oven
has recently been used, allow to cool.
• Do not place hot enamel parts in water. Leave them to
cool first.
• Do not allow vinegar, coee, milk, saltwater, lemon or
tomato juice to remain in contact with enamel parts.
• Do not use abrasive cleaners or powders that will scratch
the surface of the enamel.
• Do not attempt to repair the internal workings of your
oven.
• The oven is equipped with a safety thermostat which will
switch o the oven in the event of the oven overheating.
If the safety thermostat should switch o the power, you
must wait for the oven to cool down before using it again.
• Do not cover the oven floor with aluminium foil.
First use of the oven
The metal casing of this appliance has been coated with a
preservative to protect it during transport and storage. This should be
removed during installation by using a non-abrasive stainless steel
cleaner. Always follow the instructions given with the cleaner being
used.
Before using the oven for the first time we recommend that you clean
both oven cavities with soapy water, rinse carefully and then heat
on each of the below programmes at maximum temperature for the
specified time. A slightly unpleasant smell may be produced, caused
by grease remaining on the oven elements from the production
process.
7
Top oven
15 minutes full grill
60 minutes conventional
Lower oven
60 minutes fan oven
Please note:
• This oven has been fitted with a cooling fan to achieve maximum
eciency and to maintain low surface temperatures. The cooling fan
will switch on automatically when the oven is switched on and runs
for a while after the oven has been switched o - the length of time
can vary and will be increased by poor ventilation.
• The oven light remains on for every cooking function.
• Do not switch o the oven if you have set a programme for semi-
automatic or automatic cooking as this will cancel the programme.
• The current time must be set on the programmer/timer for the
cooking functions to work properly (see page 10).
8
Oven controls and use
Cooking function knobs
To set the function, turn the cooking function knob for the required
oven clockwise to the required function. Each of the oven functions
uses dierent elements within the oven to oer you the best choice of
cooking every time. These are explained below:
Conventional oven
This function uses the top and bottom heating elements
only with a temperature between 50ºC and 250ºC.
Natural convection creates a perfect cooking zone in the
centre of the oven, ideal for dark fruit cakes and pastries.
Warming oven
This function uses the bottom heating element only with a
temperature set between 50ºC and 250ºC. This natural
heat is perfect for dough proving and blind-baking.
Grill
This function radiates the heat from the grill element and
the top element.
This fully temperature variable grill is ideal for grilling a
full family meal. It can be set between 50ºC and 250ºC.
When grilling, please note:
• Always grill with the oven door closed.
• Put the grill pan as close to the grill as possible.
• Do not grill for more than 30 minutes at a time.
• Preheat the grill for a few minutes with the oven door closed.
9
Oven Lamp
This function switches on the oven light in the cavity.
Please note: the oven light will operate on all cooking
functions
Defrost
Using the fan only this oven function circulates the air
around the oven cavity, speeding up the natural defrost
process (1kg takes approximately one hour, depending
on the type of food).
Fan Oven
Using the circular element and the fan with a temperature
between 50ºC and 250ºC, this cooking function blows
the air into and around the oven cavity. Both cooking
temperatures and cooking times can be reduced for a
more energy ecient cooking programme. This function
is perfect for cooking various food types simultaneously
as foods are sealed quickly to prevent flavour transfer.
Temperature knob
• To set the temperature, turn the temperature knob for the required
oven clockwise to the required temperature.
• Oncetheovenhasreachedtherequiredtemperature,thetemperature
indicator lamp on the control panel will switch o.
• The temperature indicator lamp will light up when the oven elements
are working.
10
Programming the oven
Please note:
• The semi-automatic and automatic
cooking programmes will only work with
the main (lower) oven.
•
• The current time must be set in order
for the functions to work. If you are
unsure whether the current time is
mains supply for approximately 10
seconds and then turn it back on. Set
the time as per the instructions below.
Setting the clock
The clock is preset to 12:00, and will revert to this after a power failure.
When the current time indicator is flashing, touch or . When
the correct time is shown on the display, the clock will set after
approximately five seconds’ delay.
To change the clock once it has been set, touch repeatedly until the
current time indicator flashes, then touch or . When the correct
time is shown on the display, the clock will set after approximately five
seconds’ delay.
The minute minder
Fig. 1
1
2
3
4
5 6 7
1 Cooking time indicator
2 End of cooking time indicator
3 Minute minder indicator
4 Current time indicator
5 Decrease key
6 Mode key
7 Increase key
