CDA SC223 Guía de inicio rápido

Customer Care Department • The Group Ltd. • Harby Road • Langar • Nottinghamshire • NG13 9HY

T : 01949 862 012 F : 01949 862 003 E : customer.care@cda.eu W : www.cda.eu www.cda.eu

SC223 Single

Oven

Installation, use and maintenance

Contents:

3 Important information

5 Safety instructions

6 First use of the oven

7 Oven controls, functions and use

10 Electronic programmer/timer

10 Setting the current time

10 Minute minder function

11 Semi-automatic cooking

12 Automatic cooking

14 Cleaning and maintenance

15 Removing the appliance door

16 Replacing the appliance door

17 Removing the inner door glass

19 Removing the shelf supports

20 Changing the oven light bulb

21 Installation

23 Mains electrical connection

25 Troubleshooting

27 Energy Eciency Information

IMPORTANT: Please read the user instructions carefully before

using the appliance for the ﬁrst time and before installing it.

Failure to install the oven, or to have it installed, as per the user

manual could invalidate the warranty. Any service calls relating to

misuse or incorrect installation could incur a service charge.

Important

This appliance must only be used for the purpose for which it is

intended, i.e. domestic cooking. Any other use could be dangerous

and may lead to premature failure of the appliance.

The CDA Group Ltd cannot be held responsible for injuries or losses

caused by incorrect use or installation of this product. Please note that

CDA reserve the right to invalidate the guarantee supplied with this

product following incorrect installation or misuse of the appliance.

Under no circumstances should any external covers be removed for

servicing or maintenance except by suitably qualiﬁed personnel.

User information:

• Ovens become hot during and immediately after use.

•The oven door can become very hot during operation.

•After use, please ensure that the oven switches are in the ‘O’

position.

•Keep children away from the appliance when in use, and

immediately after use.

•Do not allow children to play with or on the appliance.

•Keep the oven door closed whilst grilling.

Appliance information:

Please enter the details from the appliance rating plate on to the

following page for reference, to assist CDA Customer Care in the

event of a fault with your appliance and to register your appliance for

guarantee purposes.

Appliance Model

Serial Number

EU Declarations of Conformity:

This oven has been designed, constructed and marketed in

compliance with safety requirements of EU Directive 2014/35/EU (Low

voltage) and requirements of EU Directive 2014/30/EU.

This appliance has been manufactured to the strictest standards and

complies with all applicable legislation, including Electrical safety (LVD)

and Electromagnetic interference compatibility (EMC). Parts intended

to come into contact with food conform to 1935/2004/EC.

IMPORTANT INFORMATION FOR CORRECT DISPOSAL OF THE

PRODUCT IN ACCORDANCE WITH EC DIRECTIVE 2012/19/EU.

At the end of its working life, the product must not be disposed

of as urban waste. It must be taken to a special local authority

dierentiated waste collection centre or to a dealer providing this

service.

Disposing of a household appliance separately avoids possible

negative consequences for the environment and health deriving from

inappropriate disposal and enables the constituent materials to be

recovered to obtain signiﬁcant savings in energy and resources. As a

reminder of the need to dispose of household appliances separately,

the product is marked with a crossed-out wheeled dustbin.

Important

• Read the user instructions carefully before using the oven

for the ﬁrst time.

• Follow the instructions for ﬁrst use of the oven.

•Clean the oven regularly.

•Remove spills as soon as they occur.

•Always use oven gloves when removing shelves and trays

from the ovens.

•Do not allow children near the oven when in use.

•Do not allow fat or oils to build up on the oven shelves, grill

pan or oven base.

•Do not place any cooking utensils or plates directly on the

oven base.

•Always grill with the oven door closed.

•Do not grill food containing fat without using the grill pan

grid.

•Do not cover the grill pan grid or the oven walls with

aluminium foil.

•Do not use the oven tray for roasting.

•Do not perform maintenance or cleaning of the oven

without ﬁrst switching o the electricity supply. If the oven

has recently been used, allow to cool.

•Do not place hot enamel parts in water. Leave them to

cool ﬁrst.

•Do not allow vinegar, coee, milk, saltwater, lemon or

tomato juice to remain in contact with enamel parts.

•Do not use abrasive cleaners or powders that will scratch

the surface of the enamel.

•Do not attempt to repair the internal workings of your oven.

First use of the oven

First use

•The metal casing of this appliance has been coated with a

preservative to protect it during transport and storage. This should

be removed during installation by using a non-abrasive stainless

steel cleaner. Always follow the instructions given with the cleaner

being used.

•Before using the oven for the ﬁrst time we recommend that you

clean the oven with soapy water, rinse carefully. Set the current

time on the programmer as per page 10. Heat on each of the

below programmes at maximum temperature for the speciﬁed time.

A slightly unpleasant smell may be produced, caused by grease

remaining on the oven elements from the production process.

15 minutes full grill 30 minutes fan oven

Please note:

•This oven has been ﬁtted with a cooling fan to achieve maximum

eciency and to maintain low surface temperatures. The cooling

fan will switch on automatically when the oven switches on. It is

normal for the cooling fan to run for an hour or more after use,

depending on the duration, temperature and type of cooking

programme used.

IMPORTANT: The fanned grill must only be used to a maximum

temperature of 190°C

Oven controls and use

IMPORTANT: You must set the current time on the oven

programmer, as per page 10, for the oven to operate properly.

Cooking function knob (E)

To set the function, turn the cooking function knob (E in Fig. 1) to the

required function. You will need to set a temperature on all functions

except the light and defrost functions. The neon indicator next to

the temperature knob will extinguish when the temperature has been

reached.

Each of the oven functions uses dierent elements within the oven to

oer you the best choice of cooking every time. These are explained

below and on the following two pages:

Fan oven

This function uses the circular heating element with a

temperature between 50°C and 250°C. The fan then

circulates the hot air which helps to achieve uniform

heat distribution.

Defrost

This function uses the fan to circulate air, at ambient

Fig. 1 A E

BCD

temperature, within the oven which helps to accelerate

the defrosting process.

Half Grill

This function radiates the heat from the grill element.

This fully temperature variable grill can be set between

50°C and 250°C maximum.

When grilling, please note:

• Always grill with the oven door closed.

• Put the grill pan as close to the grill as possible.

• Do not grill for more than 30 minutes at a time.

• Preheat the grill for up to ﬁve minutes with the

oven door closed.

Fanned Grill

This function radiates the heat from the grill element

and the top element but also uses the fan to circulate

the hot air. The hot air is distributed over and under the

food that you are grilling.

This fully temperature variable grill is ideal for grilling

ﬁsh or other items whose appearance can be spoiled by

a normal grill function.

It can be set between 50°C and 190°C maximum.

When fan grilling, please note:

• Always grill with the oven door closed.

• The grill pan does not need to be as close to the

grill as possible.

• Do not grill for more than 30 minutes at a time.

• Preheat the grill for up to ﬁve minutes with the

oven door closed.

Full Grill

This function radiates the heat from the grill element and

the top element.

This fully temperature variable grill is ideal for grilling a

full family meal. It can be set between 50°C and

250°C maximum.

When grilling, please note:

• Always grill with the oven door closed.

• Put the grill pan as close to the grill as possible.

• Do not grill for more than 30 minutes at a time.

• Preheat the grill for up to ﬁve minutes with the

oven door closed.

Light

This turns on the light within the oven.

Temperature knob (A)

•To set the temperature, turn the temperature knob clockwise to the

required temperature.

•Once the oven has reached the required temperature, the

temperature indicator lamp on the control panel will switch o.

•The temperature indicator lamp will light up when the oven

elements are in operation.

Electronic programmer/timer

This oven’s electronic timer is equipped with touch control sensors.

Each registered touch of a sensor ﬁeld is conﬁrmed by a single beep.

It is advisable to keep the sensor ﬁelds clean at all times to avoid

errors in operation.

Setting the current time

After connection to the mains supply, or re-connection after a power

outage, the display will show ‘12.00’ and the clock symbol will ﬂash.

•Set the current time using the timer left (B) and timer right (D)

sensors. After an approximately 5 second wait, the time will be set.

•The time can be amended at any time by following these steps.

However, you will ﬁrstly need to press the menu sensor (C) until

the display shows the ﬂashing ( ) symbol.

Please note: The time must be set for the oven to work.

Setting the minute minder function

The minute minder function can be set at any time, regardless of the

state of activity of the oven. The minute minder can be set anywhere

from 1 minute to 23 hours and 59 minutes.

•Press the menu sensor until the display shows the ﬂashing ( )

symbol.

•Set the desired duration of the minute minder using the timer

left and right sensors. After an approximately 5 second wait, the

minute minder will be set and the ( ) symbol will be solidly lit. The

minute minder duration will be shown on the timer display.

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Horno de CDA

CDA

CDA SL200BL Guía del usuario

CDA

CDA SK511 Guía de inicio rápido

CDA

CDA SK510 Single Guía de inicio rápido

CDA

CDA 11Z6 for Manual de referencia

CDA

CDA SL550SS Guía del usuario

CDA

CDA SL400SS Guía del usuario

CDA

CDA rv961 Manual de referencia

CDA

CDA sk380 Series Manual de usuario

CDA

CDA SK651 Guía de inicio rápido

CDA

CDA SC620 Manual de referencia

CDA

CDA VK702 Instrucciones de instalación y funcionamiento

CDA

CDA SK110 Guía de inicio rápido

CDA

CDA DV 980 Series Guía

CDA

CDA SV430 Manual de referencia

CDA

CDA 9Q6 Series Manual de referencia

CDA

CDA SV470 Manual de referencia

CDA

CDA CD 900 Instrucciones de operación

CDA

CDA 9Q6 Series Manual de referencia

CDA

CDA DK951 Series Guía de inicio rápido

CDA

CDA SVA 100 PP Manual de referencia

CDA

CDA SC309 Series Manual de referencia

CDA

CDA SC050 Guía del usuario

CDA

CDA SV500 for Manual de referencia

CDA

CDA SC309 Series Manual de referencia

Manuales populares de Horno de otras marcas

Bosch

Bosch HVA531NS0 Manual de usuario

Electrolux

Electrolux EOF6P46X Manual de usuario

NEFF

NEFF B44S32 5GB Series Manual de usuario

Combi

Combi BLODGETT BC142GDS Manual de usuario

AEG

AEG COMPETENCE 311704300 Manual de usuario

Falcon

Falcon DOMINATOR PLUS G3106 Series Guía del usuario

Rational

Rational SCC WE 61G Manual de usuario

Smeg

Smeg DOSPA38X Manual de instalación y operación

Electrolux

Electrolux air-o-convect 20 GN 2/1 Manual de usuario

Miele

Miele HR 1954-2 Manual de usuario

KHIND

KHIND OT50 Manual de usuario

Henny Penny

Henny Penny Smoker Box Manual de usuario

Lang

Lang ECOD-AP Manual de usuario

AEG

AEG BEK455310M Manual de usuario

Frigidaire

Frigidaire FNGE90JGR Manual de usuario

Hotpoint

Hotpoint FE9 S831 JSH IX Manual de usuario

GE Advantium SCB2000 Manual de usuario

AEG

AEG DE401301DM Manual de usuario
