Carrier 40VCC3 Instrucciones de instalación

Central Controller

MODEL NAME

Edition: 2021-04

40VCC317FQEE

Installation and Owner’s Manual

Unit :

Temp. Setting :

Auto

Unit :

Mon.

2013/11/20

16oC

O󰀨 Error

11:30

TEMP. FAN

NO. OK NO.

TEMP.

MODE

BACK

SCHEDULE

Parts and Functions-----------------------------------------------1

Operation-------------------------------------------------------------6

Central Controller Wiring Connection--------------------------21

Contents

Parts and Functions

Appearance

Mon.

2013/11/20 11:30

Unit : 11

Unit :

Auto Auto

Normal Lock

Error

O󰀩ce

201

Group : On O󰀨 Error

All

FAN

TEMP.

OK NO.NO.

TEMP.

MODE

BACK

SCHEDULE

EXQUISITE DESIGN & EXQUISITE LIFE

Temp. Setting:

20oC

English

Main interface display

Parts and Functions

Mon.

2013/11/20 11:30

Unit : 11

Unit :

Auto

Normal Lock

Error

O󰀩ce

201

Group : On O󰀨 Error

All

Temp. Setting:

20oC

Key descriptions

Parts and Functions

Mode/ESC key. Press this key for toggling between modes in the main interface and press this

key to go back to the previous interface.

Menu key. Press this key when in the main interface to enter the menu interface. The

SCHEDULE key below indicates the weekly timer setting.

Temperature adjustment keys. Press these keys to adjust the temperature in the main interface.

When the ECO function is not set, the temperature range is 16°C–30°C; temperature can be

varied in steps of 1°C. When the ECO function is set, the temperature range is limited. The

temperature adjustment keys are used for positioning the cursor when not in the main interface.

Unit No. adjustment keys. They are used for adjusting the unit or group unit no. These keys

are used for selecting between a unit or a group unit in the main and unit & group selection

interfaces; the options are as follows: unit→group→ALL→unit.

OK OK key

FAN

Fan key. Press this key to adjust the fan speed.

The options are (Low)→ (Middle) → (High) →

(Auto) → (Low)

AUTO

Auto Fan circulates as → → →

AUTO AUTO AUTO AUTO

ON/OFF key. In the main interface, short-press or tap this key to toggle between the ON/OFF

state of the unit or group (smallest unit) unit on which the cursor is placed. For example, if the

smallest unit in the group is in the ON state, after short pressing the ON/OFF key, all units in

this group will change to the OFF state. After pressing and holding the ON/OFF key down for

5 s, if the unit or smallest unit of a group on which the cursor is positioned is in the ON state,

all online units and groups will change to the OFF state, and vice versa. That is, if the smallest

unit in the group on which the cursor is positioned remains in the OFF state, after pressing and

holding down the ON/OFF key for 5 s, all units and groups online will change to the ON state.

SCHEDULE

MODE

BACK

TEMP.

NO.

English

Main interface icon descriptions

Weekly timer. When the weekly timer function is set for the units or groups

online, this icon will appear on the main interface.

Swing (reserved)

Error. When a unit or the smallest unit of a group malfunctions, this icon will

appear on the main interface.

Sleep (reserved)

Electrical heating (reserved)

Turbo (reserved)

Heat reclaim (reserved)

Health (reserved)

Child lock

Date (YY/MM/DD), time, week display area.

Mode of unit or smallest unit of group on which the cursor is

currently positioned.

Unit : 11 Unit or group on which the cursor is currently positioned.

Filter Filter (reserved)

Displays the unit or group on which the cursor is currently

positioned. Indicates whether the LIFO, Central, or Lock state is

selected.

Displays the set temperature of a unit or smallest unit of a

group on which the cursor is positioned or displays the ambient

temperature under the basic setting.

Parts and Functions

Mon.

2013/11/20 11:30

LIFO/Central/Lock

Temp. Setting:

20oC

AUTO

Error

Indicates the ON/OFF state or error in a unit or group on which the cursor is

positioned; error displays take priority.

O󰀩ce

201

Naming display. Displays the name of the unit or group on which the cursor is

positioned. If the length of the display text exceeds the display area, the text that

does not t the display area is represented by •••. If there is no name, the display

will show the unit/group as Unit1/GroupA.

Fan speed display.

Online unit display. When the cursor moves to ALL, all online units selected can be

controlled simultaneously. If the number of online units is more than 16, move the

cursor to ALL and press the RIGHT key to enter the next page. After entering the

next page, the arrow will be on the left side of the online units. Press the LEFT key

to go back to the previous page.

Group display.

Parts and Functions

AUTO

Unit :

All

Group :

English

Initialization

Function instructions

Operation

After powering on reset, the interface will display the following:

1. Mode options:

Pressing the MODE key in the main interface provides the following options in sequence:

Note: When the cursor is in the group area, the interface will show the state of the smallest unit in the group, and the

controller will adjust the mode of the smallest unit in the mode adjustment state.

2. Full control function:

When the cursor ashes under ALL, which is below the online unit display area, press the OK key to enter the full

control interface.

(1) When the online normal indoor units are controlled together, the state of the smallest indoor unit after entering the

full control function is displayed. If the smallest indoor unit is a normal indoor unit, the full control interface will be

shown as follows.

After the initialization is complete, indicated through a progress bar, you enter the main interface, and the ON/OFF

state of online units and groups will be shown on the unit and group areas.

Auto Cool Heat Fan Dry Auto

Auto AutoRecovery By-pass

Operation

Full Control

On/O󰀨

Temp. Setting

Fan

Mode

Control Mode

On O󰀨

Central Lock LIFO

Auto Cool Heat Fan Dry

Auto Low Middle High

28oC

English

Operation

3. Unit control function:

When the cursor ashes on any online unit in the main interface, press OK to enter the control interface of this

unit. Press the UP/DOWN/LEFT/RIGHT keys to move the cursor and press the OK key to conrm the selection.

Note: The functions in grey are reserved functions.

4. Group control function:

When the cursor ashes on any online group in the main interface, press OK to enter the control interface of this

group and press the UP/DOWN/LEFT/RIGHT keys to move the cursor, and press OK key to conrm the selection.

Note: The functions in grey are reserved functions

Unit Control

Group Control

Group A

Breeze/Super

Control Mode

10oC Heating

Name : O󰀩ce 102

On O󰀨

Central Lock LIFO

On O󰀨

HRV Linkage On O󰀨

Unit Included : 11 12 13 14 15 16 17 18

Unit 1

Filter

Control Mode

10oC Heating

Name : O󰀩ce 102

The region : D

Type : Normal Model

Ambient Temp.: 23oC

On O󰀨

Central Lock LIFO

On O󰀨

Breeze/Super On O󰀨
