Cardo Systems Scala 700 Manual de usuario
scala-700TM
QUICK GUIDE
COMPONENTS
Wheel
USB
Charging
Jack
Speaker
Control
Button
Ear
Loop
Status
Light
INTRODUCTION
This quick guide will assist
you with the use of the scala-
700 headset. For more
detailed information please
download the User Manual
from our website at
www.cardowireless.com.
Before using the scala-700 we
recommend that you
familiarize yourself with the
Bluetooth®functionality of
your cellular phone. See the
User Manual for safety
information.
IMPORTANT: Please visit
www.cardowireless.com/FAQ.php
to check whether your particular
cellular phone has any Bluetooth
related bugs that may affect its
operability with your headset.
scala-700TM
BEFORE USING
1. Make sure that the headset is fully charged for at least four hours
before initial use.
2. To charge the headset, plug the charger into the headset’s Charging
Jack, which is located just below the Wheel.
3. While charging, the red Status Light illuminates. When charging is
completed the light will turn off.
NOTE: Plugging in the charger turns off the headset. You must
turn on the headset after charging.
When plugging the headset into the charger, it may take up to
15 seconds before the red Status Light turns on.
GENERAL INSTRUCTIONS
All headset functions are controlled either by:
• Pressing the Control Button either for a short period of less than a
second, or a long period of over three seconds,
Or
• Moving the Wheel up or down, or by pressing it inwards.
2
scala-700TM
TURNING THE HEADSET ON FOR THE FIRST TIME
In order for your headset to work with your cellular phone, they must
first recognize each other. This process is called “pairing”, and only
needs to be performed once for each phone.
1. To initiate pairing, press the Wheel for at least 8 seconds while the
headset is turned off. The Status Light will flash red and blue indicating
that the headset is in pairing mode.
2. Turn on your phone and make sure that its Bluetooth function is
activated.
3. Search for Bluetooth devices on your phone by following the phone’s
instructions.
4. After a few seconds the phone will list the scala-700 as a “discovered
device”. Select it and follow your phone’s instructions to accept the
pairing.
5. When prompted, enter 0000 (four zeros) as your PIN or passkey.
6. Your phone will confirm that pairing has succeeded.
Note: If pairing is not completed within two minutes the headset
will return to standby mode.
3
scala-700TM
You can enter pairing mode at any time by pressing the Wheel
for at least 8 seconds while the headset is turned off
Your Headset can pair with up to eight phones, and will automatically
connect to the last phone connected to the Headset. To connect to a
different phone go to the Bluetooth menu of the active mobile phone
and disconnect the Headset. Now go to the Bluetooth menu of the
desired phone and connect the Headset to this phone.
ATTACHING THE HEADSET TO YOUR EAR
Attach the Headset to your ear using the Ear-Loop. Insert the pin of the
Ear-Loop to a suitable depth so that the speaker fits snugly into your
ear (hovering above your ear canal), then bend the flexible bow of the
Ear-Loop to produce a snug but comfortable fit.
SWAP BETWEEN TWO ACTIVE MOBILE PHONES
The scala-700 allows you to swap, i.e. to alternately use one among the
last two phones to which it has been connected.
While both phones are turned on and the headset is on standby, double-
press the wheel. Now the Headset will switch to the second phone.
Each time you double-press the wheel, the alternate phone connects
to the Headset.
4
scala-700TM
FUNCTIONS
DESIRED RESULT: REQUIRED ACTION:
Turn on the headset Press the Wheel steadily for at least 3 seconds
Turn off the headset Press the Wheel steadily for at least 3 seconds
Answer a call Short press the Control Button
NOTE: Wait until you hear the incoming call on
the headset (not only on the phone) before
pressing the Control Button
Reject an incoming call Long press the Control Button
Terminate a call Short press the Control Button
Increase the volume Move the Wheel up by steps. When you hear a beep,
it is at maximum.
Decrease the volume Move the Wheel down by steps. When you
hear a beep it is at minimum.
Mute/Un-mute During a call, short press the Wheel inwards
Transfer a call to the phone During a call, long press the Control Button
Voice Dial During standby, short press the Control button
and state the name of the person you wish to
call (after a tone is heard).
Note that your mobile phone must support the
voice dial feature.
Redial Short press the Wheel
Accept call waiting or During an active call and one call on hold or waiting,
swap between calls short press the Wheel.
Conference call During an active call and one call on hold, long
press the Wheel
5
scala-700TM
FUNCTIONS (continued)
DESIRED RESULT: REQUIRED ACTION:
Locate the headset Activate the Buzzer as follows: Dial a call with the
(Buzzer Function) mobile phone and press Send/Talk. While the call is
in progress, begin pressing the mobile phone volume
buttons up, then down repeating the up/down
sequence four or more times. The headset will start
buzzing.
Lock/Unlock buttons In standby, simultaneously press the Wheel and the
Control button for at least 3 seconds.
BATTERY MONITOR
To check the status of the headset’s battery, press the Control Button
for at least 7 seconds while the headset is on Standby position. The
Status Light will flash for 2 seconds as follows:
• Blue Fully charged
• Red and Blue Medium charge
• Red Weak charge
DISABLING / ENABLING THE STATUS LIGHT
To disable/enable the Status Light, while the Headset is on Standby,
move the Wheel down and hold for at least three seconds. The Status
Light will stop/begin flashing, depending on whether you are
disabling/enabling the Status Light.
6
scala-700TM
7
CHANGING THE WHEEL ORIENTATION
When changing volume, the default configuration of the headset is for
it to be worn on the right ear. This means that clicking up on the Wheel
towards the small ‘+’ sign on the headset increases the volume one step
at a time, while clicking down towards the ‘-’ sign on the headset
decreases the volume one step at a time.
If you wear the headset on your left ear, this headset allows you to
change the Wheel orientation from right to left ear, so that pressing the
Wheel up still increases the volume, and pressing down decreases the
volume.
In order to set the headset for left ear orientation: Power on the Headset
by pressing and holding the Control button while pressing in and holding
the Wheel for 4 seconds. Once you see 3 blue flashes, the headset is
powered on and you may release the buttons.
NOTE: The headset will revert to its default right ear configuration once
it is turned off. In order to regularly use the headset in left ear configuration,
always turn on the headset using the Control + Wheel procedure above.
NOTE: If you choose to wear the headset on your left ear but do not
with to change the Wheel orientation, the Wheel will function in the
reverse order, i.e. turning down will increase volume, turning up will
decrease volume.
scala-700TM
LOCATE THE HEADSET (Buzzer Function)
The scala-700 allows you to locate the headset by activating a buzzer.
Activate the Buzzer as follows: Dial a call with the mobile phone and
press Send/Talk. While the call is in progress, begin pressing the mobile
phone volume buttons up, then down, repeating the up/down sequence
four or more times. The headset will start buzzing.
STATUS LIGHTS
The Headset uses the following Status Lights to display its status
Status Light Status
None Headset is off or Status Light is disabled
3 blue flashes Powered on successfully
3 red flashes Powered off successfully
Alternating Red/blue flashes Pairing mode
1 blue flash every 3 seconds Standby – No call in progress
2 blue flashes every Call being initiated or in progress
3 seconds
1 red flash every 3 seconds Standby and battery is low
2 red flashes every 3 seconds Call being initiated or in progress and battery is low
Steady red Headset is being charged
8
scala-700TM
AUDIO TONES
With the exception of the actions described in the following table, all
actions are followed by a single tone to confirm that the headset has
accepted the action.
Action Tone
Mute On/off tone and mute reminder tone every 20
seconds
Volume up Tone on maximum volume
Volume down Tone on minimum volume
Locate the headset Buzzing
TROUBLESHOOTING
Note: For most problems, it is recommended as a first step that you
turn the headset off for 20 seconds and then on again. If this does
not help, try pairing the headset and phone again.
Problem Action
Pairing fails 1. Delete scala-700 from your paired
device list in your phone (if it is listed).
2. Turn off the mobile phone and headset.
3. Take the battery out of the phone and
put it back.
4. Repeat the pairing process as described
in TURNING THE HEADSET ON FOR
THE FIRST TIME section above.
9
scala-700TM
Can’t answer phone calls or (Assuming your mobile phone supports
perform voice dialing Voice Dialing) :
1. Make sure your headset is turned ON
and in standby mode while the blue light
indicator flashes slowly.
2. Verify that the Bluetooth function on your
phone is set to ON.
3. Verify that the scala-700 is the correctly
paired headset to your mobile phone
(refer to the phone manual).
4. Link the headset to the phone as
described above.
5. Check “Definitions” or “Settings” on your
mobile phone.
6. Perform the pairing process and check
again.
Battery does not provide at Make sure your headset is fully charged.
least six hours of talk time. Charging time is up to 3 hours for an empty
battery. When fully charged and charger is
connected to headset, the red light indicator
turns off.
10
