Cardo Systems S-800 Manual de usuario

When Technology Meets Design

CARDO SYSTEMS, INC.

Gebrauchsanleitung

Guide d’Utilisation

Guida di Avvio

Guia de usario

User Guide

Cardo

english

Congratulations and thank you for choosing the Cardo S-800

Bluetooth®headset. This User Guide will help you learn about the

Cardo S-800’s many features, allowing you to make the best use of

your headset.

CARDO S-800 OVERVIEW

1 Microphone

2 Multi-Function Wheel (MFW)

3 LED Status Indicator

4 Power and Hot Dial Button

5 Charging Jack

6 Control Button (CTRL)

7 Speaker

8 Earloop

1 4 7

english

GETTING STARTED

To use your Cardo S-800 (“the headset”), please follow these

initial steps:

• Charge your headset

• Pair your headset with a Bluetooth®-enabled mobile phone.

1. CHARGING YOUR HEADSET

The headset comes with a built-in rechargeable battery. Prior to using

the headset, make sure to charge the headset for at least 4 hours.

Normally it takes approximately 2 hours to fully charge the headset.

1.Connect the charger to an AC wall outlet and the charger plug to

the headset’s Charging Jack. The headset’s LED status indicator

will be red during charging.

2.When the battery is fully charged, the red LED will turn off.

3.Disconnect the charger from AC wall outlet and the headset.

NOTE: Charging indication may be delayed for a few seconds if

the headset has not been used for a long time or the battery is

drained.

The fully charged battery offers up to 8 hours talk time and up to

one week standby time.

2. PAIRING YOUR HEADSET

Before you can use your headset you must pair it to your

Bluetooth-enabled mobile phone. If you do not have a Bluetooth-

enabled mobile phone, please visit http://www.cardosystems.com /BTA

for information on the Cardo BTA II Bluetooth Adapter.

english

1.Turn on your phone and turn ON its Bluetooth function.

2.Make sure the headset is turned OFF, then press and hold the

Power Button for approximately 8 seconds until the LED status

indicator begins alternating blue and red, indicating that the

headset is in Pairing Mode.

3.Set the phone to search for Bluetooth devices by following the

instructions in the phone’s user guide. This is usually found in the

phone’s Bluetooth menu and may be referred to as “discover” or

“add” a device.

4.After a few seconds, the phone will list the “Cardo S-800” as a

discovered device. Select it from the list and press “OK” or “Yes”.

5.When prompted, enter the passkey “0000” (4 zeros) and press

“OK” to complete the pairing.

6. When the pairing is complete, your phone will conrm that the 

pairing was successful and the headset’s LED status indicator

will begin ashing slowly in blue.

You should now be able to make and receive calls using your

headset. To initially connect the headset to your phone, you may

need to tap the CTRL Button once on the headset.

IMPORTANT: If pairing is not completed within 2 minutes

while the Pairing Mode is activated, the headset will return to

Standby mode, ashing blue once every three seconds and

you must start the Pairing process again from Step 2 above.

NOTE: Your headset can pair with up to 8 phones, and will

automatically connect to the last phone connected to the headset.

english

To connect to a different paired phone, go to the Bluetooth menu

of the active phone and disconnect the headset. Then go to the

Bluetooth menu of the phone you wish to connect and connect the

headset by selecting it from the list of Paired Devices.

3. WEARING YOUR HEADSET

The S-800 headset can be worn on either your left or right ear.

There are two ways in which you can wear the S-800 headset.

1.Without the earloop: Gently insert the headset without an

earloop into your ear, and it will hold itself in place securely.

2.With the earloop: Insert the straight section of the pin of the

earloop to a suitable depth so that the speaker ts snugly in your ear. 

The earloop is exible, and may be adjusted for maximum comfort.

The lanyard for the S-800 provides

an easy and convenient way of

carrying your headset while it is not

in use.

1.To attach the headset to the

lanyard, insert the speaker into the

upper loop of the lanyard. Then pull

the headset downwards into the

lower loop, until it is held securely

in place.

2.To release the headset from the

lanyard, simply pull the headset

forward at a downward angle.

Upper

loop

Lower

loop

english

4. USING YOUR HEADSET – BASIC FUNCTIONS 5. USING YOUR HEADSET – ADVANCED FUNCTIONS

1. Redial the last dialed number

During Standby, press the MFW inwards to redial the last dialed number.

2. Reject an incoming call

During an incoming call, press and hold the CTRL Button for 3

seconds.

3. Call waiting / Toggling between calls

During an incoming call and one call on hold or waiting, tap the

MFW inwards to answer the incoming call or toggle between calls.

4. Conference call

During an active call and one call on hold, press and hold the MFW

inwards for 3 seconds to combine both calls into a Conference call.

Function Required Action

Turn ON/OFF the headset

Press and hold the Power Button for at least 4 seconds

Answer a call Tap the CTRL Button*

End a call Tap the CTRL Button

Make a call from

your phone

Dial normally from your phone and the call will be transferred to

the headset (subject to phone settings).

Make a call using

Voice Dial

During Standby, tap the CTRL Button, wait for the tone and say

the name of the person you wish to call. (Your mobile phone

must support the Voice Dial feature.)

Increase the volume

Move the MFW up by steps. When you hear a beep, it is at maximum.

Decrease the volume Move the MFW down by steps.When you hear a beep, it is at minimum.

Mute the microphone

During a call, tap the MFW inwards to turn on/off mute.

* Note: wait until you hear the incoming call on the headset (not only on the phone)

english

5. Transfer calls to/from headset

During a call, press and hold the CTRL Button for 3 seconds to

transfer the call between the headset and the mobile phone.

NOTE: On some phones, transferring a call to the headset requires

just a tap of the CTRL Button.

6. Hot Dial Function

The S-800 allows you to call any of three different phone numbers

at the press of a button.

In order to use the Hot Dial function, you must rst congure

your mobile phone’s Speed Dial settings. Please refer to your

mobile phone’s user guide for instructions on saving Speed Dial

numbers.

To Hot Dial:

• Speed dial #2: Tap the Hot Dial Button once.

• Speed dial #3: Tap the Hot Dial Button twice rapidly.

• Speed dial #4: Tap the Hot Dial Button three times rapidly.

7. SWAP (Swapping connection between two active mobile phones)

The S-800 allows you to swap, i.e. to alternately use one among

the last two phones to which it has been connected.

To SWAP between phones:

•While both phones are turned on and the headset is in Standby

mode, double-press the MFW inwards.

•The headset will switch to the second phone.

english

• Each time you double-press the MFW, the alternate phone

connects to the headset.

NOTE: This feature may only be used when the headset and both

phones are in Standby mode.

8. Battery Status Indicator

To check the status of the headset’s battery, press and hold the

CTRL Button for at least four seconds while the headset is in

Standby mode.

The LED Status Indicator will ash for two seconds as follows:

• Blue Full charge

• Red and Blue Medium charge

• Red Weak charge

9. Locating the Headset (Buzzer Function)

The S-800 allows you to locate the headset by activating an audible buzzer.

To activate the Buzzer:

• Dial a number with the mobile phone and press Send/Talk.

• While the call is in progress (or even while still ringing), turn the

mobile phone’s volume buttons up, then down, repeating the up/

down sequence ve or more times.

• The headset will start buzzing.

10. Call back the last incoming caller (Callback Function)

The S-800 allows you to place a call to the phone number of the

last incoming, missed or rejected call.

english

To use the Callback function:

• While in Standby mode, rapidly move the MFW down twice and

release (double down-click).

NOTE: The Callback number memory will be cleared if:

1. The headset is disconnected from the current phone and

connected to a different phone.

2. The headset is turned off or has been charged.

3. The last incoming caller had a blocked or restricted number.

NOTE: This feature is not supported by some mobile phones.

11. Auto-Answer Function

The S-800 allows you to automatically answer all incoming calls

using the Auto-Answer function. Please note that once this feature

is activated you are subject to unintended eavesdropping. Use of 

this feature is at your own risk!

Learn more at www.cardosystems.com/faq/s800/autoanswer

When Auto-Answer mode is enabled and there is an incoming

call, the headset will ring for a few seconds and then automatically

answer the call without the need to press the CTRL Button. Auto-

Answer is disabled by default.

To enable/disable Auto-Answer:

• While in Standby mode, press and hold the MFW upwards for

seven seconds.

• When the Auto-Answer function is enabled, the blue Status

Indicator will begin ashing rapidly.

english

NOTE:

• Auto-Answer will not answer an incoming call if you are currently

on a call (Call Waiting).

• Turning off the headset will disable the Auto-Answer function.

• Auto-answer can be enabled again after turning on the headset

by following the instructions above.

12. Button Lock

The S-800 allows you to lock its buttons, preventing the buttons

from being accidentally pressed.

To lock/unlock the buttons on the headset:

• While in Standby mode, simultaneously press the MFW and the

CTRL Button for at least four seconds.

13. Disabling / enabling the LED Status Indicator

The S-800 allows you to turn off the ashing LED Status Indicator.

• While in Standby mode, move the MFW down and hold for at

least four seconds.

• The Status Indicator will stop/begin ashing, depending on 

whether you are disabling/enabling the Status Indicator.

14. Changing the Wheel orientation

The default conguration of the headset is designed for use on your right 

ear.

This means that clicking up on the MFW towards the small ‘+’ sign

the headset increases the volume one step at a time, while clicking down

towards the ‘-’ sign on the headset decreases the volume one step at a time.

If you wear the headset on your left ear, the S-800 allows you to

Otros manuales para S-800

Tabla de contenidos

Otros manuales de Auriculares de Cardo Systems

Cardo Systems

Cardo Systems SCALA RIDER TEAMSET PRO Manual de usuario

Cardo Systems

Cardo Systems Scala-rider Q2 Manual de usuario

Cardo Systems

Cardo Systems SCALA RIDER SOLO Manual de usuario

Cardo Systems

Cardo Systems G9 Powerset Manual de usuario

Cardo Systems

Cardo Systems SPIRIT Manual de usuario

Cardo Systems

Cardo Systems SCALA RIDER G4 Manual del propietario

Cardo Systems

Cardo Systems Scala 700 Manual de usuario

Cardo Systems

Cardo Systems SCALA RIDER FM - Manual de usuario

Cardo Systems

Cardo Systems Scala-500 Combo Manual de usuario

Cardo Systems

Cardo Systems PACKTALK CUSTOM Manual de usuario

Cardo Systems

Cardo Systems G9 Powerset Manual de usuario

Cardo Systems

Cardo Systems Headset Scala 600 Manual de usuario

Cardo Systems

Cardo Systems Scala rider Q-Solo Manual de usuario

Cardo Systems

Cardo Systems Scala Rider Freecom 2 Manual de usuario

Cardo Systems

Cardo Systems Q-Line Audiokit Manual de usuario

Cardo Systems

Cardo Systems ER18 Manual de usuario

Cardo Systems

Cardo Systems Scala 700 Manual de usuario

Cardo Systems

Cardo Systems Scala-500 Combo Manual de usuario

Cardo Systems

Cardo Systems Spirit HD Manual de usuario

Cardo Systems

Cardo Systems SCALA RIDER FM - Manual de usuario

Cardo Systems

Cardo Systems Scala 500 Manual de usuario

Cardo Systems

Cardo Systems SCALA RIDER G4 POWERSET Manual de usuario

Cardo Systems

Cardo Systems SCALA RIDER G4 Manual de usuario

Cardo Systems

Cardo Systems ScalaRider Manual de usuario

Manuales populares de Auriculares de otras marcas

Sena

Sena SMH10 Manual de usuario

IASUS

IASUS Stealth IA-NT4-BASIC-BT Manual de usuario

Sennheiser

Sennheiser EPOS ADAPT 230 Manual de usuario

Doro

Doro Flexus HS2005 Manual de usuario

GE 98971 Manual de usuario

Hama

Hama 00184070 Manual de usuario

Plantronics

Plantronics Blackwire 3200 Series Manual de usuario

Blue Tiger

Blue Tiger Advantage PLUS Manual de usuario

Jawbone

Jawbone Icon Manual de usuario

Jabra

Jabra FR 20 Manual de usuario

Roxcore

Roxcore Flow A+ Manual de usuario

Turtle Beach

Turtle Beach XP 510 Manual de usuario

Philips

Philips SHB6101 Manual de usuario

Jabra

Jabra PRO 9460 Duo Manual de usuario

HyperX

HyperX HyperX Cloud Flight Manual de usuario

Bose

Bose MIE2 Mobile Manual de usuario

Jabra

Jabra Steel Manual de usuario

HyperX

HyperX cloud ii Manual de usuario
