Canon BJC-6200 Manual de usuario

V01

Contents

Introduction

How to Use This Manual

Parts and Functions of the Printer

Front View

Rear View

Inside the Printer

Operation Panel

Printing on Paper and Other Media

Media SizesYou Can Use with the Printer

Media TypesYou Can Use with the Printer

Media TypesYou Cannot Use with the Printer

Loading Paper and Other Media

Printing Area

Using Plain Paper or High Resolution Paper

Using Envelopes

Using Transparencies or Back Print Film

Using Glossy Photo Paper

Using High Gloss Photo Film

Using Glossy Photo Cards

Using Banner Paper

Using T-Shirt Transfers

Using the BJ Cartridges

BJ CartridgesYou Can Use with the Printer

Notes on Handling BJ Cartridges

Printing Photographs

Tips on Printing Photographic Images

Printing Photographic Images

About Photo Optimizer

Using the Scanner

Scanner Driver Basics

Before Using the Scanner

Installing the IS Scan Software

About the Scanning Area

Launching IS Scan

Performing White Level Calibration

Scanning an Image

Saving an Image

Routine Maintenance

Prolonging the Service Life of the Printer

BJ Cartridge Maintenance

When to Replace a BJ Cartridge

Printing a Nozzle Check Pattern

Cleaning the Print Heads

Replacing Ink Tanks

Replacing a BJ Cartridge

Aligning the Print Heads

Cleaning the Printer

Cleaning the Paper Feed Rollers

Transporting the Printer

Troubleshooting

Printout is Unsatisfactory

Printer Does Not Start or Stops in Mid-job

Paper Jams or Does Not Feed

The POWER Lamp Flashes Orange

An Error Message Appears

Scanner Problems

Other Problems

Speciﬁcations

Index

Appendix

Driver and Utility Guide for Windows Users

Driver and Utility Guide for Macintosh Users

5Introduction

Introduction

Thank you for purchasing the BJC-6200 Bubble Jet Printer.

This Reference Guide provides complete descriptions of the features and functions of the

printer. To maximise the life of your printer, familiarise yourself fully with its functions and

how to use it.

Note

This manual uses the following symbols depending on the computer system you are using.

Always observe the instructions indicated by these symbols.

Indicates information for Windows 98 and Windows 95 users only.

Indicates information for Macintosh computers with USB interface only.

For detailed information on the printer driver settings, see the "Driver and Utility Guide for

Windows Users" section or the "Driver and Utility Guide for Macintosh Users" section in this

Reference Guide.

If you are a Windows NT 4.0 user, refer to the document ﬁle (NT_Guide400.doc) provided

with the Windows NT printer driver on the supplied CD-ROM.

Windows

Macintosh

6How to Use This Manual

How to UseThis Manual

Use this button when you wish to

enlarge the instruction screen of the

Reference Guide. Select this button

in the tool bar, and click within the

screen of the Reference Guide.

Displays the next

page.

Returns to the page

you were viewing

previously. Use this

button when you

wish to move back

from another page.

Indicates a link to jump to a

page about the topic

shaded in blue.

Displays the previous page.

To view this Reference Guide, we recommend that you use Acrobat Reader 3.0 or higher. The screens dis-

played by Acrobat Reader 3.0 are slightly different.

7How to Use This Manual

Displays a table of contents for the Reference Guide.

Click the desired item to jump to the topic.

Click the "+" symbol when you wish to see detailed head-

ings for each chapter.

Click the "–" symbol when you wish to return to the

original display.

Use this button to

search for a word.

8Parts and Functions of the Printer

Parts and Functions of the Printer

Front View

Rear View

Inside the Printer

Operation Panel

9Parts and Functions of the Printer

Front View

Paper Output Tray

Holds printed sheets after they are ejected

from the printer.

Paper Guide

Ensures that the sheets from the stack in the auto

sheet feeder feed straight into the printer. Always

align this guide with the left edge of the paper.

Paper Rest

Raise to support the paper,

especially a larger paper size.

Auto Sheet Feeder

Holds multiple sheets of paper

or other media which are auto-

maticallyfedintothe printer one

sheet at a time.

Operation Panel

Front Cover

Open to install, replace or switch the BJ

Cartridges, or to remove a paper jam.

Paper Thickness Lever

Adjusts the gap between the print

heads and the surface of the paper for

the type of paper you are printing on.

10Parts and Functions of the Printer

RearView

Printer Cable Connector (Parallel Interface)

Provides a connection point for connecting a parallel

interface cable to the printer.

Printer Cable Connector (USB Interface)

Provides a connection point for connecting a

USB interface cable to the printer.

Power Connector

Provides a connection point for

connecting the power cord to the

AC power outlet. The power cord

may or may not be permanently

attached to the printer, depending

on the country of purchase.
