READ THIS SUPPLEMENT AND YOUR

CANNONDALE BICYCLE OWNER’S MANUAL.

Both contain important safety information. Keep

both for future reference.

Owner’s Manual Supplement

Lefty Ocho 120

English

Safety Messages

In this supplement, particularly important information

is presented in the following ways:

Indicates a hazardous situation which, if

not avoided, may result in death or serious

injury.

NOTICE

Indicates special precautions that must be

taken to avoid damage.

SYMBOLS:

NGLI-2

= Apply NGLI2 Synthetic grease

NYLON

= Suspension grease Buzzy’s Slick

Honey™ or R.S.P. Slick Kick

= Loctite® 242

= Loctite® 262

= Loctite® 222

N·m

= Tightening torque in Newton

meters.

CONTENTS

Safety Information....................47

Identiﬁcation ................................ 8

Technical Information............. 921

Replacement Parts............... 2224

Maintenance ......................... 2526

Limited Warranty ....................... 27

Notes ........................................... 28

Cannondale Supplements

This manual is a “supplement” to your

Cannondale Bicycle Owner’s Manual.

This supplement provides additional and

important model speciﬁc safety, maintenance,

and technical information. It may be one of

several important manuals/supplements for

your bike; obtain and read all of them.

Please contact your Authorized Cannondale

Dealer immediately if you need a manual or

supplement, or have a question about your bike.

You may also contact us using the appropriate

country/region/location information.

You can download Adobe Acrobat PDF versions

of any manual/supplement from our website:

http://www.cannondale.com.

Contacting Cannondale

Cannondale USA

Cycling Sports Group, Inc.

1 Cannondale Way,

Wilton CT, 06897, USA

1800726-BIKE (2453)

Cycling Sports Group Europe B.V

CSG Europe (Woudenberg)

Cycling Sports Group Europe B.V.

Geeresteinselaan 57

3931JB Woudenberg

The Netherlands

PH: 00.31.541.200374

International Distributors

Consult our website to identify the appropriate

Cannondale Dealer for your region.

Your Cannondale Dealer

To make sure your bike is serviced and

maintained correctly, and that you protect

applicable warranties, please coordinate all

service and maintenance through your

Authorized Cannondale Dealer.

NOTICE

Unauthorized service, maintenance, or

repair parts can result in serious damage

and void your warranty.

Lefty Ocho 120 Owner’s Manual

138227 Rev 1 01/21)

Safety Information

Intended Use

SAFETY INFORMATION

Intended Use

Ocho

Model

Wheel Size

Travel Length

(mm)

ASTM

Condition 3

(Symbol)

Ocho

Carbon

Ocho Alloy

29” / 120mm

Condition 3, Cross-Country, XC

INTENDED

For cross-country riding and racing,

intermediate terrain (e.g., hilly with small

obstacles like roots, rocks, loose surfaces and

hard pack and depressions, relatively short

suspension travel, supporting nimble handling

NOT INTENDED  DO NOT USE:

No large drops, drop-os, wooden structures,

or dirt embankments requiring long

suspension travel or heavy duty components

and hard landings.

For Extreme forms of jumping/riding (e.g.,

hard core mountain, Freeriding, Downhill,

North Shore, Dirt Jumping, Hucking).

No Tandems

No Motorcycles

No Engine powered vehicles

Using the Lefty the wrong way is

dangerous.

Please read your Cannondale Bicycle

Owner’s Manual for more information

about Intended Use ASTM Conditions 15,

and riding conditions deﬁned by each.

The intended use and riding conditions

deﬁned by on-product markings and

owner’s manual for the speciﬁc Lefty fork

model MUST match those of the frame.

A mis-match between a Lefty fork and a

frame can lead to failure of the frame or

Lefty fork. Such a failure can lead to a loss

of control, with the risk of serious injury or

death to the rider.

If you have any questions consult a

Cannondale Dealer or professional bike

mechanic with experience in Intended Use

conditions in the bicycle industry.

You can be severely injured, paralyzed

or killed in an accident if you ignore this

warning.

Safety Information

Important Composites Message

Important Composites

Message

Your bike (frame and components) is made

from composite materials also known as

“carbon ﬁber.”

All riders must understand a fundamental

reality of composites. Composite materials

constructed of carbon ﬁbers are strong

and light, but when crashed or overloaded,

carbon ﬁbers do not bend, they break.

For your safety, as you own and use the

bike, you must follow proper service,

maintenance, and inspection of all the

composites (frame, stem, fork, handlebar,

seat post, etc.) Ask your Cannondale

Dealer for help.

We urge you to read PART II, Section D.

“Inspect For Safety” in your Cannondale

Bicycle Owner’s Manual BEFORE you ride.

You can be severely injured, paralyzed

or killed in an accident if you ignore this

warning.

Crash/Impact Damage

Inspection

After A Crash Or Impact:

Inspect the entire bike, all parts; Look

carefully for damage. See “Inspect For

Safety” section in the Cannondale Bicycle

Owner’s Manual. See Support at www.

cannondale.com

Any of the following conditions indicate

that serious fork damage is present:

• Any “klunking,” creaking, knocking or

unexplained noises.

• A change in travel, and/or function.

• Loss of adjustment features, oil or air

leaks, or loose/broken parts.

• Crash or impact damage (cracking,

deep scratches, gouges, dents, or

bending)

• Carbon which has a soft feel or

altered shape, or broken, splintered, or

delaminated carbon ﬁber.)

• Visible cracks, a white or milky color

present in carbon ﬁber section

Continuing to ride a damaged frame /

fork increases the chances of frame /fork

failure, with the possibility of injury or

death of the rider.

Lefty Ocho 120 Owner’s Manual

138227 Rev 1 01/21)

Safety Information

Minimum Tire-to-Crown Clearance

Minimum Tire-to-Crown

Clearance

Modiﬁcation or installation of damping

cartridge/spacers other than speciﬁed; or

installing over-sized tires can result in

incorrect tire-to-crown clearance

Check minimum tire fork/frame

clearance with all air released from lefty

and fully compressed.

Measure between the top of the properly

inﬂated tire (1) and the bottom of the fork

crown (2).

≥ 3mm

If tire clearance is less than the minimum

speciﬁed, the rotating tire could come into

contact with with the fork crown or frame

causing the wheel to stop suddenly. This

can throw a rider o the bicycle or result in

a loss of control and crash.

Compression Assembly

55mm

For carbon steerer models, use only the

headset compression assembly (1)

speciﬁed for the model. See

“Speciﬁcations.”

Do not use other headset compression/

preload adjusters, shims, and do not

modify the steerer.

Do not Stack spacers (3) on top of the

stem (2) or exceed the 55 mm Maximum

Stack Height (total spacer height stacked

between the top of the head tube (5) and

the stem (2). Exceeding maximum stack

height with spacers (3) or locating spacers

on top of the handlebar stem can place

signiﬁcant stress on the steerer tube (4). It

could break.

Follow the Cannondale compression

assembly installation instructions.

Use a torque wrench to tighten. Follow

stem manufacturer’s torque speciﬁcations.

Safety Information

Front Brake

Making External Adjustments

Make any external adjustments only when

stopped. Attempting to adjust while riding

can result in a loss of control.

You can be severely injured, paralyzed, or

killed in an accident if you ignore these

warnings.

Disassembly or Modiﬁcation

Modiﬁcations can lead to serious fork

damage or serious personal injury.

Do not modify the Lefty in any way.

Use only original equipment (OE)

replacement parts. See “Replacement

Parts.”

Do not attempt damage repair yourself.

Have any required repair services or

procedures perform by an Authorized

Cannondale Dealer or Cannondale

Authorized Service Center.

You can be severely injured, paralyzed

or killed in an accident if you ignore this

warning.

Front Brake

The brake mount (1) is compatible with post

-mount type brake systems.

Before riding, make sure the StopLock

release lever is in the locked position

(shown). See “Front Wheel” removal and

installation instructions.

Follow brake manufacturer’s instructions

when mounting the brake caliper.

Do not ride without a front brake system

attached to the Lefty. A brake system

(disc/caliper) is an important secondary

wheel retention system. If the brake

system is missing or improperly installed,

and/or if the wheel hub axle bolt should

loosen, the front wheel could slide o the

spindle end.

You can be severely injured, paralyzed,

or killed in an accident if you ignore this

warning.

Lefty Ocho 120 Owner’s Manual

138227 Rev 1 01/21)

Identiﬁcation

Parts of the Ocho

25 26

Lefty 60

1. Steerer

2. Integrated crown race (carbon only)

3. Crown

4. Outer Tube

5. Inner Tube

6. Lockout, Remote

7. Compression, Dial

8. Brake Cable Guide, Upper

9. Brake Guide Tube

10. Wiper Seal

11. O-ring, travel indicator

12. StopLock Brake Mount

13. StopLock Release Lever

14. Wheel Spindle

15. Rebound Adjuster

16. Air Valve

17. Serial Number

18. Wheel Size/Travel

19. Lefty 60 Hub

20. Bolt, axle

21. Label, Warning

22. Serial Number Label

23. Compression Assembly K35009

24. Travel Length (mm)

25. Oset (mm)

26. Wheel Dia. (inches)

Parts of the Ocho

Identification

Technical Information

Speciﬁcations

Technical Information

Speciﬁcations

Item Speciﬁcation

Carbon

Travel Length 120mm 110mm

Wheel Size 29in.

External Adjustments Air Pressure, Rebound, Compression, Lockout

Remote Compatibility “FOX 2 POS (Fox p/n 8200701250, R) Rockshox OneLoc”

Recommended Sag 25% 30mm 27.5mm

Axle-to-Crown 530mm 520mm

1Minimum Tire-to-Crown Clearance 3mm

Fork Oset 50mm

“StopLock Brake Adapter Mount

(disc dia./ adapter)

Minimum: 160mm/ K53131

Maximum: 203mm/ K53131+20mm Post Mount Adapter

Hub Compatibility Lefty 60

2Maximum Tire Size:

(Dia./Width)”

760mm x 65mm

Headset Compression Assy. Only Cannondale

p/n K35058/K35009

Maximum Stack Height 55mm

Stem Clamp Dia. 28.6mm

Steerer: Type/ Taper Length/ Overall

Length

Tapered 1.5in - 1 1/8in/ 86mm/ 330mm

Crown Race: Type/Bearing/Degree Bonded 1.5in. / 36 degree

Manual Reset Length +/- 3mm 4mm

Air Pressure Limits Minimum: 50 psi/2.4 bar

Maximum: 250 psi / 17 bar

Intended Use ASTM CONDITION 3: Cross Country, Marathon, Hardtails

Max. Weight Limit Total

(Rider+All Equipment)

305 lbs/ 138kg

Key:

- Indicates a safety related. Read and follow instructions carefully.

(1) - Measure with all air pressure released and Lefty fully compressed. “See page 6.”

(2) - The “maximum width” of a speciﬁc tire will change with the tire type/manufacturer/model. A tire width will vary across

dierent point on the tire as well as with the tire ranges of inﬂation pressure and while riding. This speciﬁcation is only a guide. Any

installed tire, must not be able to contact the Lefty and 3mm of any part of the Lefty maintained.

Product and Speciﬁcations are subject to change without notice.

Lefty Ocho 120 Owner’s Manual

138227 Rev 1 01/21)

Technical Information

Adjustments

Air Pressure

Set the initial air pressure according to your

weight (including the weight of riding gear)

based upon the following table. Then, adjust

air pressure in small amounts for your riding

preference.

Adding more air will result in a stier

suspension feel. Less air pressure will result in

a softer suspension feel. Stay within the

minimum and maximum air pressure limits.

Figure 2

To set air pressure:

1. Clean the area around the valve and the

pump end to remove dirt or contaminants.

2 Remove the valve cap (1), attach a

high-quality suspension pump to the valve

(2) .

3. Pressurize to the recommended air

pressure

4. When completed, remove the pump;

replace the valve cap.

Air Pressure/Rebound

Recommendation

RIDER WT. Air Pressure

(psi)

Rebound

(Clicks out

from slow)

Lbs Kg

120 55 68 17

130 59 81 16

140 64 94 15

150 68 107 14

160 73 120 13

170 77 132 11

180 82 145 10

190 86 158 9

200 91 171 8

210 95 184 7

220 100 197 6

230 105 209 5

Air Pressure Limits:

Minimum: 50 psi/ 3.5 bar

Maximum: 200 psi/ 13.75 bar

Air Pressure Limits:

Minimum: 50 psi/ 3.5 bar

Maximum: 200 psi/ 13.75 bar

NOTICE

• Stay within Air pressure limits.

• Attach pump only if valve and pump

are clean.

Tabla de contenidos

Otros manuales de Bicicleta de Cannondale

Cannondale

Cannondale Quick Neo SL w/ Ebikemotion X35 Drive System... Manual

Cannondale

Cannondale CY22 Moterra Neo Guía de configuración

Cannondale

Cannondale Alloy Road Disc Manual de usuario

Cannondale

Cannondale 2016 SUPERSIX EVO Guía de configuración

Cannondale

Cannondale Mountain Hardtail Thru Axle Manual de usuario

Cannondale

Cannondale Alloy Road Rim Manual de usuario

Cannondale

Cannondale Rush 29 Manual de usuario

Cannondale

Cannondale Kids with Training Wheels Manual de usuario

Cannondale

Cannondale MOTERRA LT Manual de usuario

Cannondale

Cannondale TANDEM Guía de configuración

Cannondale

Cannondale ON Manual de usuario

Cannondale

Cannondale Jekyll 27.5 Guía de configuración

Cannondale

Cannondale SYNAPSE HI-MOD CARBON 2013 Guía de configuración

Cannondale

Cannondale Chase Series Manual de usuario

Cannondale

Cannondale SUPERMAX Guía de configuración

Cannondale

Cannondale Habit Guía de configuración

Cannondale

Cannondale Full-Suspension EBike Manual de usuario

Cannondale

Cannondale Trigger 27.5/29 Guía de configuración

Cannondale

Cannondale TRIGGER Guía de configuración

Cannondale

Cannondale Topstone Neo Carbon Guía de configuración

Cannondale

Cannondale Tesoro Neo X Speed Guía de configuración

Cannondale

Cannondale 2012 RZ ONE TWENTY Guía de configuración

Cannondale

Cannondale Slice Carbon Guía de configuración

Cannondale

Cannondale PROPHET Manual de usuario

Manuales populares de Bicicleta de otras marcas

RAMBO

RAMBO R1000X2M-FF-BFD Manual de usuario

Vermeiren

Vermeiren SAFARI Manual de usuario

Velec

Velec A2/36V Manual de usuario

Coswheel

Coswheel A-ONE Manual de usuario

Betzold

Betzold 97869 Manual de usuario

Cervélo

Cervélo S3 2019 Manual de usuario

Tenways

Tenways AGO X Manual de usuario

Festo

Festo EGSC-BS-KF Manual de lista de piezas

Gio Electric

Gio Electric H1 Volt Manual de usuario

GOGOBEST

GOGOBEST GM30 Manual de usuario

DAHON

DAHON CIAO - 2009 Manual de usuario

Aprimatic

Aprimatic ONDA 500 Guía de inicio rápido

MV Agusta

MV Agusta Lucky Explorer GRAVEL Manual de instrucciones

Greyp

Greyp G6 Series Manual de usuario

Babboe

Babboe Carve-E Manual de usuario

Huka

Huka orthros Manual de usuario

Xtracycle

Xtracycle Stoker 2021 Manual de usuario

APRILIA

APRILIA DORSODURO 750 ABS 2015 Manual de usuario
