READ THIS SUPPLEMENT AND YOUR
CANNONDALE BICYCLE OWNER’S MANUAL.
Both contain important safety information.
Keep both for future reference.
WWW.CANNONDALE.COM
© 2018 Cycling Sports Group
Trigger/Jekyll Owner’s Manual Supplement
134942 Rev. 1
Trigger/Jekyll
Owner’s Manual Supplement
Safety Messages
In this supplement, particularly important information
is presented in the following ways:
Indicates a hazardous situation which,
if not avoided, may result in death or
serious injury.
NOTICE
Indicates special precautions that
must be taken to avoid damage.
The following symbols are used in this manual:
Symbol Name Description
NGLI-2
NGLI-2 synthetic grease Apply NGLI-2 synthetic grease.
CRB-GEL
Carbon gel Apply carbon gel (friction paste) KF115/
2
Medium-strength
removable thread lock Apply Loctite® 242 (blue) or equivalent.
1
134942 Rev 1.
EnglishTrigger / Jekyll - Owners Manual Supplement
CONTENTS
Safety Information ............................2-6
Technical Information...................... 7-19
Replacement Parts ........................28-29
Tightening Torques ............................ 30
Maintenance....................................... 31
Notes.................................................. 32
Cannondale
Supplements
This manual is a “supplement” to your
Cannondale Bicycle Owner’s Manual.
This supplement provides additional
and important model specic safety,
maintenance, and technical information.
It may be one of several important
manuals/supplements for your bike;
obtain and read all of them.
Please contact your Authorized
Cannondale Dealer immediately if you
need a manual or supplement, or have
a question about your bike. You may
also contact us using the appropriate
country/region/location information.
You can download Adobe Acrobat PDF
versions of any manual/supplement from
our website:
http://www.cannondale.com.
Contacting Cannondale
Cannondale USA
Cycling Sports Group, Inc.
1 Cannondale Way,
Wilton CT, 06897, USA
1-800-726-BIKE (2453)
Cycling Sports Group Europe B.V
Mail: Postbus 5100
Visits: Hanzepoort 27
7570 GC, OLDENZAAL, Netherlands
Tel: +41 61 551 14 80
Fax:+31 54 151 42 40
Your Cannondale Dealer
To make sure your bike is serviced and
maintained correctly, and that you
protect applicable warranties, please
coordinate all service and maintenance
through your Authorized Cannondale
Dealer.
NOTICE
Unauthorized service, maintenance,
or repair parts can result in serious
damage and void your warranty.
2
134942 Rev 1.
EnglishTrigger / Jekyll - Owners Manual Supplement
SAFETY INFORMATION
Important Composites
Message
Your bike (frame and components) is
made from composite materials also
known as “carbon ber.”
All riders must understand a
fundamental reality of composites.
Composite materials constructed of
carbon bers are strong and light, but
when crashed or overloaded, carbon
bers do not bend, they break.
For your safety, as you own and use
the bike, you must follow proper
service, maintenance, and inspection
of all the composites (frame, stem,
fork, handlebar, seat post, etc.) Ask
your Cannondale Dealer for help.
We urge you to read PART II, Section
D. “Inspect For Safety” in your
Cannondale Bicycle Owner’s Manual
BEFORE you ride.
You can be severely injured,
paralyzed or killed in an accident if
you ignore this warning.
Inspection & Crash
Damage Of Carbon
Frames/Forks
After A Crash Or Impact:
Inspect frame carefully for damage
(See PART II, Section D. Inspect For
Safety in your
Cannondale Bicycle Owner’s Manual.
Do not ride your bike if you see any
sign of damage, such as broken,
splintered, or delaminated carbon
ber.
Any of the following may indicate a
delamination or damage:
· An unusual or strange feel to the
frame
· Carbon which has a soft feel or
altered shape
· Creaking or other unexplained
noises,
· Visible cracks, a white or milky
color present in carbon ber
section
Continuing to ride a damaged
frame increases the chances of
frame failure, with the possibility of
injury or death of the rider.
3
134942 Rev 1.
EnglishTrigger / Jekyll - Owners Manual Supplement
Intended Use
The intended use of
all models is ASTM
CONDITION 4,
All-Mountain.
Understand your bike and its
intended use. Using your bike the
wrong way is dangerous.
Please read your Cannondale Bicycle
Owner’s Manual for more information
about Intended Use and Conditions
1-5.
Servicing
This supplement may include
procedures beyond the scope of
general mechanical aptitude.
Special tools, skills, and knowledge
may be required. Improper
mechanical work increases the risk
of an accident. Any bicycle accident
has risk of serious injury, paralysis or
death.
To minimize risk we strongly
recommend that owners always
have mechanical work done by an
Authorized Cannondale Dealer.
4
134942 Rev 1.
EnglishTrigger / Jekyll - Owners Manual Supplement
Maximum Fork Length
Maximum Fork Length is an important frame safety testing specification for front
suspension mountain bikes. You must observe the measurement when installing
headset parts, headset adapters, installing and adjusting a fork, and selecting
replacement forks.
To Center Of
The Fork Axle
From
Bottom Of Frame
Head Tube
Maximum
Fork
Length
You must select a replacement fork not only based on head tube diameter but the
critical factor of frame maximum fork length
Do not exceed maximum fork length. Exceeding the MAXIMUM FORK LENGTH limit
can overload the frame causing it to break while riding.
Your retailer MUST follow and observe this specification for your bike. For Maximum Fork
Length specifications for Cannondale bicycles, see www.cannondale.com.
You can be severely injured, paralyzed or killed in an accident if you ignore this warn-
ing.
5
134942 Rev 1.
EnglishTrigger / Jekyll - Owners Manual Supplement
Tire Size x Maximum Width
Observe the Tire Size x Maximum Width for your bike found in the
“Specifications” page of this manual.
Mounting the wrong size tires can result in the tires hitting the fork or frame
when riding. If this happens, you can lose control of your bike and you can be
thrown off, a moving tire can be stopped because it touches the fork or frame.
Do not mount oversized tires, ones that rub or hit the fork or frame, ones that
result in too little clearance, or ones that can hit the fork or frame when the
suspension is fully compressed or when riding.
Take care that the tires you select are compatible with your bike’s fork or frame
design. Also, be sure to follow the manufacturer’s recommendations of your
front fork and rear shocks.
When you are considering tires for your bike consider...
The actual measured size of a tire may be different than its sidewall marking.
Each time you mount a new tire, take the time to inspect the actual clearance
between the rotating tire and all parts of the frame. The U.S. Consumer
Product Safety Commission (CPSC) requires at least 1/16” (1.6 mm) tire clearance
from any part of the bike. Allowing for lateral rim flex and a wheel or rim that
is out-of-true will likely mean choosing a rear tire that provides even more
clearance than the CPSC recommends.
Ask your dealer for the right tires for your bike and its particular components!
You can be severely injured, paralyzed or killed in an accident if you ignore
this warning.
6
134942 Rev 1.
EnglishTrigger / Jekyll - Owners Manual Supplement
Minimum Seat Post
Insert
Make sure at least 100 mm of the
seat post is inserted into the frame
at all times.
Failure to insert the seat post at least
100 mm can place a very high stress
on the seat tube top tube junction
causing the frame to fail while riding.
Remove the seat post. Measure 100
mm from the bottom of the seat post.
Use a permanent marker to mark the
post at 100 mm.
When adjusting the seat post height
in the seat tube, never adjust the
seat post so that the line you mark is
above the top edge of the seat tube.
You must also be aware that bicycle
seat posts are permanently marked
by the manufacturer with a “minimum
insert” line on the seat post itself.
You must not rely on this marking as
an indication of the proper minimum
seat post insertion depth.
You can be severely injured,
paralyzed or killed in an accident if
you ignore this warning.
Rear Shocks
Select only compatible shocks and
forks for your bike. Do not modify
your bike in any way to mount one.
Have your shock or fork installed by a
professional bike mechanic
Riding with the wrong rear shock can
damage the frame. You could have a
serious accident. Make sure the total
travel, eye-to-eye length, and stroke
length of the rear shock you select
meet the “Specications” listed in
this manual.
When selecting different shocks
or forks for your bike, make sure
that the shock or fork you select is
compatible with your bike’s design
and how you will use your bike.
You can be severely injured,
paralyzed or killed in an accident if
you ignore this warning.
7
134942 Rev 1.
EnglishTrigger / Jekyll - Owners Manual Supplement
TECHNICAL INFORMATION
Specications - Trigger 27.5
Item Specication
Rear Travel Hustle Mode: 115 mm
Flow Mode: 145 mm
Head Tube UPR: 1 -1/8 in, LWR: 1-1/2 in
Headset FSA Orbit C-40-ACB
w/9.1 mm stack
Bottom Bracket Type/ Width PF30 / 83 mm
Front Derailleur Low Direct Mount, Side Swing
(alloy CS only)
Seat Post Dia./Binder 31.6 mm / 34.9 mm
Min. Seat Post Insert 100 mm
Tire Size/ Max Tire Width 27.5 in x 2.5 in (measured)
Max. Fork Length 545 mm
Rear Shock: Eye-To-Eye / Stroke / Bushing
Width
210 mm / 55 mm /
FT: 30 x 8 mm, RR: 30 x 8 mm
Sag 30%, 17 mm
Chain Guide ISCG 05
Rear Brake: Mount Type /
Min/Max Rotor Dia. Flat Mount / 160 mm / 180 mm
Rear Axle Maxle TA / 148 x 12 mm,
180 mm length
Ai Offset
Rear Wheel: 3 mm Offset to NDS
SRAM Chainring: +6 mm Offset
Hollowgram SpideRing: Ai Offset
Intended Use ASTM CONDITION 4, All-Mountain
Max. Weight Limit
Total (rider+all equipment): 305 lbs / 138 kg
8
134942 Rev 1.
EnglishTrigger / Jekyll - Owners Manual Supplement
Specications - Jekyll 27.5
Item Specication
Rear Travel Flow Mode: 165 mm,
Hustle Mode: 130 mm
Head Tube UPR: 1 -1/8 in, LWR: 1-1/2 in
Headset FSA Orbit C-40-ACB
w/ 9.1 mm stack
Bottom Bracket: Type/ Width CRB: PF30 / 83 mm,
ALLY: BB30 / 83 mm
Front Derailleur N/A
Seat Post: Dia./Binder 31.6 mm / 34.9 mm
Min. Seat Post Insert 100 mm
Tire Size x Max. Width 27.5 in x 2.5 in (measured)
Max. Fork Length CRB: 565 mm, ALLY: 565 mm
Rear Shock: Eye-To-Eye / Stroke / Bushing
Width
230 mm / 60 mm /FT: 30 x 8 mm,
RR: 30 x 8 mm
Sag 30%, 18 mm
Chain Guide ISCG 05
Rear Brake: Mount Type /
Min/Max Rotor Dia. Flat Mount / 160 mm / 180 mm
Rear Axle: Type/Length Maxle TA /148 x 12 mm, 180 mm length
Ai Offset:
Rear Wheel: 3mm Offset to NDS,
SRAM Chainring: +6 mm Offset
Hollowgram SpideRing: Ai Offset
Intended Use ASTM CONDITION 4, All-Mountain
Max. Weight Limit
Total (rider+all equipment): 305 lbs / 138 kg
Este manual sirve para los siguientes modelos
1
Tabla de contenidos
Otros manuales de Bicicleta de Cannondale
Cannondale
Cannondale Slice Carbon Guía de configuración
Cannondale
Cannondale Topstone Neo Carbon Guía de configuración
Cannondale
Cannondale LEFTY HYBRID Guía de configuración
Cannondale
Cannondale Lefty Ocho 120 Guía de configuración
Cannondale
Cannondale SuperSix EVO Manual de usuario
Cannondale
Cannondale Trigger 27.5/29 Guía de configuración
Cannondale
Cannondale Carbon Road Disc Manual de usuario
Cannondale
Cannondale Adventure Neo Allroad 2023 Guía de configuración
Cannondale
Cannondale Habit Guía de configuración
Cannondale
Cannondale Adventure Neo Allroad S 2023 Manual de usuario
Cannondale
Cannondale Scalpel Si 2016 Guía de configuración
Cannondale
Cannondale TANDEMS 2009 Manual de usuario
Cannondale
Cannondale RIZE Series Guía de configuración
Cannondale
Cannondale Kinneto E-Series Manual de usuario
Cannondale
Cannondale CY22 Mavaro Neo Guía de configuración
Cannondale
Cannondale PROPHET Guía de configuración
Cannondale
Cannondale SuperSix EVO Neo Guía de configuración
Cannondale
Cannondale Treadwell Manual de usuario
Cannondale
Cannondale SuperSix EVO Guía de configuración
Cannondale
Cannondale Adventure Neo Guía de configuración
