Cabletron Systems SmartSTACK ELS100-8TXUF2 Manual de usuario

9033029

SmartSTACK

ELS100-8TXUF2

FAST ETHERNET SWITCH

INSTALLATION

AND

USER GUIDE

ELS100-8TXUF2.book Page -i Friday, June 4, 1999 4:01 PM

ELS100-8TXUF2.book Page 0 Friday, June 4, 1999 4:01 PM

Notice

9033029

NOTICE

Cabletron Systems reserves the right to make changes in specifications and other information

contained in this document without prior notice. The reader should in all cases consult Cabletron

Systems to determine whether any such changes have been made.

The hardware, firmware, or software described in this manual is subject to change without notice.

IN NO EVENT SHALL CABLETRON SYSTEMS BE LIABLE FOR ANY INCIDENTAL,

INDIRECT, SPECIAL, OR CONSEQUENTIAL DAMAGES WHATSOEVER (INCLUDING BUT

NOT LIMITED TO LOST PROFITS) ARISING OUT OF OR RELATED TO THIS MANUAL OR

THE INFORMATION CONTAINED IN IT, EVEN IF CABLETRON SYSTEMS HAS BEEN

ADVISED OF, KNOWN, OR SHOULD HAVE KNOWN, THE POSSIBILITY OF SUCH

DAMAGES.

1999 by Cabletron Systems, Inc., P.O. Box 5005, Rochester, NH 03866-5005

Printed in Taiwan, R.O.C.

Order Number: 9033029 April 1999

Cabletron Systems, is a registered trademark and SmartSwitch is a trademark of Cabletron

Systems, Inc.

All other product names mentioned in this manual may be trademarks or registered trademarks of

their respective companies.

FCC NOTICE

This device complies with Part 15 of the FCC rules. Operation is subject to the following two

conditions: (1) this device may not cause harmful interference, and (2) this device must accept any

interference received, including interference that may cause undesired operation.

NOTE:This equipment has been tested and found to comply with the limits for a Class A digital

device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable

protection against harmful interference when the equipment is operated in a commercial environment.

This equipment uses, generates, and can radiate radio frequency energy and if not installed in

accordance with the operator’s manual, may cause harmful interference to radio communications.

Operation of this equipment in a residential area is likely to cause interference in which case the user

will be required to correct the interference at his own expense.

WARNING: Changes or modifications made to this device which are not expressly approved by the

party responsible for compliance could void the user’s authority to operate the equipment.

Only qualified personnel should perform installation

procedures.
