Cabletron Systems MMAC-Plus 9H423-26 Manual
9032227-01
SmartSwitch 9000
9H423-26
Local Management Appendix
1
Appendix
9H423-26 Module Specific
Information
Introduction
This appendix contains local management information that is specific to the
9H423-26 Fast Ethernet Switch Module.
The 9H423-26 Switch Module has 26 ports:
• 24 ports (two fixed RJ21 connectors)
• 2 ports (two fixed MMF SC connectors)
This module can operate in either full duplex or half duplex mode.
Auto-negotiation provides support for 10 Mbps and 100 Mbps speeds at both half
and full duplex. 100Base-FX supports 100 Mbps speed at both half and full
duplex.
Auto-negotiation allows the module to automatically use the fastest rate
supported by the device at the other end (either 10 Mbps or 100 Mbps at either
half or full duplex). This technology is similar to how modems negotiate
transmission speed to find the highest transmission rate. Similarly,
auto-negotiation determines the highest common speed between two devices and
communicates at that speed. If no common speed is detected, the device will be
partitioned.
Modifying Fields and User Privileges
To modify fields on this module, you must have read-write or super-user
privileges. If you have read-only privileges, you can view information; however,
you cannot modify any fields. For more information about user privileges and
community names, see the
SmartSwitch 9000 Module Local Management User’s
Guide.
9H423-26 Module Specific Information
2
Module Interfaces
The 9H423-26 Fast Ethernet Switch Module has 31 interfaces. Table 1 lists the
identifying number, name, and description of each interface.
Table 1. 9H423-26 Module Interfaces
Interface
Number
Interface
Name
Interface
Description
1 SMB1 1 Mbps System Management Bus
2 SMB10 10 Mbps System Management Bus
3 HOST
4 LOCAL
5 INB Internal Network Bus
6 FENET1 Fast Ethernet Front Panel Port 1
7 FENET2 Fast Ethernet Front Panel Port 2
8 FENET3 Fast Ethernet Front Panel Port 3
9 FENET4 Fast Ethernet Front Panel Port 4
10 FENET5 Fast Ethernet Front Panel Port 5
11 FENET6 Fast Ethernet Front Panel Port 6
12 FENET7 Fast Ethernet Front Panel Port 7
13 FENET8 Fast Ethernet Front Panel Port 8
14 FENET9 Fast Ethernet Front Panel Port 9
15 FENET10 Fast Ethernet Front Panel Port 10
16 FENET11 Fast Ethernet Front Panel Port 11
17 FENET12 Fast Ethernet Front Panel Port 12
18 FENET13 Fast Ethernet Front Panel Port 13
19 FENET14 Fast Ethernet Front Panel Port 14
20 FENET15 Fast Ethernet Front Panel Port 15
21 FENET16 Fast Ethernet Front Panel Port 16
22 FENET17 Fast Ethernet Front Panel Port 17
23 FENET18 Fast Ethernet Front Panel Port 18
3
9H423-26 Module Specific Information
Use the numbers listed in Table 1 to configure the module’s default interface (see
the General Configuration Screen).
24 FENET19 Fast Ethernet Front Panel Port 19
25 FENET20 Fast Ethernet Front Panel Port 20
26 FENET21 Fast Ethernet Front Panel Port 21
27 FENET22 Fast Ethernet Front Panel Port 22
28 FENET23 Fast Ethernet Front Panel Port 23
29 FENET24 Fast Ethernet Front Panel Port 24
30 FENET25 Fast Ethernet Front Panel Port 25 (Fiber)
31 FENET26 Fast Ethernet Front Panel Port 26 (Fiber)
Table 1. 9H423-26 Module Interfaces (Continued)
Interface
Number
Interface
Name
Interface
Description
9H423-26 Module Specific Information
4
Port Configuration Screen
The 9H423-26 Port Configuration Screen (Figure 1), displays configuration
information about each port on the module (one port at a time).
Figure 1. 9H423-26 Port Configuration Screen
SmartSwitch 9000 Local Management
Port Configuration
Module Name: 9H423-26 Firmware Revision: 01.00.00
Slot Number: 1 BOOTPROM Revision: 01.00.00
PORT #: 1
Port Type RJ21
Link Status Link
Current Operation Mode 100Base-TXFD
Desired Operation Mode [Auto-Negotiation]
Advertised Ability [100Base-TXFD] [Enabled]
SAVE [PORT: 1] EXIT RETURN
5
9H423-26 Module Specific Information
Port Configuration Screen Fields
The following information briefly explains each Port Configuration Screen field.
Slot # (Modifiable)
Indicates the slot that the board occupies in the chassis.
Port #
(Read-only
)
Indicates the current port for which statistics are displayed.
PortType
(Read-only)
Displays one of the following values:
• MMF SC
• RJ21
Link Status
(Read-only)
Displays one of the following values:
• Link
• No Link
• N/A
Current Operation Mode
(Read-only)
Displays one of the following values:
• 10Base-T
Operating standard 10 Mbps Ethernet over two pairs of UTP cable.
• 10Base-TFD
Operating Full Duplex 10 Mbps Ethernet over two pairs of UTP cable. Full
Duplex indicates the module is connected to a single device, and is not
listening for other transmissions or collisions when sending data. This allows
both devices on the link to send and receive data simultaneously over the link.
Theoretically, this provides the devices with twice the bandwidth of normal,
or half duplex, Ethernet.
• 100Base-TX
Operating Fast Ethernet over two pairs of Category 5 UTP or Type 1 STP
cable.
• 100Base-TXFD
Operating Full Duplex 100 Mbps Fast Ethernet over two pairs of Category 5
UTP or Type 1 STP cable.
• 100Base-FX
Operating 100 Mbps Fast Ethernet over two strands of multimode fiber cable.
• 100Base-FXFD
9H423-26 Module Specific Information
6
Operating Full Duplex 100 Mbps Fast Ethernet over two strands of multimode
fiber cable.
Desired Operation Mode
(Toggle)
Displays one of the following values:
• Auto-Negotiation
• 10Base-T manual
• 10Base-TFD manual
• 100Base-TX manual
• 100Base-TXFD manual
• 100Base-FX manual
• 100Base-FXFD manual
Only the modes that the device is capable of using are displayed. The module
defaults to auto-negotiation. If the device connected to the module also supports
auto-negotiation, the devices self-configure to the fastest possible speed and
duplex. For example, if the other device does not support auto-negotiation, the
devices do a parallel detection and configure to either 10 Mbps or 100 Mbps, but
only at half duplex. If the device connected to the module is standard Ethernet
with no auto-negotiation support, and is configured for full duplex, the Desired
Operation Mode field must be set to 10Base-T Full Duplex.
Advertised Ability
(2 Toggles)
Allows the user to specify the advertised ability for the chosen port. The ability of
each port is presented first, followed by the ability to enable/disable on each port.
Advertised Ability is applicable only when the Desired Operation Mode field is
set to Auto-Negotiation. Otherwise this field displays N/A and is read-only.
When in auto-negotiation mode, the module auto-negotiates to the highest speed
being advertised by both devices.
Port #
(Modifiable)
Displays the current port for which configuration information is displayed. Use
the procedure in the next section to display configuration information for a
different port.
7
9H423-26 Module Specific Information
Displaying Configuration Information for a Different Port
To display configuration information for a different port:
1. Use the arrow keys to highlight the
Port #
field at the bottom of the Port
Configuration Screen.
2. Press the
Space
Bar
to increment (or press the
Delete
key to decrement) the
port number.
3. Press the
Return
key (neither the read-only
Port #
field nor the configuration
information will change until you press the
Return
key).
Exiting the Port Configuration Screen
To exit the Port Configuration Screen, use the arrow keys to highlight
RETURN
,
then press the Return key.
9H423-26 Module Specific Information
8
Port Statistics Screen
The 9H423-26 Port Statistics Screen (Figure 2), displays statistical information for
each port (one port at a time).
Figure 2. 9H423-26 Port Statistics Screen
SmartSwitch 9000 Local Management
Port Statistics
Module Name: 9H423-36 Firmware Revision: 01.02.X3
Slot Number: 1 BOOTPROM Revision: 01.00.01
PORT #: 1
Bytes: 3390336996 Link Status: Link
Frames: 49857191 Port Type: RJ21
Total Errors: 93 Admin Status: Enabled
Collisions: 87 Application: Bridging
CRC/Align Errors: 6 Operation Mode: 10Base-T Full Duplex
Undersize Packets: 0 Auto Negotiation: Yes
Oversize Packets: 0
Fragments: 87
Jabbers: 0
Broadcasts: 6
Multicast: 19090317
[Port: 1] EXIT RETURN
