SmartSwitch 9000

9E428-12/36 and 9E429-12/36

User’s Guide

Notice

Cabletron Systems reserves the right to make changes in speciﬁcations and other information

contained in this document without prior notice. The reader should in all cases consult Cabletron

Systems to determine whether any such changes have been made.

The hardware, ﬁrmware, or software described in this manual is subject to change without notice.

IN NO EVENT SHALL CABLETRON SYSTEMS BE LIABLE FOR ANY INCIDENTAL, INDIRECT,

SPECIAL, OR CONSEQUENTIAL DAMAGES WHATSOEVER (INCLUDING BUT NOT LIMITED

TO LOST PROFITS) ARISING OUT OF OR RELATED TO THIS MANUAL OR THE INFORMATION

CONTAINED IN IT, EVEN IF CABLETRON SYSTEMS HAS BEEN ADVISED OF, KNOWN, OR

SHOULD HAVE KNOWN, THE POSSIBILITY OF SUCH DAMAGES.

Cabletron Systems, Inc.

P.O. Box 5005

Rochester, NH 03867-5005

Printed in the United States of America

Order Number: 9032022-01 February 1998

LANVIEW

is a registered trademark, and

SmartSwitch

a trademark of Cabletron Systems, Inc.

CompuServe

is a registered trademark of CompuServe, Inc.

i960 microprocessor

is a registered trademark of Intel Corp.

Ethernet

is a trademark of Xerox Corporation.

Notice

FCC Notice

This device complies with Part 15 of the FCC rules. Operation is subject to the following two

conditions: (1) this device may not cause harmful interference, and (2) this device must accept any

interference received, including interference that may cause undesired operation.

NOTE:

This equipment has been tested and found to comply with the limits for a Class A digital

device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable

protection against harmful interference when the equipment is operated in a commercial environment.

This equipment uses, generates, and can radiate radio frequency energy and if not installed in

accordance with the operator’s manual, may cause harmful interference to radio communications.

Operation of this equipment in a residential area is likely to cause interference in which case the user

will be required to correct the interference at his own expense.

WARNING:

Changes or modiﬁcations made to this device which are not expressly approved by the

party responsible for compliance could void the user’s authority to operate the equipment.

VCCI Notice

This equipment is in the 1st Class Category (information equipment to be used in commercial and/or

industrial areas) and conforms to the standards set by the Voluntary Control Council for Interference

by Information Technology Equipment (VCCI) aimed at preventing radio interference in commercial

and/or industrial areas.

Consequently, when used in a residential area or in an adjacent area thereto, radio interference may be

caused to radios and TV receivers, etc.

Read the instructions for correct handling.

iii

Notice

DOC Notice

This digital apparatus does not exceed the Class A limits for radio noise emissions from digital

apparatus set out in the Radio Interference Regulations of the Canadian Department of

Communications.

Le présent appareil numérique n’émet pas de bruits radioélectriques dépassant les limites applicables

aux appareils numériques de la class A prescrites dans le Règlement sur le brouillage radioélectrique

édicté par le ministère des Communications du Canada.

Notice

DECLARATION OF CONFORMITY

ADDENDUM

Application of Council Directive(s):

89/336/EEC

73/23/EEC

Manufacturer’s Name:

Cabletron Systems, Inc.

Manufacturer’s Address:

35 Industrial Way

PO Box 5005

Rochester, NH 03867

European Representative Name:

Mr. J. Solari

European Representative Address:

Cabletron Systems Limited

Nexus House, Newbury Business Park

London Road, Newbury

Berkshire RG13 2PZ, England

Conformance to Directive(s)/Product Standards:

EC Directive 89/336/EEC

EC Directive 73/23/EEC

EN 55022

EN 50082-1

EN 60950

Equipment Type/Environment:

Networking Equipment, for use in a

Commercial or Light

Industrial Environment.

We the undersigned, hereby declare, under our sole responsibility, that the equipment packaged with

this notice conforms to the above directives.

Manufacturer Legal Representative in Europe

Mr. Ronald Fotino Mr. J. Solari

____________________________________________________ ______________________________________________________

Full Name Full Name

Principal Compliance Engineer Managing Director - E.M.E.A.

____________________________________________________ ______________________________________________________

Title Title

Rochester, NH, USA Newbury, Berkshire, England

____________________________________________________ ______________________________________________________

Location Location

Contents

Chapter 1 Introduction

Features........................................................................................................................... 1-2

Related Manuals............................................................................................................ 1-5

Getting Help .................................................................................................................. 1-5

Chapter 2 Installing the 9E428 and 9E429 Modules

Unpacking the Module................................................................................................. 2-1

User Accessible Components ...................................................................................... 2-2

Setting the Module DIP Switch................................................................................... 2-3

Installing the Module in the SmartSwitch 9000 Chassis ......................................... 2-5

The Reset Switch ........................................................................................................... 2-7

Chapter 3 Operation

ENIB................................................................................................................................ 3-2

SmartSwitch ASIC......................................................................................................... 3-3

i960 Core......................................................................................................................... 3-3

INB NIB .......................................................................................................................... 3-3

System Management Buses ......................................................................................... 3-4

SMB-1 Bus ............................................................................................................... 3-4

SMB-10 Bus ............................................................................................................. 3-4

System Diagnostic Controller...................................................................................... 3-4

DC/DC Converter ........................................................................................................ 3-5

INB Interface.................................................................................................................. 3-5

ITDM Arbitration levels........................................................................................ 3-5

Monarch/Slave SmartSwitch 9000 Modules ..................................................... 3-6

Chapter 4 LANVIEW LEDs

Contents

Chapter 5 Speciﬁcations

Technical Speciﬁcations................................................................................................5-1

CPU ..........................................................................................................................5-1

Memory ...................................................................................................................5-1

Standards.................................................................................................................5-1

Network Interfaces ................................................................................................5-1

Safety...............................................................................................................................5-2

Service.............................................................................................................................5-2

Physical...........................................................................................................................5-2

Dimensions .............................................................................................................5-2

Weight......................................................................................................................5-2

Environment ...........................................................................................................5-3

1-1

Chapter 1

Introduction

The 9E428-12/36 and 9E429-12/36 (Figure 1-1) are switching modules that

provide either 12 or 36 ports, depending on the module. The 9E428-12/36 provide

Ethernet ﬁber-optic 10Base-FL connectivity via multimode ST (straight through)

connectors, while the 9E429-12/36 modules use single mode ST connectors. There

are two ST connectors for each port, one for transmit and one for receive. Each

module also provides an additional port that connects directly to the Internal

Network Bus (INB) backplane interface. These modules use a SmartSwitch ASIC

design and an advanced Intel i960

microprocessor. This microprocessor provides

a platform for all management functions within a scalable RISC-Based

Architecture.

These modules can operate in two modes: either as a 12/36 port Ethernet

traditional switch (using 802.1d standards) with a high speed backbone

connection, or as a Secure Fast Switch (SFS) with 12/36 Ethernet connections.

Each port can be conﬁgured to operate in the Full Duplex mode. This

conﬁguration allows each port to provide a full 20 Mbps of bandwidth for ﬁle

servers or high-end, user-intensive work stations.

Network management information is available through a variety of methods. All

information based on Simple Network Management Protocol (SNMP) is

accessible either via an in-band (front panel port), Side Band (SMB-10), or via the

Environmental Module’s COM ports. Serial Line Internet Protocol (SLIP) or

Point-to-Point Protocol (PPP) is supported by the Environmental Module’s COM

ports. For more information on the SMB-10, SLIP or PPP, refer to the SmartSwitch

9000 Local Management User’s Guide.

The 9E428-12/36 and 9E429-12/36 also feature front panel LANVIEW™

Diagnostic LED’s to offer at-a-glance status information about each front panel

port, as well as the operation of the overall module.

Introduction

1-2

Features

Processor

The 9E428-12/36 and 9E429-12/36 modules are equipped with an advanced Intel

i960 microprocessor. This microprocessor provides a platform for all management

functions such as Spanning Tree, RMON, and MIB support, within a scalable

RISC-Based architecture.

Fast Packet Switching

The 9E428-12/36 and 9E429-12/36 modules incorporate a hardware based switch

design referred to as the SmartSwitch ASIC, a collection of custom ASICs

designed speciﬁcally for high speed switching. Because all frame translation,

address lookups, and forwarding decisions are performed in hardware, these

modules can obtain a throughput performance of greater than 750K pps.

Management

The 9E428-12/36 and 9E429-12/36 feature SNMP for local and remote

management. Local management is provided through the RS-232 COM ports on

the SmartSwitch 9000 Environmental Module, using a standard VT-220

terminal or emulator. Remote management is possible through Cabletron’s

SPECTRUM or any SNMP-compliant management tool. Included as management

features are the IETF Standard Management Information Base (MIBs) RMON

(RFC1271), IETF MIB II (RFC-1213), IETF Bridge MIB (RFC-1493), and a host of

other Cabletron enterprise MIBs. These modules also offer you a wide variety of

statistical network management information to enhance network planning and

troubleshooting. The 9E428-12/36 and 9E429-12/36 provide information for each

front panel Ethernet 10BASE-FL port, including packet counts along with errored

frame information such as collisions, CRCs, and Giants, via a variety of industry

standard and private MIBS. Industry standard IEEE 802.1d bridging, including

Spanning Tree Algorithm, is supported.

Connectivity

The 9E428-12/36 and 9E429-12/36 modules have one interface to the INB and

either 12 or 36 front port ST connectors. The INB interface is a ﬁxed connection to

INB-B that allows the 9E428 and 9E429 modules to communicate with other

SmartSwitch 9000 modules supporting various LAN technologies including:

Token Ring, FDDI, Ethernet, WAN and ATM. The 9E428-12/36 multimode ST

connectors provide 12 or 36 Ethernet 10BASE-FL connections, with links up to

2000 meters in length, when operating in half duplex. The 9E429-12/36 single

mode ST connectors provide 12 or 36 Ethernet 10BASE-FL connections, with links

up to 5000 meters in length, when operating in half duplex.

Standard Ethernet/Full Duplex Operation

The 9E428-12/36 and 9E429-12/36 modules support 10BASE-FL. The use of

10BASE-FL allows each port on the modules to be conﬁgured, through local and

or remote management (SNMP), to operate in standard Ethernet mode (simplex)

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Cambiar de Cabletron Systems

Cabletron Systems

Cabletron Systems 924TX Instrucciones de funcionamiento y mantenimiento

Cabletron Systems

Cabletron Systems SEHI-22FL Manual de usuario

Cabletron Systems

Cabletron Systems SMALL OFFICE CyberSwitch 150 Manual de usuario

Cabletron Systems

Cabletron Systems SmartSTACK ELS10-27TX Manual del propietario

Cabletron Systems

Cabletron Systems MMAC-Plus 9H531-18 Manual de usuario

Cabletron Systems

Cabletron Systems CyberSWITCH CSX150 Manual de usuario

Cabletron Systems

Cabletron Systems Cabletron CyberSWITCH CSX5500 Manual de usuario

Cabletron Systems

Cabletron Systems 7F06-02 FDDI SmartSwitch Manual de usuario

Cabletron Systems

Cabletron Systems SEH-24 Manual de usuario

Cabletron Systems

Cabletron Systems SmartSwitch 6500 Manual de usuario

Cabletron Systems

Cabletron Systems 9A656-04 Instrucciones de instalación y funcionamiento

Cabletron Systems

Cabletron Systems VNswitch 900GV Instrucciones de funcionamiento y mantenimiento

Cabletron Systems

Cabletron Systems FPIM 02 FPIM-02 Manual de usuario

Cabletron Systems

Cabletron Systems MMAC-Plus 9G426-02 Manual de usuario

Cabletron Systems

Cabletron Systems IA1100 Instrucciones de montaje

Cabletron Systems

Cabletron Systems TSX-1620 Manual de usuario

Cabletron Systems

Cabletron Systems SmartCell 6A000 Manual de usuario

Cabletron Systems

Cabletron Systems 6H122-16 Manual de usuario

Cabletron Systems

Cabletron Systems SmartSwitch 6500 Manual de usuario

Cabletron Systems

Cabletron Systems 2H23-50R Manual de usuario

Cabletron Systems

Cabletron Systems MRX Manual de usuario

Cabletron Systems

Cabletron Systems 9E423-36 Manual de usuario

Cabletron Systems

Cabletron Systems SmartSwitch 6500 Manual de usuario

Cabletron Systems

Cabletron Systems SmartSTACK ELS10-27MDU Instrucciones de instalación y funcionamiento

Manuales populares de Cambiar de otras marcas

URC

URC Total Control MFS-8 Manual de usuario

Azbil

Azbil HPQ-D11 Manual de usuario

Sony

Sony DFS-900M Manual de usuario

SICK

SICK i17S Manual de usuario

F&F

F&F SZR-277 Manual de usuario

Shure

Shure UAMS/BK Manual de usuario

Dräger

Dräger X-zone Switch Off Manual de usuario

Asco

Asco Joucomatic 349 Series Manual de usuario

BT Mini Hub Manual de usuario

D-Link

D-Link DES-1226G Manual de usuario

Johnson Controls

Johnson Controls FS80-C Manual de usuario

Alcatel-Lucent

Alcatel-Lucent 7450 ESS-12 Manual de usuario

MicroNet

MicroNet SP1200A Manual de usuario

Ruijie

Ruijie RG-PF2920 Series Manual de instalación y funcionamiento

Altinex

Altinex DA1914SX Manual de usuario

MiLAN

MiLAN MIL-SM2401M Manual de usuario

RJM

RJM MASTERMIND PBC/6X Manual de usuario

Atlas

Atlas MMK-KVM8 Manual de usuario
