Cabletron Systems 7C03 MMAC SmartSWITCH Manual de usuario

7C03 MMAC SmartSWITCH

™

Installation Guide

9031699-01

Notice

NOTICE

Cabletron Systems reserves the right to make changes in

speciﬁcations and other information contained in this document

without prior notice. The reader should in all cases consult

Cabletron Systems to determine whether any such changes have

been made.

The hardware, ﬁrmware, or software described in this manual is

subject to change without notice.

In no event shall Cabletron Systems be liable for any incidental,

indirect, special, or consequential damages whatsoever (including

but not limited to lost proﬁts) arising out of or related to this

manual or the information contained in it, even if Cabletron

Systems has been advised of, known, or should have known, the

possibility of such damages.

Cabletron Systems, Inc.

35 Industrial Way

Rochester, NH 03867-0505

Printed in the United States of America

Order Number: 9031699-01

MMAC

is a registered trademark of Cabletron Systems, Inc.

MMAC SmartSWITCH, MMAC-M5FNB, and MMAC-M8FNB

are trademarks of

Cabletron Systems, Inc.

Ethernet

is a trademark of Xerox Corp.

CompuServe

is a registered trademark of CompuServe Inc.

i960 microprocessor

is a registered trademark of Intel Corp.

Notice

FCC NOTICE

This device complies with Part 15 of the FCC rules. Operation is

subject to the following two conditions: (1) this device may not

cause harmful interference, and (2) this device must accept any

interference received, including interference that may cause

undesired operation.

NOTE:

This equipment has been tested and found to comply with

the limits for a Class A digital device, pursuant to Part 15 of the

FCC rules. These limits are designed to provide reasonable

protection against harmful interference when the equipment is

operated in a commercial environment. This equipment uses,

generates, and can radiate radio frequency energy and if not

installed in accordance with the operator’s manual, may cause

harmful interference to radio communications. Operation of this

equipment in a residential area is likely to cause interference in

which case the user will be required to correct the interference at

his own expense.

WARNING:

Changes or modiﬁcations made to this device which

are not expressly approved by the party responsible for

compliance could void the user’s authority to operate the

equipment.

DOC NOTICE

This digital apparatus does not exceed the Class A limits for radio

noise emissions from digital apparatus set out in the Radio

Interference Regulations of the Canadian Department of

Communications.

Le présent appareil numérique n’émet pas de bruits

radioélectriques dépassant les limites applicables aux appareils

numériques de la class A prescrites dans le Règlement sur le

brouillage radioélectrique édicté par le ministère des

Communications du Canada.

Notice

iii

VCCI NOTICE

This equipment is in the 1st Class Category (information

equipment to be used in commercial and/or industrial areas) and

conforms to the standards set by the Voluntary Control Council for

Interference (VCCI) by Information Technology Equipment aimed

at preventing radio interference in commercial and/or industrial

areas.

Consequently, when used in a residential area or in an adjacent

area thereto, radio interference may be caused to radios and TV

receivers, etc.

Read the instructions for correct handling.

Notice

DECLARATION OF CONFORMITY

Application of Council Directive(s):

89/336/EEC

73/23/EEC

Manufacturer’s Name:

Cabletron Systems, Inc.

Manufacturer’s Address:

35 Industrial Way

PO Box 5005

Rochester, NH 03886-5005

European Representative Name:

Mr. J. Solari

European Representative Address:

Cabletron Systems Limited

Nexus House, Newbury Business Park

London Road, Newbury

Berkshire RG13 2PZ, England

Conformance to Directive(s)/Product Standards:

EC Directive 89/336/EEC

EC Directive 73/23/EEC

EN55022

EN 50082-1

EN 60950

Equipment Type/Environment:

Networking Equipment, for use in a

Commercial or Light

Industrial

Environment.

We the undersigned, hereby declare that the equipment packaged with this notice

conforms to the above directives.

Manufacturer Legal Representative in Europe

Mr. Richard Michaud Mr. J. Solari

___________________________________ ___________________________________

Full Name Full Name

Manager of Engineering Services Managing Director - E.M.E.A.

___________________________________ ___________________________________

Title Title

Rochester, NH, USA Newbury, Berkshire, England

___________________________________ ___________________________________

Location Location

CONTENTS

CHAPTER 1 INTRODUCTION

1.1 USING THIS MANUAL .........................................................................1-1

1.2 USING THE SMARTSWITCH MANUAL SET ...................................1-1

1.3 7C03 MMAC SMARTSWITCH OVERVIEW .......................................1-2

1.3.1 7X00 SmartSwitch Controller Module........................................1-4

1.3.2 SmartSwitch interface modules ...................................................1-4

1.3.3 Operations.......................................................................................1-5

1.4 RELATED MANUALS............................................................................1-6

1.5 GETTING HELP.......................................................................................1-6

CHAPTER 2 INSTALLATION

2.1 UNPACKING THE 7C03 MMAC SMARTSWITCH ..........................2-1

2.2 INSTALLING THE 7C03 MMAC SMARTSWITCH...........................2-2

CHAPTER 3 TECHNICAL SPECIFICATIONS

3.1 SERVICE....................................................................................................3-1

3.2 PHYSICAL ................................................................................................3-1

3.2.1 Dimensions .....................................................................................3-1

3.2.2 Weight .............................................................................................3-1

3.3 ENVIRONMENTAL................................................................................3-1

1-1

CHAPTER 1

INTRODUCTION

Welcome to Cabletron Systems

7C03 MMAC SmartSwitch

Installation Guide

. This manual is a simple installation and reference

guide. The 7C03 MMAC SmartSwitch is a unique self-contained

module that can be placed into an MMAC series chassis

1.1 USING THIS MANUAL

Chapter 1,

Introduction

, discusses the features of the 7C03

MMAC SmartSwitch.

Chapter 2,

Installation

, explains the process of inserting the 7C03

MMAC SmartSwitch in an MMAC chassis.

Chapter 3,

Technical Specifications

, explains the physical and

operational speciﬁcations for the 7C03 MMAC SmartSwitch.

1.2 USING THE SMARTSWITCH MANUAL SET

Each SmartSwitch interface module that can be inserted in the

7C03 MMAC SmartSwitch is shipped with a module user’s guide.

For example, the

7E03-24 Ethernet SmartSwitch Interface Module

User’s Guide

explains the physical characteristics, speciﬁcations,

and installation procedures of the 7E03-24 Module.

The management module of the 7C03 MMAC SmartSwitch is

described in the

7X00 SmartSwitch Controller Module User’s Guide.

The user’s guide explains the 7X00 Module’s physical

characteristics, installation procedures, and how to locally manage

the SmartSwitch interface modules in the chassis.

Refer to Chapter 2 of this installation guide for information and

considerations regarding the placement of a 7C03 MMAC SmartSwitch in

an MMAC series chassis.

1-2

Introduction

In addition, any local management information that is speciﬁc to a

particular SmartSwitch interface module is described in a module

speciﬁc local management appendix. For example, the

7E03-24

Ethernet SmartSwitch Interface Module Local Management Appendix

explains information that is speciﬁc to local management of the

7E03-24 Module only.

1.3 7C03 MMAC SMARTSWITCH OVERVIEW

The 7C03 MMAC SmartSwitch (Figure 1-1) is a metal enclosure

that can be placed into two module slots of an MMAC chassis. The

7C03 MMAC SmartSwitch attaches to the MMAC chassis’ power

bus, but does not attach to the data channels on the chassis’

backplane. The 7C03 MMAC SmartSwitch can be installed or

removed from the MMAC chassis at any time without affecting the

operation of the rest of the network.

The 7C03 MMAC SmartSwitch has three module slots. The left-

most slot (slot one) is reserved for the 7X00 SmartSwitch Controller

Module, a management module that contains a Smart Switching

engine. The other two slots can support any combination of

Ethernet, Token Ring, FDDI, and ATM SmartSwitch interface

module

Spanning the rear wall of the 7C03 MMAC SmartSwitch is the

SmartSwitch Bus. All modules that are inserted into the 7C03

MMAC SmartSwitch connect to the SmartSwitch Bus. All

communication between modules within the 7C03 MMAC

SmartSwitch is achieved via the SmartSwitch Bus.

All data and management information from SmartSwitch interface

modules within the 7C03 MMAC SmartSwitch is relayed along the

SmartSwitch Bus to the 7X00 Module. All switching functions are

performed by the 7X00 Module. Thus, within the conﬁnes of the

7C03 MMAC SmartSwitch, data can be freely transmitted

regardless of front panel technology. With no external bridges or

routers, the transfer of data from one point to another within the

7C03 MMAC SmartSwitch is virtually direct.

Introduction

1-3

Figure 1-1. 7C03 MMAC SmartSwitch

Because the 7C03 MMAC SmartSwitch does not attach to the data

channels on the backplane of an MMAC chassis, data can not be

transmitted

internally

from SmartSwitch interface modules to the

other modules in the MMAC chassis. However, data can be

transmitted

externally

from SmartSwitch interface modules to any

other destination (in the same chassis or elsewhere) via

connections to the front panel of any SmartSwitch interface

module.

PWR

MAC ADR A

7F00

7X00

7E03-24

CPU

1-4

Introduction

1.3.1 7X00 SmartSwitch Controller Module

The 7X00 SmartSwitch Controller Module is the only processing

and management element in the 7C03 MMAC SmartSwitch. The

7X00 Module has no front panel data ports. All data enters and

exits the 7X00 Module via the SmartSwitch Bus on the 7C03

MMAC SmartSwitch’s backplane. The 7X00 Module directs

incoming data to its intended destination by using a group of

Application Speciﬁc Integrated Circuits (ASICs) collectively

known as the SmartSwitch Core. All packet switching functions

are performed in the module’s SmartSwitch Core. The

SmartSwitch Core is capable of switching up to 750,000 frames per

second. The ﬁrmware on a 7X00 Module determines the

SmartSwitch Core’s operating mode (traditional switch or

SecureFast Packet Switch). The module’s CPU (an i960

microprocessor

) is used to collect management data of the

SmartSwitch system.

Note:

The 7X00 Module is not hot-swappable. Because the 7X00

Module is the only processing/management module in the 7C03

MMAC SmartSwitch, removing the 7X00 Module will sever

communications to all

SmartSwitch interface modules in the

7C03 MMAC SmartSwitch.

1.3.2 SmartSwitch interface modules

SmartSwitch interface modules in a 7C03 MMAC SmartSwitch

communicate freely with each other via the 7C03’s SmartSwitch

Bus and 7X00 SmartSwitch Controller Module. SmartSwitch

interface modules can be installed or removed from the 7C03

MMAC SmartSwitch at any time without impacting the rest of the

network.

Otros manuales para 7C03 MMAC SmartSWITCH

Tabla de contenidos

Otros manuales de Cambiar de Cabletron Systems

Cabletron Systems

Cabletron Systems SmartSTACK ELS100-8TXUF2 Manual de usuario

Cabletron Systems

Cabletron Systems 9A426-01 Documento técnico

Cabletron Systems

Cabletron Systems ELS10-26TX Manual de usuario

Cabletron Systems

Cabletron Systems SmartCell 6A000 Manual de usuario

Cabletron Systems

Cabletron Systems SmartSwitch 9000 Documento técnico

Cabletron Systems

Cabletron Systems KBU 64 Manual de usuario

Cabletron Systems

Cabletron Systems FN10 Manual de usuario

Cabletron Systems

Cabletron Systems MMAC-Plus 9G426-02 Manual de usuario

Cabletron Systems

Cabletron Systems SmartSTACK ELS10-27MDU Instrucciones de instalación y funcionamiento

Cabletron Systems

Cabletron Systems FN100 Manual de usuario

Cabletron Systems

Cabletron Systems SmartSTACK ELS10-27TX Manual del propietario

Cabletron Systems

Cabletron Systems MMAC-Plus 9E312-12 Documento técnico

Cabletron Systems

Cabletron Systems SmartSTACK ELH100 Manual de usuario

Cabletron Systems

Cabletron Systems MMAC-Plus 9M426-02 Manual de usuario

Cabletron Systems

Cabletron Systems 9F426-02 Manual de usuario

Cabletron Systems

Cabletron Systems SmartSTACK ELS100-24TXG Manual de instrucciones

Cabletron Systems

Cabletron Systems MRX Manual de usuario

Cabletron Systems

Cabletron Systems SmartSTACK ELS100-S24TX2M Manual de usuario

Cabletron Systems

Cabletron Systems MMAC-Plus 9G426-02 Manual de usuario

Cabletron Systems

Cabletron Systems SmartSwitch 2H22 Manual del propietario

Cabletron Systems

Cabletron Systems ATX Manual de usuario

Cabletron Systems

Cabletron Systems SmartSwitch 1800 Manual de usuario

Cabletron Systems

Cabletron Systems SmartSTACK 100 ELS100-24TX Instrucciones de instalación y funcionamiento

Cabletron Systems

Cabletron Systems FlowPoint 2100 12 Manual de usuario

Manuales populares de Cambiar de otras marcas

URC

URC Total Control MFS-8 Manual de usuario

Azbil

Azbil HPQ-D11 Manual de usuario

Sony

Sony DFS-900M Manual de usuario

SICK

SICK i17S Manual de usuario

F&F

F&F SZR-277 Manual de usuario

Shure

Shure UAMS/BK Manual de usuario

Dräger

Dräger X-zone Switch Off Manual de usuario

Asco

Asco Joucomatic 349 Series Manual de usuario

BT Mini Hub Manual de usuario

D-Link

D-Link DES-1226G Manual de usuario

Johnson Controls

Johnson Controls FS80-C Manual de usuario

Alcatel-Lucent

Alcatel-Lucent 7450 ESS-12 Manual de usuario

MicroNet

MicroNet SP1200A Manual de usuario

Ruijie

Ruijie RG-PF2920 Series Manual de instalación y funcionamiento

Altinex

Altinex DA1914SX Manual de usuario

MiLAN

MiLAN MIL-SM2401M Manual de usuario

RJM

RJM MASTERMIND PBC/6X Manual de usuario

Atlas

Atlas MMK-KVM8 Manual de usuario
