Local Management Appendix

Appendix

9F206-02 Module

Speciﬁc Information

Introduction

This appendix contains local management information that is speciÞc to the

9F206-02 FDDI Repeater Module.

The 9F206-02 FDDI Repeater Module physically attaches to the FNB-1 and the

FNB-2 on the SmartSwitch 9000Õs FNB backplane. By default, the module inserts

into four rings (the primary and secondary rings of the FNB-1 and the FNB-2).

The 9F206-02 ConÞguration Screen allows you to customize this conÞguration to

your particular needs. The default values that appear on this screen are

determined by the moduleÕs DIP switches. (For more information on setting this

moduleÕs DIP switches, refer to the

SmartSwitch 9000 9F206-02 FDDI Repeater

MicroLAN Module UserÕs Guide

The 9F206-02 ConÞguration Screen allows you to:

¥ Establish whether the moduleÕs two FDDI-1 front panel connections will insert

into the backplaneÕs FNB-1 (primary and secondary) rings or bypass the FNB-1

rings (see Figure 1).

¥ Establish whether the moduleÕs two FDDI-2 front panel connections will insert

into the backplaneÕs FNB-2 (primary and secondary) rings or bypass the FNB-2

rings (see Figure 1).

The terms ÒInsertedÓ and ÒBypassedÓ refer to relays that are located on the

module. Inserted causes a relay to connect the moduleÕs speciÞc front panel

connections to the selected ring. Bypassed causes a relay to disconnect the

moduleÕs speciÞc front panel connections from the selected ring.

9F206-02 Module Speciﬁc Information

Figure 1. Front Panel Connections “Inserted” and “Bypassed”

The 9F206-02 ConÞguration Screen (Figure 2), displays the current conÞguration

of the moduleÕs front panel connections in relation to the FNB rings on the

SmartSwitch 9000 backplane, and allows you to change the conÞguration.

FDDI-1

FDDI-2

Front Panel

Connections

Backplane

FNB-1

FNB-2

FDDI-1

FDDI-2

Front Panel

Connections

FNB-1

FNB-2

Inserted

Bypassed

Inserted

Backplane

9F206-02 Module Speciﬁc Information

The 9F206-02 Conﬁguration Screen

The 9F206-02 ConÞguration Screen (Figure 2), displays conÞguration and status

information about the 9F206-02 Module.

Figure 2. 9F206-02 Conﬁguration Screen

SMARTSWITCH 9000 LOCAL MANAGEMENT

9F206-02 CONFIGURATION

Module Name: 9F206-02 Firmware Revision: 02.00.01

Slot Number: 12 BOOTPROM Revision: 01.01.02

FNB-1 Status: Wrap-A DAS-1 Status: Dual Homed

Port A Status: Link Port A Status: Link, A-M

Port B Status: Link Port B Status: Link, B-M

External Path: Primary Port A Type: FPIM-00

Configuration: Inserted Port B Type: FPIM-00

FNB-2 Status: Wrap-A DAS-2 Status: Isolated

Port A Status: Link Port A Status: No Link

Port B Status: Link Port B Status: No Link

External Path: Primary Port A Type: FPIM-00

Configuration: Inserted Port B Type: FPIM-00

SAVE RETURN

9F206-02 Module Speciﬁc Information

9F206-02 Conﬁguration Screen Fields

The following information brießy explains each 9F206-02 ConÞguration Screen

Þeld.

FNB-1 Status

(Toggle)

Allows you to control whether or not the moduleÕs FDDI-1 front panel ports will

connect (insert) to the backplaneÕs FNB-1 rings (see Figure 1).

¥ When set to Inserted, the moduleÕs FDDI-1 (A and B) ports insert directly into

the backplaneÕs FNB-1 primary and secondary rings.

¥ When set to Bypassed, the moduleÕs FDDI-1 (A and B) ports do not connect to

the backplane. Therefore, no communications between the FDDI-1 front panel

ports and the backplane can occur.

(FNB-1) Port A Status

Indicates whether there is a link or no link between the moduleÕs FDDI-1 A port

and the backplaneÕs FNB-1.

(FNB-1) Port B Status

Indicates whether there is a link or no link between the moduleÕs FDDI-1 B port

and the backplaneÕs FNB-1.

(FNB-1) External Path

(Toggle)

Indicates the speciÞc ring of the backplaneÕs FNB-1 that extends out to traverse

the moduleÕs FDDI-1 front panel A and B ports. You can change the value in this

Þeld from Primary to Secondary. A third value (Isolated) appears in this Þeld

whenever the module is not inserted into the FNB-1 (i.e., when the value in the

FNB-1 Status Þeld is ÒBypassedÓ).

(FNB-1) Conﬁguration

Indicates one of the following:

¥ FNB-1 is inserted (ÒInsertedÓ) on the backplane ring.

¥ FNB-1 is isolated (ÒBypassedÓ) from the backplane ring.

DAS-1 Status

Indicates the status of DAS-1:

¥ Dual Homed

¥ Isolated

¥ Thru

¥ Twisted

¥ Wrapped

9F206-02 Module Speciﬁc Information

(DAS-1) Port A Status

Displays the status (Link or No-Link) and the connection type (A-A, A-B, or A-M)

of the moduleÕs FDDI-1 front panel A port. The value ÒLinkÓ indicates that an

operating workstation is connected to the moduleÕs FDDI-1 front panel A port.

(DAS-1) Port B Status

Displays the status (Link or No-Link) and the connection type (A-B, B-B, B-M) of

the moduleÕs FDDI-1 front panel B port. The value ÒLinkÓ indicates that an

operating workstation is connected to the moduleÕs FDDI-1 front panel B port.

(DAS-1) Port AType

IdentiÞes the type of FDDI Port Interface Module (FPIM) that is installed in the

moduleÕs FDDI-1 front panel A port.

(DAS-1) Port BType

IdentiÞes the type of FDDI Port Interface Module (FPIM) that is installed in the

moduleÕs FDDI-1 front panel B port.

FNB-2 Status

(Toggle)

Allows you to control whether or not the moduleÕs FDDI-2 front panel ports will

connect (insert) to the backplaneÕs FNB-2 rings (see Figure 1).

¥ When set to Inserted, the moduleÕs FDDI-2 (A and B) ports insert directly into

the backplaneÕs FNB-2 primary and secondary rings.

¥ When set to Bypassed, the moduleÕs FDDI-2 (A and B) ports do not connect to

the backplane. Therefore, no communications between the FDDI-2 front panel

ports and the backplane can occur.

(FNB-2) Port A Status

Indicates whether there is a link or no link between the moduleÕs FDDI-2 A port

and the backplaneÕs FNB-2.

(FNB-2) Port B Status

Indicates whether there is a link or no link between the moduleÕs FDDI-2 B port

and the backplaneÕs FNB-2.

(FNB-2) External Path

(Toggle)

Indicates the speciÞc ring of the backplaneÕs FNB-2 that extends out to traverse

the moduleÕs FDDI-2 front panel A and B ports. You can change the value in this

Þeld from Primary to Secondary. A third value (Isolated) appears in this Þeld

whenever the module is not inserted into the FNB-2 (i.e., when the value in the

FNB-2 Status Þeld is ÒBypassedÓ).

9F206-02 Module Speciﬁc Information

(FNB-2) Conﬁguration

Indicates one of the following:

¥ FNB-2 is inserted (ÒInsertedÓ) on the backplane ring.

¥ FNB-2 is isolated (ÒBypassedÓ) from the backplane ring.

DAS-2 Status

Indicates the status of DAS-2:

¥ Dual Homed

¥ Isolated

¥ Thru

¥ Twisted

¥ Wrapped

(DAS-2) Port A Status

Displays the status (Link or No-Link) and the connection type (A-A, A-B, A-M) of

the moduleÕs FDDI-2 front panel A port. The value ÒLinkÓ indicates that an

operating workstation is connected to the moduleÕs FDDI-2 front panel A port.

(DAS-2) Port B Status

Displays the status (Link or No-Link) and the connection type (A-B, B-B, B-M) of

the moduleÕs FDDI-2 front panel B port. The value ÒLinkÓ indicates that an

operating workstation is connected to the moduleÕs FDDI-2 front panel B port.

(DAS-2) Port AType

IdentiÞes the type of FDDI Port Interface Module (FPIM) that is installed in the

moduleÕs FDDI-2 front panel A port.

(DAS-2) Port BType

IdentiÞes the type of FDDI Port Interface Module (FPIM) that is installed in the

moduleÕs FDDI-2 front panel B port.

Toggling Screen Fields

To toggle screen Þelds:

1. Use the arrow keys to highlight the particular value in the Þeld that you want

to change.

2. Press the

Space Bar

to toggle the value (for example, Inserted will toggle to

Bypassed).

9F206-02 Module Speciﬁc Information

3. Use the arrow keys to highlight

SAVE

at the bottom of the screen, and then

press the

Return

key.

When the message ÒSAVED OKÓ appears, the edits you have made are saved.

If you exit without saving, the message ÒNOT SAVED -- PRESS SAVE TO

KEEP CHANGESÓ appears. If you proceed to exit without saving, your edits

will be lost.

4. Exit the screen by using the arrow keys to highlight

RETURN

, and then

pressing the

Return

key.
