• Read this User’s Guide before you start using your P-touch.

• Keep this User’s Guide in a handy place for future reference.

USER’S GUIDE

9600/36009600/3600

PREFACE

Thank you for purchasing this P-touch!

With your new P-touch, you can create labels for any purpose. Select from a variety of frames, fonts

and character styles to design beautiful custom labels. In addition, the many pre-formatted templates

available make label-making quick and easy.

You can print professional-looking labels in no time. The quality and performance of this P-touch

make it an extremely practical machine to meet all your labelling needs.

Although this P-touch is easy to use, we suggest that you read this User’s Guide carefully before

starting. Keep this manual nearby for future reference.

NOTE

The P-touch will make a noise when it is turned on or while it is printing; however, this does not indicate a

malfunction.

Declaration of Conformity

We BROTHER INDUSTRIES, LTD.

1-1-1, Kawagishi, Mizuho-ku,

Nagoya 467-8562, Japan

declare that the Labelling System PT-9600/3600 conforms with the following normative documents:

EMC: EN 55022:1998 Class B

EN 55024:1998

EN 61000-3-2:1995

EN 61000-3-3:1995

and follows the provisions of the Electromagnetic Compatibility Directive 89/336/EEC (as amended by 91/

263/EEC and 92/31/EEC). The AC adapter also conforms with EN 60950 and follows the provisions of the

Low Voltage Directive 73/23/EEC.

Issued by: BROTHER INDUSTRIES, LTD.

P & H company

Development DIV.

QUICK REFERENCE

Entering text

Adding a space Space bar

Entering/Exiting Insert

mode i

Adding an uppercase

letter hor t+ desired character

Adding a series of

uppercase letters (enter-

ing Caps mode) c→Type character

Adding a lowercase let-

ter in Caps mode hor t+ desired character

Adding an accented

character a→Type character

d+ s→Type letter (OR n) →mor gto select letter →

Rotate r(OR jor k) to select →Press r(OR n)

:or l+ Type letter

Adding a symbol Rotate rto select SYMBOL, then press r(OR just press s) →

Rotate r(OR mor g) to select category →Rotate r(OR jor k)

to select symbol →n

Adding a new line n

Adding a new block d+ n

Adding a barcode Rotate rto select BARCODE, then press r(OR just press d+ i)

→Type barcode data →Press r(OR n)

Adding a special char-

acter to the barcode

Rotate rto select BARCODE, then press r(OR just press d+ i)

→s→mor gto select special character →n

Changing a barcode

parameter

Rotate rto select BARCODE, then press r(OR just press d+ i)

→m→ jor kto select parameter →Rotate r(OR mor g) to

select setting → Press r(OR n)

Setting up the Euro con-

version function

Rotate rto select CONVERSION SETUP, then press r(OR just press

d+ h) →Rotate r(OR mor g) to select currency →Press

r(OR n) →Type in exchange rate →Press r(OR n) →Rotate

r(OR mor g) to select separator →Press r(OR n) →Rotate r

(OR mor g) to select printing order →Press r(OR n)

Converting euros to/

from other currencies d+ 7→Rotate r(OR jor k) to select conversion direction

→Type in value to be converted →Press r(OR n)

Editing text

Deleting text bOR q

Deleting one line of text d+ q

Clearing all of the text

and formats d+ b → mor gto select TEXT & FORMAT → n

Clearing only the text d+ b → mor gto select TEXT ONLY → n

Formatting text

Changing formats for

entire text

Rotate rto select

GLOBAL FORMAT

, then press r(OR just press d+

→

Rotate r, then press r(OR jor k) to

select function

→

Rotate

r, then press r(OR mor g) to

select setting

→ Press r(OR n)

Changing formats for a

block of text j, k, mor gto select text block →Rotate rto select BLOCK

FORMAT, then press r(OR just press d+ 2) →Rotate r, then

press r(OR jor k) to select function →Rotate r, then press r

(OR mor g) to select setting → Press r(OR n)

Changing formats for a

line of text j, k, mor gto select text line →Rotate rto select LINE FOR-

MAT, then press r(OR just press d+ 3) →Rotate r, then press

r(OR jor k) to select function →Rotate r, then press r(OR m

or g) to select setting → Press r(OR n)

Changing the font Select GLOBAL FORMAT, BLOCK FORMAT or LINE FORMAT, then

press r(OR just press d+ 1, 2or 3) →Rotate r, then press

r(OR jor k) to select FONT →Rotate r(OR mor g) to select

setting → Press r(OR n)

Changing the character

size

Select GLOBAL FORMAT, BLOCK FORMAT or LINE FORMAT, then

press r(OR just press d+ 1, 2or 3) →Rotate r, then press

r(OR jor k) to select SIZE →Rotate r(OR mor g) to select

setting → Press r(OR n)

Changing the character

width

Select GLOBAL FORMAT, BLOCK FORMAT or LINE FORMAT, then

press r(OR just press d+ 1, 2or 3) →Rotate r, then press

r(OR jor k) to select WIDTH →Rotate r(OR mor g) to

select setting → Press r(OR n)

Changing the character

style

Select GLOBAL FORMAT, BLOCK FORMAT or LINE FORMAT, then

press r(OR just press d+ 1, 2or 3) →Rotate r, then press

r(OR jor k) to select STYLE1 or STYLE2 →Rotate r(OR mor

g) to select setting → Press r(OR n)

Changing the line effects Select GLOBAL FORMAT, BLOCK FORMAT or LINE FORMAT, then

press r(OR just press d+ 1, 2or 3) →Rotate r, then press

r(OR jor k) to select LINE EFFECTS →Rotate r(OR mor g)

to select setting → Press r(OR n)

Changing the frame Select GLOBAL FORMAT, BLOCK FORMAT or LINE FORMAT, then

press r(OR just press d+ 1, 2or 3) →Rotate r, then press

r(OR jor k) to select FRAME →Rotate r(OR mor g) to

select setting → Press r(OR n)

Changing the text align-

ment

Select GLOBAL FORMAT, BLOCK FORMAT or LINE FORMAT, then

press r(OR just press d+ 1, 2or 3) →Rotate r, then press

r(OR jor k) to select ALIGNMENT →Rotate r(OR mor g) to

select setting → Press r(OR n)

Changing the label mar-

gins

Select

GLOBAL FORMAT

, then press

(OR just press

)

→

Rotate

, then press

(OR

) to

select

T. MARGIN →

Rotate

(OR

) to

select setting

→

Press

(OR

)

Changing the label

length

Select

GLOBAL FORMAT

, then press

(OR just press

)

→

Rotate

, then press

(OR

) to

select

T. LENGTH

→

Rotate

(OR

) to

select setting

→

Press

(OR

)

Changing the block

margins Select GLOBAL FORMAT, then press r(OR just press d+ 1

)

→

Rotate r, then press r(OR jor k) to select B. MARGIN →Rotate

r(OR mor g) to select setting → Press r(OR n)

Changing the block

length

Select GLOBAL FORMAT or BLOCK FORMAT, then press r(OR just

press d+ 1or 2) →Rotate r, then press r(OR jor k) to

select B. LENGTH →Rotate r(OR mor g) to select setting → Press

r(OR n)

Printing in reverse (mir-

ror printing) Rotate rto select MIRROR, then press r(OR just press d+ p) →

Rotate r(OR mor g) to select setting → Press r(OR n)

Formatting text for a

stamp

d+ S→Rotate r(OR mor g) to select setting → Press r(OR

Rotating the text Select GLOBAL FORMAT or BLOCK FORMAT, then press r(OR just

press d+ 1or 2) →Rotate r, then press r(OR jor k) to

select ROTATE →Rotate r(OR mor g) to select setting → Press r

(OR n)

Using an Auto format template

Creating a label or

stamp from an Auto for-

mat template

Rotate rto select AUTO FORMAT, then press r(OR just press d

+ 6) →Rotate r(OR mor g) to select template → Press r(OR

n) → Type in each line of text, then press r(OR n) → Continue

with 1, 2, 3or 4

1Printing an Auto for-

mat template Rotate r(OR mor g) to select PRINT →Press r(OR n)

2Editing the Auto for-

mat template text Rotate r(OR mor g) to select CONTINUE →Press r(OR n)→

Type in each line of text, then press r(OR n)

3Changing the style of

the Auto format tem-

plate

Rotate r(OR mor g) to select CHANGE STYLE →Press r(OR

n)→Rotate r(OR mor g) to select format style →Press r(OR

4Quitting the Auto

format function Rotate r(OR mor g) to select FINISH →Press r(OR n)→Press

r(OR n)

Printing text

Previewing the label Rotate rto select LAYOUT PREVIEW, then press r(OR just press

d+ 9) (jor kto scroll)

Changing how the

labels are cut Rotate rto select AUTO CUT, then press r(OR just press d+ f)

→Rotate r(OR mor g) to select setting → Press r(OR n)

Printing using the cur-

rent print options p

Feeding and cutting

24 mm of tape f

Printing many copies Rotate rto select REPEAT, then press r(OR just press d+ 4) →

Rotate r(OR mor g) to select number (OR type number) → Press

r(OR n)

Printing many copies

while increasing

selected text

Rotate

to select

NUMBER

, then press

(OR just press

)

→

to select start of numbering field

→

Press

(OR

)

→

to select end of numbering field

→

Press

(OR

)

→

Rotate

(OR

)

to select (or type) number

→

Press

(OR

)

Storing, recalling, deleting & printing text files

Saving a file Rotate rto select MEMORY, then press r(OR just press d+ 8)

→Rotate r(OR mor g) to select STORE → Press r(OR n) →

Rotate r(OR mor g) to select file number → Type file name →

Press r(OR n)

Recalling a previously

saved file Rotate rto select MEMORY, then press r(OR just press d+ 8)

→Rotate r(OR mor g) to select RECALL → Press r(OR n) →

Rotate r(OR mor g) to select file number → Press r(OR n)

Deleting a previously

saved file Rotate rto select MEMORY, then press r(OR just press d+ 8)

→Rotate r(OR mor g) to select CLEAR → Press r(OR n) →

Rotate r(OR mor g) to select file number →Space bar so !

appears → Press r(OR n) → Press r(OR n)

Printing a previously

saved text file Rotate rto select MEMORY, then press r(OR just press d+ 8)

→Rotate r(OR mor g) to select PRINT → Press r(OR n) →

Rotate r(OR mor g) to select file number →Space bar so !

appears → Press r(OR n)

CONTENTS

Chapter 1

Before You Start ...................................................... 1

GENERAL DESCRIPTION .............................................................2

Top view .............................................................................................................. 2

Bottom view ........................................................................................................ 3

LCD display ........................................................................................................ 3

Keyboard ............................................................................................................. 4

Carrying case ...................................................................................................... 5

Chapter 2

Getting Started ........................................................ 7

PRECAUTIONS ............................................................................8

Connecting the AC adapter ................................................................................ 9

Turning on/off the P-touch .................................................................................. 9

Installing/replacing a tape cassette .................................................................... 9

Connecting the P-touch to a computer ............................................................. 10

Installing the Software & Printer Driver .......................................................... 11

Reading the User’s Guide ................................................................................. 27

Using P-touch Editor 3.2 .................................................................................. 28

Using P-touch Quick Editor ............................................................................. 30

Uninstalling the Software & Printer Driver ..................................................... 33

Attaching labels ................................................................................................ 36

Assembling stamps ............................................................................................ 37

Chapter 3

Functions .............................................................. 41

Performing basic operations ............................................................................ 42

Entering text ...................................................................................................... 44

Editing text ........................................................................................................ 51

Formatting ........................................................................................................ 52

Printing ............................................................................................................. 68

Storing and recalling files ................................................................................ 71

Chapter 4

Machine Adjustments ........................................... 79

Machine adjustments .........................................................................................80

ERROR MESSAGE LIST .............................................................. 83

TROUBLESHOOTING ............................................................... 89

MACHINE SPECIFICATIONS ..................................................... 93

Appendix .............................................................. 95

Symbols ..............................................................................................................96

Special barcode characters ...............................................................................99

Fonts ..................................................................................................................99

Sizes and widths ...............................................................................................100

Type styles .......................................................................................................102

Framing and shading patterns ........................................................................104

Pre-set templates .............................................................................................105

Template text styles .........................................................................................108

INDEX ..................................................................................... 109

ACCESSORIES .......................................................................... 113

Otros manuales para P-Touch 3600

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Etiquetadora de Brother

Brother

Brother P-Touch PT-12 Manual de usuario

Brother

Brother QL-1100c Manual de usuario

Brother

Brother PT-1160 Martha By Mail Manual de usuario

Brother

Brother PT-1230PC - P-Touch 1230PC B/W Thermal Transfer... Guía de inicio rápido

Brother

Brother E-100 Manual de usuario

Brother

Brother P-Touch 1800 Manual de usuario

Brother

Brother P-touch PT-1290 Manual de usuario

Brother

Brother P-touch PT-D410 Manual de usuario

Brother

Brother P-touch 2600 Manual de usuario

Brother

Brother PT7100 - P-Touch B/W Thermal Transfer... Manual de usuario

Brother

Brother P-touch PT-9400 Manual de usuario

Brother

Brother QL-810W Manual de usuario

Brother

Brother PT-P750W Manual de usuario

Brother

Brother P-Touch PT-55BM Manual de usuario

Brother

Brother P-touch PRO DX PT-9200DX Manual de usuario

Brother

Brother P-Touch 580C Manual de usuario

Brother

Brother VC-500W Manual de usuario

Brother

Brother PT-520 Manual de usuario

Brother

Brother P-touch QL-1050N Guía de configuración

Brother

Brother P-touch PT-80 Manual de usuario

Brother

Brother P-Touch PT-D200 Manual de usuario

Brother

Brother QL-1110NWB Manual de usuario

Brother

Brother PT 1000 - P-Touch 1000 B/W Thermal Transfer... Manual de usuario

Brother

Brother P-Touch PT-1850 Manual de usuario

Manuales populares de Etiquetadora de otras marcas

newell

newell Dymo LabelManager 210D Manual de usuario

U-Line

U-Line BROTHER H-8754 Manual de usuario

Tharo Systems

Tharo Systems H-435+ Manual de usuario

Godex

Godex RT700 SERIES Manual de usuario

ID Technology

ID Technology 252 Manual de usuario

Labelmate

Labelmate MC-11 Manual de usuario

CAB

CAB XD4M/300 Manual de usuario

Avery Dennison

Avery Dennison Pathfinder 6057 Manual de servicio

TSC

TSC PEX1000 Series Manual de usuario

Adkins

Adkins Label Master Manual de usuario

Epson

Epson LabelWorks LW-400 Manual de usuario

Primera

Primera 510212 Manual de usuario

Brady

Brady BradyPrinter S3100 Manual de usuario

DuraLabel

DuraLabel LabPRO Manual de usuario

Novexx Solutions

Novexx Solutions XLP 604 Manual de usuario

Epson

Epson LabelWorks LW-400 Manual de usuario

Dymo

Dymo LabelManager 420P Manual de usuario

Epson

Epson LW-PX400 Manual de usuario
