Bristan Artisan Evo Instrucciones de montaje

Installation Instructions

and User Guide

Artisan Evo

Digital Electronic Mixer

Shower

Models covered: ARDE SHCCF W &

ARDE SHCCF B

Please keep this booklet for future

reference.

Installer, when you have read these

instructions please ensure you leave

them with the user.

Contents

2 Need help? Give us a call on 0844 701 6273 and speak to one of our trained advisers.

Welcome to your new Bristan Digital Electronic Mixer Shower, featuring a contemporary

design, wireless electronic controller and digital mixing unit.

Bristan’s Digital Electronic Mixer Shower has been designed to be easy to install and

use. It has also been designed and tested in the UK to all of the relevant British

Standards.

These instructions are for your guidance to a safe and successful installation, so please

read them thoroughly and retain for future reference.

We recommend the installation is carried out by a suitably qualiﬁed person and must

conform with current I.E.E Wiring Regulations (BS7671) and Building Regulations (Part

P and Part G).

Important Safety Information …………………………………………………..…………..

General Information ……………………………………………………………………………..

Pack Contents ……………………………………………………………………………..……….

Tools Required …………………………………………………………………………….………..

Product Features ………………………………………………………………………………….

Speciﬁcations ……………………………………………………………………………………….

Dimensions ………………………………………………………………………………….……….

Installation Requirements …………………………………………………………..……….

Positioning the Mixer Valve …………………………………………..……..

Water Requirements …………………………………………………………….

Electrical Requirements ………………………………………………..…….

Installation …………………………………………………………………………………..……….

Fitting the Mixer Valve …………………………………………………..……..

Water Connections …………………………………………………..……........

Electrical Connections ………………………………………………………….

Fitting the Wireless Controller .……………………………………….……

Shower Arm & Rose..……………………………………………………….……

Commissioning ……………………………………………………………………………………..

Wireless Initialisation & Pairing …………………………………….…….

Maximum Temperature Setting ……………………………………..…….

Water / Plumbing Connections …………………………………………….

Purge Procedure …………………………………………….......................

Basic Functional Testing ………………………………………………..…….

Operating the Shower ………………………………………………………………….……….

Maintenance ………………………………………………………………………………..……….

Troubleshooting …………………………………………………………………………..……….

Spare Parts ………………………………………………………………………………….……….

Notes ………………………………………………………………………………….………...........

Guarantee ……………………………………………………………………………………………..

9-11

12-17

16-17

18-20

18-19

22-24

25-26

28-29

30-31

• Please read these instructions thoroughly and retain for future use.

• All products manufactured and supplied by Bristan are safe provided they are

installed, used correctly and receive regular maintenance in accordance with these

instructions.

• If you are in any doubt about your ability to install this product safely you must

employ the services of an experienced qualiﬁed plumber / electrically qualiﬁed

person.

• This Digital Electronic Mixer Shower needs to be installed in accordance with, and

meet the requirements of the Water Supply (Water Fittings) Regulations 1999 and

Scottish Byelaws 2004.

• Before starting any installation please consider the following:

• Before drilling into walls, check that there are no hidden electrical wires, cables or

water supply pipes. This can be checked with the aid of an electronic detector.

• If power tools are used do not forget to: - Wear eye protection

- Unplug equipment after use

• Warning: Before installing the new Digital Electronic Mixer Shower it is essential

that you thoroughly ﬂush through the pipework in order to remove any remaining swarf,

solder, etc. Failure to carry out this procedure could cause problems or damage to the

workings of the Mixing Valve.

• Do not operate the shower if the water stops ﬂowing during use or if the water is

leaking from the Mixing Valve itself. Turn off at the mains electrical supply and refer to

the Troubleshooting section (see pages 26-27) or contact Bristan Customer Services on

0844 701 6273.

• Do not block the ﬂow of water from the shower rose by smothering it on your hand or

any other part of your body or foreign object.

• Warning: Do not operate this product if you suspect it is frozen. Do not site the

Mixing Valve where it might be subjected to freezing conditions.

Important Safety Information

Need help? Give us a call on 0844 701 6273 and speak to one of our trained advisers. 3

BEAB (British Electrotechnical

Approvals Board) approval

of safety.

0359

Hereby, Bristan Group Ltd, declares that this Electronic Mixing Valve with

Wireless Controller is in compliance with the essential requirements and

other relevant provisions of the Directive 1999/5/EC. The declaration of

conformity may be consulted at www.bristan.com/dop.

General Information

4 Need help? Give us a call on 0844 701 6273 and speak to one of our trained advisers.

Recommended Usage

Domestic Heavy

Commercial

Light

Commercial Health Care

• Remove all packaging and check the contents for damage before starting any

installation.

• Fitting isolation valves to the inlet feeds is required as close as is practical to the

inlet connections for ease of maintenance.

• Always switch off the power at the consumer unit and isolate the electrical supply

before making any electrical connections or if you have to remove the cover of the

Mixing Valve.

• This product must not be modiﬁed in any way as this will invalidate the guarantee.

Pack Contents & Tools Required

Need help? Give us a call on 0844 701 6273 and speak to one of our trained advisers. 5

Wireless Controller x1

Mixing Valve Screw x4

Remote Control Screw x3

Wall Plugs x7

Arm x1

Shroud x1

Sealing

Washer x1

Rose x1

Mixing Valve x1

Drill Suitable Drill bit Phillips Screwdriver

Flat Head Screw

Driver Electrical Screwdriver

Masking TapeElectrical PliersElectrical TesterPencilSpanner

Tools Required - Not supplied

Batteries x2

1. Temperature control

Press to increase the temperature up

to a factory set maximum of 48ºC (the

maximum temperature can be overridden,

see Maximum Temperature Setting on

page 19).

Press to decrease the temperature

down to a minimum of 35ºC.

2. Lever handle

Turns the shower on and adjusts the

ﬂow of water. Turn anti-clockwise to turn

the shower on and back to to turn the

shower off.

3. Water ﬂow settings

The shower has 4 ﬂow settings.

Eco ( ), Low ( ), Medium ( ), and

High( ).

4. Digital display screen

Displays the water temperature . Any

error codes will be displayed on here.

5. Time out setting

If the shower valve has been running for

30 minutes the Mixing Valve will

automatically shut off to save water and

energy.

Normal use will be resumed once the

lever handle has been returned to the ‘Off’

position.

Product Features

6 Need help? Give us a call on 0844 701 6273 and speak to one of our trained advisers.

Speciﬁcations

Water Supply Requirements

Inlet connections: 1/2” BSP with 70mm between centres.

Operating pressure range: Min. 0.5 bar - Max. 5.0 bar

For optimum performance a minimum dynamic working pressure of 1.0 bar is required.

Minimum static pressure: 0.5 bar

Maximum static pressure: 10.0 bar

Supply requirements:

Minimum cold water supply temperature: 5ºC.

Maximum cold water supply temperature: 20ºC.

Minimum hot water supply temperature: 52ºC.

Maximum hot water supply temperature: 65ºC.

Flow Performance

Flow Setting Optimum Flow Rate (lpm)

6 lpm

8 lpm

10 lpm

12 lpm

Electrical Supply Requirements

Supply voltage: 230V AC / 35W

Need help? Give us a call on 0844 701 6273 and speak to one of our trained advisers. 7

Dimensions (mm)

8 Need help? Give us a call on 0844 701 6273 and speak to one of our trained advisers.

123

212

226

200

223

G1/2

200

145 165

Installation Requirements

Need help? Give us a call on 0844 701 6273 and speak to one of our trained advisers. 9

Positioning the mixing valve

The Mixing Valve can be positioned on

either a wall surface or ﬂat on the ﬂoor.

(Refer to the diagrams for the correct

orientation of the Mixing Valve).

The Mixing Valve can be installed in either

an airing cupboard, loft space or under the

bath. Do not site the Mixing Valve where it

may be subjected to freezing conditions or

ambient temperatures over 40ºC.

The maximum distance from the Mixing

Valve to the Wireless controller must not

exceed 10 metres as this is beyond the

operating range of the wireless controller.

Wireless installation considerations

As with any wireless / radio product:

- Metallic lined materials or metal

objects (such as steel baths or metal

tanks, etc.) can signiﬁcantly reduce the

operating range of the wireless interface

or prevent operation.

- Interference from other radio signals

has the potential to affect the ability of the

wireless interface to function correctly.

Note: If the Mixing Valve loses wireless

communication with the controller, the

shower will automatically turn off safely. Vertically up on the wall

DO NOT INSTALL UPSIDE DOWN ON

THE WALL!

Vertically down on the wall

Flat on the ﬂoor

DO NOT INSTALL HORIZONTALLY ON

THE WALL!

Installation Requirements

10 Need help? Give us a call on 0844 701 6273 and speak to one of our trained advisers.

Water Requirements

This ﬁtting needs to be installed in

accordance with the following Installation

Requirements and Notes (IRN) to ensure

they meet the requirements of the Water

Supply (Water Fittings) Regulations 1999

and the Scottish Byelaws 2004.

The ﬁtting shall be installed so that its

outlet discharges above the spill-over

level of any appliance as indicated on the

illustration below.

For backﬂow protection in premises or

installations up to, and including Fluid

Category 3 and 5.

The vertical distance of the outlet above

the spill-over level shall be not less than

20mm or twice the diameter of the inlet

pipe to the ﬁtting, which ever is the

greater. If the ﬁtting cannot be installed

as indicated it shall be installed with a

backﬂow prevention arrangement suitable

for the Fluid Category.

If the shower is to be installed in a hard

water area, we recommend that an in-line

scale inhibitor is ﬁtted which will prolong

the life of the shower. Please refer to your

supplier for advice.

Warning: the shower must not be

installed in an area subject to freezing

conditions. Do not use if you suspect the

shower is frozen, this will damage the

shower unit.

Maximum ambient temperature: 40ºC.

A minimum working inlet pressure of

0.1MPa (1bar) at a minimum ﬂow rate of

10 litres per minute is recommended for

full performance.

The maximum static inlet pressure must

not exceed 1.0MPa (10bar).

If it is intended to operate the shower

above the recommended operating /

dynamic pressure, a suitable pressure

reducing valve (PRV) should be used.

Water regulations stipulate that a

removable showerhead be constrained by

a ﬁxed or sliding attachment (hose

retainer supplied) so that it can only

discharge water at a point not less that

20mm above the spill-over lever of the

bath or shower tray or other ﬁxed

appliance.

Bath spillover

level

Shower tray

spillover level

Ceiling fed

arm & rose

Controller

Otros manuales para Artisan Evo

Tabla de contenidos

Otros manuales de Accesorios de cocina y baño de Bristan

Bristan

Bristan MINI2 TS1203 CL C Instrucciones de montaje

Bristan

Bristan Hourglass HOU 1HBF C Diagrama de cableado

Bristan

Bristan AR THBSM C Manual de usuario

Bristan

Bristan FLT BAS C Manual de usuario

Bristan

Bristan Liquorice LQR PROSNK C Diagrama de cableado

Bristan

Bristan Quest QST 1/2 C Diagrama de cableado

Bristan

Bristan W BASIN04 C Manual de usuario

Bristan

Bristan Prism PM 3HWMBAS C Manual de usuario

Bristan

Bristan IRSD1-CP Instrucciones de montaje

Bristan

Bristan Z2 BIB C Diagrama de cableado

Bristan

Bristan Prism Manual de usuario

Bristan

Bristan Club DUC HNK C Manual de usuario

Bristan

Bristan Z2 1/2 C Diagrama de cableado

Bristan

Bristan GWF BF C Diagrama de cableado

Bristan

Bristan Acute AE 1/2 C Manual de usuario

Bristan

Bristan FLT 3HBAS C Manual de usuario

Bristan

Bristan Capri Manual de usuario

Bristan

Bristan VT 1/2 C Manual de usuario

Bristan

Bristan Bright BRG BAS C Manual de usuario

Bristan

Bristan Java Series Diagrama de cableado

Bristan

Bristan Claret CLR BASNW C/WHT Instrucciones de montaje

Bristan

Bristan TO DSM C Manual de usuario

Bristan

Bristan Gummers H64WMT Instrucciones de montaje

Bristan

Bristan Pear PEA PULLSNK C Diagrama de cableado

Manuales populares de Accesorios de cocina y baño de otras marcas

Grohe

Grohe BRIDGEFORD 33 870 Manual de usuario

Hans Grohe

Hans Grohe Zenio Metro 31811000 Manual de usuario

Gröne

Gröne Zedra 32 555 Manual de usuario

Transform

Transform QL045 Manual de usuario

Sanela

Sanela SLU 09PTB Manual de usuario

Glacier bay

Glacier bay FP4A0052BNV Instrucciones de montaje

Lefroy Brooks

Lefroy Brooks C1-1400 Instrucciones de montaje

Grohe

Grohe Rapido E Manual de usuario

Danze

Danze D302455 Manual de usuario

Waterworks

Waterworks CEKM30 Hoja de instrucciones

Helvex

Helvex Omega TV-298 Manual de usuario

Tribata.

Tribata. GEORGIAN G5393 Manual de usuario

Alpha Bidet

Alpha Bidet Alpha One Manual de usuario

InSinkErator

InSinkErator H/HC3300 Manual de instalación

Clou

Clou Xo type 1 Manual de usuario

Kohler

Kohler Contra 26448T-4 Manual de usuario

Grohe

Grohe Bridgeford 20 158 Manual de usuario

Hans Grohe

Hans Grohe Croma Select S 180 Showerpipe EcoSmart... Manual de usuario
