English................................................................................................................... 4

Deutsch ................................................................................................................. 12

4 / 20

1 Imprint (German)

Bresser GmbH

Gutenbergstr. 2

46414 Rhede

Germany

http://www.bresser.de

For any warranty claims or service enquiries, please refer to the information on "Warranty" and "Ser-

vice" in this documentation. We apologize for any inconvenience caused by the fact that we cannot

process enquiries or submissions sent directly to the manufacturer's address.

Errors and technical changes excepted.

The reproduction of this documentation - even in extracts - in any form (e.g. photocopy, print, etc.) as

well as the use and distribution by means of electronic systems (e.g. image file, website, etc.) without

the prior written permission of the manufacturer is prohibited.

The designations and brand names of the respective companies used in this documentation are gen-

erally protected by trade, trademark and/or patent law in Germany, the European Union and/or other

countries.

2 Validity note

This documentation is valid for the products with the following article numbers:

5809100

Manual version: 0221

Manual designation:

Manual_5809100_Analyth-LCD_en-de_BRESSER_v022021a

Always provide information when requesting service.

3 About this Instruction Manual

NOTICE

These operating instructions are to be considered a component of the device.

Read the safety instructions and the operating manual carefully before using this device.

Keep this instruction manual in a safe place for future reference. When the device is sold or given to

someone else, the instruction manual must be provided to the new owner/user of the product.

4 Intended use

• This device is not intended for use by persons (including children) with impaired physical, sensory

or mental abilities, or for lack of experience and/or knowledge, unless they are supervised by or

have received instructions from a person responsible for their safety on how to use this device.

• This device is for personal use only.

• It was developed for an magnified representation of nature observations.

• The device is intended only for indoor use.

5 / 20

5 General safety instructions

DANGER

Risk of an electric shock!

This device contains electronic parts that are powered by a power source (AC adapter and/or batter-

ies). Improper use of this product may result in electric shock. Electric shock can cause serious or fatal

injuries. It is therefore imperative that you observe the following safety information.

• Disconnect the power supply by pulling the mains plug when the appliance is not in use, in case of

a longer interruption of operation and before any maintenance and cleaning work.

• Place your device so that it can be disconnected from the power supply at any time. The power

outlet should always be near your appliance and should be easily accessible, as the plug of the

power cord serves as a disconnect device from the mains supply.

• To disconnect the unit from the mains, always pull the mains plug and never pull the cable!

• Check this device, cables and connections for damage before use.

• Never attempt to operate a damaged device, or a device with damaged electrical parts! Damaged

parts must be replaced immediately by an authorized service agent.

• Operate the device only in a completely dry environment and do not touch the device with wet or

damp body parts.

DANGER

Danger of suffocation!

Improper use of this product may result in suffocation, especially for children. It is therefore imperative

that you observe the following safety information.

• Keep packaging materials (plastic bags, rubber bands, etc.) away from children! There is a danger

of choking!

• This product contains small parts that can be swallowed by children! Choking hazard!

• If small parts are swallowed, consult a doctor immediately!

DANGER

Explosion hazard!

Improper use of this product may result in fire. It is essential that you observe the following safety in-

formation in order to avoid fires.

• Do not expose the device to high temperatures. Use only the supplied AC adapter. Do not short-

circuit the device or batteries or dispose of in fire! Excessive heat and improper handling can

cause short circuits, fires and even explosions!

CAUTION

Risk of body injury!

This device contains components and/or accessories that can cause minor or serious body injury if

used improperly. It is therefore essential that you observe the following safety information in order to

prevent body injuries.

• Sharp-edged and pointed tools are often used for working with this device. Therefore, keep this

device and all accessories and tools in a place inaccessible to children. Danger of body injury!

6 / 20

• Chemicals and liquids do not belong in children's hands! Don't drink! Clean hands thoroughly un-

der running water after use. In case of accidental contact with eyes or mouth, rinse with water. In

case of complaints, consult a doctor immediately and show the substances.

CAUTION

Fire hazard!

Improper use of this product may result in fire. It is essential that you observe the following safety in-

formation in order to avoid fires.

• Never cover the ventilation slots or cooling fins of the device during operation or until it has cooled

down completely!

NOTICE

Danger of material damage!

Improper handling may result in damage to the unit and/or accessories. Therefore, use the device only

in accordance with the following safety information.

• Do not disassemble the device! In the event of a defect, please contact your dealer. They will con-

tact the Service Center and can arrange the return of this device for repair if necessary.

• Do not expose the device to high temperatures and protect it from water and high humidity.

• Do not subject the device to excessive vibrations.

• Only use accessories and spare parts for this device that comply with the technical specifications.

6 About this microscope

Since this microscope is a digital microscope, it is only suitable for visual observation to a limited ex-

tent.

It is equipped with a lens and a camera sensor for capturing images. The digital images can be viewed

directly on the built-in LCD display or optionally stored on a MicroSD memory card*.

*not included

7 Choice of location

Choose a suitable location before installation and commissioning.

Place the device on a stable, level and vibration-free surface.

7 / 20

8 Parts overview and scope of delivery

Illustration1: All parts of the microscope

1 LCD display (movable) 2 Memory card slot (MicroSD card*)

3 Function light (display) 4 USB-A port (mouse*)

5 Coarse focus 6 Friction adjustment

7 Fine focus 8 Incident lighting

9 On/Off switch 10 DC connection socket (power)

11 Function lights (incident light brightness) 12 Function lights (transmitted light brightness)

13 Translucent lighting 14 Object plate, exchangeable

15 Object clamps 16 Function light (voltage)

17 "Tra" button (translucent lighting) 18 "Inc" button (incident lighting)

19 Objective 20 Zoom ring

21 Microscope head 22 Mouse

23 USB A connector 24 Mains plug

25 DC barrel connector 26 Hook wrench

*not included

8 / 20

Scope of delivery:

Microscope (A), mouse (B), power adapter (C), object plate (black/white) (D), object plate (semi-trans-

parent) (E), hook wrench (F)

For object measurements, the use of a micrometer scale slide is recommended.

9 Power supply

S1 Connection socket for DC barrel con-

nector

S2 DC barrel connector

S3 Mains plug

1. Insert the DC barrel connector of the mains adapter into the DC connection socket of the device.

2. Insert the mains plug of the mains adapter into the socket.

The function light for the power supply is on. The device is ready for use.

10 Turning on/off the device

1. Move On/Off switch to position 'I' to turn on the device.

2. Move On/Off switch to 'O' position to turn off the device.

11 Adjusting the zoom

The microscope optics have a zoom range from 0.7x to 4.5x.

The zoom range can be changed by turning the zoom ring.

NOTICE!When changing the zoom range, the focus may also need to be adjusted. (see also "Fo-

cusing the object")

12 Focusing the object

The microscope has coarse and fine focusing. These can be used for object focusing as described be-

low.

1. Make the desired zoom setting.

2. Focus on the observation object using coarse focusing.

3. If necessary, adjust the object sharpness individually by fine focusing, especially when changing

the zoom setting and/or the height of the microscope head.

9 / 20

13 Adjusting the friction

F1 F2

Illustration2: Friction adjustment on the focus wheel (left or right, depending on model).

F1 Focus wheel F2 Bore

The friction for focusing can be adjusted individually as follows:

1. Loosen the clamping screw for the counter ring and move the counter ring down completely.

2. Hold the microscope head with one hand and loosen the locking screw.

3. Continue to hold the microscope head. Insert the hook wrench into the bore on the drive shaft. By

turning the wrench, the friction adjustment can be either tightened or loosened.

4. Check the friction setting by turning the focus wheel.

WARNING!If the friction setting is too loose, the microscope head may move downward by it-

self. The microscope optics and/or other attached components can thus be damaged due to a

shock!

NOTICE!The tighter the friction setting, the more stiffly is the focus wheel.

14 Working with the onscreen menu

1. Connect the mouse* to the USB-A port of the microscope.

2. Move the On/Off switch to the "I" position.

3. Position the object on the object plate and set the appropriate illumination (see “Adjusting the illu-

mination”)

4. An image of the object is shown on the LCD display and the mouse pointer is visible.

5. Move the mouse pointer to the left or bottom edge of the display to show the desired display

menu.

Left display menu

Image capturing: Clicking this button will take a photo. Info appears briefly: "Image capture successful"

Video: Clicking this button starts a video record. Info appears briefly: "Recording in progress...". In the

upper right corner the recording time starts to run. Clicking the button again will stop the video. Info

appears briefly: "Video successful".

Preview: You can view captured photos and videos in the preview. Double-click to display the desired

image. Press the "Back" button to return to the live image. Within the preview you can scroll and also

delete photos.

10 / 20

Measurement: In order to take measurements with the microscope, a reference is required to calibrate

the software.

For this purpose we recommend our microscope slide with micrometer scale: Art. No. 5916720.

Detailed information on measurement can be found in the further instructions.

Settings: The camera operates in automatic mode by default. Changing the settings is recommended

only for experienced users.

Menu language: German, English, French, Chinese.

Date and time: The clock continues to run as long as the power supply is established.

Bottom display menu

Zoom in: Click the icon several times to zoom in up to 10 times (digital zoom)

Zoom out: Click the icon several times to reset the magnification step by step

Mirroring: Horizontal image mirroring

Rotation: Image rotation by 180 degr.

Black and white: Image display in grayscales

HDR: Function for improved image reproduction at different brightness ranges

Freeze frame: Stops the live image. No recording is made. Click again to start.

Grid: Display of a grid or scale bar as a cross. For more information, see "Grid settings"

Color: Adjusting the display of lines and labels for the measurement function

Comparison: A previously taken photo is placed next to the live image

15 Save recordings

1. Put the microscope into operation.

2. Insert a suitable memory card* into the memory card slot.

3. CAUTION!The contacts of the memory card must face to the back of the display. Memory

cards that are inserted incorrectly can cause electrical damage. The recordings stored on the

memory card can be irreversibly deleted and the device may be damaged.

4. Image captures or videos can be saved to the memory card via the display menu (see "Working

with the onscreen menu").

*MicroSD card up to maximum 32 GB (not included)

16 Grid settings

1. Put the microscope into operation.

2. Set the desired grid setting in the onscreen menu:

Activating the scale bar displays a cross with a grid. This shows the scale of the set calibration

value.

By activating "activate all" a grid pattern is evenly distributed on the screen.

3. With "Reset grid" the original grid is set again.

4. In the "Grid settings" all lines can be adjusted.

5. Click "Save" to confirm the settings.

6. Click on "Back" to exit the menu.

Este manual sirve para los siguientes modelos

Tabla de contenidos

Idiomas:

Otros manuales de Microscopio de Bresser

Bresser

Bresser Biolux ICD 20x Manual de usuario

Bresser

Bresser National Geographic 9619742 Manual de usuario

Bresser

Bresser StereoMicro 88-52000 Manual de usuario

Bresser

Bresser 5803500 Manual de usuario

Bresser

Bresser MicroSet 40 -1024x Manual de usuario

Bresser

Bresser XPD-101 Manual de usuario

Bresser

Bresser NATIONAL GEOGRAPHIC 40X-640X Manual de usuario

Bresser

Bresser LCD-Micro Manual de usuario

Bresser

Bresser Analyth STR Manual de usuario

Bresser

Bresser ERUDIT ICD Manual de usuario

Bresser

Bresser NATIONAL GEOGRAPHIC 9619742 Manual de usuario

Bresser

Bresser National Geographic 9119100 Manual de usuario

Bresser

Bresser Biolux DLX Manual de usuario

Bresser

Bresser Biorit TP Manual de usuario

Bresser

Bresser StereoMicro 88-52000 Manual de usuario

Bresser

Bresser MicroSet 40x-1024x Manual de usuario

Bresser

Bresser LCD STUDENT MICROSCOPE 8.9 CM Manual de usuario

Bresser

Bresser ETD-101 Manual de usuario

Bresser

Bresser Advance ICD Manual de usuario

Bresser

Bresser 90-39000 Manual de usuario

Bresser

Bresser 300X Manual de usuario

Bresser

Bresser 5116200 Manual de usuario

Bresser

Bresser BIOLUX Advance Manual de usuario

Bresser

Bresser Duolux Manual de usuario

Manuales populares de Microscopio de otras marcas

Thermo Scientific

Thermo Scientific Nicolet iN10 Guía

National

National DC3-163 Manual de usuario

KERN Optics

KERN Optics OPE-1 Manual de usuario

OPTIKA MICROSCOPES

OPTIKA MICROSCOPES B-150D Manual de usuario

Prior

Prior Lux POL Manual de usuario

Opitec

Opitec Smartscoop 115615 Manual de usuario

KERN

KERN OPO-1 Manual de usuario

Topcon

Topcon SP-1P Manual de usuario

Motic

Motic PA43 Manual de usuario

Leica

Leica DVM5000 Guía del usuario

MshOt

MshOt MZ62 Manual de usuario

KERN Optics

KERN Optics OZR-5 Manual de usuario

VWR

VWR VisiScope 384 Series Manual de usuario

Nikon

Nikon ECLIPSE E200 POL Manual de usuario

Leica

Leica DI C800 Manual

ThermoFisher Scientific

ThermoFisher Scientific Continuµm Manual de usuario

ThermoFisher Scientific

ThermoFisher Scientific Continuµm Manual de usuario

Olympus

Olympus SZ61 Manual de usuario
