HS300

Operation Manual

Contents subject to change without notice

Version 2.1

2012-01-10

Declarations of compliance

United States

This equipment has been tested and found to comply with the limits for a Class A

digital device, pursuant to Part 15 of the FCC Rules. These limits are designed

to provide reasonable protection against harmful interference when the

equipment is operated in a commercial environment. This equipment

generates, uses, and can radiate radio frequency energy and, if not installed

and used in accordance with the instruction manual, may cause harmful

interference to radio communications. Operation of this equipment in a

residential area is likely to cause harmful interference in which case the user

will be required to correct the interference at his own expense.

Canada

This digital apparatus does not exceed the Class A limits for radio noise

emissions from digital apparatus set out in the Radio Interference

Regulations of the Canadian Department of Communications.

Le présent appareil numérique n’émet pas de bruits radioélectriques dépassant

les limites applicables aux appareils numériques de la Classe A prescrites

dans le Règlement sur le brouillage radioélectrique edicté par le ministère des

Communications du Canada.

Warnings Electrical installation

For your protection, all mains (110V or 230V) equipment used

where damp or wet conditions may occur, must be supplied from a

correctly fused source and protected by an approved ground fault

protection device (RCD, GFCI etc.).

IF IN DOUBT SEEK ADVICE FROM A QUALIFIED

ELECTRICIAN.

To avoid the possibility of electric shock or damage to the machine,

always isolate from the mains power supply before carrying out any

routine maintenance.

Cleaning the scale

Harsh abrasives, solvents, scouring cleaners and alkaline cleaning

solutions, should not be used especially on the display windows.

Under no circumstances should you attempt to wipe the inside of the

machine.

The outside of the machine may be wiped down with a clean cloth

moistened with water containing a small amount of liquid soap.

EMC compliance

The following warning may be applicable to your machine.

WARNING: This is a class A product. In a domestic environment

this product may cause radio interference in which case the user

may be required to take adequate measures.

CONTENT

Ⅰ

. SPECIFICATIONS. ……………………………………………… P1

Ⅱ

. KEY FUNCTION. ……………………………………………… P3

Ⅲ

. CALIBRATION. ………………………………….……………… P6

Ⅳ

. Examination mode………………………………………………… P9

Ⅴ

. SETUP MODE. …………………………………………………… P10

Ⅵ

. Details of RS232 Communication………………………………... P17

Ⅶ

. Calibration resolution, division and capacity …..………………… P20

Ⅷ

. Meaning of some displayed symbols. ……………………………. P23

Ⅸ

. Direction of indicator with bracket. ………………………. ……… P24

Ⅹ

.Key Definition summary: ………………………. ………………… P24

Ⅺ

.Parameters setting summary: ………………………………... … P26

140 Indicator Operation Manual

Thank you for purchasing the 140 indicator. Please read all operating

instructions carefully before use and keep the following points in mind:

* Avoid lengthy exposure to extreme heat or cold, your scale works best when

operated at normal room temperature. Always allow the scale to acclimate to a

normal room temperature before use

* Allow sufficient warm up time. Turn the scale on and wait for a few minutes if

possible, to give the internal components a chance to stabilize before weighing.

* These electronic scales are precision instruments. Do not operate near an in-use

cell phone, radio, computer or other electronic device. These devices emit RF and

can cause unstable scale readings. If your scale ever performs poorly, try moving

the scale to a different room or location.

* Avoid using in condition of heavy vibration and airflow.

* Read the weight reading in short time after loading. The output signature of load

cell and A/D may be little influenced after weighing for a long time.

Ⅰ

.SPECIFICATIONS:

SCALE INDICATOR

：

1. Input signal range: 0mV ～+30mV

2. Sensitivity: >0.2uV/grad

3. Internal Resolution: Approximately 520,000 counts

4. Display Resolution: can be selected between 500-100,000

5. System Linearity: within 0.01% of FS

6. Loadcell excitation Voltage: +4.4 VDC (MAX current: 55mA)

Max 4- 350 ohm loadcells.

7. Calibration Method: Software calibration with long-term storage in EEPROM.

SERIAL COMMUNICATIONS:

1. Mode: Full duplex or only output mode can be selected

2. Baud rate: 1200, 2400, 4800, 9600, or 19200 bps

3. Data format: 8N1, 7E1, 7O1

8data bits, non parity, 1 stop bit

7data bits, 1bit even or odd parity, 1 stop bit

4. Protocol: 7selected protocol (include the one compatible with NCI standard

SCP-01)

5. Output data: gross weight, net weight, tare weight, indicator displaying weight,

weighing unit etc.

OPERATION INTERFACE:

1. Display: 0.65” (17mm) 7-segment LCD, 51/2digits

2. Keyboard: 4-key push button

POWER:

1. Alkaline Batteries: 4 x “AAA” size cells

When all displayed segments of LCD flashed, this indicates the batteries are

low below 4.9V and you’d better to replace batteries;

When “Lo.bAt” displayed, this indicates the batteries are low below 4.7V and

you should replace batteries immediately.

2. AC Adapter: 6VDC, 500mA, with central negative:

3. Work current: ≤25mA

(when voltage in 5Vdc-8Vdc and not include load cell’s consumption)

OPERATION TEMPERATURE: 20℃±15℃

STORE TEMPERATURE: -10℃-70℃

OPERATION HUMIDITY: ≤95%RH (no condensate)

LOADCELL:

Because of more than one load cell can be used on a scale, following are

required on the load cell set to be used with this indicator,

1. Sensitivity: 0.3mV/V --- 3mV/V (must be fit to >0.2uV/display grad)

2. Input Resistor: ≥80 Ω

3. Output Resistor: <10 KΩ

LOADCELL WIRING:

PIN 1: RED, EXCITATION +

PIN2: BLACK, EXCITATION –

PIN3: GREEN, SIGNAL -

PIN4: WHITE, SIGNAL +

Ⅱ

. KEY FUNCTION:

1.FACEPLATE:

2.DISPLAY SYMBOL MEANING:

Zero ◄--------The scale is at zero point and the gross weight is 0

Net ◄---------The display reading is net weight, and the tare weight is not 0.

Hold -------The scale is under HOLD mode.

It displays the current live weight when flashed, and the locked reading will

be shown when does not flash and comes steady.

3.SUMMARY of KEY DEFINITION:

3.1 In normal weighing mode press and hold down keys for 3 seconds:

(1)

a. If this key is only set for HOLD (P2=0), press this key to enter or exit HOLD

mode.

b. If this key is only set for PRINT (P2=1), press this key to output the data

according to P4 setting.

c. If this key is set for both HOLD and PRINT function (P2=2), press this key to

output the data according to P4 setting.

HOLD

UNIT

TARE

ZERO

HOLD

(2)

Choose weighing units among kg-lb-lb: oz

Note: The weighing units that can be used are restricted by display

division, and calibration weight unit (restricted by P8, P9, and P10):

For example, if the calibration unit is “kg”; calibration display resolution

is 50kg (that means: P8=5, P9=0, P10=0), and users press UNIT key to

choose weighing units. Lb or lb:oz are not allowed to choose, since the

display resolution of 100lb or 2000oz is not available to this indicator.

(3)

Tare the weight. This function can be activated only when the scale is in

stable mode and the gross weight is not negative value.

(4)

Zero function. When the weight is within zero range, it will active as

ZERO function and clear the tare weight. When the weight is not within

zero setting range (P13 set), the scale will show 0ˉˉˉˉ(zero point is over

the setting range), or 0_ _ _ _ (zero is below the setting range).

3.2. In normal weighing mode and hold down time longer than 3s:

(1) Same meaning with that in 3.1

(2) Same meaning with that in 3.1

(3) Same meaning with that in 3.1

(4) Power off the scale.

UNIT

TARE

ZERO

HOLD

UNIT

TARE

OFF

HOLD

UNIT

TARE

OFF

(5) +

Hold these two buttons to show firmware version; A/D code or input

working voltage of indicator.

(6) +

Hold these two buttons to enter setting mode when the sealed calibration

switch is on.

(7) +

Hold these two buttons to enter calibration mode when the sealed

calibration switch is on.

3.3 In setting mode:

HOLD UNITS TARE OFF/ON

(1) Rotate the flashed position from right to left

(2) Change the digit on flashed position. The digit can be changed

to 0, 1, 2…9; and be flashed.

(3)

Confirm receiving and storing the displayed parameters,

After the setting of the las

t parameter, the indicator will

not exit the setup mode, and cycles from the first parameters

for viewing or modifications.

(4)

Exit from setting mode to normal work mode

3.4 In displaying A/D code or input voltage mode:

(1) No function

OFF

HOLD

OFF

UNIT

OFF

TARE

VOL

FLT

EXT

(2) Choose the weight inner code or input working voltage to be

displayed. The working voltage range is 4.8V-8V. If the voltage

is not within range, it may damage the indicator. Voltage value

is shown like this “U x.xx” and its unit is V.

(3) When A/D code of weight is shown, press this button to choose

filtered or un-filtered weight A/D data; when is on, the data

is filtered.

(4) Press this button to exit this mode, and auto-reset the indicator,

display all segments of LCD, full capacity… just like power on

again and then it goes back to normal weighing mode.

3.5 Calibration mode

HOLD UNITS TARE OFF/ON

(1) Rotate the flashed position from right to left

(2) Change the digit on flashed position. The digit can be changed

to 0, 1, 2…9; and be flashed.

(3) Confirm receiving input data and go into next step.

(4)

Exit from calibration mode to normal work mode

Ⅲ

.CALIBRATION:

Before calibrate the scale, you should prepare a standard weight (more than

10% of FS weight, and the unit is same as P10 setting) for calibration.

1. Move away any weight on scale. When normal weighing mode, press and

hold down TARE and ON/OFF/ZERO buttons to enter calibration mode.

2. When the indicator shows” CAL-?”, the scale is ready for calibration. Press

VOL

FLT

EXT

Otros manuales para HS300

Tabla de contenidos

Idiomas:

Otros manuales de Escala de Brecknell

Brecknell

Brecknell PS25 Manual de usuario

Brecknell

Brecknell GP100-USB Manual de usuario

Brecknell

Brecknell PS3000 Manual de usuario

Brecknell

Brecknell 67XXU Series Manual de usuario

Brecknell

Brecknell C3236 Manual de usuario

Brecknell

Brecknell DS-1 Manual de usuario

Brecknell

Brecknell HS300 Manual de usuario

Brecknell

Brecknell LPS Series Manual de usuario

Brecknell

Brecknell MS 1000-LCD Manual de usuario

Brecknell

Brecknell BS-180 Manual de usuario

Brecknell

Brecknell PS-7 Manual de operación

Brecknell

Brecknell PC3060 Manual de usuario

Brecknell

Brecknell MBS-150 Manual de usuario

Brecknell

Brecknell ELECTROSAMSON Manual de usuario

Brecknell

Brecknell 6710 Series Manual de usuario

Brecknell

Brecknell MS16 Manual de usuario

Brecknell

Brecknell EPB Series Manual de usuario

Brecknell

Brecknell 67 U Series Manual de usuario

Brecknell

Brecknell DSB Manual de instrucciones

Brecknell

Brecknell CS-200M Instrucciones de instalación

Brecknell

Brecknell MS-20 Manual de usuario

Brecknell

Brecknell BFS-150 Manual de usuario

Brecknell

Brecknell 6030 Manual del operador

Brecknell

Brecknell 405-6-LCD Manual de usuario

Manuales populares de Escala de otras marcas

AWS

AWS ZEO-50 Manual de usuario

Gima

Gima Glass Body Fat Analyzer Manual de lista de piezas

Seca

Seca 374 Manual de usuario

TEC

TEC TEC SL59 SERIES Manual de usuario

Axis

Axis B/E Series Manual de usuario

Alecto

Alecto ACW-40 Manual de usuario

Rice Lake

Rice Lake MSI-4260 IS Manual de usuario

IKA

IKA RCT basic safety control Manual de usuario

ADE

ADE M20011 Manual de usuario

Duronic

Duronic KS3000 Manual de usuario

Digi

Digi SM-720 Manual de usuario

Cardinal

Cardinal CS Series Manual de usuario

Korona

Korona Kastella Manual de usuario

A&D

A&D FC-50Ki Manual de usuario

BDA

BDA CAMARGUE Manual de usuario

Tanita

Tanita HD-357 Manual de usuario

Leifheit

Leifheit 03173 Manual de usuario

Lumme

Lumme LU-1340 Manual de usuario
