Boya BY-M3 Manual de usuario

BY-M3

User Manual • Uživatelský manuál •

Užívateľský manuál • Használati utasítás •

Benutzerhandbuch

Dear customer,

Thank you for purchasing our product. Please read the following instructions carefully

before first use and keep this user manual for future reference. Pay particular attention

to the safety instructions. If you have any questions or comments about the device,

please contact the customer line.

✉www.alza.co.uk/kontakt

✆+44 (0)203 514 4411

Importer Alza.cz a.s., Jankovcova 1522/53, Holešovice, 170 00 Praha 7, www.alza.cz

Instruction

Thank you for purchasing BOYA microphone!

The BOYA BY-M3 is a digital USB Type-C lavalier microphone, which is specially designed

for Android devices and other devices with Type-C connector, such as iPad Pro, Mac PC.

With 16bits/48kHz resolution, it is well-suitable for podcasting, vlogging, interviews, and

more. Features omnidirectional polar pattern and clip-on design, it could effectively

reduce unwanted background noise, and greatly help the mobile devices to pick-up

high-quality sound recordings.

Up to 6 meters long cable, it allows users to comfortably adapt various environments.

Components

1) USB Type-C connector

2) Microphone

3) Clothing clip

4) Foam windscreen

NOTE:

Not all Android applications can support USB external microphone when you take a video, and

you may need to download a third-party application to use this feature.

Package contents

•BY-M3 lapel mic

•Foam windscreen

•Clothing clip

•Velcro

•Carrying pouch

•User manual

How to use BY-M3 with the mobile devices

1) Connect BY-M3 to your mobile devices

2) Mounting the microphone to your Clothing

Attach the microphone to the front of your clothing with the clothing clip, about 20cm (8

inches) from your face.

Attach the microphone upside down to reduce excessive breath noises and tonal

inconsistencies due to head movements.

It is recommended that you always use the foam wind screen to avoid wind noise, even

when recording inside.

3) Turn on the video / audio application and start the recording

Features

•Omnidirectional polar pattern

•Compatible with most of Type-C devices

•6 meters long cable, comfortably adapter to various environments

•16 bits/48kHz digital resolution

•Low handing noise

•Powered by USB Type-C devices

Specifications:

Connector:

Type-C (USB-IF certified)

Sensitivity:

-40dB±3dB (0dB=1V/Pa, at 1kHz)

Polar Pattern:

Omnidirectional

Signal to Noise Ratio:

76dB or more

Bit Rate:

16Bit

Sampling Rates:

48 kHz

Frequency Response:

50Hz-20kHz

Power Requirement:

Via Type-C devices

Cable length:

6m (19,7’)

Weight:

44.5g (1.57oz)

Warranty Conditions

A new product purchased in the Alza.cz sales network is guaranteed for 2 years. If you

need repair or other services during the warranty period, contact the product seller

directly, you must provide the original proof of purchase with the date of purchase.

The following are considered to be a conflict with the warranty conditions, for

which the claimed claim may not be recognized:

•Using the product for any purpose other than that for which the product is intended

or failing to follow the instructions for maintenance, operation and service of the

product.

•Damage to the product by a natural disaster, the intervention of an unauthorized

person or mechanically through the fault of the buyer (e.g. during transport, cleaning

by inappropriate means, etc.).

•Natural wear and aging of consumables or components during use (such as

batteries, etc.).

•Exposure to adverse external influences, such as sunlight and other radiation or

electromagnetic fields, fluid intrusion, object intrusion, mains overvoltage,

electrostatic discharge voltage (including lightning), faulty supply or input voltage and

inappropriate polarity of this voltage, chemical processes such as used power

supplies, etc.

•If anyone has made modifications, modifications, alterations to the design or

adaptation to change or extend the functions of the product compared to the

purchased design or use of non-original components.

EU Declaration of Conformity

Identification data of the manufacturer's / importer's authorized representative:

Importer: Alza.cz a.s.

Registered office: Jankovcova 1522/53, Holešovice, 170 00 Prague 7

IČO: 27082440

Subject of the declaration:

Title: Microphone

Model / Type: BY-M3

The above product has been tested in accordance with the standard(s) used to

demonstrate compliance with the essential requirements laid down in the

Directive(s):

Directive No. (EU) 2014/30/EU

Directive No. 2011/65/EU as amended 2015/863/EU

Prague, 23.11.2020

WEEE

This product must not be disposed of as normal household waste in accordance with

the EU Directive on Waste Electrical and Electronic Equipment (WEEE - 2012/19 / EU).

Instead, it shall be returned to the place of purchase or handed over to a public

collection point for the recyclable waste. By ensuring this product is disposed of

correctly, you will help prevent potential negative consequences for the environment

and human health, which could otherwise be caused by inappropriate waste handling of

this product. Contact your local authority or the nearest collection point for further

details. Improper disposal of this type of waste may result in fines in accordance with

national regulations.

Vážený zákazníku,

Děkujeme vám za zakoupení našeho produktu. Před prvním použitím si prosím pečlivě

přečtěte následující pokyny a tento manuál si uschovejte pro budoucí použití. Věnujte

zvláštní pozornost bezpečnostním pokynům. Pokud máte jakékoliv dotazy nebo

připomínky k produktu, kontaktujte zákaznickou linku.

✉www.alza.cz/kontakt

✆+420 255 340 111

Dovozce: Alza.cz a.s., Jankovcova 1522/53, Holešovice, 170 00 Praha 7, www.alza.cz

Popis

Děkujeme za zakoupení mikrofonu BOYA!

BOYA BY-M3 je digitální lavalierový mikrofon USB typu C, který je speciálně navržen pro

zařízení Android a další zařízení s konektorem typu C, jako je iPad Pro, Mac PC.

S rozlišením 16 bitů / 48 kHz je vhodný pro podcasting, vlogování, rozhovory a další. Má

všesměrový polární vzor a design s klipem, který může účinně snížit nežádoucí šum na

pozadí a výrazně pomoci mobilním zařízením zachytit vysoce kvalitní zvukové záznamy.

Kabel dlouhý až 6 metrů umožňuje uživatelům pohodlně přizpůsobit různá prostředí.

Komponenty

1) USB Typ-C konektor

2) Mikrofon

3) Klip na oblečení

4) Pěnový kryt

POZNÁMKA:

Ne všechny aplikace pro Android mohou při pořizování videa podporovat externí mikrofon USB a

pro použití této funkce si možná budete muset stáhnout aplikaci jiného výrobce.
