MIC-WKT and MIC-WKT-IR

Installation Manual

EN Installation and Operation Manual

MIC-WKTI and MIC-WKT-IR Installation Manual EN | 2

Bosch Security Systems Issue 1

MIC-WKT and MIC-WKT-IR

Washer Pump Drive Card Kits for the MIC400

Camera Power Supply Units

Installation and Operation Manual

Chapters_______________________________________________

1. Introduction

2. Installation Instructions

3. Technical Specifications

MIC-WKTI and MIC-WKT-IR Installation Manual EN | 3

Bosch Security Systems Issue 1

Introduction............................................................. 1-7

Versions............................................................................................. 1-7

Features............................................................................................. 1-7

Unpacking.......................................................................................... 1-8

Packaging Contents........................................................................... 1-8

Installation…………………………………… ……… 2-9

705-200 Washer Pump Drive Card Functionality…..………………… 2-9

Installation ……………………………………………….……………….. 2-9

Connecting the washer pump to the IR power supply……………….. 2-11

Technical Specifications......................................... 3-13

Technical Specifications ……………………………………………….. 3-13

MIC-WKTI and MIC-WKT-IR Installation Manual EN | 4

Bosch Security Systems Issue 1

Safety Precautions

The following symbols are used throughout this manual please pay careful

attention to their meaning.

Important Safety Instructions

1. Read all instructions prior to installation.

2. Keep this manual for future reference.

3. Heed all warnings.

4. Install according to manufacturer’s instructions.

5. Qualified persons only should install this product, if in doubt consult a qualified

installer.

6. Use correct electrostatic discharge handling procedures when handling printed

circuit boards to avoid damage to electro-sensitive components.

7. Do not install near any strong heat sources such as furnaces.

8. Never push objects or pour liquids into the product enclosure as this can cause a

fire or electrical shock hazard.

9. Only use electronic cleaning solvent in the unlikely event of the card requiring

cleaning.

10. Ensure that the product is correctly earthed.

11. Use only the power sources indicated in this user guide and ensure that the

current rating of the supply cable is adequate for the product.

12. Do not overload power supply sockets as this can be a fire or electrical shock

hazard.

13. In the event of failure do not attempt to service this product yourself, please

contact Bosch Security Systems for assistance.

14. Only use approved attachments or accessories specified by the manufacturer. Any

changes or modifications made to the equipment, not expressly approved in writing

by Bosch Security Systems, could prevent proper or safe operation of the product

and will invalidate the warranty.

15. Please dispose of disused electrical & electronic equipment at an environmentally

compatible recycling facility (contact Bosch Security Systems for further details).

The lightning flash with an arrowhead symbol within a

triangle is intended to alert the user to the presence of non-

insulated “dangerous voltage” within the product’s

enclosure that may be of sufficient magnitude to constitute

a risk of electric shock to persons.

The exclamation point within a triangle is intended to alert

the user to the presence of important safety, operating and

maintenance (servicing) instructions in the literature

accompanying the appliance.

CAUTION

TO REDUCE THE RISK OF ELECTRICAL SHOCK,

DISCONNECT POWER SUPPLY BEFORE OPENING THE

POWER SUPPLY UNIT.

POWER DISCONNECT: POWER SUPPLY UNITS HAVE

POWER SUPPLIED WHENEVER THE POWER CORD IS

INSERTED INTO THE POWER SOURCE

WARNING

INSTALLATION SHOULD BE CARRIED OUT BY

QUALIFIED PERSONNEL ONLY IN ACCORDANCE

WITH THE APPLICABLE LOCAL CODES.

BOSCH SECURITY SYSTEMS ACCEPTS NO LIABILITY

FOR ANY DAMAGES OR LOSSES CAUSED DUE TO

INCORRECT OR IMPROPER INSTALLATION

MIC-WKTI and MIC-WKT-IR Installation Manual EN | 5

Bosch Security Systems Issue 1

This product complies with the following EC directives:-

EMC Directive (89/336/EC as amended)

Machinery Directive (98/37/EC)

LV Directive (73/23/EC)

RoHS (Restriction of Hazardous substances) 2002/95/EC

WEEE (Waste Electrical & Electronic Equipment) 2002/96/EC

Reference

Glossary of Terms

PTZ - Pan/Tilt/Zoom

PSU - Power Supply Unit

IR - Infra Red

Camset - Bosch Security Systems configuration & set up software,

please

This equipment contains electrical or electronic components

that must be recycled properly to comply with Directive

2002/96/EC of the European Union regarding the disposal of

waste electrical and electronic equipment (WEEE). Contact

your local supplier for procedures for recycling this

equipment.

MIC-WKTI and MIC-WKT-IR Installation Manual EN | 6

Bosch Security Systems Issue 1

CHAPTER 1 Introduction

The MIC-WKT and MIC-WKT-IR Washer Pump Drive Card Kits provide the

required fittings to enable third party washer kits to remotely clean the window of

the MIC400 camera.

MIC-WKTI and MIC-WKT-IR Installation Manual EN | 7

Bosch Security Systems Issue 1

Versions

This manual covers the installation and operation of Bosch Security Systems

MIC-WKT and MIC-WKT-IR Washer Pump Drive Card Kits for the MIC400 range

of PTZ Cameras.

The MIC-WKT kit consists of the 705-200 Washer Pump Drive Card, a 5mm single

jet washer nozzle and two (2) brackets to allow mounting of the washer nozzle on

to a MIC400 camera base or corner mount bracket (CMB) utilising the M8 x 20mm

fixing bolts holding the camera base or between wall and corner mount brackets.

The MIC-WKT-IR kit is identical to the MIC-WKT kit except for lacking the 705-200

Washer Pump Drive Card as this function is provided as standard on all MIC400 IR

Power Supplies.

The washer pump, reservoir bottle & 5mm tubing are not supplied by Bosch

Security Systems and will need to be purchased separately to suit the particular

installation.

The 705-200 is a Printed Circuit Board as shown below and plugs directly into Non

IR Power Supply Units for the MIC400 PTZ Camera.

This card is only required for MIC400 Power Supply Units which do not support

integrated washer or alarm operations, these are the following MIC400 Power

Supply Units:-

MIC-240PSU

MIC-12PSU

MIC-24PSU

MIC-115PSU

The following MIC400 Power Supply Units include 4 –Alarm inputs and a Washer

Pump Drive function as standard and details of setting up the washer drive are

included later in this manual, you may also refer to the MIC400 Power Supply

Units Installation and Operation Manual instead :-

MIC-IR-240PSU

MIC-IR-12PSU

MIC-IR-24PSU

MIC-IR-115PSU

Features

The MIC-WKT and MIC-WKT-IR Kits have the following features:

• Washer Pump Drive Card (for MIC-WKT)

• Easy installation into MIC400 non IR power supply units (for MIC-WKT)

• Push to Test button

• Choice of mounting brackets to suit most installations

• Washer Nozzle

MIC-WKTI and MIC-WKT-IR Installation Manual EN | 8

Bosch Security Systems Issue 1

Unpacking

• Check the exterior of the packaging for visible damage. If any items

appear to have been damaged in transit please inform the shipping

company.

• Unpack the unit carefully; although ruggedized this is electronic equipment

and should be handled with care.

• Do not use if any component appears to be damaged. Please contact

Bosch Security Systems in the event of damaged goods.

• The shipping cartoon is the best way to transport the unit, save it & all

other packaging materials for future use. If the unit must be returned, use

the original packing materials.

Packaging Contents

Please check for the following contents for the MIC-WKT Washer Kit

• MIC-WKT and MIC-WKT-IR Washer Kit Installation Manual (this Booklet)

• 705-200 Washer Pump Drive Card

• Single Jet Washer Nozzle (5mm)

• Two (2) Brackets for mounting the Washer Nozzle (200-007 & 200-008)

For the MIC-WKT-IR the following items should be included:-

• MIC-WKT and MIC-WKT-IR Washer Kit Installation Manual (this Booklet)

• Single Jet Washer Nozzle (5mm)

• Two (2) Brackets for mounting the Washer Nozzle (200-007 & 200-008)

CHAPTER 2 Installation

705-200 Washer Pump Drive Card Functionality

The 705-200 Washer Pump Drive Card provides an output relay (SK1) rated at

240vAC up to 5 Amps, wiring for this supply must be provided by the installer and

it is strongly recommended that this supply is externally fused.

A push to test button (SW1) is also provided to test the pump operation and expel

air to prime the pump ready for operation.

The drive signal Washer Dr is a TTL signal generated by the MIC400 camera, this

TTL signal causes the relay drive transistor to switch on thus energizing the relay

and closing the relay contacts thereby activating the supply to the washer pump.

WARNING: Use proper ESD handling precautions to avoid

electrostatic discharge. Wear a grounded wrist strap to

prevent damage when handling electro-sensitive printed

circuit boards.

MIC-WKTI and MIC-WKT-IR Installation Manual EN | 9

Bosch Security Systems Issue 1

Installation of the 705-200 Washer Pump Drive Card

Installation of the 705-200 Washer Pump Drive Card is best performed prior to

installing the Power Supply in the field. To install the 705-200 Washer Pump

Drive Card, please do the following:-

1. The power supply unit must be switched off and unplugged prior to

carrying out any work.

2. Ensure that the four (4) card spacer supports fitted in the power supply are

positioned in the left and right most mounting holes on the power supply

printed circuit board, so that the MIC-WSH card is supported in each

corner.

3. Should you need to reposition the card spacers first remove the four (4)

screws holding the power supply PCB to the enclosure, turn the PCB over

and remove the two (2) card spacer supports, these spacers should be re-

fixed at the correct positions shown as A and B on Figure 1 below.

4. Insert the 705-200 Washer Pump Drive Card so that the connector

labelled CN1 as shown on Figure 2 below plugs into the CN1 header on

the Power Supply labelled C on Figure 1. Then fix to the card spacer

supports using M3x6 screws.

5. The 705-200 Washer Pump Drive Card is now ready to accept third party

washer pump electrical connections. Please see Installation of the

Washer Pump for more details.

Figure 1:- MIC400 Non-IR Power Supply PCB Layout

A. Right hand - Add on

card support spacers &

holes

B. Centre – Add on

card support spacers &

holes

C. Connection

Header CN1

Figure 2:- 705-200 Washer Pump Drive Card PCB Layout

CAUTION: Electrical Danger: Ensure all power is disconnected

before opening or working upon the MIC400 Power Supply Unit.

Installation must be carried out by suitably qualified persons &

ll l

oca

ety

egu

ed.

MIC-WKTI and MIC-WKT-IR Installation Manual EN | 10

Bosch Security Systems Issue 1

Installation

To connect a third party washer pump, please do the following:-

1. Fit the washer nozzle to the appropriate bracket (wall or corner mount)

and then fix the washer nozzle bracket to the wall or corner bracket

using one of the M8 fixing bolts, ensure the washer nozzle points

towards the camera and does not obstruct the camera view see photo’s

on page 12 and 13 for installation of washer nozzle bracket.

2. Fit the washer pump and reservoir in a suitable location taking all

necessary safety precautions, observing the manufacturers instructions

and all applicable local building codes.

3. Connect the 5mm tubing from the pump to the washer nozzle.

4. Ensure the MIC400 Power Supply Unit is completely disconnected from

the power source.

5. Open the PSU lid and locate the washer pump drive header SK1 at the

upper left hand side of the 705-200 Washer Pump Drive Card (see

figure 2).

6. Feed the washer pump drive power cable through the one of the

weatherproof glands on the Power Supply Unit, leave sufficient slack to

connect to the SK1 terminal then tighten the gland. Bosch Security

Systemsstrongly recommends that the washer pump power cable

should be protected externally by a suitably rated fuse.

7. Connect the washer pump drive power cable to the 705-200 Washer

Pump Drive Card using the SK1 terminal, the connections required are

shown below:-

8. Secure all external pipe work and cabling, fill the reservoir then plug in

the MIC400 Power Supply Unit.

9. Press the push to test button (SW1) to test the pump operation, hold

button SW1 down to expel the air from the tubing & prime the pump for

operation.

10. When the pump is primed, close the MIC400 Power Supply Unit.

11. Point the MIC400 at the wash nozzle and set the wash wipe position via

the control room interface or via a laptop using Camset.

SK1 Pump Connections

1 Live

2 Neutral

3 Pump Neutral

4 Pump Live

CAUTION: Electrical Danger: Ensure all power is

disconnected before opening or working upon the MIC400

Power Supply Unit.

Installation must be carried out by suitably qualified persons

WARNING: The 705-200 may be connected via header SK1

to 240vAC or 24vAC pump systems. A correctly rated fuse

MUST be fitted for the expected current draw of the pump

system. Nominally this would be 2.5A for 240V and 5A for

24V pumps. In addition Bosch Security Systems

recommends that the external power supply feeding the

washer pump is protected with a suitably rated fuse.

Bosch Security Systems accepts no liability for damage or

injury caused by incorrect fuse installation.

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Sistema de seguridad de Bosch

Bosch

Bosch D9000 Series Guía de configuración

Bosch

Bosch CP156B Cómo utilizar

Bosch

Bosch Solution 144 Manual de usuario

Bosch

Bosch Solution 16plus Manual de usuario

Bosch

Bosch ICP-AMAX4-P2-EN Manual de usuario

Bosch

Bosch FNM-320 Series Manual de usuario

Bosch

Bosch PRAESENSA Manual de usuario

Bosch

Bosch Solution 16plus Manual de usuario

Bosch

Bosch Security System Manual de usuario

Bosch

Bosch PAVIRO Instrucciones de montaje

Bosch

Bosch D623 Series Manual de usuario

Bosch

Bosch MAP 5000 Series Manual de usuario

Bosch

Bosch FRP-OW3000 Manual de usuario

Bosch

Bosch Spexor Manual de usuario

Bosch

Bosch Solution 64 Manual de usuario

Bosch

Bosch DIP-6083-8HD Manual de usuario

Bosch

Bosch Plena LBB1990/00 Guía del usuario

Bosch

Bosch CC610PB Manual de usuario

Bosch

Bosch Plena Power Amplifier Instrucciones de montaje

Bosch

Bosch CCS 800 Ultro Manual de usuario

Bosch

Bosch B Series Manual de usuario

Bosch

Bosch Spexor Manual de usuario

Bosch

Bosch CC880/LP880, SC8016 Manual

Bosch

Bosch OD850F1 Manual de operación y mantenimiento

Manuales populares de Sistema de seguridad de otras marcas

Inner Range

Inner Range Concept 2000 Manual de usuario

Climax

Climax Mobile Lite R32 Instrucciones de montaje

CADDX

CADDX NX-6 Manual de usuario

FBII

FBII XL-31 Series Manual de usuario

Johnson Controls

Johnson Controls PENN Connected PC10 Manual de usuario

Aeotec

Aeotec Siren Gen5 Manual de usuario

Blaupunkt

Blaupunkt SA 2700 Manual de usuario

IDEAL

IDEAL Accenta Manual del propietario

AJAX

AJAX DoubleButton Manual de usuario

Swann

Swann SW-P-MC2 Manual de usuario

Ecolink

Ecolink Siren+Chime Manual de usuario

Digital Monitoring Products

Digital Monitoring Products XR150 Manual de usuario

EDM

EDM Solution 6+6 Wireless-AE Manual de usuario

Highway Safety Group

Highway Safety Group EA401 Manual de usuario

Siren

Siren LED GSM Manual de usuario

Detection Systems

Detection Systems 7090i Instrucciones de montaje

Se-Kure Controls

Se-Kure Controls MicroMini SK-4841 Manual de usuario

Siemens

Siemens FDM273 Manual de usuario
