Bosch MegaPixel NWC-0700 Manual de usuario

1en | Bosch Security Systems Megapixel IP Cameras

F.01U.032.595 | V 1.0 | 2007.03 Quick Install Guide Bosch Security Systems

Important Safety Instructions

Type numbers: NWC-0700, NWC-0800, NWC-0900

Read, follow, and retain all of the following safety instructions. Heed all

warnings on the unit and in the operating instructions.

1. Clean only with a dry cloth. Do not use liquid cleaners or aerosol clean-

ers.

2. Do not install unit near any heat sources such as radiators, heaters,

stoves, or other equipment (including amplifiers) that produce heat.

3. Do not block any ventilation openings.

4. Do not use the unit near water or expose to rain or moisture. Never

spill liquid of any kind on the unit.

5. Unplug the unit during lightning storms or when unused for long peri-

ods.

6. Adust only those controls specified in the operating instructions.

7. Do not overload outlets and extension cords, as this can cause fire or

electrical shock.

8. Protect the plug and power cord from foot traffic or pinching, at elec-

trical outlets, and at its exit from the unit.

9. Operate the unit only from the type of power source indicated on the

label.

10. Unless qualified, do not attempt to service a damaged unit yourself.

Refer all servicing to qualified service personnel.

11. Use only replacement parts specified by the manufacturer.

12. Install in accordance with the manufacturer's instructions in accor-

dance with applicable local codes.

13. Use only attachments/accessories specified by the manufacturer.

Equipment change or modification could void the user's guarantee or

authorization agreement.

DANGER! High risk:

This symbol indicates an imminently hazardous situation such

as "Dangerous Voltage" inside the product.

If not avoided, this will result in an electrical shock, serious

bodily injury, or death.

WARNING! Medium risk:

Indicates a potentially hazardous situation.

If not avoided, this could result in serious bodily injury or death

CAUTION!

Indicates a potentially hazardous situation. If not avoided, this

may result in minor or moderate injury. Alerts the user to

important instructions accompanying the unit.

Megapixel IP Cameras Quick Install Guide | en 2

Bosch Security Systems Quick Install Guide F.01U.032.595 | V 1.0 | 2007.03

CAUTION!

Indicates a potentially hazardous situation.

If not avoided, this may result in property damage or risk of

damage to the unit.

NOTICE!

This symbol indicates information or a company policy that

relates directly or indirectly to the safety of personnel or

protection of property.

CAUTION!

– U.S.A. models only - Section 810 of the National Electrical

Code, ANSI/NFPA No. 70, provides information regarding

proper grounding of the mount and supporting structure,

location of discharge unit, connection to ground elec-

trodes, and requirements for the grounding electrode.

– Power lines: do not locate the camera near overhead

power lines, power circuits, electrical lights, or where it

may contact such power lines, circuits, or lights.

– Operate the unit only from the type of power source indi-

cated on the label. Before proceeding, be sure to discon-

nect the power from the cable to be installed into the unit.

– For external power supplied units, use only the rec-

ommended or approved power supplies.

–Forlimitedpowersourceunits, this power source

must comply with EN60950. Substitutions may dam-

age the unit or cause fire or shock.

– For 9-12 VDC units, voltage applied to the unit's

power input should not exceed 12.3 VDC. User-sup-

plied wiring must comply with local electrical codes

(Class 2 power levels). Do not ground the supply at

the terminals or at the unit's power supply terminals.

If unsure of the type of power supply to use, contact your

dealer or local power company.

NOTICE! You can view and print the full version of this

Installation Manual with Adobe Acrobat Reader, both provided

on the enclosed CD-ROM. This user guide is the intellectual

property of Bosch Security Systems; protected by copyright.

3en | Bosch Security Systems Megapixel IP Cameras

F.01U.032.595 | V 1.0 | 2007.03 Quick Install Guide Bosch Security Systems

FCC & ICES INFORMATION

(U.S.A. and Canadian Models Only)

This device complies with part 15 of the FCC Rules. Operation is subject to

the following conditions:

– this device may not cause harmful interference, and

– this device must accept any interference received, includ-

ing interference that may cause undesired operation.

The user may find the following booklet, prepared by the Federal Communi-

cations Commission, helpful: How to Identify and Resolve Radio-TV Interfer-

ence Problems. This booklet is available from the U.S. Government Printing

Office, Washington, DC 20402, Stock No. 004-000-00345-4.

NOTICE!

This equipment has been tested and found to comply with the

limits for a Class A digital device, pursuant to Part 15 of the

FCC Rules and ICES-003 of Industry Canada. These limits are

designed to provide reasonable protection against harmful

interference when the equipment is operated in a commercial

environment. This equipment generates, uses, and radiates

radio frequency energy and, if not installed and used in accor-

dance with the instruction manual, may cause harmful interfer-

ence to radio communications. Operation of this equipment in a

residential area is likely to cause harmful interference, in which

case the user will be required to correct the interference at his

expense.

Intentional or unintentional modifications, not expressly

approved by the party responsible for compliance, shall not be

made. Any such modifications could void the user's authority to

operate the equipment. If necessary, the user should consult

the dealer or an experienced radio/television technician for cor-

rective action.

WARNING!

This is a class A product. In a domestic environment this

product may cause radio interference, in which case the user

may be required to take adequate measures.

Megapixel IP Cameras Quick Install Guide | en 4

Bosch Security Systems Quick Install Guide F.01U.032.595 | V 1.0 | 2007.03

1 Quick Install Guide

1.1 Camera installation using PoE switch

Equipment needed:

– PC with 100baseT or better network port

– 100 baseT or better network switch with PoE capability

–2CAT5Networkcables

1. Attach camera to a PoE port of the network switch with

CAT5 cable.

2. Attach (non-PoE) switch port to the PC LAN port with

CAT5 cable.

3. Manual iris lens: Check the lens to make sure the F-Stop is

between F2.8 and F4.0.

4. DC-iris lens: Ensure that the DC-iris cable is plugged into

the iris connector on the rear of the camera.

5. Plug in the switch's power cord.

6. A yellow LED on the back of the camera should light up

after a few seconds.

– This LED indicates that a link to the computer has

been established.

– A green LED will blink when the camera is accessed.

1.2 Camera installation with direct connection

to PC

Equipment needed:

– PC with 100baseT or better network port

– 1 CAT5 cross-linked network cable

– Power supply unit: 9-12 VDC, 500 mA.

CAUTION!

Never supply power via the Ethernet connection (PoE) when

power is already supplied via the power connector.

CAUTION!

For 9-12 VDC units, voltage applied to the unit's power input

should not exceed 12.3 VDC.

5en | Bosch Security Systems Megapixel IP Cameras

F.01U.032.595 | V 1.0 | 2007.03 Quick Install Guide Bosch Security Systems

1. Attach camera to the 100 Mbps network input of the PC

with the cross-link CAT 5 cable.

2. Manual iris lens: check the lens to make sure the F-Stop is

between F2.8 and F4.0.

3. DC-iris lens: plug in the DC-iris cable into the iris connec-

tor on the rear of the camera.

4. Plug in the camera power cord.

5. A yellow LED on the back of the camera should light up

after a few seconds.

– This LED indicates that a link to the computer has

been established.

– A green LED will blink when the camera is accessed.

1.3 Setting camera IP address

The camera is supplied with installation software on CD. The

installation software assists setting up the camera's IP address.

To run the installation software:

1. Make sure your Windows XP/2K account has administrative

privileges.

2. Using Windows Explorer, navigate to the CD and double

click the installer.exe file. The camera installer program

opens.

1.3.1 Configure firewall

As you start the application, your PC may prompt you to permit

its access to the network.

Allow the Camera Installer program to access the network.

1.3.2 Assigning IP addresses

Choosing between Basic or Advanced modes:

– Only use Basic mode (default) if the network does not

have other devices connected.

– Use Advanced mode if the network has other devices con-

nected (this is because using Automatic mode risks dupli-

cating existing IP addresses).

Megapixel IP Cameras Quick Install Guide | en 6

Bosch Security Systems Quick Install Guide F.01U.032.595 | V 1.0 | 2007.03

Basic mode

1. Click Automatic. The install program will scan the network

for all connected MegaPixel cameras and assign an IP

address automatically within the network segment of the

host PC.

When all the connected cameras show 'Success' in the

Results column, the installation process is complete.

2. Write down the (MAC) Ethernet address, corresponding IP

address, and installed location.

3. Click Save / Exit when done.

Fig. 1.1 Camera installation in basic mode showing results

7en | Bosch Security Systems Megapixel IP Cameras

F.01U.032.595 | V 1.0 | 2007.03 Quick Install Guide Bosch Security Systems

Fig. 1.2 Camera installation in advanced mode showing results

Advanced mode

1. Start making a list of Ethernet (MAC) addresses and IP

addresses assigned to them. The Ethernet address is on

the camera label.

2. Click Find Cameras.

3. Select a camera by clicking its Ethernet address.

4. Enter the IP address assigned to that camera in the New

Camera IP box.

5. Click Set IP.

6. Click Automatic.

7. Wait for result to change from unchecked to success.

8. Click Save / Exit when done.

Viewing the image

1. Open Internet Explorer.

2. In the address line, enter http://IPADDRESS/index.html.

3. Click Video to display the image.

4. Adjust the lens for optimal focus.

NOTICE! Adjust back focus if necessary.

a. Loosen the set screws in the top and bottom of the

front panel (use 1/16 inch hex key).

Megapixel IP Cameras Quick Install Guide | en 8

Bosch Security Systems Quick Install Guide F.01U.032.595 | V 1.0 | 2007.03

b. Rotate lens in or out with back focus ring until focus is

obtained.

c. Fasten the two set screws.

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Cámara de seguridad de Bosch

Bosch

Bosch MIC Series 550 Manual de usuario

Bosch

Bosch FlexiDomeXF VDC-485V03-20 Manual de usuario

Bosch

Bosch FLEXIDOME IP panoramic 6000 Series Manual de usuario

Bosch

Bosch NUC-52051-F0 Manual de usuario

Bosch

Bosch VDN-498V06-21S Manual de usuario

Bosch

Bosch FLEXIDOME IP micro 2000 Manual de usuario

Bosch

Bosch VG4-200 Series Manual de usuario

Bosch

Bosch DINION IP starlight 7000 HD Manual de usuario

Bosch

Bosch FlexiDome NDN-498V03-21P Manual de usuario

Bosch

Bosch Dinion LTC0335/20 Manual de usuario

Bosch

Bosch MIC Series 400 Manual de usuario

Bosch

Bosch EXTEGRA IP 9000 FX NXF-9x30 Manual de usuario

Bosch

Bosch NIN-73023 Manual de usuario

Bosch

Bosch AUTODOME IP starlight 5000i Manual de usuario

Bosch

Bosch DINION IP ultra 8000 MP Instrucciones de uso

Bosch

Bosch NBN-733 Manual de usuario

Bosch

Bosch VEZ-221-ECCE Manual de usuario

Bosch

Bosch MIC IP starlight 7000i Manual de usuario

Bosch

Bosch MIC IP starlight 7000i Manual de usuario

Bosch

Bosch AUTODOME IP starlight 5000i Manual de usuario

Bosch

Bosch VG4-161-CC0 Manual de usuario

Bosch

Bosch LTC-0498-21 Manual de instrucciones

Bosch

Bosch AutoDome Junior Manual de usuario

Bosch

Bosch FLEXIDOME AN micro 1000 Manual de usuario

Manuales populares de Cámara de seguridad de otras marcas

Okina USA

Okina USA SIR36-870VF650LP Manual de usuario

Divio

Divio NDR155PA Manual de usuario

Canon

Canon VB-C500D Manual de usuario

Easy Access

Easy Access EasyGuard Manual de usuario

Vivotek

Vivotek FD9389-EHV-v2 Manual de usuario

TUYA

TUYA COSMO W2 Manual de usuario

Eusso

Eusso UNC7500-IR Guía de configuración

urmet domus

urmet domus 1096/204 Manual de usuario

VC VC20 series Manual de usuario

Axis

Axis Q1614 Manual de usuario

ieGeek

ieGeek DD201 Manual de usuario

VADDIO

VADDIO ClearVIEW HD-USB PTZ 999-6990-000 Manual de usuario

Vicon

Vicon V662-D-1 Instrucciones de funcionamiento

Grundig

Grundig GCH-K0274P Manual de usuario

Lorex

Lorex VANTAGE LBC7032 Manual de usuario

4xem

4xem WPT Manual de usuario

Samsung

Samsung SCV-3082 Manual de usuario

Vitek

Vitek VTC-C544 Manual de usuario
