Bosch VC7D1305T Manual de usuario

Bosch Security Systems | 2003-08 | Version 2

EN | 1

VCM7D130/00T & VC7D1305T

| Installation Instructions

IMPORTANT SAFEGUARDS

Installation Instructions

ENGLISH

1. Read these instructions.

2. Keep these instructions.

3. Heed all warnings.

4. Follow all instructions.

5. Do not use this apparatus near water.

6. Clean only with dry cloth.

7. Install in accordance with the manufacturerís instructions.

8. Do not install near any heat sources such as radiators, heat

registers, stoves, or other apparatus (including amplifiers) that

produce heat.

9. Protect the power cord from being walked on or pinched

particularly at plugs, convenience receptacles, and the point

where they exit from the apparatus.

10. Only use attachments/accessories specified by the manufacturer.

11. Unplug this apparatus during lightning storms or when unused

for long periods of time.

12. Refer all servicing to qualified service personnel. Servicing is

required when the apparatus has been damaged in any way, such

as power-supply cord or plug is damaged, liquid has been spilled

or objects have fallen into the apparatus, the apparatus has been

exposed to rain or moisture, does not operate normally, or has

been dropped.

13. To reduce the risk of fire or electric shock, do not expose this

apparatus to rain or moisture.

14. The apparatus shall not be exposed to dripping or splashing.

15. Do not install this equipment in a confined space such as a

bookcase or similar unit.

Bosch Security Systems | 2003-08 | Version 2

EN | 2

VCM7D130/00T & VC7D1305T

| Installation Instructions

WARNING

This device is intended for use in public areas only. Surreptitious

recording of oral communications is strictly prohibited by US Federal

law. The manufacturer recommends posting obvious signs to warn

that oral communications are being recorded.

FCC INFORMATION

This equipment has been tested and found to comply with the limits

for a Class B digital device, pursuant to Part 15 of the FCC Rules.

These limits are designed to provide reasonable protection against

harmful interference in a residential installation. This equipment

generates, uses and can radiate radio frequency energy and, if not

installed and used in accordance with the instructions, may cause

harmful interference to radio communications. However, there is no

guarantee that interference will not occur in particular installation. If

this equipment does cause harmful interference to radio or television

reception, which can be determined by turning the equipment off and

on, the user is encouraged to try to correct the interference by one or

more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into and outlet on a circuit different form

that to which the receiver is connected.

• Consult the dealer or an experienced radio/ TV technician for

help.

ATTENTION:

INSTALLATION SHOULD BE PERFORMED BY

QUALIFIED SERVICE PERSONNEL ONLY IN

ACCORDANCE WITH THE NATIONAL ELECTRICAL

CODE OR APPLICABLE LOCAL CODES.

Bosch Security Systems | 2003-08 | Version 2

EN | 3

VCM7D130/00T & VC7D1305T

| Installation Instructions

Servicing: Do not attempt to service this product yourself as

removing covers expose you to dangerous voltage or other hazards.

Refer all servicing to qualified service personnel.

Damage requiring service: Unplug this product from the wall outlet

and referservicing to qualified service personnel.

Replacement Parts: When replacement parts are required, be sure the

service technician has used replacement parts specified by the

manufacturer or have the same characteristics as the original part.

Unauthorized substitutions may result in fire, electric shock, or other

hazards.

Safety Check: Upon completion of any service or repairs to this

product, ask the service technician to perform safety checks to

determine that the product is in proper operating condition.

1. INTRODUCTION

This Dome camera is designed for use with Bosch Color Observation

Systems only. It combines a high sensitivity sensor with advanced

digital signal processing, resulting in a high quality Dome camera

with excellent performance even under difficult circumstances.

2. STANDARD PACKAGE INCLUDED

• Screws x 2pcs

• Dome camera x 1pc

• Dual twisted pair cable - 15 metres x 1pc

•DFUx1pc

Bosch Security Systems | 2003-08 | Version 2

EN | 4

VCM7D130/00T & VC7D1305T

| Installation Instructions

3. INSTALLATION (refer to fig. 1)

To obtain the best results from your new Dome camera, read these

instructions carefully before use. Retain the manual for future

reference. Recommended for indoor Application Only.

This chapter describes the installation of the Dome camera. For more

detailed information about the installation and operation of the

system monitor you should consult the monitor manuals.

Remark: When the system configuration is altered, the system

monitor needs to check and memorise the cameras and accessories

connected to its inputs. This is done automatically when the mains

power is switched on (rear switch).

Use a screwdriver to

release clip

120º Horz; 120º Vertical;

360º Rotation

Pull Dome cover

to remove

Mounting screws

Fig. 1

Bosch Security Systems | 2003-08 | Version 2

EN | 5

VCM7D130/00T & VC7D1305T

| Installation Instructions

When you unpack the Dome camera, the physical default position of

the camera is that the top of the image is correspondant to the camera

'Bosch' logo side.

Before starting the installation, remove the tinted dome by pulling it

off and put it in a safe place to avoid stains and scratches

MOUNTING THE UNIT:

The unit has two cable entries for:

• Cables' route is through the surface like false ceiling or in a

wall (bottom entry)

• Cables' route is on the surface like concrete wall (side entry)

1. Open the mounting plate (1) by pushing the side tab (2b). You

can remove the mounting plate by unhooking from the tab (2a).

2. Using the mounting plate (1) as template, drill holes for camera

mount and cable entry as appropriate.

3. Connect the Dome camera to the system monitor.

4. Locate cable into the appropriate routing clip

5. Fit the camera onto the mounting plate, by hooking the clip (2a),

and then ensuring the tab (2b) clicks into it's location.

6. Connect the system monitor to the mains.

7. Switch on the mains power switch.

8. The monitor will check the system. After a short time the Dome

camera image will appear on the monitor screen.

9. If necessary adjust contrast /brightness and/or color (See the

View Settings menu of the monitor) to optimize the image on the

system monitor.

10. Adjust the viewing direction of the ball camera (3) and ensure

that the picture display on the monitor is level.

11. Click the tinted dome in place and if necessary clean its surface

with a soft cloth.

Bosch Security Systems | 2003-08 | Version 2

EN | 6

VCM7D130/00T & VC7D1305T

| Installation Instructions

Note:

The image sensors in modern CCD cameras are highly sensitive and

require special care for proper performance and extended lifetime.

Please follow the guidelines to get optimum results of your camera:

• Do not expose to direct sunlight or bright spotlights in operating

and non-operating conditions.

• Avoid bright lights in the field of view of the camera.

• These bright lights will cause a "smearing" effect, which is

visible as white lines above and below the highlight.

• Bright lights may cause bleaching of the sensor's color filters.

This will be visible as colored spots in the picture and is

irreversible.

Field of view

The figure below shows the Field of view

Bosch Security Systems | 2003-08 | Version 2

EN | 7

VCM7D130/00T & VC7D1305T

| Installation Instructions

Dome camera sound on/off

Use the On Screen Display Menus of your system monitor to enable

or disable the built-in Dome camera microphone.

System Cable

For the interconnections between the system monitor and Dome

camera 15m/45ft system cable is supplied.

For an optimum picture and sound quality you should always use 4-

wire dual twisted-pair cable when extending the connection. The

maximum allowed cable length is 200m/600ft.

Pay attention that the connectors are fixed to the cable corresponding

to the figure.

CAUTION:

The plugs used for the observation system have the same

dimensions as standard telephone plugs. Never connect a

telephone to the Dome camera or system monitor.

4-5

2-3

4-5

2-3

Bosch Security Systems | 2003-08 | Version 2

EN | 8

VCM7D130/00T & VC7D1305T

| Installation Instructions

4. TIPS FOR MAINTENANCE

Cleaning

You can clean the outside of the Dome camera with a moist fluff-free

cloth or shammy leather cloth.

When cleaning the Dome camera lens a special cleaning cloth should

be used. Do NOT use cleaning fluids based on alcohol, methylated

spirit, ammonia, etc..

Never touch the glass of the Dome camera lens to prevent its delicate

coating from damaging.

Avoid direct contact with water.

5. SPECIFICATIONS

Accessories

The following Dome camera accessories are available:

• Extension system cables (loop resistance max. 16 Ωat 100m).

• Cable extension box for providing additional power and cable

length compensation to the Dome camera at large distances (up

to 300m).

Electro Magnetic Compatibility (EMC)

This equipment complies with the European EMC directive used

standards:

EN50130-4, EN55022

USA standard: FCC part 15, class B

Australia AS/NZS 3548

VCM7D130/00T PAL Integrated lens

VC7D1305T NTSC Integrated lens

Bosch Security Systems | 2003-08 | Version 2

EN | 9

VCM7D130/00T & VC7D1305T

| Installation Instructions

Safety

according to European standard EN60065 ; USA UL6500

Environmental conditions:

This camera can be connected to a previous generation Color

Observation System Monitor at a length of 15 meters. By using an

interface box for every camera the cable length can be up to 200

meters.

If you have any problems, contact your dealer.

Operating temperature -10ºC +45ºC

Non operating temperature -25ºC +70ºC

Relative humidity Non-condense 0% to 95% RH

Input Voltage, via tp-input: 24VDC

Power consumption, Typical 2.5W

Weight 0.31 kg

Dimensions Ø 115 mm h = 80 mm

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Cámara de seguridad de Bosch

Bosch

Bosch KBN Series Manual de usuario

Bosch

Bosch WZ20NXV550-0 Manual de usuario

Bosch

Bosch AUTODOME IP starlight 5000i IR Manual de usuario

Bosch

Bosch EX70MNX804-N Manual de usuario

Bosch

Bosch VG4-522-ECS0WF Manual de usuario

Bosch

Bosch AUTODOME IP starlight 5000i Manual de usuario

Bosch

Bosch MicroDome NDC-274-P Manual de usuario

Bosch

Bosch VDC-455V09-20S Manual de usuario

Bosch

Bosch FlexiDomeXF VDC-485V03-10 Manual de usuario

Bosch

Bosch FLEXIDOME IP starlight 7000 VR Manual de usuario

Bosch

Bosch FLEXIDOME corner 9000 MP Instrucciones de montaje

Bosch

Bosch FLEXIDOME starlight Manual de usuario

Bosch

Bosch VEZ-400 Series Manual de usuario

Bosch

Bosch EX72C7V0922-N Manual de usuario

Bosch

Bosch FLEXIDOME IP indoor 5000 Manual de usuario

Bosch

Bosch MIC Series 500 Manual de usuario

Bosch

Bosch VG4-100 Series Manual de usuario

Bosch

Bosch VDC-230 Manual de usuario

Bosch

Bosch KBE-498V28-20 Manual de usuario

Bosch

Bosch BasicDome G3B Series Manual de usuario

Bosch

Bosch VG4-322-ECS0WF Manual de usuario

Bosch

Bosch series VG4-300 Manual de usuario

Bosch

Bosch LTC 0465 Series Manual

Bosch

Bosch VG5 600 Series Manual de usuario

Manuales populares de Cámara de seguridad de otras marcas

Okina USA

Okina USA SIR36-870VF650LP Manual de usuario

Divio

Divio NDR155PA Manual de usuario

Canon

Canon VB-C500D Manual de usuario

Easy Access

Easy Access EasyGuard Manual de usuario

Vivotek

Vivotek FD9389-EHV-v2 Manual de usuario

TUYA

TUYA COSMO W2 Manual de usuario

Eusso

Eusso UNC7500-IR Guía de configuración

urmet domus

urmet domus 1096/204 Manual de usuario

VC VC20 series Manual de usuario

Axis

Axis Q1614 Manual de usuario

ieGeek

ieGeek DD201 Manual de usuario

VADDIO

VADDIO ClearVIEW HD-USB PTZ 999-6990-000 Manual de usuario

Vicon

Vicon V662-D-1 Instrucciones de funcionamiento

Grundig

Grundig GCH-K0274P Manual de usuario

Lorex

Lorex VANTAGE LBC7032 Manual de usuario

4xem

4xem WPT Manual de usuario

Samsung

Samsung SCV-3082 Manual de usuario

Vitek

Vitek VTC-C544 Manual de usuario
