Bosch GLL 30 Instrucciones de montaje

Operating / Safety Instructions

Consignes d’utilisation / de sécurité

Instrucciones de funcionamiento y seguridad

GLL 30

Professional

GLL 30

IMPORTANT:

Read Before Using

IMPORTANT :

Lire avant usage

IMPORTANTE:

Leer antes de usar

English Version

See page 5 Version française

Voir page 18 Versión en español

Ver la página 33

1-877-BOSCH99 (1-877-267-2499) www.boschtools.com

-2-

-3-

1213

-4-

Make sure that

this device

and the tool

are securely

mounted

before

operation.

Assurez-vous

que cet appareil

et l’outil sont

solidement

assujettis avant de

les utiliser.

Asegúrese de que

este dispositivo

y la herramienta

estén montados

de manera segura

antes de su

utilización.

WARNING

AVERTISSEMENT

ADVERTENCIA

-5-

Read all instructions. Failure to follow all

instructions listed below may result in

hazardous radiation exposure, electric shock, fire and/or serious

injury.

SAVE ALL WARNINGS AND INSTRUCTIONS FOR

FUTURE REFERENCE

The term “tool” in the warnings listed below refers to your mains-

operated (corded) tool or battery-operated (cordless) tool.

The following labels are

on your laser tool for

your convenience and

safety. They indicate where

the laser light is emitted by the tool. ALWAYS BE AWARE of their

location when using the tool.

Do not direct the laser beam at persons or animals

and do not stare into the laser beam yourself. This tool

produces laser class 2 laser radiation and complies

with 21 CFR 1040.10 and 1040.11 except for deviations

pursuant to Laser Notice No. 50, dated June 24, 2007. This can

lead to persons being blinded.

Changes or modifications to this equipment not expressly

approved by the party responsible for compliance could void the

user’s authority to operate the equipment.

Use of controls or adjustments or performance of procedures

other than those specified herein may result in hazardous

radiation exposure.

DO NOT remove or deface any warning or caution labels.

Removing labels increases the risk of exposure to laser radiation.

General Safety Rules

WARNING

-6-

ALWAYS make sure that any bystanders in the vicinity of use are

made aware of the dangers of looking directly into the laser tool.

DO NOT place the laser tool in a position that may cause anyone

to stare into the laser beam intentionally or unintentionally.

Serious eye injury could result.

ALWAYS position the laser tool securely. Damage to the laser tool

and/or serious injury to the user could result if the laser tool fails.

ALWAYS use only the accessories that are recommended by the

manufacturer of your laser tool. Use of accessories that have been

designed for use with other laser tools could result in serious injury.

DO NOT use this laser tool for any purpose other than those

outlined in this manual. This could result in serious injury.

DO NOT leave the laser tool “ON” unattended in any operating

mode.

DO NOT disassemble the laser tool. There are no user serviceable

parts inside.

DO NOT modify the product in any way. Modifying the laser tool

may result in hazardous laser radiation exposure.

DO NOT use the laser viewing glasses as safety goggles. The

laser viewing glasses are used for improved visualization of the laser

beam, but they do not protect against laser radiation.

DO NOT use the laser viewing glasses as sun glasses or in traffic.

The laser viewing glasses do not afford complete UV protection and

reduce color perception.

DO NOT use any optical tools such as, but not limited to,

telescopes or transits to view the laser beam. Serious eye injury

could result.

DO NOT stare directly at the laser beam or project the laser beam

directly into the eyes of others. Serious eye injury could result.

-7-

Work area safety

Keep work area clean and well lit. Cluttered or dark areas invite

accidents.

DO NOT operate the laser tool around children or allow children

to operate the laser tool. Serious eye injury could result.

Electrical safety

Batteries can explode or leak, cause injury or fire. To reduce this

risk, always follow all instructions and warnings on the battery label and

package.

DO NOT short any battery terminals.

DO NOT charge alkaline batteries.

DO NOT mix old and new batteries.

Replace all of them at the same time with new batteries of the

same brand and type.

DO NOT mix battery chemistries. Dispose of or recycle batteries

per local code.

DO NOT dispose of batteries in fire.

Keep batteries out of reach of children.

Remove batteries if the device will not be used for several

months.

Personal safety

Stay alert, watch what you are doing and use common sense

when operating a tool. Do not use a tool while you are tired or

under the influence of drugs, alcohol or medication. A moment of

inattention while operating a tool may result in serious personal injury

or incorrect measurement results.

-8-

Use safety equipment. Always wear eye protection. Safety

equipment such as dust mask, non-skid safety shoes, hard hat, or

hearing protection used for appropriate conditions will reduce personal

injuries.

Use and care

Use the correct tool for your application. The correct tool will do the

job better and safer.

Do not use the tool if the switch does not turn it on and off. Any

tool that cannot be controlled with the switch is dangerous and must be

repaired.

Store idle tool out of the reach of children and do not allow

persons unfamiliar with the tool or these instructions to operate

the tool. Tools are dangerous in the hands of untrained users.

Maintain tools. Check for misalignment or binding of moving

parts, breakage of parts and any other condition that may

affect the operation. If damaged, tool repaired before use. Many

accidents are caused by poorly maintained tools.

Use the tool, accessories, etc., in accordance with these

instructions and in the manner intended for the particular type

of tool, taking into account the working conditions and the work

to be performed. Use of the tool for operations different from those

intended could result in a hazardous situation.

Service

Have your tool serviced by a qualified repair person using only

identical replacement parts. This will ensure that the safety of the

tool is maintained.

Develop a periodic maintenance schedule for tool. When cleaning

a tool be careful not to disassemble any portion of the tool since

-9-

internal wires may be misplaced or pinched or may be improperly

mounted. Certain cleaning agents such as gasoline, carbon

tetrachloride, ammonia, etc. may damage plastic parts.

SAVE THESE INSTRUCTIONS.

Preparation

Inserting/Replacing the Battery

Use only alkaline batteries.

To open the battery lid 4, press the latch of the battery lid 3and fold the

battery lid up. Insert the supplied batteries.

When inserting, pay attention to the correct polarity according to the

representation on the inside of the battery compartment.

When the batteries are low, the laser beams flash 0.10 s off, 0.20 s on,

0.10 s off, 1.0 s on in a cycle.

Always replace all batteries at the same time. Only use batteries from

one brand and with the identical capacity.

Remove the batteries from the tool when not

using it for extended periods. When storing for

extended periods, the batteries can corrode and discharge themselves.

The tool is intended for determining and checking horizontal and

vertical lines. The measuring tool is suitable exclusively for operation in

enclosed working sites.

Intended Use

WARNING

-10-

The numbering of the product features shown refers to the illustration

of the tool on the graphic page.

1Laser beam outlet

2On/Off switch

3Latch of battery lid

4Battery lid

51/4”-20 screw of flexible mounting device

6Locking screw of flexible mounting device

7Fastening screw of flexible mounting device

8Flexible mounting device

9Tripod mount 1/4”-20

10 Laser warning label

11 Serial number

12 Tripod*

13 Laser viewing glasses*

*not included.

Features
