Bosch AMC2-16IOE Manual de usuario

AMC2 Extensions

AMC2-16IOE / -8IOE / -16IE

en Installation Manual

Table of contents

1Safety Instructions 5

1.1 Important Safety Notes 5

1.2 Safety Precautions 7

1.3 Unpacking 9

2Important Information 10

2.1 Explanation of symbols in this document 10

2.2 Internet 11

3Introduction 12

3.1 Description 12

3.1.1 Extension AMC2-16IOE 12

3.1.2 Extension AMC2-8IOE 13

3.1.3 Extension AMC2-16IE 14

3.2 Equipment Configuration 15

3.3 Performance Characteristics 16

3.4 System Overview 17

4Installing 19

4.1 Mounting 19

4.2 Unmounting 20

4.3 Opening the Case 21

4.4 Closing the Case 22

4.5 Cabling 23

4.5.1 Conductor data 23

4.6 Grounding and Shielding 25

4.6.1 Grounding for Extension Interface 26

4.7 Connecting Power Supply 27

4.7.1 Direct Power Supply 27

4.7.2 Power Supply via RS-485 Interface 28

4.7.3 Overview - Power supply/consumption 29

4.8 RS-485 for extension modules 32

4.8.1 Addressing 33

4.9 Connecting Relay Outputs 33

4.10 Connecting Analog Input Devices 38

4.11 Tamper Protection 41

AMC2 Extensions Table of Contents | en 3

Bosch Sicherheitssysteme GmbH 2016-11 | AMC2-16IOE |

5Operating 42

5.1 Status Display of the AMC2 42

6Technical Data 44

7Appendices 48

7.1 Connecting Diagrams 48

Index 52

4en | Table of Contents AMC2 Extensions

2016-11 | AMC2-16IOE | Bosch Sicherheitssysteme GmbH

Safety Instructions

Important Safety Notes

1. Read, follow, and retain instructions - All safety and

operating instructions must be read and followed properly

before putting the unit into operation. Retain instructions

for future reference.

2. Do not ignore warnings - Adhere to all warnings on the unit

and in the operating instructions.

3. Accessories - Use only accessories recommended by the

manufacturer or those sold with the product. Accessories

not recommended by the manufacturer must not be used,

as they may cause hazards.

4. Installation precautions - Do not place this unit on an

unstable stand, tripod, bracket, or mount. The unit may fall,

causing serious injury to persons and damage to the unit.

Mount the unit according to the manufacturer’s

instructions.

5. Service - Do not attempt to service this unit by yourself.

Opening or removing covers may expose you to dangerous

voltages or other hazards. Refer all servicing to qualified

service personnel.

6. Damage which requires service - Disconnect the unit from

the main AC or DC power source and refer servicing to

qualified service personnel under the following conditions:

– If the power supply cord or plug is damaged.

– If liquid has been spilled or an object has fallen into

the unit.

– If the unit has been exposed to water and/or inclement

weather (rain, snow, etc.).

– If the unit does not operate normally when following

the operating instructions. Adjust only those controls

specified in the operating instructions. Improper

1.1

AMC2 Extensions Safety Instructions | en 5

Bosch Sicherheitssysteme GmbH 2016-11 | AMC2-16IOE |

adjustment of other controls may result in damage,

and require extensive work by a qualified technician to

restore the unit to normal operation.

– If the unit has been dropped or the cabinet damaged.

– If the unit exhibits a distinct change in performance.

7. Replacement parts - If replacement parts are required, the

service technician must use only replacement parts that are

specified by the manufacturer. Unauthorized replacements

may result in fire, electrical shock or other hazards.

8. Safety check - Upon completion of service or repair work

on the unit, ask the service technician to perform safety

checks to ensure that the unit operates properly

9. Power sources - Operate the unit only from the type of

power source indicated on the label. If unsure of the type

of power supply to use, contact your dealer

10. Lightning - For added protection during electrical storms

external lightning conductors can be installed. This

prevents power surges from damaging the unit.

11. The units should be installed in locations with restricted

access.

6en | Safety Instructions AMC2 Extensions

2016-11 | AMC2-16IOE | Bosch Sicherheitssysteme GmbH

Safety Precautions

Read instructions!

Before working with the AMC2 device, read these instructions

carefully. Make sure you have understood all information

described in this document.

Warning!

Risk of electric shock

External power supplies must be installed and put into service

by qualified personnel.

Ensure compliance with the relevant regulations.

Ground the controller.

Disconnect both AC and battery power supply before working

on the controller.

Warning!

Risk of fire

Installation of the AMC2 device must comply with any local fire,

health, and safety regulations. A secured door that may be part

of an escape route from an area must be installed with:

Install a fail-safe lock (A), so that the door will be released if

power fails. Ideally, use a magnetic lock.

Install a normally-closed break glass or a manual pull (B) in the

lock supply wiring, so that in an emergency the fail-safe lock

can be immediately powered down.

1.2

AMC2 Extensions Safety Instructions | en 7

Bosch Sicherheitssysteme GmbH 2016-11 | AMC2-16IOE |

Warning!

Risk of explosion of Lithium battery

The battery can explode if it is replaced incorrectly.

Replace only with the same type as recommended by the

manufacturer.

Dispose used batteries according to the battery manufacturer’s

instructions.

Notice!

Risk of damage to equipment

Protect the hardware from electrostatic discharge by observing

ESD instructions before unpacking of touching connectors of

electronics.

Always switch off power of the AMC2 device before modifying

the installation.

Do not connect or disconnect plug connectors, data cables, or

screw connectors while power is on.

Rules and Conditions

There are no specific requirements as for selling and delivery. As

for storage and safe operation, the environmental temperature

should not exceed the range of 0°C to 50°C.

Disposal

Your Bosch product is designed and manufactured with high-

quality materials and components which can be recycled and

reused.

8en | Safety Instructions AMC2 Extensions

2016-11 | AMC2-16IOE | Bosch Sicherheitssysteme GmbH

This symbol means that electrical and electronic equipment, at

their end-of-life, should be disposed of separately from your

household waste.

In the European Union, there are separate collection systems for

used electrical and electronic products. Please dispose of this

equipment at your local community waste collection/recycling

center.

Unpacking

Check the packaging for visible damage. If anything has been

damaged during transport, please inform the transport agency.

Unpack the unit carefully. This is an electronic device that must

be handled with care to avoid damage. Do not attempt to put

the unit into operation if components are damaged.

If any parts are missing, inform your customer service

representative or a Bosch Security Systems salesperson. The

shipping carton is the safest transport container for the unit.

Store it and the other packaging material for future use. If the

unit has to be sent back, use the original packaging.

1.3

AMC2 Extensions Safety Instructions | en 9

Bosch Sicherheitssysteme GmbH 2016-11 | AMC2-16IOE |

Important Information

Remarks

This hardware is part of a security system. Access should be

limited to authorized persons only.

Some states do not allow the exclusion or limitation of implied

warranties, or limitation of liability for incidental or

consequential damages, hence the above limitation or exclusion

might not apply to you.

Bosch Security Systems retains all rights not expressly granted.

Nothing in this license constitutes a waiver of Bosch’s rights

under the U.S. Copyright laws or any other federal or state law.

If you have any questions concerning this license, please, write

to:

Bosch Sicherheitssysteme GmbH

Robert-Bosch-Ring 5

85630 Grasbrunn

Germany.

Explanation of symbols in this document

Throughout this document, warning messages, important notes,

and helpful tips are presented for the reader. These appear as

follows:

Danger!

Cause of Hazard

Indicates a hazardous situation, which, if not avoided, will result

in death or serious injury.

Warning!

Cause of Hazard

Indicates a hazardous situation, which, if not avoided, could

result in death or serious injury.

2.1

10 en | Important Information AMC2 Extensions

2016-11 | AMC2-16IOE | Bosch Sicherheitssysteme GmbH
