Black Box ServShield RM470A-R2 Manual de usuario

1000 Park Drive • Lawrence, PA 15055-1018 • 724-746-5500 • Fax 724-746-0746

Order toll-free in the U.S.: Call 877-877-BBOX (outside U.S. call 724-746-5500)

FREE technical support 24 hours a day, 7 days a week: Call 724-746-5500 or fax 724-746-0746

Mailing address: Black Box Corporation, 1000 Park Drive, Lawrence, PA 15055-1018

Web site: www.blackbox.com • E-mail: [email protected]

CUSTOMER

SUPPORT

INFORMATION

JANUARY 2009

RM470A-R2

RM471

RF207

RM475

RM476

RM3055

ServShield

SERVSHIELD

TRADEMARKS USED IN THIS MANUAL

Black Box and the Double Diamond logo are registered trademarks of BB Technologies, Inc.

Plexiglas®is a registered trademark of Rohm & Haas Company.

Any other trademarks mentioned in this manual are acknowledged to be the property of the trademark owners.

Contents

Chapter Page

1. Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

2. Introduction. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

2.1 Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

2.2 What’s Included . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

2.3 Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

3. Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

3.1 Leveling the Cabinet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

3.2 Removing the Doors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

3.3 Fan Assembly (RF207) and Rear Door Fan Filter (RM475) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

3.4 Front Door Filter (RM476) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

3.5 Mounting Rails . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

1. Specifications

ServShield (RM470A-R2):

Capacity — Cabinet: 600 lb. (272 kg);

Vented Stationary Shelf: 200 lb. (90.8 kg)

Construction — Steel

19" EIA Rails — Mounting type: M6;

Mounting height: Top rails: 14U;

Bottom rails: 17U front, 23U rear;

Rail depth:

Top rails: 4.5" (11.4 cm) minimum, 33" (83.8 cm) maximum;

Bottom rails: 5.5" (13.9 cm) minimum, 33" (83.8 cm) maximum

Color — Black

Keyboard Tray — 20"W x 9.75"D (50.8 x 24.8 cm)

Writing Area — 20.7"W x 7.5"D (52.6 x 62.9 cm)

Size — 72"H x 30"W x 36"D (182.9 x 76.2 x 91.4 cm)

Weight — 330 lb. (150 kg)

Sliding, Adjustable Tower Shelf (RM471):

Capacity — 110 lb. (49.9 kg)

Size — 19"W x 22"D (48.3 x 55.9 cm)

Fan Unit (RF207):

Airflow Rate — 225 CFM

Approvals —UL®E191535

Power — 115 VAC, 50/60 Hz, 0.6 amps

SERVSHIELD

19" EIA M6

mounting rails

30"

Front view

17.876" opening

18.312" centers

31"

opening

25.75"

opening

17.876"

opening

18.312"

centers

19" EIA M6

mounting rails

Figure 1-1. Front Dimensions.

NOTE

The front door has been removed for clarity.

SERVSHIELD

36"

72"

Side view

Figure 1-2. Side Dimensions.

NOTE

The side panel has been removed for clarity.

SERVSHIELD

2. Introduction

2.1 Description

The ServShield protects your computer hardware in manufacturing environments and other industrial areas

subject to harsh conditions.

The cabinet is constructed of steel and it holds 600 lb. (272 kg)of equipment. The cabinet is preassembled, so

it’s easy to set up and use. Cabinet components include: upper, clear Plexiglas®door; isolated, steel middle

keyboard drawer; steel, perforated lower front door with dust filter; steel rear door furnished with fan assembly

and dust filters; a gland plate (12"L x 2.5"W [30.5 x 6.4 cm]), which provides cable access on the bottom of the

enclosure; one vented stationary shelf for mounting the monitor (200-lb. [90.8-kg] weight capacity); rubber

feet; and leveling glides. All doors have compression latches and locks. Cabinet dimensions are 72"H x 30"W x

36"D (182.9 x 76.2 x 91.4 cm).

The top Plexiglas door, middle keyboard door, bottom front door, and rear door are keyed the same.

2.2 What’s Included

• ServShield unit (assembled)

• (4) sets of keys

• (30) M6 cage nuts

• (30) M6 screws

• This user’s manual

2.3 Options

You may also need the following:

• 19" (48.3 cm) Sliding, Adjustable Tower Shelf (RM471)—At 19" (48.3 cm) high and 22" (55.9 cm) deep,

this shelf holds network hardware weighing up to 110 lb. (49.9 kg).

• Fan assembly (RF207)

• Rear door fan filter (RM475)

• Front door filter (RM476)

• Power strip mounting brackets (RM3055)

SERVSHIELD

3. Installation

3.1 Leveling the Cabinet

ServShield cabinets are shipped with both casters and leveling glides for your convenience. Two casters have

brakes that you can activate by turning the brake level on the side of the wheel. You can lower the leveling legs

by turning the leveling glide to the proper height using a 3⁄4" open-ended wrench.

3.2 Removing the Doors

The top and bottom front doors and the rear door are removable. To remove a door, open the door beyond 90

degrees. Then grasp the door with both hands, and carefully lift upward. When the door is free of the hinge

pins, pull the door away from the enclosure. To attach the door, align all of the hinges (two on the front doors

and three on the rear door) and slowly slide the door down until seated.

3.3 Fan Assembly (RF207) and Rear Door Fan Filter (RM475)

The fan assembly is already installed in the rear door. The part number for the rear fan filter is RM475. If you

need to replace a filter, follow these steps:

1. Replace one filter at a time. The 12 screws, which hold the filters in place, are the only thing holding on

the fan assembly. If you replace one filter at a time, you only have to remove four screws at a time so you

don’t have to remove the fan assembly.

2. Remove the fan filter cover—it snaps off.

3. Remove the four #8-32 x 3⁄4" screws holding the filter on the door.

4. Replace the filter, using the same four #8-32 x 3⁄4" screws.

5. Replace the fan filter cover.

6. Repeat steps 2 through 5 for the remaining two filters.

SERVSHIELD

Figure 3-1. Replacing a Rear Door Fan Filter.

Rear Door

Fan Filter Cover

Fan Grill (3)

#8-32 x 3⁄4" self-drilling

and tapping screws (12)

Fan Assembly

(RF207)

SERVSHIELD

3.4 Front Door Filter

You can easily remove the filter on the front door to clean or replace it. The part number for the front door

filter is RM476. To remove the filter, remove the two wing nuts on the top of the filter, swing the filter bracket

down and remove the filter.

The life of the filter depends on the environment the ServShield is installed in. You can vacuum the filters or

wash them in warm water with mild detergent. We recommend vacuuming the filter to keep it in peak

condition. If you choose to wash the filter, do so only once and replace it with a new filter when it gets dirty

again.

Bottom

Front Door

Filter

Filter Bracket

Wing Nut

Figure 3-2. Replacing the Front Door Filter.
