Break the 16-foot (5-m) USB distance barrier.

This transmitter/receiver pair extends USB

up to 328 feet (100 meters) from a computer

over CAT5e/6/7 cabling.

4-Port CAT5e/6/7 USB 2.0 Extenders Quick Start Guide

IC400A-R2

Before you get started, make sure that all the drivers required for your USB device(s) are installed.

1. Place the units where you want them and connect the CAT5e/6/7 cabling to the Link ports (RJ-45) on the local and remote

units.

LinkModeConfig ModeConfig

Maximum 328 feet (100 m)

(CAT5e/6/7 cable not included)

IC400A-R2

remote unit

IC400A-R2

local unit

FREE, live, 24/7 Tech Support is just 60 seconds away.

877-877-2269 | blackbox.com

©Copyright 2016. All rights reserved.

2. Connect the local unit to the computer.

IC400A-R2

local unit

PC

3. Connect the remote unit to the AC adapter.

IC400A-R2 remote unit

AC adapter

4. Attach the USB device(s) to the remote unit.

IC400A-R2 remote unit

USB

device

NOTE: If grounding the USB extenders is required, refer to the user manual on blackbox.com. To download the manual, enter IC400A-R2 in the

search box, then click on IC400A-R2 in the product results page. Then click on the Support tab and select the IC400A-R2 user manual

to download.

Trademarks Used in this Manual

Black Box and the Double Diamond logo are registered trademarks of BB Technologies, Inc.

Any other trademarks mentioned in this manual are acknowledged to be the property of the trademark owners
