BiPAC 7202 / 7202G

(802.11g) ADSL2+ Router

User’s Manual

Chapter 1.................................................................................................1

1.1 Introducing the BiPAC 7202(G) .............................................1

1.2 Features.................................................................................3

1.3 Applications of the BiPAC 7202(G)........................................6

Chapter 2.................................................................................................7

2.1 Important Notes.....................................................................7

2.2 Package Contents .................................................................7

2.3 The Front LEDs .....................................................................8

2.4 The Rear Ports ......................................................................9

2.5 Cabling ................................................................................ 11

Chapter 3...............................................................................................12

3.1 Before Configuration............................................................12

3.2 Factory Default Settings ......................................................17

3.3 LAN and WAN PortAddresses............................................18

3.4 Configuring with your Web Browser ....................................18

Chapter 4...............................................................................................19

4.1 Status...................................................................................20

4.1.1 ARP Table.........................................................................23

4.1.2 Wireless Association.........................................................24

4.1.3 Routing Table....................................................................25

4.1.4 DHCP Table......................................................................26

4.1.5 System Log.......................................................................27

4.1.6 Security Log......................................................................28

4.2 Quick Start...........................................................................29

4.3 Configuration .......................................................................32

4.3.1 LAN (Local Area Network)................................................33

4.3.2 WAN (Wide Area Network) ...............................................39

4.3.3 System..............................................................................46

4.3.4 Firewall .............................................................................51

4.3.5 QoS (Quality of Service)...................................................61

4.3.6 Virtual Server....................................................................73

4.3.7 Advanced..........................................................................77

4.4 Save Configuration to Flash ................................................89

4.5 Restart.................................................................................90

Chapter 5...............................................................................................91

Appendix................................................................................................93

Chapter 1

Introduction

1.1 Introducing the BiPAC 7202(G)

Thank you for purchasing the BiPAC 7202(G) ADSL Router by Billion. Your new router is an

all-in-one unit that combines an ADSL modem, ADSL router and Ethernet network switch to

provide everything you need to get the machines on your network connected to the Internet

over an ADSL broadband connection.

The BiPAC 7202(G) router complies with ADSL2+ standards for deployment worldwide and

supports downstream rates of up to 24 Mbps and upstream rates of up to 1 Mbps. Designed

for small office, home office and residential users, the router enables even faster Internet

connections. You can enjoy ADSL services and broadband multimedia applications such as

interactive gaming, video streaming and real-time audio much easier and faster than ever

before.

The BiPAC 7202(G) supports PPPoA (RFC 2364 – PPP (Point-to-Point Protocol) over ATM

Adaptation Layer 5), RFC 1483 encapsulation over ATM (bridged or routed), PPP over

Ethernet (RFC 2516), and IPoA (RFC1577) to establish a connection with your ISP. Your

new router also supports VC-based and LLC-based multiplexing.

The perfect solution for connecting a small group of PCs to a high-speed broadband Internet

connection, the BiPAC 7202(G) allows multiple users to have high-speed Internet access

simultaneously.

Your new router also serves as an Internet firewall, protecting your network from access by

outside users. Not only does it provide a natural firewall function with Network Address

Translation (NAT), it also provides rich firewall features to secure your network. All incoming

data packets are monitored and filtered. You can also configure your new router to block

internal users from accessing the Internet.

The BiPAC 7202(G) provides two levels of security support. First, it masks LAN IP

addresses making them invisible to outside users on the Internet, so it is much more difficult

for a hacker to target a machine on your network. Second, it can block and redirect certain

ports to limit the services that outside users can access. To ensure that games and other

Internet applications run properly, you can open specific ports for outside users to access

internal services on your network.

The Integrated DHCP (Dynamic Host Control Protocol) client and server services allow

multiple users to get IP addresses automatically when the router boots up. Simply set local

machines as a DHCP client to accept a dynamically assigned IP address from the DHCP

server and reboot. Each time a local machine is powered up; the router recognizes it and

assigns an IP address to instantly connect it to theLAN.

For advanced users, Virtual Service (port forwarding) functions allow the product to provide

limited visibility to local machines with specific services for outside users. You can set an

ISP (Internet Service Provider) provided IPaddress on the BiPAC 7202(G) and then you can

reroute specific services to individual computers on your local network. For instance, a

dedicated web server can be connected to the Internet via the router and then incoming

requests for web pages that are received by the router can be rerouted to your dedicated

local web server, even though the server now has a different IP address.

Virtual Server can also be used to re-task services to multiple servers. For instance, you can

set the router to allow separated FTP, Web, and Multiplayer game servers to share the same

Internet-visible IP address while still protecting the servers and LAN users from hackers.

1.2 Features

Express Internet Access – ADSL2/2+ capable

The BiPAC 7202(G) complies with ADSL worldwide standards. Supporting downstream

rates of 8Mbps withADSL, the router is capable of up to 12/24 Mbps with ADSL2/2+, and

upstream rates of up to 1 Mbps. Users enjoy not only high-speed ADSL services but also

broadband multimedia applications such as interactive gaming, video streaming and

real-time audio which are easier and faster than ever. The router is compliant with

Multi-Mode standard (ANSI T1.413, Issue 2; G.dmt (ITU G.992.1); G.hs (ITU G994.1);

G.dmt.bis (ITU G.992.3); and G.dmt.bisplus (ITU G.992.5)

Fast Ethernet Switch

A 4-port 10/100Mbps fast Ethernet switch is built-in with automatic switching between MDI

and MDI-X for 10Base-T and 100Base-TX ports, with auto dection allowing you to use either

straight or cross-over Ethernet cables.

Multi-Protocol to Establish a Connection

The router supports PPPoA (RFC 2364 - PPP over ATM Adaptation Layer 5), RFC 1483

encapsulation over ATM (bridged or routed), PPP over Ethernet (RFC 2516) and IPoA

(RFC1577) to establish a connection with an ISP. The router also supports VC-based and

LLC-based multiplexing.

Quick Installation Wizard

A web-based GUI and quick installation wizard help you easily install the BiPAC 7202(G).

Enter your ISP’s information and begin browsing the Internet immediately.

Universal Plug and Play (UPnP) and UPnP NAT Traversal

This protocol is used to enable simple and robust connectivity among stand-alone devices

and PCs from many different vendors, and it makes setting up a network simple and

affordable. UPnP architecture leverages TCP/IP and the Web to enable proximity

networking in addition to control and data transfer among networked devices. With this

feature enabled, you can seamlessly connect to Net Meeting or MSN Messenger.

Network Address Translation

Network Address Translation (NAT) allows multiple users to access outside resources such

as the Internet simultaneously with one IP address/one Internet access account. Many

application layer gateways (ALG) are supported such as web browser, ICQ, FTP, Telnet,

E-mail, News, Net2phone, Ping, NetMeeting, IP phone and others.

Firewall

NAT technology supports simple firewalls and provides options for blocking access from the

Internet, like Telnet, FTP, TFTP, WEB, SNMP and IGMP.

Domain Name System Relay

Domain Name System (DNS) relay provides an easy way to map a domain name with a

user-friendly name such as www.billion.com with an IP address. When a local machine sets

its DNS server to the router’s IP address, every DNS conversion request packet from the PC

to this router is forwarded to the real DNS on the outside network.

Dynamic Domain Name System (DDNS)

The Dynamic DNS service allows you to alias a dynamic IP address to a static hostname.

This dynamic IP address is the WAN IP address. To use the service, you must first apply for

an account from a DDNS service such as http://www.dyndns.org/.

PPP over Ethernet (PPPoE)

The BiPAC 7202(G) provides an embedded PPPoE client function to establish a connection.

You get greater access speed without changing the operation concept, while sharing the

same ISP account and paying for one access account. No PPPoE client software is required

for the local computer. Automatic Reconnect and Disconnect Timeout (Idle Timer) functions

are also provided.

Quality of Service (QoS)

QoS gives you full control over which types of outgoing data traffic should be given priority

by the router, ensuring important data like gaming packets, customer information, or

management information move through the router ay lightning speed, even under heavy

load. The QoS features are configurable by source IP address, destination IP address,

protocol, and port. You can throttle the speed at which different types of outgoing data pass

through the router, to ensure P2P users don’t saturate upload bandwidth, or office browsing

doesn’t bring client web serving to a halt. In addition, or alternatively, you can simply change

the priority of different types of upload data and let the router sort out the actual speeds.

Virtual Server:

You can specify which services are visible to outside users. The router detects an incoming

service request and forwards it to the specific local computer for handling. For example, you

can assign a PC in a LAN to act as a Web server inside and expose it to the outside network.

Outside users can browse inside the web server directly while it is protected by NAT. A DMZ

host setting is also provided for local computers exposed to the outside Internet network.

Dynamic Host Configuration Protocol (DHCP) Client and Server

On a WAN site, the DHCP client obtains an IP address from the Internet Service Provider

(ISP) automatically. On a LAN site, the DHCP server allocates a range of client IP

addresses, including subnet masks and DNS IP addresses and distributes them to local

computers. This provides an easy way to manage the local IP network.

Rich Packet Filtering

This feature filters the packet based on IP addresses as well as Port numbers. Filtering

packets to and from the Internet provides a higher level of security control.

Static and RIP1/2 Routing

An easy static routing table or RIP1/2 routing protocol supports routing capability.

Simple Network Management Protocol (SNMP)

SNMP allows convenient remote management of the router.

Web-based GUI

A web-based GUI offers easy configuration and management. User-friendly and with on-line

help, it also supports remote management capability for remote users to configure and

manage this product.

Firmware Upgradeable

You can upgrade the router with the latest firmware through its web-based GUI.

1.3 Applications of the BiPAC 7202(G)

Chapter 2

Product Overview

2.1 Important Notes

Warning

 Do not use the BiPAC 7202(G) in high humidity or high

temperatures.

 Do not use the same power source for the BiPAC 7202(G) as

other equipment.

 Do not open or repair the case yourself. If the BiPAC 7202(G) is

too hot, turn off the power immediately and have it repaired at a

qualified service center.

 Avoid using this product and all accessories outdoors.

Attention

 Place the BiPAC 7202(G) on a stable surface.

 Only use the power adapter that comes with the package. Using

a different voltage rating power adaptor may damage the router.

2.2 Package Contents

BiPAC 7202(G) ADSL Router

CD-ROM containing the online manual

RJ-11 ADSL/telephone Cable (1.8M)

Ethernet (CAT-5 LAN) Cable (2M Straight)

AC-DC power adapter (12V DC, 1A)

Quick Start Guide (105*150mm)

2.3 The Front LEDs

BiPAC 7202

BiPAC 7202G

LED Description

1 PPP : Steady glow when there is a PPPoA / PPPoE connection.

2 ADSL: Lights when successfully connected to an ADSL DSLAM

(linesync).

3 LAN Port

1-4:

Steady glow when connected to an Ethernet device.

Glows green for 100Mbps; Orange for 10Mbps.

Blinking light when data is Transmitted / Received.

4 WLAN

(7202G

only)

Lit green when the wireless connection is established.

Flashes when sending/receiving data.

5 SYS : Lights when the system is ready.

6 PWR : Lights when the power is ON.

Otros manuales para BiPAC 7202

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Enrutador de red de Billion

Billion

Billion BiPAC 711C2 Manual de usuario

Billion

Billion BiPAC 7401V(G)P R4 Manual de usuario

Billion

Billion BILLION BIPAC-7500GL Manual de usuario

Billion

Billion BiPAC 7202 Manual de usuario

Billion

Billion BiPAC 5100S Manual de usuario

Billion

Billion BiPAC 8500 Manual de usuario

Billion

Billion BiPAC 7402G Manual de usuario

Billion

Billion BIPAC 5102 Series Manual de usuario

Billion

Billion BiPAC 7100 Manual de usuario

Billion

Billion BiPAC 7402G Manual de usuario

Billion

Billion BiPAC 7402 Manual de usuario

Billion

Billion BiPAC 7402NX Manual de usuario

Billion

Billion BiPAC 8800NL R2 Guía de configuración

Billion

Billion BiPAC 7402(G)X(L) Series Manual de usuario

Billion

Billion BiPAC 7100SV Manual de usuario

Billion

Billion BiPAC 7404V series Manual de usuario

Billion

Billion BiPAC 7401V(G)PX Manual de usuario

Billion

Billion BIPAC-7402 Manual de usuario

Billion

Billion BiPAC 7404VGOX Manual de usuario

Billion

Billion BIPAC-74x GE Series Manual de usuario

Billion

Billion BiPAC 6404VGP R3 Manual de usuario

Billion

Billion BiPAC 6200NXL Manual del propietario

Billion

Billion BiPAC 7402NX Manual de usuario

Billion

Billion BiPAC 4700AZ Manual de usuario

Manuales populares de Enrutador de red de otras marcas

Allnet

Allnet ALL0333AU Manual de usuario

HomeSeer

HomeSeer HT-SEL Manual de usuario

Sercomm

Sercomm Genesis OC3505D Manual de usuario

TP-Link

TP-Link TD-8817 Manual de usuario

Motorola

Motorola MR1900 Manual de usuario

Digi

Digi IX14 Manual de usuario

Cisco

Cisco NCS 540 Manual

XAVi

XAVi X8821e Manual de usuario

BEC

BEC 6200WZL Manual de usuario

MikroTik

MikroTik hAP ac3 Series Manual de usuario

Korenix

Korenix JetNet 5428G Series Manual de usuario

NETGEAR

NETGEAR FS526T - Switch Manual de usuario

Korenix

Korenix JetNet 5710G Series Manual de usuario

Automated Logic

Automated Logic ZN551 Manual del propietario

Cisco

Cisco ASR 1000 Series Manual del operador

EnGenius

EnGenius ESR-9710 Manual de usuario

Cisco

Cisco 805 Series Instrucciones de funcionamiento y seguridad

LevelOne

LevelOne FBR-1416 Manual de usuario
