BiPAC 5200 Series

(802.11g) ADSL2+ Firewall Router

User’s Manual

Chapter 1 ................................................................................................1

1.1 Introducing the BiPAC 5200 Series .......................................1

1.2 Features of the BiPAC 5200 Series.......................................3

1.3 Applications for the BiPAC 5200 Series.................................6

Chapter 2 ................................................................................................8

2.1 Important note for using the BiPAC 5200 Series ...................8

2.2 Package Contents .................................................................8

2.3 The Front LEDs .....................................................................9

2.4 The Rear Ports ....................................................................10

2.5 Cabling ................................................................................12

Chapter 3 ..............................................................................................13

3.1 Before Configuration............................................................13

3.2 Step-by-Step Installation......................................................18

3.3 Factory Default Settings ......................................................22

3.4 LAN and WAN Port Addresses............................................23

3.5 Information from your ISP....................................................23

3.6 Configuring with your Web Browser ....................................24

Chapter 4 ..............................................................................................25

4.1 Quick Start...........................................................................26

4.2 Interface Setup ....................................................................31

4.3 Advanced Setup...................................................................42

4.4 Access Management ...........................................................51

4.5 Maintenance........................................................................60

4.6 Status...................................................................................65

4.7 Help .....................................................................................71

Chapter 5 ..............................................................................................72

APPENDIX.............................................................................................74

Chapter 1

Introduction the BiPAC 5200 Series

1.1 Introducing the BiPAC 5200 Series

Welcome to the Billion BiPAC 5200 Series ADSL2+ Modem/Router. Your Billion router is an

“all-in-one” unit, combining an ADSL modem, ADSL router and Ethernet network switch,

providing everything you need to get the machines on your network connected to the

Internet over your ADSL broadband connection.

The BiPAC 5200 Series complies with ADSL2+ standards for worldwide deployment and

supports downstream rates of up to 24 Mbps and upstream rates of up to 1 Mbps. It is

designed for small office, home office and residential users, enabling even faster speed

Internet connections. User can enjoy ADSLservices and broadband multimedia applications

such as interactive gaming, video streaming and real-time audio much easier and faster

than ever before.

The product supports PPPoA (RFC 2364 – PPP (Point-to-Point Protocol) over ATM

Adaptation Layer 5), RFC 1483 encapsulation over ATM (bridged or routed), PPP over

Ethernet (RFC 2516), and IPoA (RFC1577) to establish a connection with ISP. The product

also supports VC-based and LLC-based multiplexing.

It is the perfect solution to connect a small group of PCs to a high-speed broadband Internet

connection. Multi-users can have high-speed Internet access simultaneously.

This product also serves as an Internet firewall, protecting your network from being

accessed by outside users. Not only provide the natural firewall function (NetworkAddress

Translation, NAT), it also provides rich firewall features to secure user’s network. All

incoming data packets are monitored and filtered. Besides, it can also be configured to

block internal users from accessing to the Internet.

The product provides two levels of security support. First, it masks LAN users’IPaddresses

which are invisible to outside users on the Internet, making it much more difficult for a hacker

to target a machine on your network. Secondly, it can block and redirect certain ports to limit

the services that outside users can access. For example, to ensure that games and other

Internet applications will run properly, user can open some specific ports for outside users to

access internal services in network.

Integrated DHCP (Dynamic Host Control Protocol) services, client and server, allow multiple

users to get their IP addresses automatically on boot up from the product. Simply set local

machines as a DHCP client to accept a dynamically assigned IP address from DHCP server

and reboot. Each time local machine is powered up; the router will recognize it and assign

an IP address to instantly connect it to theLAN.

For advanced users, Virtual Service function allows the product to provide limited visibility to

local machines with specific services for outside users. An ISP (Internet Service Providers)

provided IP address can be set to the product and then specific services can be rerouted to

specific computers on the local network. For instance, a dedicated web server can be

connected to the Internet via the product and then incoming requests for HTML that are

received by the product can be rerouted to the dedicated local web server, even though the

server now has a different IP address. In this example, the product is on the Internet and

vulnerable to attacks, but the server is protected.

Virtual Server can also be used to re-task services to multiple servers. For instance, the

product can be set to allow separated FTP, Web, and Multiplayer game servers to share the

same Internet-visible IP address while still protecting the servers and LAN users from

hackers.

1.2 Features of the BiPAC 5200 Series

ADSL Multi-Mode Standard

Supports downstream rates of up to 24 Mbps and upstream rates of up to 1 Mbps. It also

supports rate management that allows ADSLsubscribers to select an Internet access speed

suiting their needs and budgets. It is compliant with Multi-Mode standard (ANSI T1.413,

Issue 2; G.dmt(G.992.1); G.lite(G992.2)), G.hs (G994.1), G.dmt.bis (G.992.3), G.dmt.bisplus

(G.992.5)). The Annex A and B are supported in different H/W platforms.

Wireless Ethernet 802.11g (BiPAC 5200G Series only)

With built-in 802.11g access point for extending the communication media to WLAN while

providing the WEP, WPA and WPA2 for securing your wireless networks.

Fast Ethernet Switch

A 10/100Mbps fast Ethernet switch is built in with automatic switching between MDI and

MDI-X for 10Base-T and 100Base-TX ports. An Ethernet straight or cross-over cable can be

used directly for auto detection.

Multi-Protocol to Establish A Connection

Supports PPPoA(RFC 2364 - PPP overATM Adaptation Layer 5), RFC 1483 encapsulation

over ATM (bridged or routed), PPP over Ethernet (RFC 2516) and IPoA (RFC1577) to

establish a connection with the ISP. The product also supports VC-based and LLC-based

multiplexing.

Quick Installation Wizard

Supports a WEB GUI page to install this device quickly. With this wizard, end users can

enter the information easily which they get from their ISP, then surf the Internet immediately.

Universal Plug and Play (UPnP) and UPnP NAT Traversal

This protocol is used to enable simple and robust connectivity among stand-alone devices

and PCs from many different vendors. It makes network simple and affordable for users.

UPnP architecture leverages TCP/IP and the Web to enable seamless proximity networking

in addition to control and data transfer among networked devices. With this feature enabled,

users can now connect to Net meeting or MSN Messenger seamlessly.

Network Address Translation (NAT)

Allows multi-users to access outside resources such as the Internet simultaneously with one

IP address/one Internet access account. Many application layer gateway (ALG) are

supported such as web browser, ICQ, FTP, Telnet, E-mail, News, Net2phone, Ping,

NetMeeting, IP phone and others.

Firewall

Supports simple firewall with NAT technology and provides option for blocking access from

Internet, like Telnet, FTP, WEB, SNMP and IGMP.

Domain Name System (DNS) relay

Provides an easy way to map the domain name (a friendly name for users such as

www.yahoo.com) and IP address. When a local machine sets its DNS server with this

router’s IP address, every DNS conversion request packet from the PC to this router will be

forwarded to the real DNS in the outside network.

Dynamic Domain Name System (DDNS)

The Dynamic DNS service allows you to alias a dynamic IP address to a static hostname.

This dynamic IP address is the WAN IP address. For example, to use the service, you must

first apply for an account from a DDNS service like http://www.dyndns.org/.

PPP over Ethernet (PPPoE)

Provides embedded PPPoE client function to establish a connection. Users can get greater

access speed without changing the operation concept, sharing the same ISP account and

paying for one access account. No PPPoE client software is required for local computer. The

Automatic Reconnect and Disconnect Timeout (Idle Timer) functions are provided, too.

Virtual Server

User can specify some services to be visible from outside users. The router can detect

incoming service request and forward it to the specific local computer to handle it. For

example, user can assign a PC in LAN acting as WEB server inside and expose it to the

outside network. Outside user can browse inside web server directly while it is protected by

NAT. ADMZ host setting is also provided to a local computer exposed to the outside network,

Internet.

Dynamic Host Configuration Protocol (DHCP) client and server

In the WAN site, the DHCP client can get an IP address from the Internet Service Provider

(ISP) automatically. In the LAN site, the DHCP server can allocate a range of client IP

addresses and distribute them including IP address, subnet mask as well as DNS IP

address to local computers. It provides an easy way to manage the local IP network.

RIP1/2 Routing

Supports RIP1/2 routing protocol for routing capability.

Simple Network Management Protocol (SNMP)

It is an easy way to remotely manage the router via SNMP.

Web based GUI

Supports web based GUI for configuration and management. It is user-friendly and comes

with on-line help. It also supports remote management capability for remote users to

configure and manage this product.

Firmware Upgradeable

Device can be upgraded to the latest firmware through the WEB based GUI.

1.3 Applications for the BiPAC 5200 Series

BiPAC 5200S/ 5200SR2/ 5200SR3

BiPAC 5200/ 5200R3

BiPAC 5200G/ 5200GR2/ 5200GR3/ 5200GR4/ 5200GR5

Chapter 2

Installing the BiPAC 5200 Series

2.1 Important note for using the BiPAC 5200 Series

Warning

 Do not use the BiPAC 5200 Series in high humidity or high

temperatures.

 Do not use the same power source for the BiPAC 5200 Series

as other equipment.

 Do not open or repair the case yourself. If the BiPAC 5200

Series is too hot, turn off the power immediately and have it

repaired at a qualified service center.



void usin

this

roduct and all accessories outdoors.

Attention

 Place the BiPAC 5200 Series on a stable surface.

 Only use the power adapter that comes with the package. Using

a different voltage rating power adaptor may damage the router.

2.2 Package Contents

BiPAC 5200 Series ADSL2+ Router

CD-ROM containing the online manual

RJ-11 ADSL/telephone Cable (1.8M)

Ethernet (CAT-5 LAN) Cable (1.8M Straight)

AC-AC power adapter (12V AC, 1A): for 5200S/ 5200SR2/ 5200SR3/ 5200GR2/

5200GR3/ 5200GR4/ 5200GR5

AC-AD power adapter (12V DC, 1A): for 5200/5200R3/5200G

Quick Start Guide (105*150*mm)

Otros manuales para BiPAC 5200

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Enrutador de red de Billion

Billion

Billion BiPAC 2072 Manual de usuario

Billion

Billion BiPAC 7404VGO Manual de usuario

Billion

Billion BiPAC 5400SW Manual de instalación y operación

Billion

Billion BiPAC 5200N Manual de usuario

Billion

Billion BiPAC 4700ZU Manual de usuario

Billion

Billion BiPAC 7800 Manual de usuario

Billion

Billion BiPAC 5200W-T R2 Manual de usuario

Billion

Billion BiPAC 5200S RC Series Manual de usuario

Billion

Billion BiPAC 6200NXL Manual del propietario

Billion

Billion BiPAC 7300M Manual de usuario

Billion

Billion BiPAC 7300G RA Manual de usuario

Billion

Billion myGuard 7202 Manual de usuario

Billion

Billion BiPAC 7404VGP Manual de usuario

Billion

Billion BiPAC 5200N Manual de usuario

Billion

Billion BiPAC 7800 Manual de usuario

Billion

Billion BiPAC 7300 G Manual de usuario

Billion

Billion BiPAC 711C2 Manual de usuario

Billion

Billion BiPAC 8501 Manual de usuario

Billion

Billion BiPAC 8900AX-1600 R2 Manual de usuario

Billion

Billion BiPAC 7800GZ Manual de usuario

Billion

Billion BiPAC 8500 Manual de usuario

Billion

Billion BiPAC 5200W Manual de usuario

Billion

Billion BiPAC 7402VGO Manual de usuario

Billion

Billion BiPAC 4500NZ(L) Manual de usuario

Manuales populares de Enrutador de red de otras marcas

Allnet

Allnet ALL0333AU Manual de usuario

HomeSeer

HomeSeer HT-SEL Manual de usuario

Sercomm

Sercomm Genesis OC3505D Manual de usuario

TP-Link

TP-Link TD-8817 Manual de usuario

Motorola

Motorola MR1900 Manual de usuario

Digi

Digi IX14 Manual de usuario

Cisco

Cisco NCS 540 Manual

XAVi

XAVi X8821e Manual de usuario

BEC

BEC 6200WZL Manual de usuario

MikroTik

MikroTik hAP ac3 Series Manual de usuario

Korenix

Korenix JetNet 5428G Series Manual de usuario

NETGEAR

NETGEAR FS526T - Switch Manual de usuario

Korenix

Korenix JetNet 5710G Series Manual de usuario

Automated Logic

Automated Logic ZN551 Manual del propietario

Cisco

Cisco ASR 1000 Series Manual del operador

EnGenius

EnGenius ESR-9710 Manual de usuario

Cisco

Cisco 805 Series Instrucciones de funcionamiento y seguridad

LevelOne

LevelOne FBR-1416 Manual de usuario
