Belkin F5U021 Guía de instalación

USB 4 Port Hub F5U021

Q: How do I install the USB hub in Windows or Mac?

•First turn on your computer, then with nothing plugged into the hub, plug it into your

PC or Mac. The computer should automatically install the USB hub drivers. For

PCs, Windows may ask for the Win95/98 CD ROM. The four port lights should light

up.

Q: Why use a USB hub?

•Using a USB Hub allows you to increase the number of USB devices that you can

attach to a USB port.

Q: What operating systems will the USB ExpressBus work with?

•Windows 95 Rev B, Windows 98 and Windows 2000, Mac OS 8.1 or higher.

Q: Does it require software or drivers?

•No, it not does require software or drivers. If your computer already has USB drivers

and support then all you should have to do is plug it into an open USB port.

Q: How can I tell if my computer is USB ready?

•Make sure the USB interface for your computers CMOS has been enabled (follow

instructions in your computer user’s manual on how to configure your CMOS).

•Go to Start, Settings, Control Panel, System and click on Device Manager. You

should have the last device as USB Serial Bus Controller. When you click on it you

should have the USB Universal Host Controller and USB Root Hub.

•If you don’t have these 2 drivers then you need to contact your computer

manufacturer.

Q: What is the maximum distance between each connected device when connecting

the USB hubs.

•5 meters

Q. What are the specs for the power supply? Does it come with one?

•Itdoes ship with one, the specs are 7.5 Volts DC, 2.1A.

Q: How can I tell if the hub is in Self-powered or Bus powered mode?

•Look on the side of the hub, there should be a switch that will move left to right.

Q: What is Self-powered mode and Bus powered mode?

•In Self-powered mode the ExpressBus is being powered by an external power source

of 6 VDC, 2.1A. This mode is used when connecting another hub, or when

connecting power hungry devices like keyboards, scanners and cameras.

•In Bus powered mode the ExpressBus gets it power from the USB ports on the

computers. Bus powered means you are not using a power supply.

•Downsteam power

Self-powered: 500mA per port.

Bus-powered: 100mA per port.

Q. What is the Data Transfer rate for the USB hub?

•It supports both full speed of 12Mbps and a low speed of 1.5 Mbps.

Q: What is maximum number of device can you hook up using the USB hub.

•By cascading additional USB hubs you can connect up to 127 different devices to a

single USB port on the computer.

If your question was not answered here, please e-mail your question to

[email protected] or call Belkin Technical Support at 310-898-1100 x2263. Before

calling, please ensure that you have all of your equipment connected and you are at the

computer.

©1998 Belkin Components. All Rights Reserved.

All trademarks and logos shown herein are the property of their respective owners.

Bus

Self

For Bus-powered

mode, move the

switch to the left. For Self-powered

mode, move the

switch to the right.
