Installation and Operating instructions for

Built-in Panel PC CP63xx

Version: 1.3

Date: 2006-01-11

Table of contents

General instructions 2

Notes on the Documentation 2

Liability Conditions 2

Description of safety symbols 2

Basic safety measures 3

Operator's obligation to exercise diligence 4

Operator requirements 4

Product Description 5

Appropriate Use 5

Structure 5

Interfaces 7

Serial interfaces 7

Network connection 7

PS/2 connections 7

VGA connection 7

free slot 7

USB interfaces 7

DVI interface 7

Installation Instructions 8

Transport and Unpacking 8

Transport 8

Unpacking 8

Installation of the PC in the control cabinet 9

Earthing measures 9

Power supply 10

Connecting devices 11

Connecting cables 11

Verifying the voltage and connecting 11

Operating Instructions 12

Switching the Industrial PC on and off 12

First switching on and driver installation 12

Maintenance 13

Cleaning the Industrial PC 13

Replacing the battery on the motherboard 13

Servicing 13

Shutting down 13

Disposal 13

Troubleshooting 14

Fault correction 14

Service and Support 15

Beckhoff Service 15

Beckhoff Support 15

Company headquarters 15

Appendix 16

Technical data 16

Approvals 16

FCC: Federal Communications Commission Radio Frequency Interference

Statement 16

FCC: Canadian Notice 16

1 CP63XX

General instructions

Notes on the Documentation

This description is only intended for the use of trained specialists in control

and automation engineering who are familiar with the applicable national

standards. It is essential that the following notes and explanations are

followed when installing and commissioning these components.

Liability Conditions

The responsible staff must ensure that the application or use of the

products described satisfy all the requirements for safety, including all the

relevant laws, regulations, guidelines and standards.

The documentation has been prepared with care. The products described

are, however, constantly under development. For that reason the

documentation is not in every case checked for consistency with

performance data, standards or other characteristics. None of the

statements of this manual represents a guarantee (Garantie) in the

meaning of § 443 BGB of the German Civil Code or a statement about the

contractually expected fitness for a particular purpose in the meaning of

§ 434 par. 1 sentence 1 BGB. In the event that it contains technical or

editorial errors, we retain the right to make alterations at any time and

without warning. No claims for the modification of products that have

already been supplied may be made on the basis of the data, diagrams

and descriptions in this documentation.

this publication, whether in whole or in part, without the written permission

of Beckhoff Automation GmbH, is forbidden.

Description of safety symbols

The following safety symbols are used in this operating manual. They are

intended to alert the reader to the associated safety instructions.

Danger

This symbol is intended to highlight risks for the life or health of personnel.

Warning

This symbol is intended to highlight risks for equipment, materials or the

environment.

Note

This symbol indicates information that contributes to better understanding.

2CP63XX

General instructions

Basic safety measures

Only switch the PC off after

closing the software

Before the Industrial PC is switched off, software that is running must

be properly closed.

Otherwise it is possible that data on the hard disk is lost. Please read the

section Switching the Industrial PC on and off.

Warning

Switch off all parts of the equipment, then uncouple the fieldbus!

Before opening the housing of the PC, and whenever the PC is being used

for purposes other than plant control, such as during functional tests

following repair, all parts of the equipment must first be switched off, after

which the Industrial PC can be uncoupled from the plant.

Pulling out the fieldbus connection plug uncouples the PC (optional).

Items of equipment that have been switched off must be secured against

being switched on again.

The Industrial PC’s power supply unit must be supplied with 24 VDC.

Warning

Do not exchange any parts when under power!

When components are being fitted or removed, the supply voltage must be

switched off.

Fitting work on the Industrial PC can result in damage:

• If metal objects such as screws or tools fall onto operating circuit

boards.

• If connecting cables internal to the PC are removed or inserted

during operation.

• If plug-in cards are removed or inserted when the PC is switched

on.

CP63XX 3

General instructions

Operator's obligation to exercise diligence

The operator must ensure that

• the Industrial PC is only used for its intended use (see also

Product Description chapter).

• the Industrial PC is in a sound condition and in working order

during operation.

• the operation manual is in good condition and complete, and

always available for reference at the location of the Industrial PC.

• the Industrial PC is operated, maintained and repaired only by

sufficiently qualified and authorised personnel.

• the personnel is instructed regularly about relevant occupational

safety and environmental protection aspects, and is familiar with

the operating manual and in particular the safety notes contained

herein.

• none of the safety and warning notes attached to the Industrial PC

are removed, and that all notes remain legible.

National regulations

depending on the machine

type

Depending on the type of machine and plant in which the Industrial PC is

being used, there will be national regulations for the control of such

machines and plant that the operator must observe. These regulations

cover, amongst other things, the intervals between inspections of the

controller.

The operator must initiate such inspections in good time.

Warning

Only trained persons may open the Industrial PC housing!

The operator is responsible for ensuring that only trained electrical staff

opens the housing of the Industrial PC.

Procedure in the event of a

fault

In the event of a fault in the Industrial PC, appropriate measures can be

determined with the aid of the list in the Fault correction section.

Operator requirements

Read the operating

instructions

Every user of the Industrial PC must have read these operating

instructions.

Software knowledge Every user must be familiar with any of the functions of the software

installed on the PC that he can reach.

4CP63XX

Product Description

Appropriate Use

The Built-in Panel PC CP63xx is designed for front installation in control

cabinets in machine and plant engineering applications.

Structure

Opening the housing

To open the PC housing, release the screw (1) by one turn using a

screwdriver. The plastic cap (2) can be then be pulled forward, thereby

releasing the lid (3).

View of the individual

components

The aluminium lid can now be lifted off. Avoid damaging the electrical

supply line to the fan!

CP63XX 5

Product Description

View of the open PC in

basic configuration

The computer chassis can now be removed from the housing. The power

supply (1) and the hard disk (2) are located in the lower part of the chassis.

The slot motherboard (3) is located in the central slot of the housing.

6CP63XX

Product Description

Interfaces

Interfaces of the

Built-in Panel PC CP63xx

Serial interfaces

RS 232

COM1 - COM2

The basic version of the CP63XX Industrial PC has two serial interfaces,

COM1 (1) and COM2 (2), using the type RS232, which are brought to a 9

pin SUB-D plug connector.

Network connection

Network The PC is connected with the local network via the 10/100 Base-T RJ-45

connector (3) of the on-board Ethernet adapter.

PS/2 connections

PS/2 The upper PS/2 connector (4) allows a PS/6 mouse to be used, while a PC

keyboard can be connected to the lower PS/2 connector (7).

VGA connection

VGA A 15-pin SUB-D socket connector (5) allows a VGA monitor to be

connected.

free slot

free slot A free slot (7) enables the expansion of the Industrial PC with a PCI plug-in

card.

The type plate of the PC housing provides information about the

configuration of the Industrial PCs in the delivery state.

USB interfaces

USB1 – USB2 One of the two USB interfaces (8) and

(9) is used for connecting the Control

Panel.

The remaining port can be used to

connect peripheral devices with USB

interface.

DVI interface

DVI The DVI interface (10) is used for connecting the Control Panel.

8 9

CP63XX 7

Installation Instructions

Please also refer to chapter General instructions.

Transport and Unpacking

The specified storage conditions must be observed (see chapter Technical

data).

Transport

Despite the robust design of the unit, the components are sensitive to

strong vibrations and impacts. During transport, your Industrial PC should

therefore be protected from excessive mechanical stress. Therefore,

please use the original packaging.

Warning

Danger of damage to the unit!

If the device is transported in cold weather or is exposed to extreme

variations in temperature, make sure that moisture (condensation) does not

form on or inside the device.

Prior to operation, the unit must be allowed to slowly adjust to room

temperature. Should condensation occur, a delay time of approximately 12

hours must be allowed before the unit is switched on.

Unpacking

Proceed as follows to unpack the unit:

1.Remove packaging.

2.Do not discard the original packaging. Keep it for future relocation.

3.Check the delivery for completeness by comparing it with your order.

4.Please keep the associated paperwork. It contains important

information for handling the unit.

5.Check the contents for visible shipping damage.

6.If you notice any shipping damage or inconsistencies between the

contents and your order, you should notify Beckhoff Service.

8CP63XX

Tabla de contenidos

Otros manuales de Panel táctil de Beckhoff

Beckhoff

Beckhoff CP22 Series Manual de usuario

Beckhoff

Beckhoff CP72 Series Manual de usuario

Beckhoff

Beckhoff CP37-1600 Series Manual de usuario

Beckhoff

Beckhoff CP72 Series Manual de usuario

Beckhoff

Beckhoff CP71 Series Manual de usuario

Beckhoff

Beckhoff CP6606-0001-0020 Manual de usuario

Beckhoff

Beckhoff CP6606 Manual de usuario

Beckhoff

Beckhoff CPX27 0010 Series Manual de usuario

Beckhoff

Beckhoff CP26 Series Manual de usuario

Beckhoff

Beckhoff CP32 -2 -0020 Series Manual de usuario

Beckhoff

Beckhoff CP6600 Manual de usuario

Beckhoff

Beckhoff CP77 Series Manual de usuario

Beckhoff

Beckhoff CP37 1600 Series Manual de usuario

Beckhoff

Beckhoff CP6600-0001-0020 Manual de usuario

Beckhoff

Beckhoff CP64 Series Manual de usuario

Beckhoff

Beckhoff CP32-2-0020 Series Manual de usuario

Beckhoff

Beckhoff CP67 Series Manual de usuario

Beckhoff

Beckhoff CP7709 Manual de usuario

Beckhoff

Beckhoff CP65**-0060 Manual de usuario

Beckhoff

Beckhoff CP32-1600 Series Manual de usuario

Beckhoff

Beckhoff CP37 Series Manual de usuario

Beckhoff

Beckhoff CP32-2 Series Manual de usuario

Beckhoff

Beckhoff CP6207 0020 Series Manual de usuario

Beckhoff

Beckhoff CP6201 Manual de usuario

Manuales populares de Panel táctil de otras marcas

FlowLine

FlowLine Data loop Manual de usuario

ALPEX

ALPEX AEx-8 P Series Manual de usuario

Ltech

Ltech E5S Manual de usuario

Harman

Harman AMX MODERO S MSD-701-L2 Manual de usuario

Acnodes

Acnodes PC 1150 Manual de usuario

AIS

AIS IP10IA99 series Manual de usuario

IBASE Technology

IBASE Technology ASTUT-152-RE1S Manual de usuario

YASKAWA

YASKAWA TP 610C Manual de usuario

B&R

B&R Power Panel C Series Manual de usuario

Beijer Electronics

Beijer Electronics X2 control Manual de usuario

AXIOMTEK

AXIOMTEK GOT321W-521 Manual de usuario

TRIDONIC.ATCO

TRIDONIC.ATCO x-touchBOX Manual de usuario

Qomo

Qomo QIT1386 Manual de usuario

DFI

DFI KS104-CD Manual de usuario

AMX

AMX AXP-PPC Guía

Sartorius

Sartorius X3 PR 5410 Manual de usuario

AMX

AMX Modero X Series Manual de usuario

Advantech

Advantech TPC-30 Series Manual de usuario
