AA-07FBAA-07FB SILVER multi apartment panel is an excellent solution for oﬃce buildings, apartment complexes and cottage communities.A distinctive feature of this panel is a color TFT screen with backlight, as well as a high-resolution IP camera with wide viewing angles.Full User ManualDevice descriptionwiki.bas-ip.comENTRANCE PANEL Main features• Panel type: Multi-apartment.• Display: 4.3’’ TFT, color with backlight.• Keypad: Backlight mechanical buttons.• Camera: 1/3”.• Resolution: 2 Мp.• Сamera angle: 110° (horizontal).• Output video: Full HD (1920 × 1080), H.264 Main Proﬁle.• Night backlight: 6 LEDs.• Light sensitivity: 0,01 LuX.• Protection class: IP65.• IK-Code: IK07.• Working temperature: -40 — +65 °С.• Power consumption: 6,5 W, in standby — 3,6 W.• Power supply: +12 V DC.• Body: Aluminum.• Colors: Silver.• Dimensions for installation: 141 × 351 × 60 mm.• Size of the panel: 155 × 375 × 55 mm.• Installation: Flush, surface with BR-AA7 bracket.Appearance1234567890*#TProximity sensors.Keypad.Reader.Backlight.Loudspeaker.Camera.4.3’’ Display.1234567-------1324675

Completeness check of the productBefore installation of the outdoor panel, it is necessary to check thatit is complete and all components are available.Outdoor panel kit includes: Outdoor panel Manual Flush mount bracket Set of wires with connectors for connection of power supply,lock, and additional modules A set of cups Set of screws with a wrench1 pc1 pc1 pc1 pc1 pc1 pcAfter verifying the device's completeness, you can switch to the outdoor panelconnection.For connection you will need: Electrical connectionAn Ethernet UTP CAT5 or higher cable connected to a PoE network switchor regular switch/router. Cable length recommendationsThe maximum length of the UTP CAT5 cable segment should not exceed 100 meters,according to the IEEE 802.3 standard. Power supply at +12 V, 2 amps.Wires must be connected to connect the door sensor, the exit button and the two locks control module (optional).EAN: 5060514914373 (SILVER)

Connection scheme of electromechanical lockusing third party power supply+12VDCElectromechanical lock-+LAN (PoE)123+12V485+RS485 / Exit Button / Door Sensor45GNDEXIT485-6DS78DINFIN123+12VNCSupply / Relay Outputs45GNDNOCOM123+5VWD0Wiegand Out4GNDWD1SH-42(optional)SH-45Door SensorExit ButtonGND+12V+12VDC-+Connection scheme of electromagnetic lockusing third-party power supply+12VDCElectromagnetic Lock-+LAN (PoE)123+12V485+RS485 / Exit Button / Door Sensor45GNDEXIT485-6DS78DINFIN123+12VNCSupply / Relay Outputs45GNDNOCOM123+5VWD0Wiegand Out4GNDWD1SH-42(optional)SH-45Door SensorExit ButtonGND+12V+12VDC-+

Mechanical mountingand the local network.Attention: the hole at the bottom is designed to drain the water. Do not intentionally close it. Also it is necessary to make a drain for water Before installation of the outdoor panel it is necessary to provide a hole or a recess into a wall with dimensions 143×353x61 mm (for ﬂush mount) dimensions of the bracket (mounting box) = 141×351×60 mm.at the bottom of the niche which will serve to divert water out. It is also necessary to provide supply of a power cable, additional modules 141 mm

351 mm239 mm

EAN: 5060514914373 (SILVER)Outdoor PanelFlush BracketNicheScrewsOutdoorPanel

143 mm

353 mm109-130 cm

155 mm

375 mm

55 mm1234567890*#T

1234567890*#T

Flush Bracket

WarrantyThe warranty card numberModel nameSerial numberSeller nameWith following stated terms of warranty is familiar, functional test wasperformed in my presence: Customer signatureWarranty conditionsThe warranty period of the product — 36 (thirty-six) months fromthe date of sale.Transportation of product must be in its original packaging or supplied oneby the seller.The product is accepted in warranty repair only with a properly ﬁlled warrantycard and the presence of intact stickers or labels.The product is accepted for examination in accordance with the casesprovided by law, only in the original packaging, in a full complete set,appearance corresponding to the new equipment and presence of all relevantproperly ﬁlled documents.This warranty is in addition to the constitutional and other consumer rightsand in no way restrict them. Terms of warrantyThe warranty card must indicate the name of the model, serial number,purchase date, name of the seller, seller company stamp andthe customer’s signature. Delivery to the warranty repair is carried out by the buyer himself.Warranty repairs carried out only during the warranty period speciﬁedin the warranty card.The service center is committed to do everything possible to carry outthe repair warranty products, up to 24 working days. The period spenton the restoration of product functionality is added to the warranty period.
