Avalue Technology FPC-05R1 Manual de usuario

Part No. E201705R1A0R

FPC-05R1

5.7” SVGA TFT RISC Multifunctional Panel PC

Quick Reference Guide

1st Ed –25 July 2013

FPC-05R1

2 FPC-05R1 Quick Reference Guide

CONTENT

1. Getting Started............................................................................................................3

1.1 Safety Precautions ................................................................................................3

1.2 Packing List...........................................................................................................3

1.3 System Specifications ...........................................................................................4

1.4 System Overview...................................................................................................6

1.4.1 Front & Top View ......................................................................................................................... 6

1.4.2 Right Side View............................................................................................................................ 6

1.4.3 Left Side View.............................................................................................................................. 7

1.4.4 Rear View..................................................................................................................................... 7

2. Hardware Configuration.............................................................................................8

2.1 Jumper & connector list.........................................................................................9

2.2 Jumper & connector settings...............................................................................10

2.2.1 Serial port connector (COM)...................................................................................................... 10

2.2.2 Boot Mode selector (DIP)........................................................................................................... 11

2.2.3 DC power-in connector (DC-IN)................................................................................................. 11

2.2.4 Debug port connector (Debug port)........................................................................................... 12

Quick Reference Guide

FPC-05R1 Quick Reference Guide

1. Getting Started

1.1 Safety Precautions

Warning!

Always completely disconnect the power cord from your

chassis whenever you work with the hardware. Do not

make connections while the power is on. Sensitive

electronic components can be damaged by sudden power

surges. Only experienced electronics personnel should

open the PC chassis.

Caution!

Always ground yourself to remove any static charge before

touching the CPU card. Modern electronic devices are very

sensitive to static electric charges. As a safety precaution,

use a grounding wrist strap at all times. Place all electronic

components in a static-dissipative surface or static-shielded

bag when they are not in the chassis.

1.2 Packing List

1 x FPC-05R1 5.7” SVGA TFT RISC Multifunctional Panel PC

1 x CD/DVD-ROM contains the followings:

—User’s Manual (this manual in PDF file)

—Win CE & Linux software (bootloader, Kernel, Image, BSP, SDK)

—iMX_AdvancedToolKit

—Mfgtools

1 x Quick Reference Guide

Other major components include the following:

—1 x Power Adapter(12V/5A)

FPC-05R1

4 FPC-05R1 Quick Reference Guide

1.3 System Specifications

System

Mother Board

RSC-IMX51

CPU

Freescale i.MX51 800 MHz

PMU

Freescale MC13892

eMMC

4GB onboard

Memory

512MB DDR2 SDRAM onboard

RTC

ISL1208

Watchdog Timer

Generates a time-out system reset, setting via software

Adapter

+12 Vdc / 2 A (24W)

Power Management

Support AT Mode

Expansion Card

SD socket Support SDHC (eSDHC-2)

Operating System

Linux & Win CE 6.0, Android

Other

1 x 18/24-bit LVDS with 640x480 LCD

Storage

Other Storage Device

4GB eMMC on board

Panel

LCD Panel

5.7”VGA TFT (P/N: FG050722DSSWDGT1)

Backlight

LED

Touch Screen

4-wire Resistive

Touch Screen

Controller

TBC

Other

Interface: LVDS

Resolution: 640x480, 262K

Pixel pitch: 0.06mm(H) x 0.18mm(V)

Luminance: 320 cd/m²

Contrast ratio: 300

Viewing angle: 60(U), 40(D), 70(L), 70(R)

Response time: 15 ms

Touch Light Transmission: 80%

External I/O

Serial Port

2 x DB9 (1xRS232/422/485, 1x debug port)

USB Port

Host: 2 x Independent USB interfaces (Type A)

Client: 1 x Mini-USB connector

Audio Port

2 x Speaker

LAN Port

1 x RJ-45

Quick Reference Guide

FPC-05R1 Quick Reference Guide

Switch

1 x On/Off Power Switch

Expansion Slots

1 x SD socket Support SDHC (eSDHC-2)

Others

1 x Reset button

Mechanical

Power Type

AT, +12 Vdc / 2 A (24W)

Power Connector

Type

DC Power Jack

Color

Front & Rear panel Black

Fanless

Yes

Mounting

Wall/Stand/VESA 100 mm X 100 mm

Dimension

TBD

Weight

TBD

Reliability

EMI Test

CE/FCC Class A

Vibration Test

As standards

Drop Test

As standards

Operating

Temperature

0°C to 40°C (32°F to 140°F)

Operating Humidity

0%~90% relative humidity, non-condensing

Storage Temperature

-20°C to 60°C

OS Support

Android

Yes

Linux

Yes

WinCE

Win CE 6.0

FPC-05R1

6 FPC-05R1 Quick Reference Guide

1.4 System Overview

1.4.1 Front & Top View

1.4.2 Right Side View

Connectors

Label

Function

Note

SD Card Slot

SD/SDHC card socket

Right side

MINI USB

USB on The Go connector

Mini USB connector

COM

Serial port connector

DB-9 male connector

GPIO

General purpose I/O connector

Quick Reference Guide

FPC-05R1 Quick Reference Guide

1.4.3 Left Side View

1.4.4 Rear View

Connectors

Label

Function

Note

DC-IN

+12V DC power-in connector

Debug port

Debug target application

DB-9 male connector

LAN

RJ-45 Fast Ethernet connector

DIP

Boot Mode selector

PWR

System power switch

RESET

Reset button

USB1&2

USB 2.0 connector 1&2

FPC-05R1

8 FPC-05R1 Quick Reference Guide

2.Hardware

Configuration

Jumper and Connector Setting

For advanced information, please refer to:

1- RSC-IMX51 Installation Guide or User’s Manual

2- AUX-MPCIE (Optional) Installation Guide.

Note: If you need more information, please visit our website:

http://www.avalue.com.tw

Quick Reference Guide

FPC-05R1 Quick Reference Guide

2.1 Jumper & connector list

Connectors

Label

Function

Note

COM

Serial port connector

DB-9 male connector

DC-IN

+12V DC power-in connector

Debug port

Debug target application

DB-9 male connector

LAN

RJ-45 Fast Ethernet connector

DIP

Boot Mode selector

MINI USB

USB on The Go connector

Right side

PWR

System power switch

RESET

Reset button

SD Card Slot

SD/SDHC card socket

Right side

USB1&2

USB 2.0 connector 1&2

GPIO

General purpose I/O connector

FPC-05R1

10 FPC-05R1 Quick Reference Guide

2.2 Jumper & connector settings

2.2.1 Serial port connector (COM)

RS232 mode

Signal

GND

RTS

CTS

RS422 mode

Signal

TX-

RX+

TX+

RX-

GND

RS485 mode

Signal

DATA-

DATA+

GND
