4KEX100-DP-KVM

DP KVM Extender Over HDBase-T

User Manual

Disclaimers

The information in this manual has been carefully checked and is believed to be

accurate. AV Access Technology Limited assumes no responsibility for any

infringements of patents or other rights of third parties which may result from its

use.

AV Access Technology Limited assumes no responsibility for any inaccuracies that

may be contained in this document. AV Access Technology Limited also makes no

commitment to update or to keep current the information contained in this

document.

AV Access Technology Limited reserves the right to make improvements to this

document and/or product at any time and without notice.

Copy, Reproduce, Distribute and/or Edit of this document or part of it as well as

utilization of its contents and communication thereof to others without express

authorization are prohibited. Offenders will be held liable for payment of damages.

All rights created by patent grant or registration of a utility model or design patent

Trademarks Notice

All products or service names mentioned in this document may be trademarks of

the companies with which they are associated.

Business inquiry: [email protected]

Technical problems: support@avaccess.com

Important Safety Instructions

Do not expose this device to rain, moisture, dripping or splashing. No objects

filled with liquids, such as vases, shall be placed on the device.

Do not install or place this unit in a bookcase, built-in cabinet, or in another

confined space. Ensure the unit is well ventilated.

To prevent risk of electric shock or fire hazard due to overheating, do not

obstruct the unit’s ventilation openings with newspapers, tablecloths,

curtains, or similar items.

Do not install near any heat sources such as radiators, heat registers, stoves,

or other device (including amplifiers) that produce heat.

Do not place sources of naked flames, such as lighted candles, on the unit.

Clean this device only with dry cloth.

Unplug this device during lightning storms or when unused for long periods

of time.

Protect the power cord from being walked on or pinched, particularly at

plugs.

Only use attachments / accessories specified by the manufacturer.

Refer all servicing to qualified service personnel.

www.avaccess.com 1

Table of Contents

Overview...............................................................................................................2

Package Contents.................................................................................................................. 3

Panel .......................................................................................................................................... 4

Installation Instructions.......................................................................................7

Trouble Shooting..................................................................................................8

Specification .......................................................................................................11

Warranty .............................................................................................................13

Overview

www.avaccess.com 2

Overview

The 4KEX100-DP-KVM extender is a 100m 4K DisplayPort over HDBT extender

with USB 2.0 and audio pass-through.It offers the distribution of uncompressed

4K@30Hz UHD video, audio, power, RS232 and USB 2.0 together up to 100m/328ft

over a single CatX cable.

With USB 2.0 pass-through, it allows users to control or monitor a remote server

from a harsh environment, or operate a physically inaccessible PC, server or

workstation remotely. Bi-directional audio pass-through allows for audio

distribution in both direction.

With 48V PoE integrated inside, a single power adapter connected to the transmitter

powers both units. Its 12V power adapter is secured with a screw-on connector to

prevent the power being accidentally disconnected. LED indicators for power

supply to units and signal status show established connection between

connected devices.

Slim appearance and space saving

One way PoE, transmitter supplies the power for receiver

Via Cat 6a/7 cable, 4Kx2K@30Hz or 1080P@60Hz output up to 100m.

Via Cat 5e/6 cable, 4Kx2K@30Hz output up to 90m, 1080P@60Hz up to 100m

DP 1.2 supported, up to 4k@30Hz and HDCP 1.4 compliance

Supports Bi-directional stereo audio, RS232 and EDID pass through over

HDBaseT

USB 2.0 pass through over HDBaseT, with USB-HOST built in transmitter and

USB-DEVICE built in receiver.

All connectors in one side for easy installation

Overview

www.avaccess.com 3

Package Contents

Before you start the installation of the product, please check the package

contents:

Transmitter 4KEX100-DP-KVM x 1

Receiver 4KEX100-DP-KVM x 1

Power Adapter (DC 12V 2A) x 1

Phoenix Male Connector (3.5mm 3 Pin) x 2

Mounting Bracket x 4

User Manual x 1

Overview

www.avaccess.com 4

Panel

Front Panel

Transmitter/Receiver

No. Name Description

1 Power LED

(Red)

On: The device is powered on.

Off: The device is powered off.

2 Status LED

(Green)

Blinking: The device is working properly.

Off: The device is not working properly.

3 HDCP LED

(Blue)

On: Audio and video signal is HDCP protected.

Blinking: Audio and video signal is not HDCP

protected.

Off: No Audio and video signal

4 Link LED

(Green)

On: Link to receiver has been established.

Off/Blinking: Connection exceptions exist

between the transmitter and the receiver.

Overview

www.avaccess.com 5

Rear Panel

Transmitter

No. Name Description

1 DC 12V

Connects to a DC 12V power adapter.

Note: Only one power adapter is needed at transmitter

side.

2 HDBT Out Connects to the receiver via a CatX cable.

3 RS232 RS232 pass-through

3 DP In Connects to a DisplayPort source.

4 Audio In Connects to an audio source device such as PC.

5 Audio Out Connects to an audio device such as earphone, amplifier.

6 USB Host Connects to device to be controlled such as server,

computer etc.

Overview

www.avaccess.com 6

Receiver

No. Name Description

1 DC 12V

Connects to a DC 12V power adapter.

Note: Only one power adapter is needed at transmitter

side.

2 HDBT In Connects to the transmitter via a CatX cable.

3 RS232 RS232 pass-through

4 DP Out Connects to a DisplayPort display.

5 Audio In Connects to an audio source such as PC.

6 Audio Out Connects to an audio device such as earphone, amplifier.

7 USB Device Connects to USB devices such as mouse, keyboard, USB

disk etc.
