ATEN VS481b Manual de usuario

VS481B

USER MANUAL

4-Port HDMI Switch

EMC Information

FEDERAL COMMUNICATIONS COMMISSION INTERFERENCE

STATEMENT: This equipment has been tested and found to comply with

the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules.

These limits are designed to provide reasonable protection against harmful

interference when the equipment is operated in a commercial

environment. This equipment generates, uses, and can radiate radio

frequency energy and, if not installed and used in accordance with the

instruction manual, may cause harmful interference to radio

communications. Operation of this equipment in a residential area is likely

to cause harmful interference in which case the user will be required to

correct the interference at his own expense.

The device complies with Part 15 of the FCC Rules. Operation is subject

to the following two conditions: (1) this device may not cause harmful

interference, and (2) this device must accept any interference received,

including interference that may cause undesired operation.

FCC Caution: Any changes or modifications not expressly approved by

the party responsible for compliance could void the user's authority to

operate this equipment.

CE Warning: This is a class A product. In a domestic environment this

product may cause radio interference in which case the user may be

required to take adequate measures.

RoHS

This product is RoHS compliant.

SJ/T 11364-2006

The following contains information that relates to China.

- 3 -

VS481BUser Manual

Online Registration

Telephone Support

Technical Support

For international online technical support – including

troubleshooting, documentation, and software updates:

http://support.aten.com

For North American technical support:

International http://support.aten.com

International 886-2-8692-6959

China 86-10-5255-0110

Japan 81-3-5615-5811

Korea 82-2-467-6789

North America 1-888-999-ATEN ext 4988

United Kingdom 44-8448-158923

Email Support [email protected]

Online

Technical

Support

Troubleshooting

Documentation

Software Updates

http://support.aten.com

Telephone Support 1-888-999-ATEN ext 4998

- 4 -

Package Contents

The VS481Bpackage contains the following items:

1 VS481B4-Port HDMI Switch

1 HDMI Cable

1 IR Remote Control

1 Power Adapter

1 User Instructions*

Check to make sure that all the components are present and that

nothing got damaged in shipping. If you encounter a problem,

contact your dealer.

Read this manual thoroughly and follow the installation and

operation procedures carefully to prevent any damage to the unit,

and/or any of the devices connected to it.

*Features may have been added to the VS481Bsince this

manual was published. Please visit our website to download

the most up-to-date version of the manual.

Manual Date: 10/2014

Firmware: V1.0.062

ATEN and the ATEN logo are trademarks of ATEN International Co., Ltd. All rights

reserved. All other trademarks are the property of their respective owners.

- 5 -

Overview

The VS481B4-Port HDMI Switch allows you to connect 4 HDMI

sources to one HDMI display and quickly switch between the

devices via front panel pushbuttons, RS-232 or IR remote control.

The VS481Bhas four HDMI ports to provide device connections

for digital cameras, Blue-ray players, satellite receivers,

camcorders, PC's, gaming consoles and more.

The VS481Bsupports resolutions up to 4k2k using the new Ultra

HD digital format for high-definition displays.

The VS481B’s Instant Switching capability provides a smooth

transition between HDMI ports to increase system efficiency. The

auto switching feature provides different modes for auto port

selection when a device loses power or a new device is plugged

into the VS481B.

The built-in bi-directional RS-232 serial port allows the switch to

be controlled through a high-end controller, PC, and/or

automation/theater software package.

- 6 -

Features

Allows up to four HDMI A/V sources to be connected to one

HDMI display

Quick and easy switching between HDMI sources via front

panel pushbuttons, RS-232 or IR Remote control

Supports 340MHz bandwidth for high performance video

Auto switching modes for auto port selection

HDMI (3D, Deep Color, 4kx2k); HDCP compatible

Long distance transmission – up to 15 m (24 AWG)

Consumer Electronics Control (CEC) support

Supports Dolby True HD and DTS HD Master Audio

Built-in bi-directional RS-232 serial port for high-end system

control*

Instant switching between HDMI input sources

Supports IR extension using a receiver extension cable**

LED indication of selected video source

Note: 1. The RS-232 AP can be downloaded from our website:

www.aten.com.

2. The IR extension cable is sold separately. To purchase

an IR extension cable, contact your dealer and refer to

part 2XRT-0003G.

- 7 -

System Requirements

Source Device(s)

HDMI Type A output connector(s)

Note: A DVI/HDMI adapter is required when connecting a DVI

source device.

Display Device

A display device or receiver with an HDMI Type A input

connector

Cables

4 HDMI cables

Note: 1. We strongly recommend that you purchase high-quality

cables of appropriate length since this will affect the

quality of the audio and video display. Contact your

dealer to purchase the correct cables.

2. If you wish to utilize the VS481B’s high-end serial

controller function, you will also need to purchase an

appropriate RS-232 cable. See Installing the RS-232

Controller, page 11.

- 8 -

Components

VS481BFront View

No. Component Function

1 HDMI Input Port Plug the cable from an HDMI source

device into this port.

2 Port Selection

Pushbuttons

Pressing a port selection pushbutton

routes the A/V source from the

corresponding input port to the output port

for display.

3 IR Receiver This receives signals from the IR remote

control.

4 Port LEDs The SELECTED LED lights up (green) to

indicate that the port is selected.

- 9 -

VS481BRear View

No. Component Function

1 Power Jack The power adapter cable plugs in here.

2 HDMI Output Port The cable from the HDMI display device

plugs in here.

3 HDMI Input Port The cables from the HDMI source devices

can plug into any of three available ports.

4 RS-232 Serial

Port

This is the serial remote port for input

source selection and high-end system

control.

5 IR Extension Port Connect the IR Extender to this port.

Note: An IR receiver can be purchased

separately, contact your ATEN dealer for

details.

21 45

- 10 -

IR Remote Control

No. Component Function

1 Port Up / Port

Down Buttons

Press the Port Up button to cycle forward

through the source devices (1 to 2; 2 to 3; 3 to

4; 4 to 1).

Press the Port Down button to cycle backward

through the source devices (4 to 3; 3 to 2; 2 to

1; 1 to 4).

2 Port Selection

Buttons

Press a button to bring the focus directly to the

source device attached to its associated port.
