AOpen VKM400AM-S Manual de usuario

Table of Contents

Table of Contents ................................................................................... 1

1.1 A Thank-you Note Before You Get Start..........................................................4

1.2 Features of This Manual ...............................................................................5

1.3 Safety Information ......................................................................................5

Chapter 2 Introduction to This Motherboard............................................... 6

2.1 How does your motherboard look like?...........................................................6

2.2 Specification...............................................................................................7

2.3 Block Diagram ............................................................................................8

Chapter 3 Hardware Installation............................................................... 9

3.1 Quick Installation Procedure .........................................................................9

3.2 Installation You Have to Know.....................................................................10

Installing CPU...........................................................................................10

Installing CPU and System Fans..................................................................11

Installing Memory Modules .........................................................................12

Connecting IDE and Floppy Cables ..............................................................13

Connecting Front Panel Cable .....................................................................14

Connecting ATX Power Cables.....................................................................15

3.3 Other Installation for Your Reference ...........................................................16

Setting CPU Voltage and Frequency.............................................................16

Connecting Serial ATA (only for vKM400Am-S) .............................................17

Adjusting your Hard Disk Setting (only for vKM400Am-S)...............................18

Connecting AGP 8X Expansion Slot (only for vKM400Am-S)............................19

Connecting AGP 4X Expansion Slot (only for vKM266Pm) ...............................20

Connecting CNR (Communication and Network Riser) Expansion Slot...............21

Connecting IrDA........................................................................................22

10/100 LAN Supported...............................................................................23

Connecting USB2.0....................................................................................24

Tab

Super 5.1 Channel Audio Effects .................................................................25

Connecting Front Audio..............................................................................26

Connecting AUX_IN ...................................................................................27

Connecting CD_IN.....................................................................................28

Connecting Case Open...............................................................................29

Connecting S/PDIF (Sony/Philips Digital Interface) ........................................30

Colored Coded Back Panel..........................................................................31

LED Indication ..........................................................................................32

3.4 Jumper Settings........................................................................................33

Chapter 4 Special Features and Utilities................................................... 34

RAID (Redundant Array of Independent Disks)..............................................34

RAID BIOS Setting Utility (only for vKM400Am-S) .........................................34

SilentTek – Noise is Gone!..........................................................................35

Other Useful Features................................................................................38

Chapter 5 Setting BIOS......................................................................... 39

Introduction .............................................................................................39

How to Use Phoenix-Award™ BIOS Setup Program........................................40

How To Enter BIOS Setup ..........................................................................40

BIOS Upgrade under Windows environment..................................................41

Vivid BIOS technology ...............................................................................43

Chapter 6 Installing Drivers................................................................... 44

Auto-run Menu from Bonus CD....................................................................44

Installing VIA 4 in 1 Driver .........................................................................44

Installing VIA S3G Unichrome Graphics Win2K/XP Driver (for vKM400Am-S) ....45

Installing VIA S3G Unichrome IGP Win2K/XP Driver (for vKM266Pm)...............45

Installing Audio Driver ...............................................................................46

Installing LAN Driver..................................................................................46

Installing VIA USB 2.0 Driver......................................................................47

Installing VIA Serial ATA RAID Driver (only for vKM400Am-S).........................47

Chapter 7 Troubleshooting..................................................................... 48

Chapter 8 Technical Support .................................................................. 49

Model Name and BIOS Version....................................................................50

Technical Support......................................................................................51

1.1 A Thank-you Note Before You Get Start

First of all, we would like to express our gratitude for purchasing AOpen products.

Once again, this motherboard is designed uniquely to meet all your personal

needs with our great industry-designing ability and our everlasting perseverance

to the quality of all our products.

This manual will introduce you how this motherboard is installed. Please keep it

well for your future reference. If you lost your printed manual, you may also go to

our website at http://www.aopen.com to download the updated file.

Now, we would like to invite you to personally experience this user-friendly

manual and all of the powerful functions this AOpen product offers.

The logos of Adobe and Acrobat are the registered trademarks of Adobe Systems

Incorporated.

The logos of AMD, Athlon, and Duron are the registered trademarks of Advanced Micro

Devices, Inc.

The logos of Intel, Intel Celeron, Pentium II, III and Pentium 4 are the registered

trademarks of Intel Corporation.

The logos of nVidia are the registered trademarks of nVidia Corporation.

The logos of Microsoft, Windows are the registered trademarks of Microsoft Corporation in

America and other countries.

All the titles of the products and the trademarks mentioned in this manual are for the

purpose of illustrative conveniences and are possessed by their respective firms.

We regret not informing about any changes in usage standards and other related

information. AOpen reserves the right of altering or modifying the content of this manual. In

case of any mistakes or incorrect descriptions, which include those on the products, AOpen

makes no guarantee or commitments.

This document is based on the copyright laws in order to protect our company and reserve

all rights.

Under no circumstances are any types of duplicating and loading this brochure in any

databases and media permitted except the permission signed on formal document by

AOpen Company.

1.2 Features of This Manual

To help you grab the useful information of this motherboard and aware of certain

conditions that you might need to know, you will see the icons below frequently:

1.3 Safety Information

This contains knowledge you should know in process

of assembling, or some helpful tips.

This tip tells you some useful information that will

make your installation smoothly.

Please be careful when you see this mark. It

highlights mistakes that occur often during

assembling, or something you need to pay attention

to.

Please wear a wrist strap and attach it to a metal part of the system unit

before handling a component. Alternatively, you can also touch an object

that is of ground connection or with metal surface.

Always unplug the power before you make any jumper setting.

Before you install or remove any components on the motherboard, please

make sure to disconnect the power first in case of damaging motherboard

or other components.

Note

Warning

Warning / Caution

Warning

Tip

Chapter 2 Introduction to This Motherboard

2.1 How does your motherboard look like?

1. JP28 PS2 KB/Mouse Wakeup Jumper 15. RealTek 10/100 Mbps LAN Chip

2. ATX Power Connector 16. S/PDIF Connector

3. Low ESR Capacitors 17. AUX-IN Connector

4. SYSFAN1 Connector 18. Onboard AC’97 CODEC

5. AGP Protection LED 19. Front Audio Connector

6. AGP 8X Expansion Slot (vKM400Am-S)

7. AGP 4X Ex

ansion Slot

(

vKM266Pm

)

20. CD-IN Connector

7. 462-pin CPU socket supporting AMD

7. AthlonTM / AthlonTMXP / Duron CPU 21. CNR Expansion Slot

8. VIA KM400A / VIA 8237 Chipsets

(vKM400Am-S)

VIA KM266Pro / VIA 8235CE Chipsets

(vKM266Pm)

22. 32-bit PCI Expansion Slots X 3

9. 184-pin DIMMs X 2 23. USB2.0 Connectors X 2 (vKM400Am-S)

23. USB2.0 Connector X 1 (vKM266Pm)

10. CPUFAN Connector 24. Serial ATA Ports X 2(only for vKM400Am-S)

11. SYSFAN2 Connector 25. JP14 CMOS Data Clear Jumper

12. IrDA Connector 26. Case Open Connector

13. FDD Connector 27. Front Panel Connector

14. IDE Connectors x 2

Chapter 2 Introduction to This Motherboard

2 3

4 5

27 12

2.2 Specification

Here is the main function of your motherboard.

Models vKM400Am-S vKM266Pm

CPU AMD Athlon XPTM / AthlonTM / Duron CPU

Socket A

FSB400 MHz/333MHz/266MHz

AMD Athlon XPTM / AthlonTM / Duron CPU

Socket A

FSB 333 MHz/266MHz

Chipset VIA KM400A / VIA 8237 VIA KM266Pro / VIA 8235CE

Main

Memory

DDR 266/333/400MHz

DDR DIMM x 2

DIMM Type : 64/128/256/512MB &1GB

Max Memory : 2GB

DDR 266/333MHz

DDR DIMM x 2

DIMM Type : 64/128/256/512MB & 1GB

Max Memory : 2GB

Graphics Integrated VGA Engine in chipset

8X AGP slot Integrated VGA Engine in chipset

4X AGP slot

IDE

Integrated ATA133 and Serial ATA

Controller

Max Disk: 144,000,000GB [by 48 bits

LBA Spec.]

Integrated ATA133 Controller

Max Disk: 144,000,000GB [by 48 bits

LBA Spec.]

LAN Realtek 10/100 Mbps PCI LAN Chip Realtek 10/100 Mbps PCI LAN Chip

Sound Realtek AC'97 CODEC onboard, support

5.1 Channel Realtek AC'97 CODEC onboard, support

5.1 Channel

USB Integrated in chipset, USB 2.0 x 8 Integrated in chipset, USB 2.0 x 6

Slots AGP x 1

PCI x 3

CNR x 1

AGP x 1

PCI x 3

CNR x 1

Back Panel

I/O

PS/2 Keyboard x 1, PS/2 Mouse x 1

USB Port x 4, LAN Port x 1,

VGA Port x 1,

COM Port x 1, Printer Port x 1

Speaker_Out x 1, Line_In x 1, MIC_In x1

PS/2 Keyboard x 1, PS/2 Mouse x 1

USB Port x 4, LAN Port x 1,

VGA Port x 1,

COM Port x 1, Printer Port x 1

Speaker_Out x 1, Line_In x 1, MIC_In x1

On Board

Connector

Floppy Driver Connector x 1

IDE Channel: ATA133 x 2

Serial ATA Channel x 2

Front Panel x 1

Front Audio x 1

CPU FAN x 1,System FAN x 2

Case Open Connector x 1

AUX_IN Connector x 1, CD_IN x 1

IrDA x 1, USB Connectors x 2

Floppy Driver Connector x 1

IDE Channel: ATA133 x 2

Front Panel x 1

Front Audio x 1

CPU FAN x 1,System FAN x 2

Case Open Connector x 1

AUX_IN Connector x 1, CD_IN x 1

IrDA x 1, USB Connector x 1

BIOS Award PnP 4Mb Flash ROM BIOS Award PnP 2Mb Flash ROM BIOS

Form Factor Micro ATX Micro ATX

Board Size 244 mm x 220 mm 244 mm x 220 mm

2.3 Block Diagram

VIA KM400A

(vKM400Am-S)

VIA KM266Pro

(vKM266Pm)

DIMM Sockets x2

DDR400/333/266

RAM Up to 2 GB

(vKM400Am-S)

Socket 462

AMD Athlon/

Ahtlon XP/Duron

CPU

266/333/400MHz

System Bus (400MHz

only for vKM400Am-S)

AGP bus

VGA Onboard

VIA 8237

(vKM400Am-S)

VIA 8235CE

(vKM266Pm)

32-bit PCI Slots

PCI Bus

Serial ATA Ports x2

(for vKM400Am-S)

150MB

IDE Drives x 4

RealTek

AC97

CODEC

ATA

33/66/133

4Mbits FlashEEPROM

(vKM400Am-S)

2Mbits FlashEEPROM

(vKM266Pm)

Parallel Port

USB Ports x8

(vKM400Am-S)

USB Ports x6

(vKM266Pm)

Floppy Disk

Drive

AGP 8X

(vKM400Am-S)

AGP4X

(

vKM266Pm

)

Realtek

LAN Chip

LAN connect

Com

onent

DDR333/266

RAM Up to 2 GB

(vKM266Pm)

Serial Port x 1

Chapter 3 Hardware Installation

3.1 Quick Installation Procedure

1. Installing CPU

2. Installing CPU

Fan & System Fan

3. Installing

Memory Module

4. Installing HD,

CD-ROM and

SATA Disk, etc

6. Connecting ATX

Power Cable

5. Connecting Front

Panel Cable

7. Installing AGP & PCI Cards

8. Installing Other

Devices (USB, Front

Audio, etc)

9. Connecting

Back Panel Ports

(Keyboard,

Mouse, etc)

10. Loading

Default BIOS,

Setting CPU

Fre

uenc

11. Installing

Operating System

(such as, Windows

XP)

12. Installing Drivers &

Utilities

3.2 Installation You Have to Know

Installing CPU

This motherboard supports AMD®Athlon Socket 462 series CPU. Be careful of

CPU orientation when you plug it into CPU socket (with CPU Overheat Protection

function implemented, the system will be automatically powered off when the

temperature of CPU reaches to 97 degree, but it works only on AthlonTMXP /

Duron CPU).

1. Pull up the CPU socket lever and up to 90-degree angle.

2. Locate Pin 1 in the socket and look for a golden arrow on the CPU upper

interface. Match Pin 1 and golden arrow. Then insert the CPU into the

socket.

3. Press down the CPU socket lever to finish CPU installation.

Note: If you do not m

CPU socket Pin 1 and C

edge well, you may da

CPU socket lever

Socket Pin 1

Golden Arrow

Otros manuales para VKM400AM-S

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Placa madre de AOpen

AOpen

AOpen MX36CE Guía de configuración

AOpen

AOpen nCK804a-LFS Manual de usuario

AOpen

AOpen DX34R-U Guía de configuración

AOpen

AOpen AX4SP-G Hoja de datos

AOpen

AOpen AK77-8X Guía de configuración

AOpen

AOpen MX36 Guía de configuración

AOpen

AOpen MX4BS Guía de configuración

AOpen

AOpen MX3S-U Hoja de datos

AOpen

AOpen MK77-333 Manual de usuario

AOpen

AOpen AK77-600N Manual de usuario

AOpen

AOpen MX4SG-4DL Guía de configuración

AOpen

AOpen MX34-U Hoja de datos

AOpen

AOpen MK73LE-V Guía de configuración

AOpen

AOpen s760GXm-SL Manual de usuario

AOpen

AOpen AK79G TUBE Guía de configuración

AOpen

AOpen MX46L Hoja de datos

AOpen

AOpen AX45F-1394 Hoja de datos

AOpen

AOpen AX4C-G Guía de configuración

AOpen

AOpen Fortress 9500 Manual de usuario

AOpen

AOpen AX4B-533 Tube Guía de configuración

AOpen

AOpen MK77M-V Manual de usuario

AOpen

AOpen AX59PRO Manual de usuario

AOpen

AOpen AX6C-L Manual de usuario

AOpen

AOpen AX4SP Guía de configuración

Manuales populares de Placa madre de otras marcas

DFI

DFI SD170 Manual de usuario

ASROCK

ASROCK ROMED8-2T Manual de usuario

Asus

Asus P2L97A Manual de usuario

Winmate

Winmate IC70 Manual de usuario

Asus

Asus MES-B Manual de usuario

Grantech

Grantech SYS8F377VGGA-3OMN Manual de usuario

Telit Wireless Solutions

Telit Wireless Solutions SL869-3DR Manual de usuario

Gigabyte

Gigabyte GA-9IVDT Manual de usuario

Texas Instruments

Texas Instruments ADS8372EVM Manual de usuario

Commell

Commell MS-C73 Manual de usuario

IBT Technologies

IBT Technologies MB860 Manual de usuario

Nvidia

Nvidia TEGRA DG-04927-001_V01 Manual de usuario

Biostar

Biostar M7VIT Bravo Instrucciones de funcionamiento e instalación

Intel

Intel D33217CK Manual de usuario

Asus

Asus F1A55-M LX PLUS R2.0 Manual de usuario

EPC

EPC EPC9147C Manual de usuario

Asus

Asus EX-B760M-V5 D4 Manual de usuario

EPOX

EPOX MU-8KHA0010 Manual de usuario
