Site Master ™

S810A, S818A

Antenna and

Coax/Waveguide Analyzer

User’s Guide

Hand-Held Tester For Antennas, Transmission Lines

And Other RF Components

Color Cover P/N: 00986-00019

WARRANTY

The ANRITSU product(s) listed on the title page is (are) warranted

against defects in materials and workmanship for one year from the

date of shipment.

ANRITSU’s obligation covers repairing or replacing products which

prove to be defective during the warranty period. Buyers shall prepay

transportation charges for equipment returned to ANRITSU for war-

ranty repairs. Obligation is limited to the original purchaser. ANRITSU

is not liable for consequential damages.

LIMITATION OF WARRANTY

The foregoing warranty does not apply to ANRITSU connectors that

have failed due to normal wear. Also, the warranty does not apply to

defects resulting from improper or inadequate maintenance by the

Buyer, unauthorized modification or misuse, or operation outside the

environmental specifications of the product. No other warranty is ex-

pressed or implied, and the remedies provided herein are the Buyer’s

sole and exclusive remedies.

TRADEMARK ACKNOWLEDGEMENTS

MS-DOS, Windows, Windows for Workgroups, Windows NT, and

Windows 95 are registered trademarks of the Microsoft Corporation.

Site Master and Cable Mate are trademarks of ANRITSU Company.

NOTICE

ANRITSU Company has prepared this manual for use by ANRITSU

Company personnel and customers as a guide for the proper installa-

tion, operation and maintenance of ANRITSU Company equipment

and computer programs. The drawings, specifications, and informa-

tion contained herein are the property of ANRITSU Company, and any

unauthorized use or disclosure of these drawings, specifications, and

information is prohibited; they shall not be reproduced, copied, or

used in whole or in part as the basis for manufacture or sale of the

equipment or software programs without the prior written consent of

ANRITSU Company.

MANUAL ERRATA

MANUAL:

Title: Site Master S810A, S818A Antenna and Coax/

Waveguide Analyzer User’s Guide

Part Number: 10580-00014

Rev. Ltr/Date: A / November 1997

ERRATA PACKET

Part Number: 10901-00133

INSTRUCTIONS

1. Make the manual change listed below.

ERRATA 1, December 1997

1. Page 1-3

Delete the following items from the Optional Accessories

list:

•Armoured Test Port Extension Cable, 3.0 meter, N(m)

to N(f), Part No. 15NNF50-3.0B

•Armoured Test Port Extension Cable, 5.0 meter, N(m)

to N(f), Part No. 15NNF50-5.0B

S810A, S818A UG E-1

Table of Contents

General Information ..........1-1

Introduction..................1-1

Description ..................1-1

Standard Accessories.............1-2

Options ....................1-3

Optional Accessories .............1-3

Performance Specifications .........1-5

Operation ................2-1

Introduction..................2-1

Control Descriptions .............2-1

Test Panel ........................2-1

Keypad .........................2-2

Soft Keys ........................2-6

Operating Procedures............2-24

Making Common Function Selections . . . 2-25

Applying Power ....................2-25

Performing a Calibration...............2-25

Setting Options ....................2-27

Setting Markers ....................2-28

Setting Scale/Limits..................2-28

Determining Remaining Battery Life ........2-29

Making Frequency-Domain Measurements2-30

Return Loss or SWR Measurement ....2-30

Selecting a Frequency Range.............2-30

Performing a Calibration...............2-31

Making a Measurement ...............2-32

Scaling the Display ..................2-32

Adjusting Markers ..................2-33

Adjusting a Limit ...................2-33

Saving a Setup.....................2-34

Recalling a Setup ...................2-34

Storing a Display ...................2-34

Recalling a Display ..................2-35

November 1997 10580-00014

Coax/Waveguide Loss Measurement . . . 2-35

Selecting a Frequency Range.............2-35

Performing a Calibration...............2-36

Making a Measurement ...............2-37

Scaling the Display ..................2-38

Adjusting Markers ..................2-38

Adjusting a Limit ...................2-39

Saving a Setup.....................2-39

Recalling a Setup ...................2-39

Storing a Display ...................2-40

Recalling a Display ..................2-40

Making Distance-Domain Measurements . 2-41

Selecting a Frequency Range.............2-41

Performing a Calibration...............2-43

Performing a DTF Measurement ..........2-44

Scaling the Display ..................2-45

Adjusting Markers ..................2-45

Adjusting a Limit ...................2-46

Saving a Setup.....................2-47

Recalling a Setup ...................2-47

Storing a Display ...................2-47

Recalling a Display ..................2-48

Making Power Measurements .......2-48

Entering Power Monitor Mode ...........2-48

Zeroing the Power Monitor .............2-48

Measuring High Input Power Levels ........2-48

Displaying Power in dBm and Watts ........2-49

Displaying Relative Power ..............2-49

Printing....................2-50

Printer Switch Settings ................2-50

Printing a Screen ...................2-51

Symbols ...................2-52

Self Test ...................2-52

Error Codes .................2-52

Self Test Errors ....................2-52

Range Errors .....................2-52

Replacing the Battery ............2-52

Using the Soft Carrying Case........2-57

Software Tools Program........3-1

Description ..................3-1

Requirements .................3-1

Communication Port Setting.........3-2

Changing COM Port Settings–Windows 3.1 .....3-2

Changing COM Port Settings–Windows 95 .....3-4

Software Installation .............3-5

Plot Capture..................3-6

Capture multiple to database .............3-7

Capture multiple traces to PC screen.........3-8

Single trace capture ..................3-8

Program Operation..............3-9

Fault Location Software ..........3-10

Smith Chart Software............3-10

Saving a Plot as a Windows Metafile....3-11

Saving Data to a Spreadsheet........3-11

Saving Data to a Data Base .........3-12

“Drag-n-Drop” ...............3-12

Printing....................3-12

Appendix A Reference Data .....A-1

Description ..................A-1

iii/iv

How to Use this Manual

The operation of the Site Master ™ is straightforward and intuitive.

However, you may find it helpful to review the operation of the keys

and menus prior to first-time use.

Descriptions of the keys and menus, along with measurement proce-

dures, are provided in Chapter 2.

First-time users and maintenance supervisors will benefit from perusing

the material in Chapter 1. This chapter describes the instrument and

provides listings of options and performance specifications.

Please Recycle

This product contains a rechargeable nickel-

cadmium battery. Spent nickel-cadium bat-

teries are valuable resources, do not throw

them away. Arrange for proper return for re-

cycling in your locality. If you do not have

access to proper disposal methods, return the

battery to your ANRITSU service center.

Service centers will dispose of the unit at no

charge. ANRITSU service centers are listed

in Table 2-4 (page 2-58).

1-0

Figure 1-1. Site Master System

Chapter 1

General Information

Introduction

This chapter provides description, specification, and optional accesso-

ries for the Site Master Series instruments. This series has two mem-

bers, as shown below. Throughout this manual, the term Site Master

will refer to the series; whereas, the terms Site Master S810A and

S818A will refer to the applicable individual models.

Model Frequency Range

S810A 3.3 to 10.5 GHz

S818A 3.3 to 18.0 GHz

Description

The Site Master (Figure 1-1) is a hand held SWR/RL(standing wave

ratio/return loss) and Distance-To-Fault measurement instrument that

includes a built-in synthesized signal source and an optional power

monitor. It uses a keypad to enter data and a liquid crystal display

(LCD) to provide a graphical indication of SWR or RL over the

selected frequency range. The Site Master has a built-in distance-to-

fault capability. The Site Master is capable of up to two hours of con-

tinuous operation from a fully charged internal battery. It can also be

operated from a 12.5 dc source (which will also simultaneously charge

the battery). Built-in energy conservation features can be used to extend

battery life over an eight-hour work day.

The Site Master is designed for measuring SWR, return loss, or coax/

waveguide insertion loss and locating faulty RF components in antenna

systems. Power monitoring capability is available as an option. The

displayed trace can be scaled and/or enhanced with settable frequency

markers and/or a limit line. A menu option provides for an audible

1-1
