AMX RMX 16 Manual de usuario

RMX 16: Digital Reverberation System

500 Series Module

Installation Guide Issue 1

Health & Safety Notice

FOR YOUR OWN SAFETY AND FOR THE PROTECTION OF OTHERS

PLEASE OBSERVE THE FOLLOWING HEALTH AND SAFETY INSTRUCTIONS

•READ THESE INSTRUCTIONS AND KEEP THEM HANDY

•HEED ALL SAFETY WARNINGS

•DO NOT USE NEAR WATER

•CLEAN ONLY WITH A DRY CLOTH

•DO NOT INSTALL NEAR HEAT SOURCES

•DO NOT BLOCK VENTILATION OPENINGS

•USE ONLY ACCESSORIES SPECIFIED BY THE MANUFACTURER

•REFER ALL SERVICING TO QUALIFIED PERSONNEL ONLY

•NO USER SERVICEABLE PARTS INSIDE

FAILURE TO OBSERVE THESE PROCEDURES AND RECOMMENDATIONS

WILL INVALIDATE THE MANUFACTURER’S WARRANTY

means or disclosed in part or whole to any third party without written permission.

As part of our policy of continual product improvement, we reserve the right to alter specifications without notice but with due regard to all current legislation.

Disclaimer: The information in this manual has been carefully checked and is believed to be accurate at the time of publication. However, no responsibility is

taken by us for inaccuracies, errors or omissions nor any liability assumed for any loss or damage resulting either directly or indirectly from use of the

information contained within it.

457 011 FAX +44 (0) 1282 417 282 WEB www.ams-neve.com

Table of Contents

Health & Safety notice ...............................................................................................2

Important safety Instructions U.S................................................................................4

Warning symbols .....................................................................................................5

Environmental Considerations .....................................................................................5

Cooling ...................................................................................................................5

Important Safety Instructions UK ...............................................................................6

RMX 16 Front Plate ...................................................................................................7

RMX 16 Rear Plate ....................................................................................................8

RMX 16 Side Plate.....................................................................................................9

Dimensions & Power requirements............................................................................. 10

Audio Specification.................................................................................................. 10

Audio Connection.................................................................................................... 10

Unit Connection Table.............................................................................................. 11

15-Way Pin outs ..................................................................................................... 11

For full operational instructions, please refer to the RMX 16 User Manual.

Important Safety Instructions

Read these instructions

Keep these instructions

Heed all warnings

Follow all instructions

Do not use this apparatus near water

Clean only with a dry cloth

Do not block any ventilation openings.

Install in accordance with the manufacturer's

instructions.

Only use attachments / accessories specified by the

manufacturer.

Unplug this apparatus during lightning storms or when

unused for long periods of time.

Refer all servicing to qualified service personnel.

Servicing is required when the apparatus has been

damaged in any way, such as power-supply cord or plug is

damaged, liquid has been spilled, or objects have fallen into

the apparatus, the apparatus has been exposed to rain or

moisture, does not operate normally or has been dropped.

WARNING:

TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS

APPARATUS TO RAIN OR MOISTURE.

Warning Symbols

Environmental considerations

Temperature Operating 5°C to 30°C

(41°F to 86°F)

Non-operating -20°C to 50°C

(-2°F to 122°F)

Max Gradient 15°C/Hour

(59°F/Hour)

Relative Humidity Operating 20% to 80%

Non-operating 5% to 90%

Max wet bulb 28°C non-condensing

(or 57°F non-condensing)

Altitude Operating 0 to 2,000m

Non-operating 0 to 12,000m

Cooling

Care must be taken not to place any accessories that could

block the ventilation above or below the units external PSU

or the Units ventilation system.

Please refer to the manual before operating

Important Safety Instructions

READ THESE INSTRUCTIONS AND KEEP THEM HANDY

HEED ALL SAFETY WARNINGS

THE UNIT MUST BE EARTHED WHEN OPERATED

DO NOT USE NEAR WATER

CLEAN ONLY WITH A DRY CLOTH

DO NOT INSTALL NEAR HEAT SOURCES

DO NOT BLOCK VENTILATION OPENINGS

THE AMBIENT ROOM TEMPERATURE SHOULD BE NO

GREATER THAN 30°C / 86°F

USE ONLY ACCESSORIES SPECIFIED BY THE

MANUFACTURER

OPTIONAL CARDS (IF SPECIFIED) SHOULD NOT BE

INSERTED OR REMOVED WITH THE POWER ON

REFER ALL SERVICING TO QUALIFIED PERSONNEL ONLY

NO USER SERVICEABLE PARTS INSIDE



500 Series Installation Diagram

RMX 16 Front Plate

RMX 16 Rear Plate

RMX 16 Side view
