AMX MAX-AOM Manual de usuario

audio output module

PLAYBACK & DISTRIBUTION

The MAX Audio Output Module (AOM) distributes audio to multiple

zones throughout a commercial facility or residential property.

Engineered as a streaming audio playback USB module, the AOM

provides up to four stereo outputs for both digital and analog channels.

The AOM is designed to work in conjunction with the full line of MAX-

MMS Integrated Content Servers.

IN ANY ZONE, ATANY TIME

Deliver custom audio distribution by simply adding an audio channel to

each area (zone) where audio can be distributed, according to project

specifications or as desired by the end user. The AOM communicates

directly with the MMS server to create a distinct audio zone that can be

controlled using an AMX Modero® Touch Panel. The result: instant

access to audio files, all from multiple locations. The end user even has

the ability to select and play different audio files simultaneously, in any

zone, at any time.

CONFIGURATION OPTIONS

The AOM is available in two configurations: as a single module (with four

stereo outputs) and as two side-by-side modules using the optional

Expansion Kit (AOM-EX). The kit adds another four audio outputs for a

total of eight. It allows both modules to appear as one single rack unit,

while taking up a minimum amount of space on the equipment rack.

MAX-AOM (FG2178-55)

POWER

•5VDC 0.9A external power supply (included)

•110-240 VAC 50/60 Hz

AUDIO OUTPUT

•4audio output channels, each with RCA SPDIF digital,

analog stereo

•Digital audio output: 6-channel Dolby digital and DTS

•Analog audio output: stereo

•24-bit D/A conversion, 129X over sampling

•48kHz sampling rate

•Output level – 10dBV nominal

•Signal to Noise Ratio: 110db A-weighted

•Frequency Response: 20 Hz to 20 kHz

•Dynamic Range: 110dB

REAR PANEL COMPONENTS

•USB Connector: Type B

•Power Cable Connector: DC 3-pin DIN

•Audio Output: Four sets of three connectors:

-(D): One RCA S/PDIF (coax) connector for digital output

-(L, R): Two RCA connectors for stereo analog output

DIMENSIONS (HWD)

•MAX-AOM (only): 1.75" x 8.48" x 10.47"

(4.44 cm x 21.53 cm x 26.59 cm)

•Two MAX-AOMs with AOM-EX Rack Mount Kit:

1.75" x 19.1" x 12.02" (4.44 cm x 48.51 cm x 30.53 cm)

WEIGHT

•MAX-AOM: 10.0 lbs (4.53 kg)

•MAX-AOM-EX: 8.45 lbs (3.83 kg)

INCLUDED ACCESSORIES

•5VDC 2.4A external power supply

• 6’ (1.83 m) USB (A to B) cable

•Removable Faceplate

OPTIONAL ACCESSORIES

•AOM-EX Expansion Kit (FG2178-56): includes a second

MAX-AOM unit with mounting brackets and hardware

CERTIFICATION

•FCC, CE

audio output module

ARGENTINA • AUSTRALIA • BELGIUM • BRAZIL • CANADA • CHINA • ENGLAND • FRANCE • GERMANY • GREECE • HONG KONG • INDIA • INDONESIA • ITALY • JAPAN

LEBANON • MALAYSIA • MEXICO • NETHERLANDS • NEW ZEALAND • PHILIPPINES • PORTUGAL • RUSSIA • SINGAPORE • SPAIN • SWITZERLAND • THAILAND • TURKEY • USA

ATLANTA • BOSTON • CHICAGO • CLEVELAND • DALLAS • DENVER • INDIANAPOLIS • LOS ANGELES • MINNEAPOLIS • PHILADELPHIA • PHOENIX • PORTLAND • SPOKANE • TAMPA

3000 RESEARCH DRIVE, RICHARDSON, TX 75082 • 800.222.0193 • 469.624.8000 • +1.469.624.7400 • 469.624.7153 fax • www.amx.com

©2006 AMX. All rights reserved. AMX and the AMX logo are all trademarks of AMX. AMX reserves the right to alter specifications without notice at any time.
