HD-9

LIFETIME™ OVAL

WHIRLPOOLS BY AMERICAN STANDARD

HIGH GLOSS ACRYLIC

LIFETIME™ OVAL

5-1/2' Whirlpool and Bathing Pool

❏ Model# 2645L (specify color)

• Acrylic with berglass reinforcement

• Molded-in lumbar back rest

• Factory installed and tested whirlpool system

• 1.4 HP single speed, self-draining pump/motor

• Six adjustable Ideal Flow Comfort Jets™

• Side-mounted air switch On/Off

• Two air volume controls

• Factory installed and tested whirlpool system

• Self leveling feet

• Designed with undermount installation option

❏ Model# 2645LC:

• Same as above with the EverClean™ whirlpool

system. The EverClean™ antimicrobial system

incorporates AlphaSan®, a patented

antimicrobial agent manufactured right into the

circulation system components, which

suppresses the growth of unsightly algae,

fungus, mold and mildew.

❏ Model# 2645L.002 Bathing Pool only

Nominal Dimensions:

66” x 36” x 19-3/4”

(1676 x 914 x 502mm )

Compliance Certications -

Meets or Exceeds the Following Specications:

• Underwriters Laboratories - Hydromassage

Bathtubs UL 1795

• ASME A112.19.7M for Whirlpool Appliances

• ANSI Z124.1 for Plastic Bathtubs

• ASTM E162 for Flammability

• NFPA 258 for Smoke Density

SEE REVERSE FOR ROUGHING-IN DIMENSIONS

AND PRODUCT SPECIFICATIONS

Revised 7/07

To Be Specied - Required:

❏ Color:

❏ Bath Filler: (specify nish)

❏ Bath Drain: 1583.470 (specify nish)

OR 1599.500.020 (white only)

To Be Specied - Optional:

❏ 5-1/2 Foot Acrylic Apron: 9366.018.XX (specify color)

❏ 5-1/2 Foot Apron: 9266.018.XXX (specify color)

For color/nish availability and other faucet choices, please

see the Product Selector and Pricing Guide.

* See American Standard Faucet Selector

AlphaSan® is a registered trademark of Milliken & Co.

HD-10

LIFETIME™ OVAL

WHIRLPOOLS BY AMERICAN STANDARD

HIGH GLOSS ACRYLIC

Revised 7/07

NOTES:

BATH CAN BE INSTALLED EITHER ABOVE OR BELOW FLOOR LINE AS PIER, ISLAND, OR PENINSULA TYPE INSTALLATION. SUMP

OF BATH IS SUPPORTED BY INTEGRAL FEET. NO ADDITIONAL SUPPORT REQUIRED. ENCLOSING MATERIAL BY OTHERS.

■ REFER TO INSTALLATION INSTRUCTIONS SUPPLIED WITH WHIRLPOOL FOR ADDITIONAL INFORMATION.

OPTIONAL APRON 9266.018 OR 9366.018 AVAILABLE AND MUST BE ORDERED SEPARATELY.

FITTINGS NOT INCLUDED AND MUST BE ORDERED SEPARATELY.

IF INSTALLING A DECK-MOUNTED FITTING, BEFORE DRILLING ANY HOLES: CHECK FOR INTERFERENCE WITH CIRCULATING

SYSTEM PIPING, DRAIN OVERFLOW, AND APRON INSTALLATION. MOUNTING HOLES DRILLED BY INSTALLER.

PROVIDE SUITABLE REINFORCEMENT FOR ALL SUPPORTS.

IMPORTANT: Dimensions of xtures are nominal and may vary within the range of tolerances established by ANSI Standard Z124.1.

These measurements are subject to change or cancellation. No responsibility is assumed for use of superseded or voided pages.

66"

(1676mm)

5-3/8"

(137mm)

(152mm) 36"

(914mm)

8-1/4"

(210mm)

(76mm)

11-1/4"

(286mm)

36"

(914mm)

18"

(457mm)

19-3/4"(H)

(502mm)

18-1/4"(C)

(464mm)

C/L OF

DRAIN

15-1/4"(A)

(387mm)

CUT OUT IN FLOOR

FOR DRAIN

DIMENSIONS OF FIXTURES ARE NOMINAL AND MAY VARY WITHIN THE RANGE

OF TOLERANCES ESTABLISHED BY ANSI STANDARDS Z124.1 AND A112.19.7.

66 x 36 x 19-3/4 In.

(1676 x 914 x 502mm)

96 Lbs. (44 Kg.)

580 Lbs. (263 Kg.)

58 Gal. (219 L)

42 Gal. (159 L)

49 x 26 In. (1245 x 660mm)

62 X 32 In. (1575 x 813mm)

12-3/4 In. (324mm)

35 Lbs./Sq.Ft. (171 Kgs./Sq.m)

GENERAL SPECIFICATIONS FOR 2645L BATHING POOL

INSTALLED SIZE

WEIGHT

WEIGHT w/WATER

GAL. TO OVERFLOW

WHIRLPOOL MIN. OPERATING VOL.

BATHING WELL AT SUMP

BATHING WELL AT RIM

WATER DEPTH TO OVERFLOW

FLOOR LOADING

(PROJECTED AREA)

WHIRLPOOL ELECTRICAL SPECIFICATIONS

1.4 HP, 9.7 AMPS, 120V.PUMP
