QUICK START GUIDE
Aleratec
1:4 DVD/CD Tower Publisher HLS
™
Win/Mac
Part No. 260170
www.aleratec.com
Welcome!
Congratulations on your purchase of an Aleratec 1:4 DVD/CD Tower
Publisher HLS Win/Mac, considered by industry experts to be one of the
finest DVD/CD Duplicators available.
The entire Aleratec team is committed to providing you with courteous
service. Our knowledgeable staff will strive to make owning and
operating your new Aleratec 1:4 DVD/CD Tower Publisher HLS Win/Mac
a pleasant experience.
For more detailed information on configuring the 1:4 DVD/CD Tower
Publisher HLS Win/Mac and applying it’s various capabilities, please
refer to the User Guide on the CD included.
This Quick Start Guide will lead you step-by step through the basic
operation procedures of your 1:4 DVD/CD Tower Publisher HLS Win/
Mac.
We at Aleratec appreciate your selection of our product, and wish you
great success and enjoyment of your new 1:4 DVD/CD Tower Publisher
HLS Win/Mac.
Check out Aleratec online!
www.aleratec.com
www.twitter.com/Aleratec
www.youtube.com/Aleratec
Included Items
1:4 DVD/CD Tower Publisher HLS Win/Mac•
Power Cord•
USB Cable•
Installation CD•
Quick Start Guide (this document)•
Aleratec Registration Card•
NOTE: Please store and track the included software, registration codes
and parts carefully. Requests for replacement software, registration
codes, and/or parts may incur a fee.
www.aleratec.com 1
Product Features
The 1:4 DVD/CD 1:4 DVD/CD Tower Publisher HLS Win/Mac is a
multiple disc DVD/CD Duplicator and LightScribe Disc Labeler.
Fast recording speed for high-volume copying.•
Duplicates up to four DVDs or CDs simultaneously.•
Records up to four DVDs or CDs simultaneously.•
Burns labels on up to four LightScribe discs simultaneously.•
Key Items on the
1:4 DVD/CD Tower Publish HLS Win/Mac
Note: Choose a Good Location
Allow adequate clearance for moving parts.1.
Do not place near heat sources such as radiators or air ducts, or2.
in a place subject to direct sunlight, excessive dust, mechanical
vibration or shock.
Good care will help assure maximum product life. Improper3.
operating environment and misuse may void the warranty.
LightScribe
DVD/CD
Recorders
(4)
Power Switch
USB
Connector
Voltage Selector
Switch
www.aleratec.com
2
Software Installation
Your Aleratec 1:4 DVD/CD Tower Publisher HLS Win/Mac is equipped with a USB
2.0 port that is a bridge to all four LightScribe DVDRW drives.
For Windows Users
For Windows users, use the Aleratec Disc Publishing Software Suite CD to install
the Acoustica and Roxio software.
For Mac Users
Mac users please see the Discribe Robotic Software Quick Start Guide.
Disc Publishing
Connect the USB cable (included) to the USB port on the back of your1.
duplicator and to an empty USB port on your computer.
Check that the red Voltage Selector Switch on the back of the unit is set to 1152.
VAC. Power on your 1:4 DVD/CD Tower Publisher HLS Win/Mac.
Getting Started
Simultaneous LightScribe Disc Labeling
Please install the Acoustica disc labeling software from the included software CD.
For
best results, Aleratec Duplicator Grade LightScribe Media is recommended. See
specic information at the back of this Quick Start Guide.
Launch the DVD/CD Label Maker from the Acoustica program group in your1.
Start menu.
www.aleratec.com 3
When the program rst starts, you will be presented with the “new label” wizard. 2.
Click on the “Cancel” button to close the wizard and you will see the label design
workspace.
If you have already designed a label you wish to use, select the saved project from
the “File > Open” dialog box and skip to step 6.
To design a new label, choose the appropriate mode from the drop-down box3.
shown. “Full Mode” allows you to use the maximum area of the disc for your
label.
You may use one of the included backgrounds (Backgrounds tab) or you may4.
use any other image you may have as a background (“Art Browse” tab).
www.aleratec.com
4
Getting Started - continued
Add text to the label using the “Text” tool, and basic shapes can be added with 5.
“Shape.”
When you are ready to begin labeling, click on the “LightScribe” button.6.
Click to place a check mark next to each recorder that will be used for labeling.7.
Choose the desired print quality (the “Best” setting yields the highest contrast).
Press “Print” to continue.
www.aleratec.com 5
Insert discs into each of the recorders you wish to use, with the label side facing8.
down (shiny side facing up) and then click “OK.” The LightScribe process will
begin on each selected recorder.
Acoustica will display the status of the job with a progress bar corresponding to9.
each recorder. When the job has completed successfully, the labeled discs will
be will ejected automatically.
Note: If you have any questions about your Aleratec publishing system, please
consult our on-line Knowledge Base at: http://www.aleratec.com.
www.aleratec.com
6
Getting Started - continued
Simultaneous DVD/CD Duplication Instructions
The 1:4 DVD/CD Tower Publisher HLS Win/Mac can be used to make four copies
directly from an unprotected disc. These instructions assume your computer’s
internal DVD/CD drive will be used to read the source disc.
Launch Roxio Creator from the Roxio program group in your Start menu.1.
Click on the “Home” button to the left, and then choose “Applications” below.2.
From the list of applications, click on “Disc Copier” to start this component.3.
When Disc Copier opens, select from the options in the “Source” drop-down 4.
box to choose the drive you will use to read the source disc. If you have not
already inserted the disc you want to copy into the appropriate tray, do so now
and it will be recognized in a few moments.
www.aleratec.com 7
Click on the5. DOWN arrow to the right of the “Copy Now” button, and choose
“Advanced Copy.”
In the Burn Setup window that appears, click to place a check in the box next to6.
the recorders you want to use to copy. Make sure the drive containing the source
disc is not selected.
www.aleratec.com
8
Getting Started - continued
(Optional) Adjust the “Write Speed” setting from the Burn Options section to a 7.
suitable speed.
Note: Lower write speeds will reduce the chance of playback difficulties when
creating audio CDs or DVDs for home playback.
Click “OK” when you are ready to begin duplication.8.
Roxio Disc Copier will display the progress of the duplication job and will notify9.
you when the task has been completed successfully.
