AGPtek A16 Manual de usuario

CONTENT

English

Deutsch

Français

Italiano

Español

日本語

01/10

11/22

23/33

34/45

46/57

58/66

Before use

Buttons and Controls

Quick Guide

Thank you for purchasing AGPTEK Music Player. Please read the

manual carefully before using the product. Specifications are

subject to change without prior notice.

1. Charge the player

Charge by computer

Connect the player to a running computer via USB cable.

The USB cable can both be used for data transfer and charging the

player.

Use 5V/500mA charger (The charger is not included).

Plug one end of the micro USB cable into the USB port of a charger,

the other end to the port on your device.

2. Power On/Off:

Long press the power button for 3 seconds to turn on/off the

1. Power on/off; Screen on/off

2. Enter/ Play/ pause

3. Back

4. Menu

5. Previous/ Fast backward

6. Next/ Fast forward

7. Move up

8. Move down

9. Volume down

10. Volume up

11. Micro SD card slot

12. Headphone jack

13. Mic/ Reset hole

14. USB interface

player.

Short press the power button to turn on/off the screen display.

Note:

When you turn off the player with music playing/paused in

the background, next time you turn on the player, it will start from

the last position it left off.

3. Home Menu:

The Home menu is the starting point of each application. There are

8 main functions on the home menu: Music/ Bluetooth/ FM radio/

Tools/ Recordings/ Pedometer/ Folder/ Settings.

4. Basic Operation:

When it’s on main interface, tap the button / to choose

its 8 different functions on main interface, and tap the middle

button to enter it.

When it’s on menu list interface, tap button / to select

items, tap button to enter/confirm, tap button to go

back and hold button to go back to the Home menu

directly.

When it’s on main interface and there is music playing or

paused in the background, tap the button to and it will

bring you back to the music playing interface.

5. Import and Transfer Music

Connect the computer via the USB cable. Copy the music and

other files you need to transfer in the computer, and then paste in

the player, or just drag and drop the music files or folders directly

when connected to computer.

Note:

Do not disconnect your player during the transferring

process. If you do, the file being transferred will be damaged.

6.Insert / Remove Micro SD Card

Insert the Micro SD card into its slot and push inward, the deck will

automatically lock the Micro SD card. When remove the Micro SD

card, push inward and then let go, the card will automatically pop

up.

Note:

Please insert the memory card while the player is off, or it

may not able to read the data.

Music

Find “Music” on Home menu and tap the button to access to

its function.

The related list will show, including: All songs, Resume(Now

playing), Artists, Albums, Genres, Playlists, Update playlists, Local

folder and Card folder.

Note:

Local folder and Card folder functions are only available

when the Micro SD card inserted.

All songs - All the music files in local folder or card folder.

Resume (Now playing) - Take you back to the song or audio file

you are playing now or played last time.

Artists /Albums /Genres - View music files sorted by artists

/albums /genres.

Playlist - There 3 default playlist on the player: Playlist on the go

[1]/[2]/[3].

Update Playlists - Update music files.

Local folder / Card folder - View music file in the local folder or

card folder.

Note:

Local folder and card folder are conflict with each other. It

will stop playing music in the local folder to view the files card

folder.

1. Play the music

While it’s on music playing interface, hold the button to fast

forward, tap to switch to next music file; hold the button to

fast rewind, click to the previous song files. Tap button to

play/pause. Tap the button / to adjust volume.

2. Submenu

While it’s on music playing interface, tap button to access to

the submenu. Tap button / to select items or adjust value,

tap the button to enter or confirm.

1) Play mode

"Play music from…", choose to play songs from all songs or this

artist/album/genre.

Play music via Bluetooth

"Repeat", choose repeat mode: repeat 1, repeat all, and preview

or turn off repeat mode. If you select option "preview", the

player would only play the first 10 seconds of a track and then

skip.

"Shuffle", choose to turn on/off shuffle mode.

“Repeat settings”, A-B repeat mode.

- Replay Mode: Set A-B repeat period. Tap button to confirm

the starting time A when A is flashing. Then tap the button to

set the ending time B when B is flashing. The passage from time A

to B will be repeated automatically. The icon for A-B indication will

appear on the screen. Tap button again to back to normal

playback.

- Replay times: Set the replay times from 1 to 10.

- Replay intervals: Set the replay interval from 1 to 10 (seconds).

2) Sound settings

"Equalizer", choose from the 6 sound effects, or choose "off" to

turn off equalizer.

"Variable speed playback", adjust playback speed from

-8(Slowest) to +8(Fastest).

“Volume limit”, Set the maximum volume limit. Tap the button

/ to adjust value and tap button to confirm.

3) Add to playlist/ Remove from playlist, choose to add to or

remove from the 3 existing playlist.

4) Delete, choose to delete the song that is playing now.

5) Bookmarks, choose to add bookmark for the song that is

playing now, or go to /delete the bookmark you added.

Find “Bluetooth” on Home menu and tap button to access to

its function and enable Bluetooth.

Note:

Please open the Bluetooth of the device you want to connect

first.

Search devices

Search the nearby devices, then all of the devices which has

FM radio

opened its Bluetooth will be listed.

Device List

Choose from the available devices and tap the button to

connect/disconnect.

All music

After successfully connected, this player is ready to play music via

Bluetooth. Tap button to enter and play music.

Bluetooth music playback

Tap the button to enter the Bluetooth music playing interface.

Find “FM radio” on Home menu with the button to enter to its

function. A related list will show: Presets, Manual tune, Auto tune,

FM Recording.

Presets - View preset station list. While it’s on preset station list,

tap the button to choose to delete preset station or clear all

the presets

Manual tune /Auto tune - Choose to search stations manually

or automatically.

FM Recording - View the radio recording files. The radio

recordings will also be saved in Recordings > Recordings library.

Submenu

While it’s on radio playing interface, tap button to switch

among preset stations. Tap to access to its submenu which

includes: Play via Bluetooth, Start FM radio recording, Save to

presets, Clear preset, Auto tune, Turner Region and FM Recording.

Play via Bluetooth

Choose to listen to radio via Bluetooth. Please open the Bluetooth

of the device you want to connect first.

Start FM radio recording

Choose "Start FM radio recording", tap button to

pause/continue, tap and select “Yes” to save the recording

file.

Auto tune / Save to / Clear preset

Recordings

Tools

- “Auto tune”, search stations automatically. You can see the

searched stations in “Presets”.

- “Save to preset”, save the station you are listening to “Playlist”.

- “Clear preset”, tap button to enter the preset list, choose the

station you want to clear, then tap and choose “yes” to clear

the station

Find “Recordings” on the Home menu, tap button to access to

its function. The related list will show, including: Start voice

recording, Recordings library, Storage (only available when SD card

inserted),Record Format, Record Setting.

Start voice recording - Choose “Start voice recording” and tap

button to start voice recording, tap again to pause. Tap the

button and choose “Yes” to save the recording file.

Recordings library - Find the saved recordings in

Recordings >Recordings library. Tap button to play the

recording file. When it’s on recording file list interface, tap

button / to choose file and hold the button for 3

seconds and choose “Delete” to delete the file.

Storage - Choose to store your recordings in internal or external

memory. Confirm your selection with button .

Record Format - Choose the record format between MP3/WAV.

Record Settings - Track AVR mode. When you start recording

under AVR mode, the recorder will start recording automatically

if sound is detected and stop recording when no sound

detected.

Find "Tools" on the Home menu, tap button to access to its

function. A related list will show EBook, Videos, Calendar, Pictures,

Stopwatch and Alarm.

1. EBook

While it’s on text playing interface, tap button / to turn

the pages. Tap the button to play automatically, click again

Pedometer

to stop.

While it’s on book reading interface, click to enter its

submenu and set your preference, including Auto playtime

settings(set the automatic playback interval), Delete ebook,

Select bookmark, Delete bookmark, Add Bookmark, Select Page,

etc.

Note:

The device can only recognize the article in “txt” format.

2. Videos

Tap button to access to its function. You will need to choose

from local folder or card folder if the memory card is inserted.

Tap button to watch videos, tap / to go to

previous/next video or hold to fast backward/forward.

When it’s on video playing interface, press button to

access to its submenu, including: Brightness, Repeat, Delete

Video, Update Playlist. Set according to your preference.

Note:

This player can only support the AVI/AMV format in

128*160, you should convert video files by format conversion

software first.

3. Pictures

Tap to view pictures, tap / to go to previous/next

picture.

When it’s on picture viewing interface, tap button to access

to its submenu, including: Brightness, Backlight timer,

Slideshow settings, Delete picture. Set according to your

preference.

Note:

The device only supports pictures in JPG, BMP and GIF

format.

4. Stopwatch

Tap button to enter, tap again to start the timer, then tap

again to stop or tap to resume. Tap to start a new one.

The maximum Stopwatch list is 5.

Find "Pedometer" on Home menu, tap button to access to its

function, then a related list will show as Start the pedometer,

Settings

Personal info, History and Clear history.

Choose "Start the pedometer", it will display your realtime

workout information as below:

S: Step counts D: Distance traveled C: Calories burned;

S: Walking speed T: Elapsed time

Tap button and choose “Yes”/”No” to save the step record or

not.

"Personal info", set your step length between 0~200cm with

button to confirm.

"History", all your saved step record will be listed here, you can

save up to 3 records.

"Clear history", you can choose to delete the record you want

or delete all the record.

Find “Settings” on Home menu with the button to enter to its

function. A related list will show, including: Language, Date and

time, Display, Shutdown settings, Radio background, Button lights,

Information, Format device, Default settings. Always tap button

to confirm when you’ve done the settings.

Date and time: Choose “Date settings” to set date format and

date. To set date, tap / to switch among day|month|year,

tap button / to adjust the value of day|month|year. Set

time under “Time setting” and adjust the time in the same way.

Display settings: Set Brightness, Backlight time and Screensaver.

Shutdown settings

- Sleep timer: The device will shut down automatically when

reaches the set time;

- Power Off: When there is no operation on the device, the device

will shut off automatically when reaches the set time.

Radio background: Choose to turn on/off radio background. If

you choose the option “On”, the radio will continue playing

when you exit the FM radio.

Button lights

- Always on: Button lights stay on while the player is working.

Tabla de contenidos

Idiomas:

Otros manuales de Reproductor de MP3 de AGPtek

Manuales populares de Reproductor de MP3 de otras marcas

Blaupunkt

Blaupunkt Compact Drive MP3 Manual de usuario

Memorex

Memorex MMP9008 - 8GB USB 2.0 Manual de usuario

Meizu Electronic Technology

Meizu Electronic Technology E5 Manual de usuario

Naxa

Naxa NMV-173NX Manual de usuario

Philips

Philips PSA250 Manual de usuario

Zipy

Zipy go! Waving Manual de usuario

Sylvania

Sylvania SMPK4068 Manual de usuario

Sony

Sony NW-MS7 - Memory Stick Walkman Manual de usuario

Irradio

Irradio RF-42UC Manual de usuario

NABAIJI

NABAIJI SWIM MUSIC 100 Manual de usuario

Laser

Laser MP3-A9-4GB Manual de usuario

Samsung

Samsung YP-T7F Manual de usuario

Savant

Savant SMS-1001-00 Guía de referencia rápida

Trevi

Trevi XP 71 BT Manual de usuario

MobiBlu

MobiBlu DAH-1500i Manual de usuario

Denver

Denver MPS-201 Manual de usuario

Steren

Steren MP3-002 Manual de usuario

Kenwood

Kenwood M1GD50 Manual de usuario
