AGPtek c05 Manual de usuario
AGPTEK
User Manual
C05
Quick Guide
1. Press the button for about 3 seconds to turn on/off the device,
tap the button / to choose
its 9 different functions on
main interface, and tap to
enter it, tap for back.
2. Plug Earphone into the jack on
bottom left ofyour device, tap
the icon “Music” to access to
its function. Tap the /
button to adjust the volume.
3. Charge the Device: Plug one
end of the micro USB cable
into the device, plug the other
end into the charger (or into
the USB port of a computer).
4. Keys definition
1
Play Your Music
Select music application on main menu to enter it, and then play
your
songs according to a related list including “All songs”, “Artists”,
“Albums”, “Genres”, “Playlists”, “Album art”, “Audiobooks” and
“Update card data”.
1 Play/Pause/Power On-Off /Enter
2
Previous, moving up and fast forward playing
3
Next, moving down and fast backward playing
4
Volume+
5
Volume-
6
Menu button, exit to superior menu/back
7 Micro-SD socket
8 Micro-USB jack
2
Rewind/forward
When it’s on main playing interface, long press the / for
rewind/forward, and tap it to the previous/next song.
Note: the rewind/forward function is notsupported under Bluetooth
mode.
Shuffle/repeat
Shuffle your music through the button submenu
When it’s on main playing interface, long press the button and then
a related list will show, select the item “Shuffle” and “Repeat” under
the choice “Play mode”. Then choose the shuffle and repeat mode you
want.
Shuffle your music through “Setting”
You can also shuffle your songs under play mode by tap the icon
“Setting” on main interface, then select the item “Shuffle” and “Repeat”
under the choice “Play mode”.
Note: if you play the song through “Music”, it will only shuffle the songs
in the folder which your music is included. If you play the song through
3
“Folder”, it will shuffle songs by folder;
If you play songs through “Music”, it will only repeat in the folder
which your songs is included. If you play songs through “Folder”, it will
repeat by folder with the option “Repeat all”.
Playlist
To use the preset playlist
Long Press the button and then choose the option “Add to playlist”
for the song you want to operate. There are 3 items prepared for you,
including “Playlist on the go [1]”, “Playlist on the go [2]” and “Playlist
on the go [3]”, you can add the song to any one of these three as you
like.
To create the playlist by yourself
There is a free program called Media Go. It's the easiest program to use
for transferring playlists to the AGPTek. . Just create your playlists in
Media Go and then right-click its name and select 'Add playlist to
X :( Which is your MP3 player's disk) '. (You can download it at
http://mediago.sony.com/chs/download).
Note: Playlist is not supported under Bluetooth mode.
4
Add bookmark for your audio book
Long Press the button and then choose the option “Add
bookmark” under “Bookmarks”.
It is marked bythe stopping timeas“hh:mm:ss”. So you can set
the stopping time before you addit for continues playing next
time conveniently.
Maximum number ofbookmarks supported byeach audio file is
10. You can also cover the previous bookmark with new bookmark,
and then the old one will be replaced bythe new.
You can find the bookmarks you saved with the option “Go
to bookmark” under item “Bookmarks”, and you can delete them
with the option “Delete bookmark”.
Bluetooth Function
Select Bluetooth application on main menu to enter it.
1. Please make sure your BT device is on pairing mode before you
search it, which means the green and red light flash at the same time
for most BT devices.
5
2. Your device will be connected with the player automatically be with
“Bluetooth connected” for the first time.
3. If it’s not connected automatically, you can take the following steps
Please make sure you BT device is on pairing mode
Choose the item “Bluetooth Search”, when your BT device is
showed on player, choose it with the option “Connect Bluetooth”,
it will be connected successfully.
4. In Bluetooth mode, the shuffle option only works in an individual
folder, it will shuffle each folder one by one. And you can put all of your
songs into one folder (Music) to get them to shuffle if you need.
Note:
Make sure the previous paired device is under pairing mode.
Playlist is not supported under Bluetooth mode;
The rewind/forward function is not supported under Bluetooth
mode.
Folder/Recordings/Tools
Folder
6
Select folder view application on main menu to enter it, then you can
browse all the files saved in the player, including files of recording,
music, video, pictures etc.
Note: the player supports AMV and AVI video file, and you can use the
Video Tool to transfer the formats to the correct.
Recordings
There are 4 items under “Recordings” including Start voice recording,
Recording library, Record format and Record setting. Tap the button
for entering. In the meantime please note:
1. During recording, only and can be effective. You can adjust the
volume by tapping /
2. Tap to save present recording file, orchoose “yes” when you back
to the main menu.
Tools
There are Calendar, Stopwatch, Alarm and Video included in this item.
Choose according to your need.
Pictures/E book/ FM radio
Pictures
7
Tap the button for enter/play, tap the button / to choose upand
down.
When it’s on main playing interface, long press to access to sub-
menu, including “Brightness”, “Backlight timer”, “Slideshow settings”,
“Delete picture” and “Update card data”. Choose according to your
need.
Ebook
You can read and edit the article inthe device. The device only can
recognize the article in “txt.” format.
FM radio
Select Bluetooth application onmain menu to enter it, and then a
related list will show including “Presets”, “Manual tune”, “Auto tune”
and “FM recording”.
Presets
The frequency points of radio station are displayed with 30 frequency
points reserved at most.
Manual tune
Press to enter manual search mode, you can search programs
8
manually through pressing / button.
Auto tune
Press to enter Auto tune mode, it will show “Do you want to auto-
tune the presets”, press to confirm Yes or No. If choose Yes, it will
be searching automatically and automatically save searched station in
Presets.
FM recording
When listening to the broadcast station program, long press to
appear sub-menu, including Bluetooth link, Start FMradio recording,
Save topreset, Clear preset and Tuner Region.
Note: the player isdefaulted with command band, if you are in Japan,
you need to change to Japan Band.
Trouble Shooting
Media player doesn’t work or screen doesn’t display the content:
-Check battery power Unable to download files
-Check the connection between USB port of the computer and USB
cable.
-Format the media player.
9
