Agilent Technologies 34450A Manual de usuario

Agilent Technologies

Agilent 34450A

5½Digit Multimeter

Quick Start Guide

II 34450A Quick Start Guide

Notices

No part of this manual may be reproduced in

any form or by any means (including elec-

tronic storage and retrieval or translation

into a foreign language) without prior agree-

ment and written consent from Agilent

Technologies, Inc. as governed by United

States and international copyright laws.

Manual Part Number

34450-90007

Edition

First Edition, October, 2012

Agilent Technologies, Inc.

5301 Stevens Creek Blvd.

Santa Clara, CA 95052 USA

Warranty

The material contained in this docu-

ment is provided “as is,” and is sub-

ject to being changed, without notice,

in future editions. Further, to the max-

imum extent permitted by applicable

law, Agilent disclaims all warranties,

either express or implied, with regard

to this manual and any information

contained herein, including but not

limited to the implied warranties of

merchantability and fitness for a par-

ticular purpose. Agilent shall not be

liable for errors or for incidental or

consequential damages in connec-

tion with the furnishing, use, or per-

formance of this document or of any

information contained herein. Should

Agilent and the user have a separate

written agreement with warranty

terms covering the material in this

document that conflict with these

terms, the warranty terms in the sep-

arate agreement shall control.

Technology Licenses

The hardware and or software described in

this document are furnished under a license

and may be used or copied only in accor-

dance with the terms of such license.

Restricted Rights Legend

U.S. Government Restricted Rights. Soft-

ware and technical data rights granted to

the federal government include only those

rights customarily provided to end user cus-

tomers. Agilent provides this customary

commercial license in Software and techni-

cal data pursuant to FAR 12.211 (Technical

Data) and 12.212 (Computer Software) and,

for the Department of Defense, DFARS

252.227-7015 (Technical Data - Commercial

Items) and DFARS 227.7202-3 (Rights in

Commercial Computer Software or Com-

puter Software Documentation).

Safety Notices

CAUTION

A CAUTION notice denotes a haz-

ard. It calls attention to an operat-

ing procedure, practice, or the like

that, if not correctly performed or

adhered to, could result in damage

to the product or loss of important

data. Do not proceed beyond a

CAUTION notice until the indicated

conditions are fully understood and

met.

WARNING

A WARNING notice denotes a

hazard. It calls attention to an

operating procedure, practice, or

the like that, if not correctly per-

formed or adhered to, could result

in personal injury or death. Do not

proceed beyond a WARNING

notice until the indicated condi-

tions are fully understood and

met.

34450A Quick Start Guide III

Safety Symbols

The following symbols on the instrument and in the documentation indicate precautions

which must be taken to maintain safe operation of the instrument.

Environmental Conditions

This instrument is designed for indoor use and in an area with low condensation. The table

below shows the general environmental requirements for this instrument.

Earth (ground) terminal Caution, risk of electric shock

Frame or chassis terminal Caution, risk of danger (refer to this manual

for specific Warning or Caution information)

IEC Measurement Category II. Inputs may be

connected to mains (up to 300 VAC) under

Category II overvoltage conditions.

CAT II

300 V

Environmental Conditions Requirements

Operating temperature Full accuracy at 0 °C to 55 °C

Operating humidity Full accuracy up to 80 % R.H at 30 °C

(non-condensing)

Storage temperature –40 °C to 70 °C

Altitude Operating up to 3,000 metres

Pollution degree Pollution Degree 2

NOTE

The Agilent 34450A 5½ digit dual display multimeter complies with the following

EMC and safety requirements:

• IEC 61010-1:2010 / EN 61010-1:2010 (3rd Edition)

• IEC 61326-1:2005 / EN61326-1:2006

• CISPR 11:2003 / EN 55011:2007 Group 1 Class A

• Canada: ICES/NMB-001:Issue 4, June 2006

•Australia/New Zealand: AS/NZS CISPR 11:2004

IV 34450A Quick Start Guide

Regulatory Markings

Additional Safety Information

For further information on safety, refer to the 34450A User’s Guide.

The CE mark is a registered trademark

of the European Community. This CE

mark shows that the product complies

with all the relevant European Legal

Directives.

The C-tick mark is a registered

trademark of the Spectrum

Management Agency of Australia. This

signifies compliance with

the Australia EMC Framework

regulations under the terms of the

Radio Communication Act of 1992.

ICES/NMB-001 indicates that this ISM

device complies with the Canadian

ICES-001.

Cet appareil ISM est confomre a la

norme NMB-001 du Canada.

This instrument complies with the

WEEE Directive (2002/96/EC) marking

requirement. This affixed product label

indicates that you must not discard

this electrical or electronic product in

domestic household waste.

The CSA mark is a registered

trademark of the Canadian Standards

Association.

This symbol indicates the time period

during which no hazardous or toxic

substance elements are expected to

leak or deteriorate during normal use.

Forty years is the expected useful life

of the product.

34450A Quick Start Guide V

Contents

Standard Shipped Items 1

The Front Panel at a Glance 2

The Display at a Glance 3

The Rear Panel at a Glance 4

Locking and Unlocking the Front Panel Keys 5

Adjusting the Carrying Handle 6

Selecting Measurement Functions 7

Selecting Resolution/Speed 8

Using the Dual Display 9

Accessing Null Function 10

Accessing Math Function 10

Editing Math Values 11

Connecting Test Leads to the Terminals 12

NOTE

For further information on any topics mentioned in this Quick Start Guide,

please refer to the 34450A User’s Guide.

VI 34450A Quick Start Guide

THIS PAGE HAS BEEN INTENTIONALLY LEFT BLANK.

34450A Quick Start Guide 1

Standard Shipped Items

Agilent 34450A 5½Digit Multimeter

Certificate of

Calibration

Product

Reference CD ROM

Agilent IO Library

Suite CD ROM

Quick Start Guide

USB Interface cableTest Kit Leads

Power Cord

88.5mm

272.3mm

212.6mm

234450A Quick Start Guide

The Front Panel at a Glance

358

11710 9

NOTE

For a complete list of all keypad functions and descriptions, please refer to

Chapter 1, “Getting Started Tutorial” in the 34450A User’s Guide.

Display

Power ON/OFF Switch

Measurement functions

Math Operations

State Store/Recall, Utility Menu

Data Log, View

Auto range and Manual range

Resolution, Measurement Speed

SHIFT (selects blue shifted keys) and Local Key

Secondary Display Key

Input Terminals

34450A Quick Start Guide 3

The Display at a Glance

Single Display Screen

Figure 1-1 Typical single display screen

Dual Display Screen

Figure 1-2 Typical dual display screen

NOTE

For a complete list of all annunciator descriptions, please refer to Chapter

1, “Getting Started Tutorial” in the 34450A User’s Guide.

434450A Quick Start Guide

The Rear Panel at a Glance

Figure 1-3 Rear panel at a glance

78 9

Serial Interface Connector

USB Interface Connector

GPIB with Option 3445GPBU installed

Current Fuse

Model and Serial Number Label

Kensington Lock

Chassis Ground Lug

AC Power Connector

AC Line Fuse

AC Line Voltage Selector
