AgfaPhoto Sensor 500-X Manual de usuario

Thank you for purchasing this AgfaPhoto digital camera. Please read these operating instructions

carefully in order to use the digital camera correctly. Keep the instructions in a safe place after read-

ing so that you can refer to them later.

Notice: this User’s Manual has been written for the following camera models: AgfaPhoto

sensor 500-X, AgfaPhoto sensor 505-X and AgfaPhoto sensor 510-X.

Precautions

Before using the camera, please ensure that you read and understand the safety precautions de-

scribed below. Always ensure that the camera is operated correctly.

•Do not point the camera directly into the sun or other intense light sources which could damage

your eyesight.

•Do not try to open the case of the camera or attempt to modify this camera in any way. High-voltage

internal components create the risk of electric shock when exposed. Maintenance and repairs should

be carried out only by authorized service providers.

• Donotretheashtooclosetotheeyesofanimalsorpeople,especiallyyoungchildren.Eyedamage

mayresult.Inparticular,keepatleastonemeterawayfrominfantswhenusingtheash.

•Keep the camera away from water and other liquids. Do not use the camera with wet hands. Never

use the camera in the rain or snow. Moisture creates the danger of electric shock.

•Keep the camera and its accessories out of the reach of children and animals to prevent accidents

or damage to the camera.

•If you notice smoke or a strange odor coming from the camera, turn the power off immediately. Take

the camera to the nearest authorized service center for repair. Never attempt to repair the camera

on your own.

•Use only the recommended power accessories. Use of power sources not expressly recommended

forthisequipmentmayleadtooverheating,distortionoftheequipment,re,electricalshockor

other hazards.

Disclaimer

We assume no responsibility over and above the provisions of the Product Liability Law for damages

suffered by the user or third parties as a result of inappropriate handling of the product or its acces-

sories, or by their operational failure and by their use. We reserve the right to make changes to this

product and its accessories without prior notice.

Warning! Never open the camera or remove any parts of it. This will void all guarantee claims.

Using your batteries

For best performance and prolonged battery life, we recommend the use of AAA-sized rechargeable

NiMH batteries.

Extending battery life

The following functions use up a great deal of battery power and should therefore only be used

occasionally:

• Excessiveuseofash

• Editingimagesonthecameradisplay

The battery life can be affected by soiling. Please clean the contacts with a clean, dry cloth before

putting the batteries in the camera. Battery performance drops at temperatures below 5° C (41° F). If

you use the camera at low temperatures you should have replacement batteries to hand and ensure

theydonotgettoocold.Pleasenote:youshouldnotdisposeofcoldandseeminglyatbatteries

because these batteries may work again at room temperature.

Parts of the Camera

1. Flash

2. Selftimer lamp

3. Lens

4. Operation lamp

5. LCD display

6. Playback button

Five-way control button

7.OK/Enterbutton(vertically)

8. Right

9. Down

10. Up

11. Left

12.MENUbutton

13. Shutter button

14. Mode button

15. Power button

16. Microphone

17. Strap mount

18. Battery cover

19. USB jack

20. Tripod socket

Attaching the Strap

Attach the strap to your camera as shown in the image.

Caution

Do not swing the camera around by the strap

Inserting the Batteries

The camera is powered by two AAA-size alkaline batteries or rechargeable NiMH batteries.

1Open the battery cover.

Slide the battery cover in the direction indicated by the arrows.

2Insert the batteries.

Insert two AAA-size batteries with the positive (+) and negative

(-) poles matching the directions indicated inside the battery

compartment.

3Close the battery cover.

Turning Power On & Off

Press the Power button (1) to turn on the camera in the Capture

mode.ThepowerturnsonandtheLED(2)lightsred.

2PressthePowerbutton(1)againtoturnthepoweroff.ThepowerturnsoffandtheLEDturns

off.

Changing the Mode

You can record images and voices in the REC mode and use the Playback mode to replay, delete or

edit images on the LCD monitor.

Switching between REC and Playback Mode

In REC mode, press the Playback button (2) to switch to the

Playback mode.

In Playback mode, press the Playback button (2) to switch to the

REC mode.

Selecting the REC Mode

1Press the Power button to enter the Capture mode.

IfthecameraisinPlaybackmode,pressthePlaybackbuttontochangetoRECmode.

2Press the Mode button (1) to change the REC mode.

EachtimetheMode buttonispressedtheRECmodeiconchanges.Itincludesthreemodesin

RECmode:Capturemode,VideomodeandAudiomode.

Display Title Description

Capture mode For taking still photos.

Videomode For recording movie clips.

Audio mode Forrecordingaudioles.

Caution

The Mode button will not work when the camera is in Playback mode.

Using the Menu in REC Mode

Whenamenuisdisplayed,theve-waycontrolbuttonisusedtomakethedesiredsettings.The

AudiomodedoesnothaveamenusotheMENUbuttonwillnotworkinAudiomode.

1Capture menu.

Turn the power on, and set the camera to the Capture

mode

2Open the Capture menu.

PresstheMENUbutton(2)todisplaythemenu.

3Select an item.

Press or ontheve-waycontrolbutton(1)toselect

an item.

4Change the setting.

Press ontheve-waycontrolbutton(1)tolaunchthe

submenu. Press or ontheve-waycontrolbutton(1)

to change the setting.

5PressOK/Enterontheve-waycontrolbutton(1)tosavethesettingsandnallypressthe

MENUbutton(2)toclosethemenu

Using the Menu in Playback Mode

Whenamenuisdisplayed,theve-waycontrolbuttonisusedtomakethedesiredsettings.

Using the Menu in Playback Mode

1Turn the power on and set the camera to the Playback

mode

2Open the Playback menu.

Press the Menu button (2) to display the menu.

3Select an item.

Press or ontheve-waycontrolbutton(1)toselectan

item.

4Change the setting.

Press ontheve-waycontrolbutton(1)tolaunchthe

submenu. Press or ontheve-waycontrolbutton(1)tochangethesetting.

PressOK/Enter(1)tosavethesettingsandnallypresstheMenubutton(2)toclosethemenu.

Caution

Iftheiteminthemenulistisgrayitmeansthisitemdoesn’tworkinthisleformat.

Setting the Display Language / Date & Time

Whenusingthecameraforthersttimeafterpurchasingit,besuretochoosealanguageandsetthe

date & time before using the camera.

Setting Display Language

1Turn the power on, and set the camera to the Setup Menu.

2Select [Language].

Press or to select [Language] then press to launch

the submenu.

3Select a language.

Press or ontheve-waycontrolbuttontoselecta

language and press OK/Enter button to apply the setting.

4Press the MENU button to close the menu.

Setup Menu

1Turn the power on and set the camera to the REC or

Playback mode.

2PresstheMENUbutton(2)toopentheRECorPlayback

menu. The menu displayed depends on whether you are in the

RECmodeorthePlaybackmode.

3Open the Setup menu.

Press ontheve-waycontrolbutton(1)toselect[Setup] to

display the Setup menu.

4Select an item.

Press or ontheve-waycontrolbutton(1)toselectamenuitemthenpress on the

ve-waycontrolbutton(1)tolaunchthesubmenu.

5Change the setting.

Press or ontheve-waycontrolbutton(1)toselectanoptionandpressOK/Enter(1)to

apply the setting.

6Press the MENU button (2) to close the menu.
