Advidia M-44-V-T-V2 Manual de usuario

Network Eyeball Cameras

Quick Guide

V1.00

M-44-V-T-V2

Waterproof Requirements

Please waterproof cables in accordance with the following instructions. User shall

assume all responsibility for device damage caused by water due to improper

waterproof measures.

NOTE!

⚫Before you start, connect all the needed cables and cut off the copper wires for

the cables that you don't use.

⚫Please use self-adhesive waterproof tape (supplied with some products) to

protect the cables.

⚫Use waterproof components to protect the network cable. Waterproof the

power cable separately if you don’t use it. The video cable does not need

waterproof treatment.

1. Use insulation tape (not included in the package) to insulate the connection part

of each cable.

2. Waterproof the cables with self-adhesive waterproof tape.

(1) Fully stretch the waterproof tape at both ends.

(2) Wrap the connection part and the cable ends tightly with waterproof tape.

Make sure the tape is fully stretched during the process.

(3) Tighten the tape at both ends to prevent water leakage.

Connection part

Insulation tape

3. Install the supplied waterproof components to the network cable in sequence.

CAUTION!

You need to mount the rubber ring onto the network cable interface first.

4. If your camera has a DC cable and you will not use it, insert the plug into the

interface.

5. (Optional) After the waterproof treatment is completed, put the cables into a

waterproof junction box (purchased separately).

CAUTION!

⚫The cable connector must not be exposed and must be kept away from water.

⚫Restore and fasten the device after dismounting.

⚫Place the power adapter in a power distribution box.

Wrap the unused cables together into a bundle

Tighten Tighten

Waterproof tape

Tighten

DC interface

Plug

1Packing List

Contact your local dealer if the package is damaged or incomplete. The attachments

may vary with models, please see the actual model for details.

No.

Name

Qty

Unit

Camera

PCS

Waterproof components（1）

Set

Screw components（2）

Set

Mount accessory （3）

Set

User manual

Set

Remarks:

* means optional and supplied with certain models only.

(1)Including one or more waterproof components such as tape and plug.

(2)Including one or more accessories such as screws and hex key.

(3)Including one or more items from drilling template, bracket adapter, anti-static

gloves, etc.

2Safety Instructions

Installation and removal of the unit and its accessories must be carried out by

qualified personnel. You must read all of the safety instructions before installation

and operation.

2.1 Precautions

⚫Use a power adapter or a PoE device that meets requirements. Otherwise, the

device may be damaged.

⚫Be careful not to blur, scratch, damage the dome cover or leave fingerprints on

it because this could decrease image quality. Keep the protective film on the

dome cover until installation is complete.

⚫Make sure the length of the power cable between the power adapter and the

camera is not too long, otherwise the voltage of the camera is lowered, causing

the camera to work abnormally. If it is required to lengthen the power cable,

lengthen the cable between the power adapter and the mains.

⚫Do not overbend the cables during the installation, otherwise, poor cable contact

may cause malfunction.

⚫When connecting to an external interface, use an existing connection terminal,

and ensure that the cable terminal (latch or clamp) is in good condition and

properly fastened. Ensure that the cable is not tense during mounting, with a

proper margin reserved to avoid poor port contact or loosening caused by shock

or shake.

⚫During transportation, special attention is required to protect the transparent

dome cover from friction, scratch and stain, etc. Do not remove the protective

film from the cover until mounting is finished. Remove the protective film before

powering on the device.

⚫Make sure the wall or ceiling is strong enough to support the weight of the

camera. If dust falls during mounting, take off the dome cover and keep it away

from dust. Install the dome cover after the base is installed.

⚫Contact professionals for maintenance information. Do not attempt to dismantle

the device by yourself. We shall not assume any responsibility for problems

caused by unauthorized repair or maintenance.

2.2 Maintenance

⚫If there is dust on the front glass surface, remove the dust gently using an oil-

free brush or a rubber dust blowing ball.

⚫If there is grease or a dust stain on the front glass surface, clean the glass surface

gently from the center outward using anti-static gloves or an oil-free cloth. If the

grease or the stain still remains, use anti-static gloves or an oil-free cloth dipped

with detergent and clean the glass surface gently until it is clean.

⚫Do not use organic solvents (such as benzene and alcohol) to clean the

transparent dome cover.

3Appearance

3.1 Dimensions

The appearance and tail cable may vary with device model.

Type A

Type B

3.2 Cable Connection

The appearance and tail cable may vary with device model.

Type A

110mm

4.3"

129mm

5.1"

129mm

5.1''

111mm

4.4''

Type B

1. Bottom ring

2. Housing

3. Mic

4. Lens

5. Power interface(12 VDC)

6. Ethernet interface

Network

NOTE!

Use a pin to press and hold the Reset button for about 15 seconds to restore factory

default settings. Perform this operation within 10 minutes after the device is

powered on or the reset will fail otherwise.

4Mount Your Camera

You can adopt ceiling mount or wall mount and purchase hardware accessories by

yourself. The following part takes ceiling mount as an example. Wall mount is similar

to ceiling mount and therefore is omitted here.

1. Attach the sticker to ceiling, and then drill 30-mm deep guide holes using a drill

bit (6mm or 6.5mm in diameter) according to the sticker.

2. Insert the plastic anchors.

(1) Drill a hole to lead cables out of the ceiling.

(2) Knock in plugs.

3. Loosen the fixing screw, then remove the housing. Loosen the fixing screw, then

turn the housing to the position shown in figure to remove it.

4. Connect the cable and then secure the bottom ring.

5. Mount the housing.

Adjust the housing to the position shown in figure above.Align the screw hole on the

Attach bottom ring to ceiling with

taping screws

Connect cable and protect it

with waterproof tape

(Optional) insert a

micro SD card

housing with the tail cable outlet on the base, attach the housing gently and then

rotate clock/counterclockwise at least 8 degrees to lock.To ensure proper image

display and illumination effects, make sure the mark (see figure above) is aligned

with the screw hole when installation is complete.

6. Adjust the monitoring direction. Adjust the monitoring direction, then tighten the

screw.

NOTE!

⚫Do not adjust monitoring direction by force with the screw fully tightened.

Loosen the screw first.

⚫For open installation, lead the tail cable out of the open slot on the base plate

first and then fasten the screw.

5Startup

After you have installed the device, connect one end of the power adapter

(purchased separately) to power supply, and then connect the other end to the

power interface to start up the device.

6Access Your Camera

1. Open your Web browser, enter the camera's IP address in the address bar, and then

press Enter. The default IP is 192.168.1.13.
