Advidia B-5360 5MP Manual de usuario

B-5360 5MP

360˚Weather-Proof Mini Dome

Hardware Manual

B-5360 Hardware Manual

Table of Contents

Precautions

Safety Instructions ...........................................................................5

Introduction 6

Package Contents.............................................................................6

Physical Description ........................................................................7

Mounting Options.............................................................................9

Installation Procedures 10

Step 1: Prepare for Installation......................................................10

Step 2: Open the Dome Cover ....................................................... 11

Step 3: Route the Cables................................................................12

Step 4: Install the Camera..............................................................13

Step 5: Waterproof the Cable Connection....................................14

Step 6: Connect to Network...........................................................17

Step 7: Access the Camera Live View........................................... 17

Step 8: Close the Dome Cover.......................................................18

Other Adjustments and Accessories 19

How to Install / Remove the Memory Card ...................................19

How to Insert the Memory Card ...................................................19

How to Remove the Memory Card...............................................19

How to Connect Audio In Device...................................................20

How to Adjust the Viewing Orientation.........................................21

Accessing the Camera 22

Configure the IP Addresses...........................................................22

Using DHCP Server to Assign IP Addresses................................22

Using the Default Camera IPAddress..........................................24

Access the Camera.........................................................................26

B-5360 Hardware Manual

Precautions

Read these instructions

You should read all the safety and operating instructions before using this product.

Heed all warnings

You must adhere to all the warnings on the product and in the instruction manual. Failure to

follow the safety instruction given may directly endanger people, cause damage to the system

or to other equipment.

Servicing

Do not attempt to service this video device yourself as opening or removing covers may

expose you to dangerous voltage or other hazards. Refer all servicing to qualified service

personnel.

Trademarks

All names used in this manual are probably registered trademarks of respective companies.

Liability

Every reasonable care has been taken during the writing of this manual. Please contact

Advidia if you find any inaccuracies or omissions. We cannot be held responsible for any

typographical or technical errors and reserve the right to make changes to the product and

manuals without prior notice.

B-5360 Hardware Manual

Federal Communications Commission Statement

This equipment has been tested and found to comply with the limits for a

class B digital device, pursuant to Part 15 of the FCC Rules. These limits are

designed to provide reasonable protection against harmful interference in a

residential installation. This equipment generates, uses, and can radiate radio frequency

energy and, if not installed and used in accordance with the instructions, may cause harmful

interference to radio communications. However, there is no guarantee that interference will not

occur in a particular installation. If this equipment does cause harmful interference to radio or

television reception, which can be determined by turning the equipment off and on, the user is

encouraged to try to correct the interference by one or more of the following measures:

Reorient or relocate the receiving antenna.

Increase the separation between the equipment and receiver.

Connect the equipment into an outlet on a circuit different from that to which the

receiver is connected.

Consult the dealer or an experienced radio/TV technician for help.

Warning: Changes or modifications to the equipment that are not expressly approved by the

responsible party for compliance could void the user’s authority to operate the equipment.

European Community Compliance Statement

This product has been tested and found to comply with the limits for Class B

Information Technology Equipment according to European Standard EN 55022

and EN 55024. In a domestic environment, this product may cause radio interference in which

cause the user may be required to take adequate measures.

B-5360 Hardware Manual

Safety Instructions

Cleaning

Disconnect this video product from the power supply before cleaning.

Attachments

Do not use attachments not recommended by the video product manufacturer as they may

cause hazards.

Water and Moisture

Do not use this video product near water, for example, near a bathtub, washbowl, kitchen sink,

or laundry tub, in a wet basement, or near a swimming pool and the like.

Don’t use accessories not recommended by the manufacturer

Only install this device in a dry place protected from weather

Servicing

Do not attempt to service this video product yourself as opening or removing covers may

expose you to dangerous voltage or other hazards. Refer all servicing to qualified service

personnel.

Damage Requiring service

Disconnect this video product from the power supply immediately and refer servicing to

qualified service personnel under the following conditions.

1) When the power-supply cord or plug is damaged

2) If liquid has been spilled, or objects have fallen into the video product.

3) If the video product has been directly exposed to rain or water.

4) If the video product does not operate normally by following the operating Instructions in

this manual. Adjust only those controls that are covered by the instruction manual, as an

improper adjustment of other controls may result in damage, and will often require

extensive work by a qualified technician to restore the video product to its normal

operation.

Safety Check

Upon completion of any service or repairs to this video product, ask the service technician to

perform safety checks to determine if the video product is in proper operating condition.

B-5360 Hardware Manual

Introduction

Package Contents

Check if the camera package comes with the following items:

B-5360 Camera Body

Screw Kit

Drill Template

Hexagon Screwdriver

Cable Grommet

Quick Start Guide

IMPORTANT: When the camera is taken out from the box, the lens cover is covered by a

protective film. DO NOT remove this film. It is used to protect the lens cover from scratches or

fingerprint marks which may happen during installation. Remove this film only after the camera

is securely installed and all connections are complete.

B-5360 Hardware Manual

Physical Description

Item

Description

System LEDs

Indicates the camera status:

Amber LED: Blinks when network activity is in progress.

Blue LED: Lights up when the camera is powered up and

goes off again after the boot up process is complete.

Green LED: Lights up when the camera is connected to a

network.

B-5360 Hardware Manual

Item

Description

Audio Input

Connects to audio input devices, such as a microphone with

built-in amplifier, etc. See How to Connect Audio Device on

page 20.

NOTE: The microphone must have a built-in amplifier.

Connecting an ordinary microphone will dwarf sounds and will

result in inaudible recording.

Ethernet Port

(RJ-45)

Connects to a network using an Ethernet cable with RJ-45

connector.

Reset Button

Restores the factory default settings of the camera. To reset the

camera, while the power is on, press and hold the Reset Button

for at least 5 seconds or until the Blue LED lights up.

Memory Card Slot

Insert a memory card (not included) into the slot for local

recording purposes. See How to Install / Remove the Memory

Card on page 19 for more information.

NOTE: Supports only microSDHC and microSDXC cards.

B-5360 Hardware Manual

Mounting Options

Select the most suitable solution for your installation environment. The camera can be

mounted by either of the following methods:

Mount Types

Accessories

Surface Mount

Suitable when mounting the camera directly on walls or ceilings without

additional mounting accessories. See Installation Procedures on page

10 for more information.

Gangbox

Suitable when mounting the camera on a 4” Round or 4” Octagon

Gangbox. The use of gangbox is lawfully required in some areas in the

United States. A Gangbox Converter (purchased separately) is required

for this type of installation.

Wall Mount

Suitable when mounting the camera on the wall with the camera facing

down as if installed on the ceiling. The Wall Mount (optional mounting

accessory) is required for this type of installation.

Pendant Mount

Suitable when installing the camera on high ceilings where a straight

tube is used to lower the camera. The Pendant Mount with Mount Kit

(optional accessory set) is required for this type of installation.

NOTE:

For more information about the mounting solutions and accessories, please check our

website.

The above mounting accessories are not included in the package. Contact your sales

agents to purchase.

B-5360 Hardware Manual

Installation Procedures

This section describes procedures in mounting the camera on a flat surface.

NOTE: The camera images on this documentation are for reference only and may be different

from the actual camera.

Step 1: Prepare for Installation

1. Before installing the camera, prepare the additional accessories required for installation.

Required Accessories

Exterior-grade Ethernet Cable with RJ-45 connector (not included in the package)

Cable Grommet (Included)

2. Depending on the material of the mounting surface where the camera will be installed, it

may be necessary to drill the three (3) screw holes and use the supplied anchors. In this

case, attach the included drill template on the surface and drill the screw holes.
