User Manual

TPC-1550H/1551H

Industrial Touch Panel

Computers with Intel®Atom™

Processors

TPC-1550H/1551H User Manual ii

The documentation and the software included with this product are copyrighted 2011

by Advantech Co., Ltd. All rights are reserved. Advantech Co., Ltd. reserves the right

to make improvements in the products described in this manual at any time without

notice. No part of this manual may be reproduced, copied, translated or transmitted

in any form or by any means without the prior written permission of Advantech Co.,

Ltd. Information provided in this manual is intended to be accurate and reliable. How-

ever, Advantech Co., Ltd. assumes no responsibility for its use, nor for any infringe-

ments of the rights of third parties, which may result from its use.

Acknowledgements

Intel and Pentium are trademarks of Intel Corporation.

Microsoft Windows and MS-DOS are registered trademarks of Microsoft Corp.

All other product names or trademarks are properties of their respective owners.

This Manual Covers the Following Models:

TPC-1550H

TPC-1551H

Part No. 2003155000 Edition 1

Printed in Taiwan December 2011

iii TPC-1550H/1551H User Manual

Product Warranty (2 years)

Advantech warrants to you, the original purchaser, that each of its products will be

free from defects in materials and workmanship for two years from the date of pur-

chase.

This warranty does not apply to any products which have been repaired or altered by

persons other than repair personnel authorized by Advantech, or which have been

subject to misuse, abuse, accident or improper installation. Advantech assumes no

liability under the terms of this warranty as a consequence of such events.

Because of Advantech’s high quality-control standards and rigorous testing, most of

our customers never need to use our repair service. If an Advantech product is defec-

tive, it will be repaired or replaced at no charge during the warranty period. For out-

of-warranty repairs, you will be billed according to the cost of replacement materials,

service time and freight. Please consult your dealer for more details.

If you think you have a defective product, follow these steps:

1. Collect all the information about the problem encountered. (For example, CPU

speed, Advantech products used, other hardware and software used, etc.) Note

anything abnormal and list any onscreen messages you get when the problem

occurs.

2. Call your dealer and describe the problem. Please have your manual, product,

and any helpful information readily available.

3. If your product is diagnosed as defective, obtain an RMA (return merchandize

authorization) number from your dealer. This allows us to process your return

more quickly.

4. Carefully pack the defective product, a fully-completed Repair and Replacement

Order Card and a photocopy proof of purchase date (such as your sales receipt)

in a shippable container. A product returned without proof of the purchase date

is not eligible for warranty service.

5. Write the RMA number visibly on the outside of the package and ship it prepaid

to your dealer.

TPC-1550H/1551H User Manual iv

Declaration of Conformity

This product has passed the CE test for environmental specifications when shielded

cables are used for external wiring. We recommend the use of shielded cables. This

kind of cable is available from Advantech. Please contact your local supplier for

ordering information.

FCC Class A

Note: This equipment has been tested and found to comply with the limits for a Class

A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to

provide reasonable protection against harmful interference when the equipment is

operated in a commercial environment. This equipment generates, uses, and can

radiate radio frequency energy and, if not installed and used in accordance with the

instruction manual, may cause harmful interference to radio communications. Opera-

tion of this equipment in a residential area is likely to cause harmful interference in

which case the user will be required to correct the interference at his own expense.

Technical Support and Assistance

1. Visit the Advantech web site at http://support.advantech.com where you can find

the latest information about the product.

2. Contact your distributor, sales representative, or Advantech's customer service

center for technical support if you need additional assistance. Please have the

following information ready before you call:

–Product name and serial number

–Description of your peripheral attachments

–Description of your software (operating system, version, application software,

etc.)

–A complete description of the problem

–The exact wording of any error messages

v TPC-1550H/1551H User Manual

Safety Instructions

1. Read these safety instructions carefully.

2. Keep this User Manual for later reference.

3. Disconnect this equipment from any AC outlet before cleaning. Use a damp

cloth. Do not use liquid or spray detergents for cleaning.

4. For plug-in equipment, the power outlet socket must be located near the equip-

ment and must be easily accessible.

5. Keep this equipment away from humidity.

6. Put this equipment on a reliable surface during installation. Dropping it or letting

it fall may cause damage.

7. The openings on the enclosure are for air convection. Protect the equipment

from overheating. DO NOT COVER THE OPENINGS.

8. Make sure the voltage of the power source is correct before connecting the

equipment to the power outlet.

9. Position the power cord so that people cannot step on it. Do not place anything

over the power cord.

10. All cautions and warnings on the equipment should be noted.

11. If the equipment is not used for a long time, disconnect it from the power source

to avoid damage by transient overvoltage.

12. Never pour any liquid into an opening. This may cause fire or electrical shock.

13. Never open the equipment. For safety reasons, the equipment should be

opened only by qualified service personnel.

14. If one of the following situations arises, get the equipment checked by service

personnel:

The power cord or plug is damaged.

Liquid has penetrated into the equipment.

The equipment has been exposed to moisture.

The equipment does not work well, or you cannot get it to work according to

the user's manual.

The equipment has been dropped and damaged.

The equipment has obvious signs of breakage.

15. DO NOT LEAVE THIS EQUIPMENT IN AN ENVIRONMENT WHERE THE

STORAGE TEMPERATURE MAY GO BELOW -20° C (-4° F) OR ABOVE 60° C

(140° F). THIS COULD DAMAGE THE EQUIPMENT. THE EQUIPMENT

SHOULD BE IN A CONTROLLED ENVIRONMENT.

16. CAUTION: DANGER OF EXPLOSION IF BATTERY IS INCORRECTLY

REPLACED. REPLACE ONLY WITH THE SAME OR EQUIVALENT TYPE

RECOMMENDED BY THE MANUFACTURER, DISCARD USED BATTERIES

ACCORDING TO THE MANUFACTURER'S INSTRUCTIONS.

The sound pressure level at the operator's position according to IEC 704-1:1982 is

no more than 70 dB (A).

DISCLAIMER: This set of instructions is given according to IEC 704-1. Advantech

disclaims all responsibility for the accuracy of any statements contained herein.

Caution! Danger of explosion if battery is incorrectly replaced. Replace only with

the same or equivalent type recommended by the manufacturer. Dis-

pose of used batteries according to the manufacturer's instructions.

TPC-1550H/1551H User Manual vi

vii TPC-1550H/1551H User Manual

Chapter 1 General Information ............................1

1.1 Introduction ............................................................................................... 2

1.2 Specifications ............................................................................................ 2

1.2.1 System Kernel............................................................................... 2

1.2.2 I/O Ports........................................................................................ 2

1.2.3 Safety and Environment................................................................ 3

1.3 LCD Specifications.................................................................................... 3

1.4 Touchscreen Specifications ...................................................................... 3

1.5 Power ........................................................................................................ 4

1.6 I/O Ports Arrangement .............................................................................. 4

Figure 1.1 TPC-155OH - I/O Port Arrangement .......................... 4

Figure 1.2 TPC-1551H - I/O Port Arrangement ........................... 4

1.7 Panel Mounting ......................................................................................... 5

Figure 1.3 Panel Mounting........................................................... 5

1.8 Dimensions and Cutout............................................................................. 5

Figure 1.4 TPC-1550H Dimensions............................................. 6

Figure 1.5 TPC-1551H Dimensions............................................. 7

Chapter 2 System Setup.......................................9

2.1 System Setup.......................................................................................... 10

Figure 2.1 Unpack the Package ................................................ 10

Figure 2.2 Install CompactFlash Memory Card ......................... 11

Figure 2.3 Power Connector and Power Lines .......................... 11

Figure 2.4 Power Receptor & Button Pin Assignment ............... 12

2.1.1 Installing the Drivers ................................................................... 12

Chapter 3 Features in Windows XP Embedded15

3.1 Features in Windows XP Embedded ...................................................... 16

3.2 EWF ........................................................................................................ 16

3.3 HORM ..................................................................................................... 16

Appendix A Serial Port Settings ...........................17

A.1 Jumper Settings & Connector List........................................................... 18

A.2 Pin Assignment ....................................................................................... 18

A.3 RS-485 / RS-422 Setting......................................................................... 19

TPC-1550H/1551H User Manual viii

Chapter 1

1General Information

TPC-1550H/1551H User Manual 2

1.1 Introduction

The TPC-1550H and TPC-1551H Touch Panel Computers are state-of-the-art

Human Machine Interfaces featuring 15" displays with Intel Atom eMenlow XL pro-

cessors and the following key features:

Fanless

By using a low-power processor, the system does not have to rely on fans,

which often are unreliable and causes dust to circulate inside the equipment.

Bright Display

The TFT LCD display suits industrial demands for clear interfaces. Wide Oper-

ating Temperature & Isolation Protection (TPC-1551H Only) These products

provide a -20 ~ 60° C wide operating temperature solution and complete isola-

tion 2KV protection for their serial ports.

Windows CE Support

In addition to the OS support of Windows XP, Advantech offers platform support

for Windows CE and Windows XP embedded. The optional Windows CE oper-

ating system specifically for Industrial Touch Panel Computers is also available.

Energy Star Approval

1.2 Specifications

1.2.1 System Kernel

CPU: Intel® Atom™ N270H 1.6GHz (1550H) Z520 1.33GHz (1551H)

BIOS: Award 4 Mbit flash BIOS

System Chipset: 945GSE + ICH7M (1550H)

eMenlow XL + Poulsbo (1551H)

VGA: Integrated in 945GSE (1550H) eMenlow XL (1551H)

Ethernet: 10/100/1000Base-T

Watchdog Timer:

–TPC-1550H: W83627DHG watchdog timmer; 1.6 second timeout period

–TPC-1551H: SCH3114X1 watchdog timer; 1.6 second timeout period

Storage: CompactFlash® slot or SATA HDD x 1 (TPC-1550H only CF for

storage)

1.2.2 I/O Ports

TPC-1550H:

2 serial ports: RS-232 x 2 (w/o isolation)

1 RJ-45 Ethernet port

2 USB 2.0 Ports: compliant with USB 1.0 and 1.1. (Host)

TPC-1551H:

2 serial ports: RS-232 x 1 (w/ isolation), RS-422/485 x 1 (w/ isolation)

2 RJ-45 Ethernet port

2 USB 2.0 Ports: compliant with USB 1.0 and 1.1. (Host)

Tabla de contenidos

Otros manuales de Panel táctil de Advantech

Advantech

Advantech PPC-A84 Manual de usuario

Advantech

Advantech PPC-154 Manual de usuario

Advantech

Advantech TPC-1770 Manual de usuario

Advantech

Advantech PPC-3150-XE4BE Manual de instalación y operación

Advantech

Advantech PPC Series Manual de usuario

Advantech

Advantech IPPC-5211WS Series Manual de usuario

Advantech

Advantech PPC-3151SW Manual de usuario

Advantech

Advantech PPC-3211SW Manual de usuario

Advantech

Advantech PPC-3100-RE9A Manual de instalación y operación

Advantech

Advantech TPC-51WP Series Manual de usuario

Advantech

Advantech PPC-306 EHL Manual de instalación y operación

Advantech

Advantech PPC-612 Manual de instalación y operación

Advantech

Advantech COASTIPC PPC-412 Manual de instalación y operación

Advantech

Advantech PPC-A84/A120-X5X Manual de usuario

Advantech

Advantech POC-W211 Manual de instrucciones

Advantech

Advantech PPC-6151C Manual de usuario

Advantech

Advantech TPC-1260H Manual de usuario

Advantech

Advantech Intel XScale PXA Touch Panel Computer TPC-66... Manual de usuario

Advantech

Advantech UTC-W101E Manual de usuario

Advantech

Advantech PPC-125 Manual de usuario

Advantech

Advantech TPC-1560 Manual de usuario

Advantech

Advantech IPPC-6152A Manual de usuario

Advantech

Advantech PPC-L127T Manual de usuario

Advantech

Advantech ProFlat IDP31-156WP45HIB1 Manual de usuario

Manuales populares de Panel táctil de otras marcas

FlowLine

FlowLine Data loop Manual de usuario

ALPEX

ALPEX AEx-8 P Series Manual de usuario

Ltech

Ltech E5S Manual de usuario

Harman

Harman AMX MODERO S MSD-701-L2 Manual de usuario

Acnodes

Acnodes PC 1150 Manual de usuario

AIS

AIS IP10IA99 series Manual de usuario

IBASE Technology

IBASE Technology ASTUT-152-RE1S Manual de usuario

YASKAWA

YASKAWA TP 610C Manual de usuario

B&R

B&R Power Panel C Series Manual de usuario

Beijer Electronics

Beijer Electronics X2 control Manual de usuario

AXIOMTEK

AXIOMTEK GOT321W-521 Manual de usuario

TRIDONIC.ATCO

TRIDONIC.ATCO x-touchBOX Manual de usuario

Qomo

Qomo QIT1386 Manual de usuario

DFI

DFI KS104-CD Manual de usuario

AMX

AMX AXP-PPC Guía

Sartorius

Sartorius X3 PR 5410 Manual de usuario

AMX

AMX Modero X Series Manual de usuario

B&R Industries

B&R Industries MAPPC900-ENG Manual de usuario
