UNO-2172

P e n t i u m - M / C e l e r o n - M

Universal Network Controller

with PCI-104 Expansion

User Manual

UNO-2172 User Manual ii

nal manufacturer reserves the right to make improvements to the products

described in this manual at any time without notice.

No part of this manual may be reproduced, copied, translated or transmit-

ted in any form or by any means without the prior written permission of

the original manufacturer. Information provided in this manual is

intended to be accurate and reliable. However, the original manufacturer

assumes no responsibility for its use, nor for any infringements upon the

rights of third parties that may result from such use.

Acknowledgements

IBM, PC/AT, PS/2 and VGA are trademarks of International Business

Machines Corporation.

Intel® and Pentium® are trademarks of Intel Corporation.

Microsoft Windows and MS-DOS are registered trademarks of Microsoft

Corp.

C&T is a trademark of Chips and Technologies, Inc.

All other product names or trademarks are properties of their respective

owners.

This manual is for UNO-2172.

Part No. 2003217200 1st Edition

Printed in Taiwan June 2007

iii

Product Warranty

Advantech warrants to you, the original purchaser, that each of its prod-

ucts will be free from defects in materials and workmanship for one year

from the date of purchase.

This warranty does not apply to any products that have been repaired or

altered by persons other than repair personnel authorized by Advantech,

or which have been subject to misuse, abuse, accident or improper instal-

lation. Advantech assumes no liability under the terms of this warranty as

a consequence of such events.

Because of Advantech high quality-control standards and rigorous test-

ing, most of our customers never need to use our repair service. If an

Advantech product is defective, it will be repaired or replaced at no

charge during the warranty period. For out-of-warranty repairs, you will

be billed according to the cost of replacement materials, service time and

freight. Please consult your dealer for more details. If you think you have

a defective product, follow these steps:

Step 1. Collect all the information about the problem encountered. (For

example, CPU speed, Advantech products used, other hardware

and software used, etc.) Note anything abnormal and list any on-

screen messages you get when the problem occurs.

Step 2. Call your dealer and describe the problem. Please have your man-

ual, product, and any helpful information readily available.

Step 3. If your product is diagnosed as defective, obtain an RMA (return

merchandize authorization) number from your dealer. This

allows us to process your return more quickly.

Step 4. Carefully pack the defective product, a fully completed Repair

and Replacement Order Card and a photocopy proof of purchase

date (such as your sales receipt) in a shippable container. A prod-

uct returned without proof of the purchase date is not eligible for

warranty service.

Step 5. Write the RMA number visibly on the outside of the package and

ship it prepaid to your dealer.

UNO-2172 User Manual iv

Declaration of Conformity

This product has passed the CE test for environmental specifications

when shielded cables are used for external wiring. We recommend the use

of shielded cables. This kind of cable is available from Advantech. Please

contact your local supplier for ordering information.

FCC Class A

Note: This equipment has been tested and found to comply with the limits

for a Class A digital device, pursuant to part 15 of the FCC Rules. These

limits are designed to provide reasonable protection against harmful

interference when the equipment is operated in a commercial environ-

ment. This equipment generates, uses, and can radiate radio frequency

energy and, if not installed and used in accordance with the instruction

manual, may cause harmful interference to radio communications. Opera-

tion of this equipment in a residential area is likely to cause harmful inter-

ference in which case the user will be required to correct the interference

at his own expense.

Technical Support and Assistance

Step 1. Visit the Advantech web site at www.advantech.com/support

where you can find the latest information about the product.

Contact your distributor, sales representative, or Advantech's customer

service center for technical support if you need additional assistance.

Please have the following information ready before you call:

- Product name and serial number

- Description of your peripheral attachments

- Description of your software (operating system, version, application

software, etc.)

- A complete description of the problem

- The exact wording of any error messages

v Table of Contents

Contents

Chapter 1 Overview ...........................................................2

1.1 Introduction ....................................................................... 2

1.2 Hardware Specifications ................................................... 3

1.3 Safety Precautions ............................................................. 4

1.4 Chassis Dimensions........................................................... 5

Figure 1.1:Chassis Dimensions 1.................................... 5

Figure 1.2:Chassis Dimensions 2.................................... 5

Figure 1.3:Chassis Dimensions 3.................................... 5

1.5 Accessories........................................................................ 6

Chapter 2 Hardware Functionality ..................................8

2.1 Introduction ....................................................................... 8

Figure 2.1:UNO-2172 Front Panel ................................. 8

Figure 2.2:UNO-2172 Rear Panel .................................. 8

2.2 RS-232 Interface (COM1~COM2) ................................... 8

2.3 RS-232/422/485 Interface (COM3~COM4) ..................... 9

2.3.1 16C550 UARTs with 16-byte standard .......................... 9

2.3.2 RS-422/485 detection ..................................................... 9

2.3.3 Automatic Data Flow Control Function for RS-485 ...... 9

2.3.4 Termination Resistor (CN21) ......................................... 9

2.3.5 RS-232/422/485 Selection ............................................ 10

Figure 2.3:RS-422/485 Jumper Setting ........................ 10

Figure 2.4:RS-232 Jumper Setting................................ 10

2.3.6 RS-485 Auto Flow & RS-422 Master/Slave Mode ...... 11

Table 2.1:Auto Flow & Slave/Master Selection........... 11

2.3.7 IRQ and Address Setting .............................................. 12

Table 2.2:IRQ Setting via switch 1 at SW5.................. 12

Table 2.3:IRQ Setting via switch 1 at SW5.................. 12

2.4 LAN: Ethernet Connector .............................................. 13

2.5 Power Connector ............................................................. 13

2.6 PS/2 Keyboard and Mouse Connector ............................ 13

2.7 USB Connector ............................................................... 13

2.8 PCMCIA: PC Card Slot .................................................. 14

2.9 VGA Display Connector ................................................. 14

2.10 Battery Backup SRAM.................................................... 14

2.10.1 Lithium Battery Specification....................................... 14

Figure 2.5:SRAM Lithium Battery Location................ 15

2.10.2 Jumper Setting for SRAM ............................................ 15

2.11 Reset Button .................................................................... 16

2.12 Power Button................................................................... 16

2.13 Audio............................................................................... 16

UNO-2172 User Manual vi

2.14 PCI-104 ........................................................................... 16

Figure 2.6:PCI-104 Power Selection ........................... 16

Chapter 3 Initial Setup.....................................................18

3.1 Chassis Grounding .......................................................... 18

Figure 3.1:Chassis Grounding Connection................... 18

3.2 Inserting a CompactFlash Card ....................................... 18

3.3 Installing a Hard Disk ..................................................... 19

3.4 Connecting Power ........................................................... 20

3.5 BIOS Setup and System Assignments ............................ 20

3.6 Installing PCI-104 Modules ............................................ 21

Appendix A System Settings & Pin Assignments .............24

A.1 System I/O Address & Interrupt Assignments................ 24

Table A.1: UNO-2172 System I/O Ports ...................... 24

A.2 Board Connectors and Jumpers....................................... 26

Figure A.1:Connectors & Jumpers (frontside) ............. 26

Figure A.2:Connectors & Jumpers (backside).............. 26

A.3 RS-232 Standard Serial Port (COM1~COM2) ............... 28

A.4 RS-232/422/485 Serial Port (COM3~COM4) ................ 29

A.5 Ethernet RJ-45 Connector (LAN1~LAN2)..................... 29

A.6 Phoenix Power Connector (PWR)................................... 30

A.7 PS/2 Keyboard and Mouse Connector ............................ 30

A.8 USB Connector (USB1~USB2) ...................................... 31

A.9 VGA Display Connector (DVI-I to DVI & VGA Cable) 31

A.10 DVI-I Connector ............................................................. 32

Table A.11:DVI-I connector pin assignment................ 32

A.11 External & Internal SATA Connectors ........................... 33

Table A.12:External SATA connector pin assignment 33

Table A.13:Internal SATA DATA Connectors (CN40)33

Table A.14:Internal SATA Power Connectors (CN41) 34

CHAPTER

Overview

This chapter provides an overview of

UNO-2172’s specifications.

Sections include:

• Introduction

• Hardware specification

• Safety precautions

• Chassis dimensions

UNO-2172 User Manual 2

Chapter 1 Overview

1.1 Introduction

UNO-2172 is an embedded Application Ready Platform (ARP) that can

shorten your development time and offers rich networking interfaces to

fulfill extensive needs in different projects. Advantech’s Universal Net-

work Controller is designed to be a total solution for network enabled

Application Ready Platforms.

Leveraging field-approved and worldwide approved real-time OS tech-

nology, Advantech’s UNO-2000 series provides a Windows CE .NET

and Windows XP Embedded ready solution, and supports several stan-

dard networking interfaces, such as Ethernet, Wireless LAN, RS-232/

422/485 and so on. Because of its openness, great expansion capability

and reliable design (fanless and diskless), the UNO-2000 series are ideal

embedded platforms for implementing custom applications for diversi-

fied applications.

3 Chapter1

1.2 Hardware Specifications

• CPU: Pentium M/ Celeron M

• Memory: 1GB or 512MB on board

• Battery-backup RAM: 512 KB Battery-backup RAM

• Keyboard/Mouse: PS/2 keyboard & mouse

• Display: DVI-I, support dual display

• Serial Ports: 2 × RS-232 and 2 x RS-232/422/485 with DB-9 connectors.

Automatic RS-485 data flow control

• Serial Speeds: RS-232: 50~115.2 kbps, RS-422/485: 50~921.6 kbps

• LAN: Two 10/100/1000 Base-T RJ-45 Ports

• USB Interface: Two USB ports, USB EHCI, Rev. 2.0 compliant

• Audio: Mic in, Line in, Line out

• PC Card: One PC Card slot. Supports CardBus (Card-32) Card and 16-bit

(PCMCIA 2.1/JEIDA4.2) Card. Supports +5 V, +3.3 V working power

• SSD: One internal Type I / Type II CompactFlash card slot

• LEDs: Power (Power Standby: Orange, Power on : Green), IDE,

Alarm for RAM Backup Battery

• PCI-104: PCI-104 slot, Supports +3.3V/5V Power

• HDD: One standard 2.5” SATA or PATA HDD

• Watch Dog Timer: Programmable

• Anti-Shock: 20 G @ Wall mounting, IEC 68 2-27, half sine, 11 ms w/

HDD50 G @ Wall mounting, IEC 68 2-27, half sine, 11 ms w/CF

• Anti-Vibration: 2 Grms w/CF @IEC 68 section 2-64, random, 5 ~ 500 Hz,

1 Oct./min, 1 hr/axis. 1 Grms w/ HDD @ IEC 68 section

2-64, random, 5 ~ 500 Hz, 1 Oct./min, 1 hr/axis

• Power Requirement: Min. 48 W (9 ~ 36 VDC) (5A, MAX) (ATX)

• Power Consumption: 45W (Typical)

• Operating Temperature:

-20 ~ 50° C (-4~122° F) (For Pentium 1.6GHZ and Celeron 1.5GHZ)

-20 ~ 60° C (-4~149° F) (For Celeron 1GHZ)

• Storage Temperature: -20~80° C (-4~176° F)

• Relative Humidity: 95% @ 40°C

UNO-2172 User Manual 4

• Weight: 2.8 kg

• Chassis Size (W × L × H): 255 x 152 x 69 mm (10”× 6.0”× 2.7”)

• Software options: Windows XP Embedded, Win/2000/XP

• Certification: CE, FCC Class A, UL

1.3 Safety Precautions

The following sections tell how to make each connection. In most cases,

you will simply need to connect a standard cable.

Warning! Always disconnect the power cord from your

chassis whenever you are working on it. Do not

connect while the power is on. A sudden rush of

power can damage sensitive electronic compo-

nents. Only experienced electronics personnel

should open the chassis.

Caution! Always ground yourself to remove any static

electric charge before touching UNO-2172. Mod-

ern electronic devices are very sensitive to static

electric charges. Use a grounding wrist strap at

all times. Place all electronic components on a

static-dissipative surface or in a static-shielded

bag.

Tabla de contenidos

Otros manuales de Hardware de computadora de Advantech

Advantech

Advantech MIC-3365 Manual de usuario

Advantech

Advantech ASMB-785 Manual de instalación y operación

Advantech

Advantech MIC-75G20-10A2 Manual de instalación y operación

Advantech

Advantech ROM-5420 Manual de usuario

Advantech

Advantech PCE-7131 Manual de instalación y operación

Advantech

Advantech ASMB-831 Series Manual de instalación y operación

Advantech

Advantech MIO-2375 Manual de usuario

Advantech

Advantech ADAM CPU 821 Series Manual de usuario

Advantech

Advantech MIO-2361 Series Manual de instalación y operación

Advantech

Advantech ADAM-3956 Manual de instalación y operación

Advantech

Advantech PCM-3864 Manual de instalación y operación

Advantech

Advantech VEGA-2002 Manual de usuario

Advantech

Advantech USB-4750 Manual de usuario

Advantech

Advantech PCL-818L Manual de usuario

Advantech

Advantech FWA-3050 Manual de usuario

Advantech

Advantech SOM-4463 B2 Manual de usuario

Advantech

Advantech IDK-2119 Series Manual de usuario

Advantech

Advantech AIMB-786 Manual de instalación y operación

Advantech

Advantech ASMB-816 Series Manual de usuario

Advantech

Advantech PCA-6753 Manual de instalación y operación

Advantech

Advantech PCE-3B06-02 Manual de instalación y operación

Advantech

Advantech MIO-5376 Manual de usuario

Advantech

Advantech SOM-3565 Manual de usuario

Advantech

Advantech AIMC-3202 Manual de instalación y operación

Manuales populares de Hardware de computadora de otras marcas

EMC2

EMC2 VNX Series Manual del propietario

Panasonic

Panasonic DV0PM20105 Manual de usuario

Mitsubishi Electric

Mitsubishi Electric Q81BD-J61BT11 Manual de usuario

Gigabyte

Gigabyte B660M DS3H AX DDR4 Manual de usuario

Raidon

Raidon iT2300 Manual de usuario

National Instruments

National Instruments PXI-8186 Manual de usuario

Hauppauge

Hauppauge WinTV-HVR-2250 Manual de usuario

Kontron

Kontron CP6002 Manual de usuario

Manhattan

Manhattan 702843 Manual de usuario

Aphex

Aphex 230 Manual de usuario

AMD

AMD Phenom II Manual operacional

Intel

Intel NUC 12 Pro Manual de usuario

dbx

dbx Zone Pro 1260 Manual de usuario

Galaxy

Galaxy GHDX2-2430S-24F4D Manual de usuario

Intel

Intel AXXRMFBU4 Manual de usuario

Kontron

Kontron DIMM-PC/MD Manual de usuario

ST X-NUCLEO-SAFEA1B Instrucciones de funcionamiento

STEINWAY LYNGDORF

STEINWAY LYNGDORF SP-1 Manual de usuario
